ACME BW-545 User manual

BW-545
User Manual
Please read the instructions carefully before use

TABLE OF CONTENTS
1. Safety Instructions............................................................................................................................2
2. Techical Specfications.......................................................................................................................4
3. How To Set The Fixture ....................................................................................................................4
3.1 Control Panel..................................................................................................................................4
3.2. Main Functions..............................................................................................................................5
4.How To Control The Unit .................................................................................................................10
4.1 Master/Slave Built In Preprogrammed Function .........................................................................10
4.2 DMX Controller.............................................................................................................................10
4.3 DMX 512 Configuration................................................................................................................11
4.4 DMX512 Connection ....................................................................................................................13
5. Troubleshooting .............................................................................................................................14
6. Fixture Cleaning .............................................................................................................................14
1B

1. Safety Instructions
WARNING
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure
that they also receive this instruction booklet.
Caution
：
All fixtures are intact from the manufacturer, please operate follow up the user manual,
artificial fault are not under guarantee repair.
Unpack and check carefully there is no transportation damage before using the unit.
Do install and operate by operator.
Use safety chain when fixes the unit.
The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces.
Be sure that no ventilation slots are blocked, otherwise the unit will be overheated.
Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
Maximum ambient temperature TA : 40℃. Don’t operate it where the temperature is higher
than this.
Don’t connect the device to any dimmer pack.
First run, there will be smoke or smells, and all disappearing a few minutes later.
Make sure there are no flammable materials close to the unit while operating, as it is fire
hazard.
Look over power wires carefully, replace immediately if there is any damage.
Unit surface temperature may reach up to 60℃. Don’t touch the housing bare-hand during its
operation.
Never run on for a long time lest shortening lifespan.
Do not operate in dirty and dusty environment, also cleaning fixtures regularly.
Do not allow children to operate the fixture.
Please read the instructions carefully which include important
information about the installation, operation and maintenance.
2B

Do not touch any wire during operation as there might be a hazard of electric shock.
Avoid power wires together arounding other cables.
In the event of serious operating problem, stop using the unit immediately.
Never turn on and off the unit time after time.
The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Do not open the unit as there are no user serviceable parts inside. Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center.
Disconnect the mains power if the fixture is not used for a long time.
Do use original packing materials once transport it again.
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or
moisture.
Do not look directly at the LED light beam while the fixture is on.
To protect the machine, power off 10s rear can electrify.
Installation
The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is
firmly fixed to avoid vibration and slipping while operating. Always ensure that the structure to
which you are attaching the unit is secure and is able to support a weight of 10 times of the
unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit
when installing the fixture.
The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people and has no one pass by or under it.
3B

2. Techical Specfications
Voltage: AC 100-240V/50HZ
Power consumption: 162W
Light source: 3W LED x 54pcs (14pcs x Red, 14pcs x Green, 14pcs x Blue, 12pcs x White)
Power Cord Daisy Chain: 3 Fixtures Max. (120V/60Hz), 6 Fixtures Max. (230V/5 0Hz)
Lens Option: 19 Degree
Dimension: 230 x 302 x 350 mm
Weight
：
9 kg
3. How To Set The Fixture
3.1 Control Panel
1: Power
Water proof connectors for power input/output
2: DMX input/output
Water proof connectors for DMX 512 operation, 3-pin XLR cable to link the units together
3: Display
To show the menu and the selected functions
4B

Button:
3.2. Main Functions
To select any functions, press the MENU button until the required one is shown on the display.
Select the function by the ENTER button and the display will blink. Use the DOWN and UP button
to change the mode. Once the required mode has been selected, press the ENTER button to setup
or it will automatically return to the main functions without any change after idling one minute.
Back to the functions without any change press the MENU button. The main functions are shown
below:
4. MENU
To select the programming functions
5. DOWN
To go backward in the selected functions
6. UP
To go forward in the selected functions
7. ENTER
To confirm the selected functions
Once you set to , after running in show mode for 5 minutes
without any change or restarting the unit, the key board become locked.
Press ENTER button to enable the menu, the display will show , press
UP and DOWN button until it shows , then press ENTER to unlock.
5B

6B

DMX 512 Address Setting
Press the MENU button up to when the is shown on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to change the DMX 512 address. Once the
address has been selected, press ENTER button to setup or automatically exit menu mode without
any change after one minute. Back to the previous functions without any change press MENU
button.
Channel mode
Press the MENU button up to when the is shown on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (4 channels),
(5 channels) or (7 channels). Once select, press ENTER button to setup or
automatically exit menu mode without any change after one minute. To go back to the functions
without any change press the MENU button.
Show mode
Press the MENU button up to when the is shown on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (show 1) …
(show 16) or (Manual). After select the show mode, use DOWN and UP button to
adjust the value for fade mode and speed mode. Once select, press ENTER button to store or
automatically return to the main functions without any change after one minute. To go back to the
previous functions without any change press the MENU button.
Slave mode
Press the MENU button up to when the is shown on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (Master),
(slave 1) or (slave 2). Once select, press ENTER button to store or automatically return
to the main functions without any change after one minute. To go back to the previous functions
without any change press the MENU button.
Dimmer mode
Press the MENU button up to when the is shown on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (Dimmer Curve
7B

1) … (Dimmer Curve 4). Once select, press ENTER button to store or automatically return
to the main functions without any change after one minute. To go back to the previous functions
without any change press the MENU button.
Dimmer Speed
Press the MENU button up to when the is shown on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (Smooth),
(Fast). Once select, press ENTER button to store or automatically return to the main functions
without any change after one minute. To go back to the previous functions without any change
press the MENU button.
DMX State
Press the MENU button up to when the is shown on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (Master-Slave) or
(Blackout mode). Once select, press ENTER button to store or automatically return to
the main functions without any change after one minute. To go back to the previous functions
without any change press the MENU button.
Blackout mode
Press the MENU button up to when the is shown on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (On) or
(Off). Once select, press ENTER button to store or automatically return to the main functions
without any change after one minute. To go back to the previous functions without any change
press the MENU button.
Display
Press the MENU button up to when the is shown on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (Normal) or
(Off). Once select, press ENTER button to store or automatically return to the main
functions without any change after one minute. To go back to the previous functions without any
change press the MENU button.
White Balance
8B

Press the MENU button up to when the is showing on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (Red),
(Green) or (Blue) mode. Once the mode has been selected, press the DOWN and Up
button to select the value from 125 to 255, press the ENTER button to setup or automatically
return to the main functions without any change after one minute. To go back to the previous
functions without any change press the MENU button.
Manual Test
Press the MENU button up to when the is showing on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (Red),
(Green), or (Blue), (White), (Color), (Dimmer) or
(Strobe) mode. Once the mode has been selected, press the DOWN and Up button to
select the value from 0 to 255, press the ENTER button to setup or automatically return to the
main functions without any change after one minute. To go back to the previous functions without
any change press the MENU button.
Key Board Lock
Press the MENU button up to when the is showing on the display. Press ENTER button
and the display will blink. Use DOWN and UP button to select the (Key board lock On)
or (Key board lock Off). Once select, press the ENTER button to setup or automatically
return to the main functions without any change after one minute. Back to the previous functions
press MENU button.
Self-Test
Press the MENU button up to when the is blinking on the display. Press ENTER button
and the unit will run self-test by built-in program. To go back to the functions press the MENU
button again.
Temperature Test
Press the MENU button up to when the is blinking on the display. Press ENTER button
and the display will show the temperature of the unit. To go back to the functions press the MENU
button again.
9B

Fixture Hours
Press the MENU button up to when the is blinking on the display. Press ENTER button
and the display will show the number of working hours of the unit. To go back to the functions
press the MENU button.
Software version
Press the MENU button up to when the is blinking on the display. Press ENTER button
and the display will show the version of software of the unit. To go back to the functions press the
MENU button again.
4.How To Control The Unit
You can operate the unit in two ways：
1. By master/slave built-in preprogram function
2. By DMX controller
No need to turn the unit off when you change the DMX address, as new DMX address setting will
be affected at once. Every time you turn the unit on, it will show on the display and
move all the motors to their ‘home’ position. After that the unit will be ready to receive DMX
signal or run the built in programs.
4.1 Master/Slave Built In Preprogrammed Function
By linking the units in master/slave connection, the first unit will control the other units to give an
automatic, sound activated, synchronized light show. This function is good when you want an
instant show. You have to select (show 1) … (show4) show for the first unit.
Its DMX input jack will have nothing plugged into. The other units will be slave mode
automatically.
4.2 DMX Controller
Use universal DMX controller to control the units, you have to set DMX address from 1 to 512
channel so that the units can receive DMX signal.
Press the MENU button up to when the is showing on the display. Press the ENTER
button and the display will blink. Use the DOWN and UP button to change the DMX512 address.
10B

Once the address has been selected, press and keep the ENTER button pressed up to when the
display stops blinking or storing automatically 8 seconds later. To go back to the functions without
any change press the MENU button again.
Please refer to the following diagram to address your DMX512 channel for the first 4 units：
Channel
mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
4 Channels 1 5 9 13
5 Channels 1 6 11 16
7 channels 1 8 15 22
4.3 DMX 512 Configuration
4 Channels Mode:
Channel Value Function
1
0 - 255
RED
0% 100%
2
0 - 255
GREEN
0% 100%
3
0 - 255
BLUE
0% 100%
4
0 - 255
WHITE
0% 100%
5 Channels Mode:
Channel Value Function
1
0 - 255
RED
0% 100%
2
0 - 255
GREEN
0% 100%
3
0 - 255
BLUE
0% 100%
4
0 - 255
WHITE
0% 100%
5
0 - 255
DIMMER
0% 100%
11B

7 Channels Mode:
Channel Value Function
1
0 - 255
RED
0% 100%
2
0 - 255
GREEN
0% 100%
3
0 - 255
BLUE
0% 100%
4
0 - 255
WHITE
0% 100%
5
0 - 7
8 - 15
16 – 23
24 - 31
…
232 - 239
240 - 247
248 – 254
255
COLOR WHEEL
OFF
PRESET COLOR 1
PRESET COLOR 2
PRESET COLOR 3
…
PRESET COLOR 30
PRESET COLOR 31
PRESET COLOR 32
Off
6
0 - 7
8 - 15
16 - 131
132 - 139
140 - 181
182 - 189
190 - 231
232 - 239
240 - 247
248 - 255
STROBE
OFF
OPEN
SPEED FROM SLOW TO FAST
OPEN
FAST CLOSE SLOW OPEN
OPEN
FAST OPEN SLOW CLOSE
OPEN
RANDOM STROBE
OPEN
7
0 - 255
DIMMER
0% 100%
12B

4.4 DMX512 Connection
1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable.
2. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120 ohm 1/4W
resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the
DMX-output of the last unit.
3. Connect the unit together in a `daisy chain` by XLR plug from the output of the unit to the
input of the next unit. The cable can not branched or split to a `Y` cable. DMX 512 is a very
high-speed signal. Inadequate or damaged cables, soldered joints or corroded connectors can
easily distort the signal and shut down the system.
4. The DMX output and input connectors are pass-through to maintain the DMX circuit, when
one of the units’ power is disconnected.
5. Each lighting unit needs to have an address set to receive the data sent by the controller. The
address number is between 0-511 (usually 0 & 1 are equal to 1).
6. The end of the DMX 512 system should be terminated to reduce signal errors.
7. 3 pin XLR connectors are more popular than 5 pin XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin 4/Pin 5: Not used.
13B

5. Troubleshooting
Following are a few common problems that may occur during operation. Here are some
suggestions for easy troubleshooting:
A. The unit does not work, no light and the fan does not work
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly.
2. If the DMX LED is on and no response to the channel, check the address settings and DMX
polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the
unit or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or run alongside to high voltage cables that may cause
damage or interference to DMX interface circuit.
6. Fixture Cleaning
The cleaning of internal must be carried out periodically to optimize light output. Cleaning
frequency depends on the environment in which the fixture operates: damp, smoky or particularly
dirty surrounding can cause greater accumulation of dirt on the fixture’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days.
14B

Innovation, Quality, Performance
Declaration of Conformity
We declare that our products (lighting equipments) comply with the following
specification and bears CE mark in accordance with the provision of the
Electromagnetic Compatibility (EMC) Directive 89/336/EEC.
EN55103-1: 2009 ; EN55103-2: 2009; EN62471: 2008;
EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008.
&
Harmonized Standard
EN60598-2:2015; EN60598-1:2008+ A11: 2009
EN 62471:2008; EN 62493: 2010
Safety of household and similar electrical appliances
Part 1: General requirements
