ACME CP?64 BD15 User manual

COLORPAR64
CP‐64BD15
CP‐64PD15
UserManual
Pleasereadtheinstructioncarefullybeforeuse

1A
Contents
1.SafetyInstruction .....................................................................................................2
2.TechnicalSpecification..............................................................................................3
3.Installation................................................................................................................4
4.DMXAddressSetting ................................................................................................4
A.DMXaddresssettingbydip‐switches...................................................................5
B.AutomaticDMX‐addressing..................................................................................5
C.RemoteDMXaddresssettingbyCA‐TDMXTESTER.............................................6
D.RemoteDMXaddresssettingbyUniversalDMXcontroller .................................6
5.Howtocontrolthefixture ........................................................................................7
A.UniversalDMXcontroller .....................................................................................7
B.Master/Slaveoperation........................................................................................8
C.EasyController(ByCA‐8)......................................................................................8
6.DMX512Connections ..............................................................................................9
7.Troubleshooting......................................................................................................10
8.FixtureCleaning......................................................................................................11


2A
1.SafetyInstruction
WARNING
♦PleasekeepthisUserManualforfutureconsultation.Ifyouselltheunittoanotheruser,besure
thattheyalsoreceivethisinstructionbooklet.
♦Unpackandcheckcarefullythereisnotransportationdamagebeforeusingtheunit.
♦Beforeoperating,ensurethatthevoltageandfrequencyofpowersupplymatchthepower
requirementsoftheunit.
♦It’simportanttogroundtheyellow/greenconductortoearthinordertoavoidelectricshock.
♦Disconnectmainspowerbeforemaintenanceorservicing.
♦Usesafetycablewhenfixesthisunit.Don’thandlethefixturebytakingitsheadonly,butalways
takingitsbase.
♦MaximumambienttemperatureTA:40 .℃Don’toperateitwhenthetemperatureishigher.
♦Intheeventofseriousoperatingproblem,stopusingtheunitimmediately.Nevertrytorepair
theunitbyyourself.Repaircarriedoutbyunskilledpeoplecanleadtodamageormalfunction.
Pleasecontactthenearestauthorizedtechnicalassistancecenterandalwaysusethesametype
spareparts.
♦Donotconnectthedevicetoanydimmerpack.
♦Donottouchanywireduringoperationashighvoltagemightbecausingelectricshock.
♦Thehousingmustbereplacediftheyarevisiblydamaged.
♦DonotlookdirectlyattheLEDlightbeamwhilethefixtureison.
♦Theunitisforindooruseonlyanduseonlyinadrylocation.
♦Theunitmustbeinstalledinalocationwithadequateventilation,atleast50cmfromadjacent
surfaces.Besurethatnoventilationslotsareblocked.
♦Therearenouserserviceablepartsinsidetheunit.Donotopenthehousingorattemptany
repairsyourself.Intheunlikelyeventyourunitmayrequireservice,pleasecontactyournearest
dealer.
Pleasereadtheinstructioncarefullywhichincludingimportant
informationabouttheinstallation,operationandmaintenance.

3A
2.TechnicalSpecification
•InputVoltage:AC120V~60HzorAC230/240/250V~50Hz
•Powerconsumption:28W
•LED:212pcs
Red70pcs,Green71pcs,Blue71psc
•Channels:
Channel1=Red
Channel2=Green
Channel3=Blue
Channel4=Dimmer/SoundChase/Strobe
•Dimension:216x216x205mm
•Weight:3kg

•BeamAngel:15°
Luminousintensity:

4A
3.Installation
Pleasecheckoutthevoltagebeforeapplyingpower.
Donotconnectthefixturetoanelectricaldimmersystemwhichcoulddamagetheinside
electronics.
4.DMXAddressSetting
Eachfixtureneedstohaveanaddresssettoreceivethedatasentbythecontroller.Theaddress
numberisbetween0~511(usually0&1areequalto1).Theaddress,alsoknowasthestart
channel,isthefirstchannelusedtoreceiveinstructionsthecontroller.
TherearefourwaystosetthefixtureDMXstartaddress:
A.DMXaddresssettingbydip‐switches
B.AutomaticDMX‐addressing
C.RemoteDMXaddresssettingbyCA‐TDMXTESTER
D.RemoteDMXaddresssettingbyuniversalDMXcontroller
IfyouusethefunctionB,CorDtosettheDMXstartaddress,thefixturesofthechainallDIP
switchMUSTbesettoOFF.


5A
A.DMXaddresssettingbydip‐switches
1.SelectthechannelsofDMXcontroller
2.Dipswitches
Dip#1#2#3#4#5#6#7#8#9#10
Value1248163264128256Nofunction
Example:
Channel01:dip/on:#1(=1)
Channel05:dip/on:#1,#3(1+4=5)
Channel09:dip/on:#1,#4(1+8=9)
Channel13:dip/on:#1,#3,#4(1+4+8=13)

B.AutomaticDMX‐addressing
1TheDMXaddressoffixturecanbesetautomatically.Youhavetopresstheautoaddressing
buttonfromthefirstfixture’smainPCBoard.Whenyouholdthebutton5secs,thefixturewill
besettheDMXaddressto1,andtheotherfixturesofthechainwillbesettheirownDMX
addressautomatically.
2.Thefixtureusedfourchannels,thenextfixture’swillbeautomaticcalculatetheirownDMX
address,noneedtocalculatetheDMXchannelsofeachfixtureinthechain.
(Fixture1=1,Fixture2=5,Fixture3=9,Fixture4=13,Fixture…)
3.NoneedtoturnthefixtureoffwhenyouchangetheDMXaddress,asnewDMXaddresssetting
willbeaffectedatonce.Everytimeyouturnthefixtureon,itwillbereadytoreceiveDMX
signalorturnthebuilt‐inprograms.


6A
C.RemoteDMXaddresssettingbyCA‐TDMXTESTER
ThefixturecanbesettheDMXaddressremotelybyCA‐TDMXTESTER.Pleaserefertothe
CA‐TusermanualtosettheDMXaddresstothefixture.

D.RemoteDMXaddresssettingbyUniversalDMXcontroller
1.MakesuretheDMXcableofallunitsareconnected.
2.ConnectthefirstunittoauniversalDMXcontroller.
3.Connectallunitstothemainssotheyareswitchedon.
4.SetallDMX‐channelsonyourDMX‐controllertozero(value000).
5.SetallDMX‐channels,thatyouwanttoassignasDMXstartaddressonyourprojector,tot
maximum(value255).
6.Pressthe“AutoDMXaddress”buttonontheprojectorshortly.
7.IfyouwanttosetanotherprojectortothesameDMXstartaddress.Simplypressit’s“Auto
DMXaddress”,buttonanditwillreceivethesameaddress.
8.Done!
Anexampletomakethingsclear:
1.WewillsettheDMXstartaddressofaprojectorto106.
2.ConnecttheprojectortotheDMX‐controllerasdescribedaboveandmakesureallisswitched
on.
3.SetallDMX‐channelsonthecontrollertozero(000).

7A
4.NowsetSMX‐channel106tomaximum(255).
5.Pressthe“AutoDMXaddress”buttonontheprojectorshortly.
6.Done!YourprojectornowhasDMXaddress106!
5.Howtocontrolthefixture
Threewaystoset‐uptheDMXaddress:
A. UniversalDMXcontroller
B. Master/Slaveoperation
C. Easycontroller(byCA‐8)
A.UniversalDMXcontroller
ThefixturecanbesettheDMXaddressremotelybyuniversalDMXcontroller.First,youneedto
programmingtwoscenesintoachase,andthenlinkthefixturestotheuniversalDMXcontroller.
Whenyourunthechase,allthefixtureofthechainwillbesettheseriesDMXaddress
automatically.Ifyouuseacontrollerwith5pinsDMXconnector,youneedtousea5to3pin
adapter.Thefixtureusesfourchannels.Pleasereferthefollowingdiagramtouseyourcontroller
toactivatethefixture.


8A
B.Master/Slaveoperation
Thefixtureswillallowyoutolink16fixturestogetherandoperatewithoutacontroller.In
Master/Slavemode,thefirstfixturewillcontroltheotherstogiveanautomatic,soundactivated,
synchronizedlightshow.Thisfunctionisgoodwhenyouwantaninstantshow.Thefirstunitit’s
DMXinputcablewillhavenothingconnectit,andtheotherfixtureswillbesetinslavemode
automatically.TheirDMXinputcablesconnectthelastfixtureDMXoutputcable(daisychain).Any
fixturecanactasamasterorasaslave.

C.EasyController(ByCA‐8)
Theeasyremotecontrolisusedonlyinmaster/slavemode.Thereisa
terminatorforconnecttheeasycontrollerinsidethefixture.Byconnectingthe
cableintoDMXINwaterproofcableglandtotheCA‐8terminatorofthefirst
fixture,youwillfindthattheremotecontrolonthefirstfixturewillcontrolall
theotherunitsforStandby,FunctionandMode.Built‐inlightingshows
triggeredbyEasyController:

StandbyBlackoutthefixture
Function
Strobe
1.SynchronousStrobeinwhite
color
2.Thesamecolorchase
3.Differentcolorstrobe
9Colorselect
White→
Red→
Blue→
Purple→
Orange→
Green→
Yellow→
Magenta→
Cyan

ColorChase
1.Thesame
color
2.Different
color
3.Onelight
chase
4.Twolights
chase
5.Four
lightschase
ColorFade
1. Fastspeed
2. Middlespeed
3. Slowspeed
ModeSound1(LEDOFF)Manual(LEDON)
Sound2
(LEDslow
blinking)
Auto(LED
fastblinking)




9A
6.DMX512Connections
TheDMX512iswidelyusedinintelligentlightingsandwithamaximumof512channels.

1. Connecttheunittogetherina‘daisychain’byXLRplugfromtheoutputoftheunitto
theinputofthenextunit.Thecablecannotbebranchedorsplittoa‘Y’cable.DMX
512isaveryhigh‐speedsignal.Inadequateordamagedcables,solderjointsor
corrodedconnectorscaneasilydistortthesignalandshutdownthesystem.
2. TheDMXoutputandinputconnectorsarepass‐throughtomaintaintheDMXcircuit,
whenpowerisconnectedtotheunit.
3. Atlastunit,theDMXcablehastobeterminatedwithaterminator.Soldera120ohm
1/4 W resistorbetweenpin2(DMX‐)andpin3(DMX+)intoa3‐pinXLR‐plugandplugit
intheDMX‐outputofthelastunit.
4. Eachlightingunitneedstohaveanaddresssettoreceivethedatasentbythe
controller.Theaddressnumberisbetween0‐511(usually0&1areequalto1).
5. 3pinXLRconnectorsaremorepopularthan5pinXLR.
3pinXLR:Pin1:GND,Pin2:Negativesignal(‐),Pin3:Positivesignal(+)
5pinXLR:Pin1:GND,Pin2:Negativesignal(‐),Pin3:Positivesignal(+)





10A
7.Troubleshooting
Followingareafewcommonproblemsthatmayoccurduringoperation.Herearesome
suggestionsforeasytroubleshooting:
A.Theunitdoesnotwork,nolightandthefandoesnotwork
1. Checktheconnectionofpowerandmainfuse.
2. Measurethemainsvoltageonthemainconnector.
B.NotrespondingtoDMXcontroller
1. DMXLEDshouldbeon.Ifnot,checkDMXconnectors,cablestoseeiflinkproperly.
2. IftheDMXLEDisonandnoresponsetothechannel,checktheaddresssettingsand
DMXpolarity.
3. IfyouhaveintermittentDMXsignalproblems,checkthepinsonconnectorsoronPCBofthe
unitorthepreviousone.
4. TrytouseanotherDMXcontroller.
5. CheckiftheDMXcablesrunnearorrunalongsidetohighvoltagecablesthatmaycause
damageorinterferencetoDMXinterfacecircuit.
C.Someunitsdon’trespondtotheeasycontroller
1. YoumayhaveabreakintheDMXcabling.ChecktheLEDfortheresponseofthemaster/
slavemodesignal.
2. WrongDMXaddressintheunit.Settheproperaddress.
D.Noresponsetothesound
1. MakesuretheunitdoesnotreceiveDMXsignal.
2. Checkmicrophonetoseeifitisgoodbytappingthemicrophone
E.Oneofthechannelsisnotworkingwell
1. ThesteppermotormightbedamagedorthecableconnectedtothePCBisbroken.
2. Themotor’sdriveIConthePCBmightbeoutofcondition


11A
8.FixtureCleaning
Thecleaningofinternalandexternalopticallensesand/ormirrorsmustbecarriedoutperiodically
tooptimizelightoutput.Cleaningfrequencydependsontheenvironmentinwhichthefixture
operates:damp,smokyorparticularlydirtysurroundingcancausegreateraccumulationofdirton
theunit’soptics.
yCleanwithsoftclothusingnormalglasscleaningfluid.
yAlwaysdrythepartscarefully.
yCleantheexternalopticsatleastevery20days.Cleantheinternalopticsatleastevery30/60
days.

Declaration of Conformity
We declare that our products (lighting equipments) comply with the
following specification and bears CE mark in accordance with the
provision of the Electromagnetic Compatibility (EMC) Directive
2004/108/EC.
EN55103-1: 2009 ; EN55103-2: 2009;
EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008.
&
Harmonized Standard
EN 60598-1:2008 + All:2009; EN 60598-2-17:1989 + A2:1991;
EN 62471:2008; EN 62493: 2010
Safety of household and similar electrical appliances
Part 1: General requirements

Innovation,Quality,Performance
