Acer AT350 F1 Specifications
Product Overview
The Acer AT350 F1 is a dual socket Tower Server that can be converted to rack mount use for
flexible deployments requiring blazing performance and exceptional expansion capability. Offering
high reliability features, leading edge technologies, cost-effective scalability features, and a
comprehensive list of management features the Acer AT350 F1 delivers high-availability with
optimal power efficiency for demanding departmental and medium enterprise deployments.
Product Front View
Product Inside View
Product Inside View
1. 18 x ECC DDR3 1066/1333 MHz registered or unbuffered memory slots
2. 2 x Intel
®
Xeon
®
5600 series processors supporting up to 6-cores per processor
3. Hot-plug redundant system cooling fans
4. 2 x USB 2.0 Front-mounted connectors
5. Power button, System ID button, LED indicators (Power, HDD activity, LAN 1-2 status, system
ID/status/fault)
6. Support for up to sixteen 2.5” or eight 3.5” hot-plug SATA or SAS hard disk drives
7. 3 x Optical drive bays
8.
6 x PCI Express
®
slots with risers

2
Acer AT350 F1 Specifications
Product Rear View
1. PS2 keyboard connector
2. PS2 mouse connector
3. 4 x USB 2.0 connectors
4. Management IPMI LAN connector
5. COM (Serial) connector
6.
Video connector
7.
2
x Gigabit LAN connector
s
8. ID LED
What's New
 New Intel
®
Xeon
®
5600 Series processors
 2 x 720 W 80PLUS
®
gold-level efficient power supply units (1+1 redundant, hot-pluggable)
 DDR3 memory
 Energy Star Certified
Product Specifications
Processors and Chipset
 Up to two Intel
®
Xeon® 5600 series processors
 Chipset: Intel
®
5520
Memory
1
 Memory capacity:
 Registered DIMM: 2, 4, 8, 16 GB
2
 Unbuffered DIMM: 2, 4 GB
 Up to 192 GB registered DIMMs when fully populated with 2 DIMMs per channel in 12 slots
 Up to 48 GB unbuffered DIMMs when fully populated with 2 DIMMs per channel in 12 slots
Network Controllers
 Integrated Intel
®
82576EB dual-port Gigabit Ethernet Controller (2 ports total)
1
Mixed use of registered memory and unbuffered ECC memory not supported.
2
16 GB memory modules available by special request only.

3
Acer AT350 F1 Specifications
Storage
 Hard disk form factor: 2.5” or 3.5”
 Type: SAS/ SATA/ SSD with hot plug capability
 HDD Capacity (enterprise level):
 3.5” SAS HDD capacity: 300 GB, 450 GB, 600 GB
 3.5” SATA HDD capacity: 250 GB, 500 GB, 1TB, 2TB
 2.5” SAS HDD capacity: 73 GB, 146 GB, 300 GB, 450 GB, 600 GB
 2.5” SATA HDD capacity: 150 GB, 300 GB, 500 GB
 2.5” SSD capacity: 32 GB and 64 GB
 3.5” Maximum capacity:
 Up to 16 TB SATA HDD (2 TB 3.5" x 8 HDDs)
 Up to 4.8 TB SAS (600 GB 3.5” x 8 HDDs)
 2.5” Maximum capacity:
 Up to 8 TB SATA HDD (500 GB 2.5" x 16 HDDs)
 Up to 9.6 TB SAS (600 GB 2.5” x 16 HDDs)
Storage Controllers
 Integrated Intel® ICH10R Serial ATA host controller (six 3 Gb/s SATA ports) with RAID 0, 1, 5, 10
support
 Optional PCIe
®
4-port/8-port and 16-port 6Gb/s SAS RAID card (standard on some models)
Expansion slots
 Two full height PCI-E 2.0 x16 slot (with x8 link)
 Two full height PCI-E 2.0 x8 slots (with x4 link)
 One full height PCI-E 1.0 x8 slot (with x4 link)
 One Acer Flex I/O (PCI-E 2.0 x8) slot
Management
 Acer Smart Server Manager
 System ID LED buttons, System Health LED
 Acer Smart Console for server management and KVM over IP remote management
Deployment/Serviceability
 Acer Smart Setup
 BIOS Update Tool
 IPMI Firmware Update Tool
Operating Systems
•Windows Server
®
2008
•Windows Server
®
2008 R2
•Windows Server
®
2003
•Red Hat
®
Enterprise Linux 5.4
•SUSE
®
Linux Enterprise Server 11
•VMware ESXi
™
4
•VMware ESX
™
4

4
Acer AT350 F1 Specifications
Input/output interface
Front
 One Power/off button
 LED indicators: power, HDD activity, LAN port 1 through 2, and ID
 Two USB ports
Rear
 PS2 keyboard port
 PS2 mouse port
 Four USB 2.0 ports
 Two RJ-45 ports (dual Gigabit NIC) with activity and link indicators
 RJ-45 port (dedicated for management NIC) with activity and link indicators
 Serial (DB-9) port
 SVGA (DB-15) port
 ID LED
Optical drive
 5.25" half height SATA DVD/RW
Chassis/Form Factor
 Tower/ 4U (convertible for rack mounting)
Power Supply
 1 Power Supply Standard, 2nd optional
 Up to 2 x 720 W 80 PLUS
®
Gold-level efficient hot-swap power supplies (1+1 redundant)
Regulatory Compliant Standards
EMC
 FCC (Class A)
 CE (Class A)
 BSMI (Class A)
Safety
 UL/cUL
 CB
 Nemko/GS

5
Acer AT350 F1 Specifications
Technical Specifications
Dimensions
(with bezel)
434 (W) x 648 (D) x 178 (H) mm (17.2 x 25.5 x 7 inches)
Form factor
4U tower, rack mountable
System inlet
temperature
Operating 10°- 35°C (50°- 95°F) at sea level with an altitude
derating of 1°C per 305 m (1.8°F per 1000 ft.) above
sea level to a maximum of 3050 m (10,000 ft.) no direct
sustained sunlight. Maximum rate of change is 10°C/hr.
(18°F/hr.). The upper limit depends on the type and
number of options installed. System performance may
be reduced if operating with a fan fault or above 30°C
(86°F).
Non-operating -40°- 70°C (-40°- 158°F) Maximum rate of change is
20°C/hr. (36°F/hr.).
Relative humidity
(non-condensing)
Operating 8 - 90 % relative humidity (Rh), 28°C (82.4°F)
maximum wet bulb temperature, non-condensing
Non-operating 5 - 95 % relative humidity (Rh), 38.7°C (101.7°F)
maximum wet bulb temperature, non-condensing
Emissions
classification
(EMC)
FCC rating
Class A
Normative standards EN55022, EN 61000-3-2, EN 61000-3-3, CISPR 22
Class A
Power supply Rated Steady –state power 720 W
Maximum Peak Power 728 W
BTU rating 2456.64 BTU/hr. at 100 - 240 VAC

6
Acer AT350 F1 Specifications
Standard Features
Processors
Intel
®
Xeon
®
Six-Core processor
X5675 (12 MB L3 cache, 3.06 GHz, 6.4 GT/s, DDR3-1333 MHz, 95 W)
Intel
®
Xeon
®
Quad
-
Core processor
E5620 (12 MB L3 cache, 2.40 GHz, 5.86 GT/s, DDR3-1066 MHz, 80 W)
L5630 (12 MB L3 cache, 2.13 GHz, 5.86 GT/s, DDR3-1066 MHz, 40 W)
E5606 (8 MB L3 cache, 2.13 GHz, 4.8 GT/s, DDR3-1066 MHz, 80 W)
Chipset
Intel
®
5520
Memory
3
Type
DDR3 1066/1333 MHz Registered memory
DDR3 1066/1333 MHz Unbuffered ECC memory
DIMM sockets 18
Capacity
Registered DIMM: 2 / 4 / 8 / 16 GB
4
Unbuffered ECC DIMM: 2 / 4 GB
Maximum capacity Registered DIMM: 192 GB
Unbuffered DIMM: 48 GB
Memory protection ECC, Mirroring, Sparing, Lockstep Mode, x4/x8 SDDC
Network controller Integrated dual Intel
®
82576EB Gigabit Ethernet Controller (two ports)
3
Mixed use of registered memory and unbuffered ECC memory not supported.
4
16 GB memory modules available by special request only.

7
Acer AT350 F1 Specifications
Expansion slots
The primary I/O bus for the main board is PCIe
®
Gen2. The following table lists the characteristics of the
PCI-E bus segments.
PCI express
®
Bus Segment Characteristics of PCI Express
®
Topology
Expansion Slot # # of
slots
Type Bus
Width
1
Vol. Con.
Width
Length
PCIe
®
2
PCIe
®
Gen 2
x8
3.3
V
x16
Full height
PCIe
®
2 PCIe
®
Gen 2 x4 3.3V x8 Full height
PCIe
®
1 PCIe
®
Gen 1 x4 3.3V x8 Full height
Acer Flex I/O 1 PCIe
®
Gen 2 x8 3.3V x8
NOTE:
1. Indicates the number of physical electrical lanes running to a PCIe
®
connector.
2. Inserting cards with PCI™ bridges may alter the actual bus assignment number.
3. Slots are enumerated differently based on the operating system. Microsoft® operating systems
enumerate Device ID by bus starting from the lowest bus to the highest.
Storage controllers Intel 82801JR (ICH10R) I/O Controller Hub
Note: Onboard SATA software RAID cannot be enabled when add-on SAS RAID is
enabled.
Integrated Serial ATA
controller
Simultaneous drive
transfer channels
6 channels
Transfer rate
synchronous
(maximum theoretical)
3 GB/s per channel
Data transfer method non-RAID mode
RAID mode
Drive support Serial ATA
Data transfer modes Legacy mode
Combined mode
Protocol Serial ATA
Feature NCQ (Native Command Queuing)
AHCI (Advanced Host Controller Interface)
RAID levels supported 0, 1, 5, 10 (Windows
®
)
0, 1, 10 (Linux)
RAID features
•
Supports multiple logical volumes
•Supports setup through ROM based array
configuration utility installation scripting
NOTE: This controller requires the software RAID driver to
support hot-plug functions.
RAID OS support Windows Server
®
2008
Windows Server
®
2008 R2
Red Hat
®
Enterprise Linux 5.4
SUSE
®
Linux Enterprise Server 11

8
Acer AT350 F1 Specifications
Embedded dual-port
Gigabit server adapter
(Intel
®
82576EB)
Network interface 10Base-T
100Base-TX
1000Base
-
TX
Compatibility IEEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3u 100Base-TX
Data transfer method Four lane (x4), 100 MHz PCI Express reference clock
Network transfer rate
10Base-T (half-duplex) 10 Mb/s
10Base
-
T (full
-
duplex)
20 Mb/s
100Base-TX (half-duplex) 100 Mb/s
100Base-TX (full-duplex) 200 Mb/s
1000Base-TX (half- and full-duplex) 2000 Mb/s
Connector RJ-45
Cable support
CAT 5e wire
Virtualization
acceleration
Intel
®
I/O Acceleration Technology
Virtual Machine Device Queues (VMDq)
PCI-SIG
®
SR-IOV implementation
Manageability NC-SI SMBus, PXE, iSCSI boot
Storage
Maximum internal
storage
Hard disk drive
•
Up to 8 hot-pluggable 3.5" SATA/SAS HDD
•Up to 16 hot-pluggable 2.5” SATA/SAS/SSD
HDD
3.5” Maximum capacity
2.5” Maximum capacity
•
Up to 16 TB SATA
•Up to 4.8 TB SAS
•Up to 8 TB SATA
•Up to 9.6 TB SAS
•Up to 1 TB SSD

9
Acer AT350 F1 Specifications
Drive Support
–
Optical and Hard Disk Drive
Optical drive support
Drive Quantity
Supported
Bay Supported Required Controller
5.25” SATA DVD/RW Optical
Drive
Up to 3 A, B, C Integrated SATA controller
Hard Disk Drive Support
Drive Quantity
Supported
Bay Supported Required Controller
2.5” SATA/SAS/SAS hard drive Up to 16 0 – 15 Integrated SATA controller for
up to 4 SATA HDD’s
4-port SAS RAID card for up to 4
SAS/SATA/SSD HDD’s*
8-port SAS RAID card for up to 8
SAS/SATA/SSD HDD’s*
16-port SAS RAID card for up to
16 SAS/SATA/SSD HDD’s*
A
B
C
A
B
C
9 10 11 12 13 14 15
0 1 2 3 4 5 6 7

10
Acer AT350 F1 Specifications
3.5” SATA/SAS hard drive Up to 8 0 – 7 Integrated SATA controller for
up to 4 SATA HDD’s
4-port SAS RAID card for up to 4
SAS/SATA HDD’s*
8-port SAS RAID card for up to 8
SAS/SATA HDD’s*
*standard on some models.
NOTE: Transfer rates of drives are dependent on the maximum transfer rate supported by the host bus
adapter (HBA) or controller.
Tape Backup Support
Drive Bay Supported Required Controller
LTO-3 1U SAS Rackmount (external)
Tape Drive kit External SAS card
LTO-4 1U SAS Rackmount (external)
Tape Drive kit External SAS card
160/320 GB, DAT320, 5.25”, internal half
height, USB interface
B and C Internal USB 2.0 ports
80/160 GB, DAT160, 5.25”, internal half
height, USB interface B and C Internal USB 2.0 ports
36/72 GB, DAT72 (DDS Gen-5), 5.25”,
internal half height, USB interface B and C Internal USB 2.0 ports
