DSIM-CG
Installation Guide Rev C
Instructions for Dual Pilot AGC Operation
1. Remove the RF module cover. If needed remove the 3 jumpers so the DSIM can be
installed. There is no need to adjust the slope or gain POTs, these will be controlled by the
DSIM after it is installed. Install the DSIM-CG AGC module into the amplifier. Then re-
install the RF module faceplate.
2. Set the input levels to outside plant specifications with the input pad.
3. Plug the controller into the DSIM-CG.
4. The controller LED should be solid blue, indicating MGC-Gain Control Mode. If it is not solid
blue press the mode button several times until it is solid blue.
a. Use the “+” and '-' button to set the output level at 750 MHz, or the highest
frequency to the correct output level.
5. Press the mode button once to go to manual slope control mode. In this mode the
controller LED flashes purple every half second. Use this mode to set the amplifier low
frequency level using the + and minus buttons again. The level at 750MHz shouldn't
change more than 1dB. If it does, cycle back to manual gain control mode, by pressing the
mode button 3 times, to readjust the gain.
6. From manual-slope control mode press the mode button once to start the align process.
a. The align process takes 30 to 40 seconds.
b. When done, the controller LED will flash blue every half second. This indicates that
the DSIM is in AGC mode and the setup is complete.
7. Remove the controller from the cable and then the cable from the DSIM.
Page 3 of 14
DSIM-CG
Installation Guide Rev C
Table of Contents
1. INSTRUCTIONS FOR DUAL PILOT AGC OPERATATION.......................................................... 2
2. DSIM-CG AGC MODULE & DSIM CONTROLLER OVERVIEW................................................. 4
3. DSIM MODE DEFINITIONS .................................................................................................. 5
4. DSIM CONTROLLER OPERATION INSTRUCTION GUIDELINES .............................................. 6
5. DSIM CONTROLLER STATUS LED ESSENTIALS...................................................................... 7
6. DSIM-CG MODULE STATUS LED ESSENTIALS....................................................................... 7
7. LED SECONDARY PILOT CHANNEL FREQUANCIES ............................................................... 9
8. LED PRIMARY PILOT CHANNEL BLINK SERIES OVERVIEW ................................................. 10
Page 4 of 14
DSIM-CG
Installation Guide Rev C
DSIM CONTROLLER
DICGTAL STATION INTELLIGENCE
MANAGER
DSIM Controller Interface
Connector
Status LED
Blue / Orange
Status LED
Red/Blue
DSIM Module
Interface
Connector
Mode
Decreas
e
Increase
2. DSIM-CG AGC Module & DSIM Controller Overview
The Digital Station Intelligence Manager (DSIM) product line is the next generation of automatic
gain control modules that provides the outside plant maintenance team with station diagnostic tools
that are unprecedented in the industry. The DSIM-CG AGC module is agile that allows the program
settings to be modified at any time to change the pilot channel number and type from analog to
digital or to change the operational mode into the AGC or manual modes of operation. Having this
flexibility to reprogram the DSIM-CG modules is a huge cost savings when doing system pilot
channel modifications over the fixed AGC since only the program settings need to be changed
instead of having to change out the entire AGC fixed module.
The DSIM-CG module is programmed to operate as a dual pilot AGC. In the AGC mode the primary
pilot can be programmed to either analog or digital pilot signal from channels 52 to 142. The
secondary pilot can be ether analog or digital from channels 2 to 25. In AGC mode the DSIM-CG
remembers the output control values for operational temperatures, so if one of the pilots channels
are lost the DSIM-CG recalls what the control values are for the current temperature. The DSIM-
CG will operate on memory until both pilot channels have been restored. The DSIM-CG
incorporates a bi-colored blue and orange LED that indicates the different operational modes and
settings of the DSIM-CG during setup and operation.
The DSIM controller is used to set the DSIM-CG module’s pilot channel and to change into the
different operational modes during the amplifier setup. The bi-colored blue and red LED indicator's
blinking patterns will denote the current optional mode setting.
Page 5 of 14
DSIM-CG
Installation Guide Rev C
The DSIM-CG modules has a default primary pilot channel 88 digital (609.00 MHz) and secondary
pilot channel 3 digital (63.00 MHz). The DSIM controller is used to set the DSIM-CG modules to
the customer selected pilot channel. In the setup of the DSIM-CG module the pilot channels that
are programmed into the controller are downloaded into the memory of the DSIM-CG module. The
pilot channel settings in the DSIM-CG module can be changed in the future by simply using a
controller programmed with the new desired pilot channels.
3. DSIM Mode Definitions
Operation Mode
Definition
MGC- Gain Control Mode
Gain Control Mode is for manually setting the inter-stage gain.
MGC- Slope Control Mode
Slope Control Mode is for manually setting the inter-stage slope.
AGC
In Automatic Gain Control (AGC) mode will make gain adjustments
to the station based on the level changes that occur on the pilots
channel.
TGC
Direct Thermal Gain Control (TGC) is not active for the DSIM-CG.
The DSIM-CG does have active thermal fall back, in case one or
both of the pilot are lost.
Page 6 of 14
DSIM-CG
Installation Guide Rev C
4. DSIM Controller Operation Instruction Guidelines
Switch
Function
Description
+
Increase
In MGC Gain Mode, Click to increase the inter-stage RF
level.
MGC - Slope Mode, Click to increase inter-stage slope
In AGC Mode, no function
In TGC Mode, Click to increase cable length value
-
Decrease
In MGC Mode, Click to decrease the inter-stage RF level
In MGC Slope Mode, Click to decrease the inter-stage slope.
In AGC Mode, no function
In TGC Mode, Click to decrease cable length value
Mode
Mode Change
In MGC mode, Click to go to Align Mode to load controller
channel setting, DSIM module will then automatically switch
to AGC mode
In AGC Mode, Click to return to TGC Mode
In TGC Mode, Click to go to MGC Mode
Page 7 of 14
DSIM-CG
Installation Guide Rev C
5. DSIM Controller Status LED Essentials
6. DSIM-CG Module Status LED Essentials
Operation Blinking Patterns for DSIM-CG Module
LED Blinking Pattern
Indications
Steady Repeating Blue Dashes
MGC - Gain Control & Slope Control
Series of Blue Blinks
Pilot Channel Number ‐ See tables in section
10 at the end of the guide for blinking sequences
Single Blue Long Dash Between Series
of Blue Blinks
IRC Analog channel is set
2 Blue Long Dashes Between Series
of Blue Blinks
Digital channel is set
3 Blue Long Dashes Between Series
of Blue Blinks
TGC Mode‐ The default cable length setting for
TGC mode is 27 dB of cable in front of the
amplifier
Quick Blue / Orange Blinks
Pilot paste in progress‐Wait
or Pilot channel not found or lost
LED Blinking Pattern
Indications
Quick Blue / Red Blinks
DSIM controller to module syncing process -
Occurs when controller is installed into the DSIM
module.
Aligning process: in progress
Steady on Blue
In MGC Gain Control Mode
Series of Purple Blinks
In MGC Slope Control Mode
Series of Blue Blinks
In AGC Mode
Steady on Purple
In TGC Mode
Page 8 of 14
DSIM-CG
Installation Guide Rev C
LED Fault Conditions Blinking Patterns
LED Blinking Pattern
Indications
Steady on Pink
24 volt input into DSIM-CG module is out of the
operational range of 21.5 to 26.5 VDC. If this
occurs, check for correct AC voltage input to the
amplifier and for correct output DC voltage of
internal power supply to the RF module
Steady Repeating Orange Blinks
Temperature in DSIM-CG module is too high / low
(above 221ºF/105ºC or below -40ºF/-40ºC)
Quick Blue / Orange Blinks
Pilot Lost; DSIM-CG automatically switches to
Thermal (TGC) mode until Pilot channel is
restored
Note: The DSIM-CG LED blinks after the pilot channel count will be orange during programming and
blue when in operation.
Page 9 of 14
DSIM-CG
Installation Guide Rev C
7. LED Secondary Pilot Channel Frequancies
Channel
IRC
DIGITAL
Channel
IRC
DIGITAL
MHz
MHz
MHz
MHz
2
55.25
57.00
28
247.25
249.00
3
61.25
63.00
29
253.25
255.00
4
67.25
69.00
30
259.25
261.00
7
175.25
177.00
31
265.25
267.00
8
181.25
183.00
32
271.25
273.00
9
187.25
189.00
33
277.25
279.00
10
193.25
195.00
34
283.25
285.00
11
199.25
201.00
35
289.25
291.00
12
205.25
207.00
36
295.25
297.00
13
211.25
213.00
37
301.25
303.00
14
121.25
123.00
38
307.25
309.00
15
127.25
129.00
39
313.25
315.00
16
133.25
135.00
40
319.25
321.00
17
139.25
141.00
41
325.25
327.00
18
145.25
147.00
42
331.25
333.00
19
151.25
153.00
43
337.25
339.00
20
157.25
159.00
44
343.25
345.00
21
163.25
165.00
45
349.25
351.00
22
169.25
171.00
46
355.25
357.00
23
217.25
219.00
47
361.25
363.00
24
223.25
225.00
48
367.25
369.00
25
229.25
231.00
49
373.25
375.00
26
235.25
237.00
50
379.25
381.00
27
241.25
243.00
51
385.25
387.00
Page 10 of 14
DSIM-CG
Installation Guide Rev C
8. LED Primary Pilot Channel Blink Series Overview
Channel
IRC
DIGITAL
Set 1
Set 2
Set 3
Set 4
MHz
MHz
Blue
Blue
Blue
Blue-Operation
Orange-Programming
52
391.25
393.00
5-Dits
2-Dits
1 IRC / 2 DIGITAL
Long dash
53
397.25
399.00
5-Dits
3-Dits
54
403.25
405.00
5-Dits
4-Dits
55
409.25
411.00
5-Dits
5-Dits
−
56
415.25
417.00
5-Dits
6-Dits
−
57
421.25
423.00
5-Dits
7-Dits
−
58
427.25
429.00
5-Dits
8-Dits
−
59
433.25
435.00
5-Dits
9-Dits
−
60
439.25
441.00
6-Dits
1-Dash
−
61
445.25
447.00
6-Dits
1-Dits
−
62
451.25
453.00
6-Dits
2-Dits
−
63
457.25
459.00
6-Dits
3-Dits
−
64
463.25
465.00
6-Dits
4-Dits
−
65
469.25
471.00
6-Dits
5-Dits
−
66
475.25
477.00
6-Dits
6-Dits
−
67
481.25
483.00
6-Dits
7-Dits
−
68
487.25
489.00
6-Dits
8-Dits
−
69
493.25
495.00
6-Dits
9-Dits
−
70
499.25
501.00
7-Dits
1-Dash
−
71
505.25
507.00
7-Dits
1-Dits
−
72
511.25
513.00
7-Dits
2-Dits
−
73
517.25
519.00
7-Dits
3-Dits
−
Page 11 of 14
DSIM-CG
Installation Guide Rev C
Channel
IRC
DIGITAL
Set 1
Set 2
Set 3
Set 4
MHz
MHz
Blue
Blue
Blue
Blue-Operation
Orange-Programming
74
523.25
525.00
7-Dits
4-Dits
1 IRC / 2 DIGITAL
Long dash
75
529.25
531.00
7-Dits
5-Dits
76
535.25
537.00
7-Dits
6-Dits
−
77
541.25
543.00
7-Dits
7-Dits
−
78
547.25
549.00
7-Dits
8-Dits
−
79
553.25
555.00
8-Dits
9-Dits
−
80
559.25
561.00
8-Dits
1-Dash
−
81
565.25
567.00
8-Dits
1-Dits
−
82
571.25
573.00
8-Dits
2-Dits
−
83
577.25
579.00
8-Dits
3-Dits
−
84
583.25
585.00
8-Dits
4-Dits
−
85
589.25
591.00
8-Dits
5-Dits
−
86
595.25
597.00
8-Dits
6-Dits
−
87
601.25
603.00
8-Dits
7-Dits
−
88
607.25
609.00
8-Dits
8-Dits
−
89
613.25
615.00
8-Dits
9-Dits
−
90
619.25
621.00
9-Dits
1-Dash
−
91
625.25
627.00
9-Dits
1-Dits
−
92
631.25
633.00
9-Dits
2-Dits
−
93
637.25
639.00
9-Dits
3-Dits
−
94
643.25
645.00
9-Dits
4-Dits
−
100
649.25
651.00
1-Dits
1-Dash
1-Dash
Page 12 of 14
DSIM-CG
Installation Guide Rev C
Channel
IRC
DIGITAL
Set 1
Set 2
Set 3
Set 4
MHz
MHz
Blue
Blue
Blue
Blue-Operation Orange-
Programming
101
655.25
657.00
1-Dits
1-Dash
1-Dits
1 IRC / 2 DIGITAL
Long dash
102
661.25
663.00
1-Dits
1-Dash
2-Dits
103
667.25
669.00
1-Dits
1-Dash
3-Dits
104
673.25
675.00
1-Dits
1-Dash
4-Dits
105
679.25
681.00
1-Dits
1-Dash
5-Dits
106
685.25
687.00
1-Dits
1-Dash
6-Dits
107
691.25
693.00
1-Dits
1-Dash
7-Dits
108
697.25
699.00
1-Dits
1-Dash
8-Dits
109
703.25
705.00
1-Dits
1-Dash
9-Dits
110
709.25
711.00
1-Dits
1-Dits
1-Dash
111
715.25
717.00
1-Dits
1-Dits
1-Dits
112
721.25
723.00
1-Dits
1-Dits
2-Dits
113
727.25
729.00
1-Dits
1-Dits
3-Dits
114
733.25
735.00
1-Dits
1-Dits
4-Dits
115
739.25
741.00
1-Dits
1-Dits
5-Dits
116
745.25
747.00
1-Dits
1-Dits
6-Dits
117
751.25
753.00
1-Dits
1-Dits
7-Dits
118
757.25
759.00
1-Dits
1-Dits
8-Dits
119
763.25
765.00
1-Dits
1-Dits
9-Dits
120
769.25
771.00
1-Dits
2-Dits
1-Dash
121
775.25
777.00
1-Dits
2-Dits
1-Dits
122
781.25
783.00
1-Dits
2-Dits
2-Dits
Page 13 of 14
DSIM-CG
Installation Guide Rev C
Channel
IRC
DIGITAL
Set 1
Set 2
Set 3
Set 4
MHz
MHz
Blue
Blue
Blue
Blue-Operation Orange-
Programming
123
787.25
789.00
1-Dits
2-Dits
3-Dits
1 IRC / 2 DIGITAL
Long dash
124
793.25
795.00
1-Dits
2-Dits
4-Dits
125
799.25
801.00
1-Dits
2-Dits
5-Dits
126
805.25
807.00
1-Dits
2-Dits
6-Dits
127
811.25
813.00
1-Dits
2-Dits
7-Dits
128
817.25
819.00
1-Dits
2-Dits
8-Dits
129
823.25
825.00
1-Dits
2-Dits
9-Dits
130
829.25
831.00
1-Dits
3-Dits
1-Dash
131
835.25
837.00
1-Dits
3-Dits
1-Dits
132
841.25
843.00
1-Dits
3-Dits
2-Dits
133
847.25
849.00
1-Dits
3-Dits
3-Dits
134
853.25
855.00
1-Dits
3-Dits
4-Dits
135
859.25
861.00
1-Dits
3-Dits
5-Dits
136
865.25
867.00
1-Dits
3-Dits
6-Dits
137
871.25
873.00
1-Dits
3-Dits
7-Dits
138
877.25
879.00
1-Dits
3-Dits
8-Dits
139
883.25
885.00
1-Dits
4-Dits
9-Dits
140
889.25
891.00
1-Dits
4-Dits
1-Dash
141
895.25
897.00
1-Dits
4-Dits
1-Dits
142
901.25
903.00
1-Dits
4-Dits
2-Dits
Page 14 of 14
DSIM-CG
Installation Guide Rev C
ACI Communications, Inc.
23307 66th Avenue South
Kent, Washington 98032
Tel: (253) 854-9802
Fax: (253) 813-1001
Toll Free: (800) 336-3526
2020 ACI Communications, Inc.
All rights reserved
Rev C 9-21-2020 Printed in U.S.A.
ACI Communications, Inc. reserves the right to discontinue the
manufacture or change specifications without prior notice on any
parts illustrated in this data sheet. Registered trademarks are the
property of their respective owners
Table of contents
Other aci Controllers manuals
