Ace Amusement Robot Storm User manual

Robot Storm Manual
Robot Storm
MANUAL
* Please read the manual before installation and use.
* Please put the manual together with the machine.
Warning
ACE Amusement Technologies Co., Ltd.
ADD: #5 Building, No. 6, HengFeng 6th Road,
Gangkou Town, Zhongshan City, Guangdong,
P. R. China PC: 528447
TEL: [phone]
E-Mail: [email protected]
Web: www.ACE-Amusement.com

Robot Storm Manual
CONTENTS
I Specifications and Technical Parameters................................................................1
II Accessory List ...........................................................................................................2
III How to Handle and Position the Machine ............................................................2
(I) Handling Method...............................................................................2
(II) Fixing Method..................................................................................3
(III) Product Placement ..........................................................................3
(IV) Installation Location Dimension ....................................................4
IV Wiring and Precautions..........................................................................................4
V Description of the Game ..........................................................................................5
(I) Game Introduction.............................................................................5
(II) Game Play........................................................................................5
VI Game Background Settings....................................................................................8
VII Electrical Parameters of the Machine ...............................................................10
(I) Electrical parameters on the front side............................................10
(II) Electrical parameters on the back side...........................................10
VIII. Installation and maintenance...........................................................................12
IX. Fault Analysis and Troubleshooting ..................................................................13
XI Instructions on Restoring U Disk ........................................................................16

Robot Storm Manual
1
Machine Introduction and Features:
“Robot Storm” is a new indoor medium and high-end ball shooting simulation game
machine developed by our company. The unique robot theme is beautiful and pleasing.
Reasonable ergonomic design allows players to feel better the pleasure of the game.
At the same time, it is a high-yield amusement product in the amusement park.
1. Small machinery products;
2. The game play is novel, exciting, highly interactive, and highly entertaining;
3. The appearance design is artistic, the pattern is bright and delicate, and the
materials are strong and endurable;
4. Adopt integrated circuit, built-in program, stable working performance, good
safety and reliability;
5. Adapt to universal lottery tickets;
6. The standalone control computer is stable and reliable
I Specifications and Technical Parameters
1) Operating voltage: AC220V - 240V 50/60 Hz (or AC 110V±5%, 60Hz.
For the specific voltage, see the nameplate on the machine.)
2) Maximum power: 450W
3) Overall dimensions: W110 × D262 × H208 (cm)
4) Weight: About 280 kg
5) Ambient condition: Temperature (indoors): 0℃～35℃;
6) Humidity:≤90%;
7) Atmospheric pressure: 86Pa～106Pa.
Warning: After turning off the machine, please wait 3 minute if you want to turn it on.

Robot Storm Manual
2
II Accessory List
For the normal use of the machine, please check whether the following items are
included carefully after you open the package.
1. The accessory list is below:
Please open the package and check whether all accessories are included. If not, please
contact the distributor of the machine for check.
III How to Handle and Position the Machine
(I) Handling Method
The machine is equipped with caster under the base plate. When moving the machine
for a short distance, you should raise foot to make the casters touch the ground and
push the machine.
S/N
Name
No./Specification
Quantity
Unit
Remarks
1
Power
cord
10A/250V-3M
1
Piece
2
Fuse
Φ5×20mm T5A
250VAC
1
Piece
3
Manual
English
1
Copy
4
Key
AA33
2
Piece
5
Key
AA32
2
Piece
Caster

Robot Storm Manual
3
(II) Fixing Method
Please place it on flat ground where it won’t slide easily, loosen the locked nuts of the
foot, tighten the anchor bolts with a wrench, and keep the caster approximately 5mm
away from the ground.
(III) Product Placement
Do not place the product in the following places:
Do not place the machine in a humid place with high humidity;
Do not place the machine near a hot object;
Do not place the machine next to flammable items;
Do not place the machine on a smooth or uneven ground surface;
Do not place the machine near high-frequency vibration objects;
Do not place the machine in the dusty areas.
Caution Please unplug the power plug before moving to prevent accidents and faults.
Please take care not to damage the power cord during moving to prevent accidents and faults.
Please raise the foot to the maximum height before moving to prevent accidents and faults.
Fixation
About 5 cm

Robot Storm Manual
4
(IV) Installation Location Dimension
The machine should be placed according to the following dimensions for customers’ safety and enough space to
run the machine.
Game area:
IV Wiring and Precautions
Connect one end of the cable to the terminal box of the machine, and connect the other end to the socket.
Connect the power supply according to the voltage (110V or 220V) on the label, or the machine might be
damaged.
Please confirm whether there is grounding in the socket to avoid unnecessary damage.
If the grounding cannot be done through the socket, please try other methods.
Plug
Socket
Cable
Plug
Terminal
box

Robot Storm Manual
5
V Description of the Game
(I) Game Introduction
1. It consists of 5 levels and unlocks the new level after two passes.
2. The player shoots the ball to the screen to shoot a variety of targets (small, medium, large targets) to
obtain scores and coins to maintain the life.
3. Props with special functions appear randomly. After the player hits the props, it takes 10 seconds to use
the prop to destroy more targets.
4. In the second half of each game, Boss will suddenly jump out with a life value. There are some specific
targets on the body for player to attack. Every hit will bring points and coins to maintain player life.
5. The player passes with satisfying scores and move on to the new level. Players can reinsert coins to play
new levels.
6. At any time when your life value is 0, you need to reinsert coins to continue or end the game.
(1) Game start (2) Level selection
The player can start the game by putting in the corresponding game coins or swiping the card and the game
enters the next screen.
The game consists of five levels and begins to open the space base and mechanical maze by default.
Players can unlock mysterious forests and future urban levels after passing space base and mechanical maze.
Players can unlock the sand star battle level after passing mysterious forests and future urban. The player
completes all the passes to end the game.
（II）Game Play
(1)Normal fight：
1. When targets gets into shooting range, you
need to aim and press shooting key to destroy it
with ball.
2.When you successfully destroy the aim,
corresponding points will be obtained.
3. If the targets attack you, your life value will
be decreased with prompt of image effect.
4. When your life value is reduced to 0, the
game will suggest whether you will continue the
game. To continue, you need to put in coins or
swipe card.
6. If you fail, game returns to the start screen.

Robot Storm Manual
6
2. Space base Boss first form remote attack:
3. Space base Boss first form close attack:
4. Space base Boss second form: 5. Mechanical maze Boss first form:
6. Mechanical maze Boss second form: 7. Mysterious forest Boss first form:
8. Mysterious forest Boss second form: 9.Future urban Boss first form:
(2)Fight with Boss:
1. Boss shows up at the end of each
pass. Each boss has many forms. Bosses in
the first four passes are divided into two
kinds. Bosses in the final pass are divided
into three kinds. You pass the level after
defeating the Boss and unlock following
passes..
2. All Boss attack will have specific
target for the hitting of player.You only
need to hit all targets within specified time
to crack down the attack of Boss, or you
will be attacked.
I. Space base Boss first form:

Robot Storm Manual
7
10. Future urban Boss second form: 11. Sand Star Battle Boss first form:
12.Sand Star Battle Boss second form: 13.Sand Star Battle Boss third form:
(III) End of the game:
1. When the player's life value drops to 0, the game prompts whether to continue the game. If the player inputs
enough coins and presses the start button, the game continues, otherwise, the game ends.
2. After the player does not continue the game or clears the game, the game end interface appears, and the
player completes the one-time game experience.
1. Game passes: 2. Game continues: 3. Game ends:
(IV) Special props:
1. Sometimes a fireball target appears in the screen and the player can get special props after hitting it. At this
point, the speed of the ball shot by the player is increased and a large number of enemies can be destroyed in an
instant.
2. Gold coins and medical kits:
◎A number of gold coins and medical kits will be randomly scattered in the checkpoint.
◎Players can get a lot of points by hitting the gold coins.
◎Players can recover part of their life by hitting the medical kit.
(V) Free mode
1. Under free mode, players do not need to insert coin or swipe to play.
2. Under free mode, players do not need to insert coin or swipe to renew.

Robot Storm Manual
8
VI Game Background Settings
(I) Main menu:
(1) Option description:
1. Language: including Chinese and English
2. Game volume: all in the game
Volume adjustment for music and sound effects, 0 for mute
3. Demo volume: all the sounds in the demo
Volume adjustment for music and sound, 0 for mute
Number of coins per game: Coins required for one game of player, 0 for free game
Prize mode: reward items, including: lottery, gashapon or no prize
6. Lottery point: the corresponding ratio of points to lottery
7. Gashapon point: the corresponding ratio of points to gashapon
8. Resume waiting time: when the player's life value is 0, wait for the game to continue.
9. Difficulty of the game:simple, medium and difficult
10. 1P, 2P gun correction: gun type controller for correcting the shot
11. Ball speed setting: set the ball speed
12. I / O test: used to test hardware features
13. Revenue record: record the number of coins, the number of tickets and the number of gashapon
14. Daily record: record the number of coins, the number of tickets and the number of gashapon in the last
50 days.
15. Game reset: used to restore the factory default settings
16. Exit and save
17. Exit without saving
Optio
n
KEY1
Test (Choose)
KEY2
Confirm
(Replenish lotteries)
KEY3
Confirm (Modify)
KEY1
KEY2
KEY3

Robot Storm Manual
9
(2) 1P, 2P gun correction
(3) Ball speed setting: (4) I/O test:
(5) Revenue record: (6) Daily record:
(7) Game reset:

Robot Storm Manual
10
VII Electrical Parameters of the Machine
（I）Electrical parameters on the front side
（II）Electrical parameters on the back side
S/N
Name
Specification
Quantity
1
Speaker
Whole tone, 4 inch, 4Ω, 25W
2
2
Lottery
machine
TL TL-001 generation 3rd
2
3
Coin collector
TL TW-131
2
4
Counter
C-012 12VDC 18CPS
(including diode)
2
KEY1
Test (choose)
1
KEY2
Confirm (Replenish lotteries)
1
5
KEY3
Confirm (modify)
1
S/N
Name
Specification
Quantity
1
Industrial computer (mid
tower)
（MT-A5235）A55/5300/
memory2G*2 hard disk16G
1
Memory
DDR3 4G
1
GPU
R7350
1
2
2.0-A amplifier board
Y-218B
1
Stereo audio cable
3.5 double RCA 3M*2
1
3
IO main board
MB-MINI..PCB V1.2
1
Casing line
Water Battle Little Monster in
Chinese version
1
USB data cable
Type A/B 1m
1
4
Power box of machine (12 V)
SPD-400W
1
5
Power box of machine (24 V)
EPT-H150S24
1
6
Driver
MOS DRIVER PCB V1.0

Robot Storm Manual
11
I/O Board

Robot Storm Manual
12
VIII. Installation and maintenance
1 Installation and Commissioning
Please check the components according to the list to assemble components before installation;
After installation, plug the cable and turn on the machine to check whether each part runs normally. If no,
immediately turn off the machine for troubleshooting.
2. Appearance Inspection
To ensure the safe use of the machine, please check the following before startup:
Whether the warning sign is intact, visible and stuck correctly.
Whether parameters of power supply are consistent with the requirements of the machine.
Whether screws of each component and components of the steering wheel are loose.
Whether the connectors and terminals are loose.
Whether the machine is placed stably; whether the adjustment of the casters and the top foot are proper.
Whether the machine is placed in the proper area.
3. Running Inspection
Whether the speaker works normally.
Whether the daylight lamp and the button light are on.
Whether the image is clear and normal.
4 Maintenance
Before operation, test run must be done before the machine is used;
When there is dirt on the machine, wipe it with a soft cotton cloth with detergent;
After the new machine has been used for one month, check whether each part runs normally;
Often check the machine;
The machine must be cleaned and maintained once a month.
Screen PVC will crack and wear in the use process, please check and clean once in a week.
5. Ball strength adjustment
When the ball has no velocity or offset, the velocity can be by 1
in the figure. First loosen the nut 2, adjust the screw 3. Adjust the
two screws to tighten and make the ball gain velocity, and
unscrew to make ball lose velocity
This mechanism is adjusted when the ball is weak due to wear of
the silicone wheel. If the silicone wheel is completely worn, you
will need to replace it with a new one.

13
IX. Fault Analysis and Troubleshooting
Common faults
Fault phenomena
Main cause
Corrective action
The monitor is not energized.
Please reconnect the power cable or
replace it with new.
After the machine
is powered on,(the
power supply fan
works), but the
display is not on.
The signal wire of the display is not
connected or damaged.
Please reconnect the signal wire or
replace it with new.
The power supply is inconsistent with the
machine’s parameters.
Please check whether the power supply
is consistent with the machine’s
parameters.
Fuse is burnt out.
Please replace the fuse.
The power supply is not connected.
Please confirm 110V~220V power
supply is connected and the power
switch is on
After the machine
is powered on,
nothing happens
and the screen is
not lit.
The signal wire of the display is not
connected or damaged.
The signal wire of the display is not
connected or damaged.
The machine is not
powered on.
Check whether the input of the 110V~220V
power supply is right. The short circuit is
not allowed.
Please check whether the voltage of the
circuit board inside the machine is
abnormal.
The control panel
is not powered on
Check whether the output of 12V of the
power supply box is normal.
Please adjust the cable to the correct
position.
The cable of the display might fall off or be
loosen due to vibration.
Please check the power supply circuit or
replace the power line.
The display has no
raster.
The display is not on..
Turn on the machine again manually.
The power is off on
the midway.
The circuit protector generates an action
and the power switch is turned off (Note:
The circuit protector cuts off the current
when the abnormal current flows).
Please turn on the power switch again.
When the circuit protector repetitively
acts, it indicates that the machine is
abnormal. Please contact the dealership.
Manually start the power start button of
the host machine.
The host power is bad or replaced.
The motherboard memory bank is bad or
replaced.
After the product is
powered on, the
display is a white
screen without any
image or sound.
The host machine does not work.
The motherboard is bad. Please contact
professional and manufacturer.
Pressing start key
cannot start the
The start button holder is loose, and the
switch line is loose.
The button holder is broken or replaced,
the switch wire is pressed, and the start

Robot Storm Manual
14
game.
button switch is broken or replaced.
The coin collector is damaged.
Replace coin collector.
The signal line of the coin collector is
loose.
Check if the signal line of the coin
collector is loose.
No response to
coin collector.
IO control board is damaged.
Replace IO control board.
The sample coin is not placed well.
Please check whether the sample coin is
placed well, or try another sample coin.
The coin slot is not aligned or deformed.
Please check whether the coin slot is
aligned or deformed, and adjust coin slot.
Coins are blocked
in the coin
collector
The coin collector is not assembled
properly. The red braking bar above the
coin collector is pressed.
Please re-insert it into the coin collector.
Check whether there is signal feedback.
Please re-connect the coin collector. It
will make a sound if there is signal.
The connected target board is not connected
to the pull-up resistor.
Please connect the pull-up resistor.
Check whether the token in the coin
collector is the same with that inserted in
the coin collector.
Please replace it with the proper token.
The gear of the switch (normally on and
normally off) is incorrect
Please check whether the gear of the
switch (normally on, normally off) is
correct.
The coin collector
does not score.
The socket outlet of the coin connector is in
poor contact.
Please check whether the socket outlet of
the coin connector is in poor contact.
Whether the circuit board of the power
amplifier is powered on.
Please turn on the switch of the amplifier
circuit board to power on
The volume is too low.
Please turn the volume up.
Whether the audio connection port falls off
or is damaged.
Please re-connect the audio connection
port.
The circuit board of the power amplifier
goes wrong.
Please replace the circuit board.
The speaker does
not make a sound.
The speaker goes wrong.
Please replace the speaker.
No lottery fed.
The ticket machine goes wrong or the
switch is turned on wrongly.
Please replace the ticket machine or set
the switch to the factory settings.
Shooting is not
accurate.
Check if the potentiometer of the gun is
damaged.
Replace the potentiometer and re-align
the gun.

Robot Storm Manual
15
X Error Prompt
1. Cause: Disconnection with the IO board
2. Solution: Restart the machine, and press the reset button on the IO board (there is only
one button on the board)
1. Cause: No enough lotteries, or the ticket machine is damaged
2. Solution: Replenish lotteries; replace the ticket machine
1. Cause: The memory of the host is insufficient
2. Solution: Plug out the memory of the host, and then plug it in again.
Warning:
Cut off the power supply for maintenance and repair of the machine.
To prevent short circuit, relevant personnel should cut off the power supply when touching
internal components of the machine. If the operation requires power supply, it should meet
the requirements of the manual.
Use proper parts for replacement.
Improper parts may cause short circuit, and damage of the main board and the components.
Do not disassemble, assemble and change the equipment randomly.
It may cause short circuit and machine failure, and even fire disaster.
Do not place vases, cups and containers with water, chemicals or heavy objects on the
machine.
The spilt liquid may cause short circuit and damage of parts. Meanwhile, falling objects may
injure people and damage the machine.
Do not place objects in the exhaust outlet of the machine.
The blocked exhaust outlet may cause temperature rise inside the machine, affect the normal
operation of the game, and even damage the parts.
Do not repair the machine by yourself.
It may cause short circuit or malfunction and other failure.
Ticket Error
Ticket owned:
Communication Error

Robot Storm Manual
16
XI Instructions on Restoring U Disk
When the machine is turned off, plug the U
disk into the USB port behind the host, and
the U disk will restore after the machine
restarts. As shown in the figure, the system
is restoring, and it needs about 20 minutes.
Prompt for system completion. The
system restoring is completed as
shown in the left figure, and you
can unplug the U disk.
The system restoring needs about 20
minutes. Do not cut off the power
supply and wait patiently! Please
forgive if there is any
inconvenience!
ACE Amusement Technologies Co., Ltd.
ADD: #5 Building, No. 6, HengFeng 6th Road,
Gangkou Town, Zhongshan City, Guangdong,
P. R. China PC: 528447
TEL: [phone]
E-Mail: [email protected]
Web: www.ACE-Amusement.com
