ACME DP-01 User manual

Model: DP-01
www.acme.eu

3
GB 4 User’s manual 150 Warranty card
LT 16 Vartotojo gidas 151 Garantinis lapas
LV 28 Lietošanas instrukcija 152 Garantijas lapa
EE 41 Kasutusjuhend 153 Garantiileht
PL 53 Instrukcja obsługi 154 Karta gwarancyjna
DE 65 Bedienungsanleitung 155 Garantieblatt
FI 77 Kayttoohje 156 Takuulomake
SE 89 Bruksanvisning 157 Garantisedel
RO 101 Manual de utilizare 158 Fişa de garanţie
BG 113    159  
RU 125   160  
UA 138  161  

4
GB
TABLE OF CONTENTS
INTRODUCTION...................................................................... 5
Preface............................................................................................... 5
Packing List..................................................................................... 5
Cautions............................................................................................ 5
Usage Cautions................................................................. 5
Power ................................................................................... 5
Radio Interference........................................................... 5
Repair ................................................................................... 6
Others .................................................................................. 6
Production Introduction .......................................................... 6
Front Panel ......................................................................... 6
Back Panel........................................................................... 6
Connecting to a TV...................................................................... 7
TV Connect......................................................................... 7
Connecting a USB Device ............................................. 9
Connecting the Power Supply .................................... 9
Power on/o.................................................................................10
Power on.......................................................................................... 10
Power o...........................................................................10
Remote control............................................................................10
OPERATING THE HD MEDIA PLAYER....................11
Main Page......................................................................................11
Setup Page ....................................................................................11
Photo ..............................................................................................12
Music ..............................................................................................13
Playlist................................................................................ 13
Movie ..............................................................................................13
File ..............................................................................................14
Device..............................................................................................14
FIRMWARE UPGRADE ...................................................... 15
APPENDIXES............................................................................ 15
Product Specications.............................................................15
Copyrights and Trademarks..................................................15
ACME Digital Home Multimedia Center
User’s Manual

5
GB
Introduction
Preface
Dear Customer,
Thank you very much for purchasing the ACME digital home multimedia center. In the digital era, this product is a great home
entertainment partner. With the outstanding design, you can enjoy movies and music, view photos of precious moments.
This player has the following functionality:
Movie Playback - Supports AVI, MP4, MOV, M2TS, MKV, TS, TRP, MPG, VOB;
Music Playback - Supports MP3, WMA
Photo Playback - Supports digital camera JPEG and BMP JPEG/PNG les.
USB HOST - Supports USB 2.0 host ports.
HDMI - High-Denition Multimedia Interface transmits the highest quality digital video and audio via a
single cable, simplies cabling and provides high quality home theater experience.
Packing List
Part Quantity
Player 1
A/V cable 1
Y/Pb/Pr cable 0
USB cable 0
Remote Control 1
Remote Control Battery 2
AC/DC adaptor Power Cord 1
User Manual (printed) 1
Driver CD (with User Manual) 0
HDMI cable 0 (optional)
Note:
The actual contents in the package might be dierent from the packing list in this manual.
Cautions
This player’s design and manufacture has your safety in mind. In order to safely and eectively use this player, please read the
following before usage.
Usage Cautions
User should not modify this player. If commercial hard disk is being used, the environmental temperature should be
within +5o~ +35o.
Power
The player’s power voltage: DC 5V.
When using this player, please connect the supplied AC adapter or AC adapter cable to the player’s power jack. When placing
the adapter cable, make sure it can not get damaged or be subject to pressure. To reduce the risk of electric shock, unplug the
adapter rst before cleaning it. Never connect the adapter to the player in a humid or dusty area. Do not replace the adapter or
cable’s wire or connector.
Radio Interference
- If not properly shielded, almost all electronic devices will get radio interference. Under some conditions, your player might
get interference.
- The design of this player has followed the FCC/CE standard, and has followed the following rules:
(1) This player may not cause harmful interference;
(2) This player could accept some interference received including interference that may cause undesired operation.

6
GB
Repair
If the player has a problem, you should take it to an appointed repair center and let the specialists do the repair, never repair
the player yourself, you might damage the player or endanger yourself or your data.
Others
When using this player, please do not let the player come into contact with water or other liquid, if water is accidentally spilled
on the player, please use a dry cloth to absorb the spillage.
Electronic products are vulnerable, when using please avoid shaking or hitting the player, and do not press the buttons too
hard.
• Do not let the player come into contact with water or other liquid.
• Do not disassemble the player, repair the player or change the design of the player, any damage done will not be included
in the repair policy.
• Do not press the buttons of the player too hard.
• Avoid hitting the player with hard object, avoid shaking the player, and stay away from magnetic elds.
• During electrostatic discharge and the strong electromagnetic eld, the product will malfunction, then unplug the power
cable and the product will return to normal performance next time it is powered on.
Production Introduction
Front Panel
1. Power button
2. USB indicator
3. IR receiver
Back Panel
1. DC in jack
2. Y/Pb/Pr OUT jack
3.A/V OUT jack
4. HDMI jack
5. USB HOST port
6. S/PDIF OPTICAL jack

7
GB
Connecting to a TV
TV Connect
The below connection method can help you to enjoy the high quality movie, music and photo.
The standard connection uses the AV cable.
The best connection uses the HDMI cable.
Note: HDMI and Toslink (Optical) cables are sold separately.
A/V OUT (Standard Denition)
(1) Follow the picture and plug in the 3 color connector to the player’s A/V OUT jack;
(2) Follow the picture and plug in the 3 color connector to the TV’s A/V IN jack.
(3) Select the appropriate TV input source.
Y/Pb/Pr Component OUT
(1) Follow the picture and plug in the 3 color connector to the player’s Y/Pb/Pr jack;
(2) Follow the picture and plug in the 3 color connector to the TV’s Y/Pb/Pr jack.
Y/Pb/Pr cable connection only output video, you will need AV cable or S/PDIF (coaxial or optical) cable for audio output.

8
GB
Follow the Audio Connection method as below:
First method: Use the audio output from the A/V OUT jack;
Second method: Use the audio output from the S/PDIF Optical jack.
HDMI OUT (High Denition)
The HDMI connection can provide video quality resolution up to 1080p.
(1) Follow the picture and plug one connector on your HDMI cable to the player’s HDMI jack;
(2) Follow the picture and plug the other connector on your HDMI cable to the TV’s HDMI jack.
(3) Select the appropriate TV input source.
In this way, you can also enjoy videos, music
and photos in the player on TV.

9
GB
Connecting a USB Device
(1) Make sure the player is powered on;
(2) Plug in the USB stick or USB HDD etc. to the USB HOST port of this player.
Connecting the Power Supply
The Movie cube installation procedure is outlined below:
(1) Follow the picture and connect the AC adaptor to the player’s DC IN jack;
(2) Follow the picture and plug in the AC adaptor to the power outlet.
In this way, you can browse contents on the USB device.
In this way, you can browse contents on the memory card.

10
GB
Power on/o
Power on
After connecting the power supply cord and turning on the POWER switch, the player will soon enter the main page, and the
POWER indicator on the front panel will turn blue.
Power o
When the system is running, press the POWER button on the front panel or remote control, the player will be shut down.
Remote control
Picture No. Button Function
1 POWER Press to turn o the power
2 MUTE Press to mute audio output, and press again to
resume.
3 TV SYS Press to change aspect ratio
4 INFO Press to get the multimedia information
5 REPEAT Press to switch the play mode among - one, all
and Shue.
6 AUDIO Press to select an audio track.
7 ZOOM Press to zoom in/out the image.
8 THUMBNAIL Press to play the pictures with 8 thumbnail
9 VOL- Press to decrease the volume.
10 HOME Press to view the main page.
11 UP Press the arrow buttons to select menu options.
12 LEFT Press the arrow buttons to select menu options.
13 ENTER Press to select options in menus.
14 PREV Press to go to the previous le
15 DOWN Press the arrow buttons to select menu options.
16 DEVICE Press to view the device page.
17 PLAY/PAUSE Press to play/pause the playback of a title.
18 FR Press to fast rewind the current playback.
Press repeatedly to select speeds.
19 PAGE - UP Press to page up
20 PAGE - DOWN Press to page down
21 SETUP Press to view the setup page.
22 RED Special functions according to dierent app
23 GREEN Special functions according to dierent app
24 YELLOW Special functions according to dierent app
25 BLUE Special functions according to dierent app
26 FF Press to fast forward the current playback.
Press repeatedly to select speeds.
27 STOP Press to stop playback.
28 NEXT Press to go to the next le
29 RIGHT Press to move the highlight right while navigating
menus.
30 RETURN Press to return to previous page
31 VOL+ Press to increase the volume.
32 SLIDESHOW Press to auto play the pictures one by one
33 SUBTITLE Press to activate the subtitle list menu if available.
34 PLAYLIST Press to enter playlist app
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
34
33
32
31
30
29
28
27
26
25
24

11
GB
Operating the HD Media player
Main Page
There are six options, including MOVIE, MUSIC, PHOTO, FILE, SETUP
and DEVICE. Use the LEFT/RIGHT navigational buttons to select a
menu. Press ENTER to conrm. Press RETURN to cancel and display the
previous menu screen.
Use the LEFT/RIGHT navigational buttons to select an option, and then
press ENTER.
Setup Page
The Setup menu allows you to personalize and congure the preferences for your player.
Use the UP/DOWN navigaonal buons to select an opon, and LEFT/RIGHT to choose to change.
System Settings:
Use the UP/DOWN navigational buttons to select an option, and LEFT/RIGHT to switch options/changing relative functions.
OSD LANGUAGE English/Lithuanian/Latvian/Estonian/French/
Russian/Germanian/Dutch/Spanish/Italian/
Aspect Rate 16:9 Wide Screen/ 4:3Pan&Scan /4:3 FULL/
4:3 LetterBox/AUTO
TV Format PAL / NTSC
HDMI 480p/720p/1080i/1080p/
SPDIF HDMI Raw Data/SPDIF Raw Data/pcm/o
Preview On/o
rmware version Display software version
Movie Settings:
Use the UP/DOWN navigational buttons to select an option, and
LEFT/RIGHT to switch options/changing relative functions.
Subtitle Specic Normal /BIG/ Small
Subtitle BG Transparent / Gray /Yellow Green /White
Subtitle FontColor Red/Bule/Green
Start Resume On/o
Photo Settings:
Use the UP/DOWN navigational buttons to select an option, and LEFT/
RIGHT to switch options/changing relative functions.
Slideshow Time 2S/3S/5S/7S

12
GB
Only supported picture les can be showed on this page
Background Music:
Keys Functions
PLAYLIST
Press once to playback the background music,
and press again to stop it(only available when
there are les in the PLAYLIST)
SLIDESHOW Playback automatic the pictures one by one
according to the SLIDE TIME
THUMBNAIL Press to enter the 8 pictures page
TV SYS Switch signals’resolution among 480P/576P,
720P, 1080I and 1080P
Thumbnail Mode:
Keys Functions
ZOOM To ZOOM in/out the current playing pictures
at 2X,4X,8X,1X,1/8X,1/4X,1/2X,1X
PLAY/ENTER playback in 8 pictures preview page
Up/Down In current playing pictures, UP: 90, 180, 270,
360, DOWN, Reversal
PAGE UP / DOWN Do paging in 8 pictures preview page
RETURN
To stop the current playback le and
return to 8 pictures preview page; and in 8
pictures preview page, press it to return to
upper directory.
INFO Open/Close the le information of current
playback le.
PLAYLIST
Press once to playback the background
music, and press again to stop it(only
available when there are les in the
PLAYLIST)
PREVIOUS/NEXT In 8 pictures preview page, move to the
previous/next 8 pictures
Slide Show
This function can be fully settled in SETUP menu.
Keys Functions
REPEAT Press to set repeat option: One, All, Shue
and cancel repeat function.
PLAYLIST
Press once to initialize the background
music, and press again to stop it(only works
when there are les in the PLAYLIST)
INFO Open/Close le basic information during
full screen playback mode.
RETURN Return to File page
PREVIOUS/NEXT Playback the previous/next picture
ZOOM To ZOOM in/out the current playing
pictures at 2X,4X,8X,1X,1/8X,1/4X,1/2X,1X
Up/Down In current playing pictures, UP: 90, 180, 270,
360, DOWN: Reversal
Play/Pause Play/Pause
Stop Stop playback and return to File page

13
GB
Music
Only supported picture music le can be showed on this page
Keys Functions
RIGHT Mark the supported audio le to be added
in playlist
ENTER Playback the highlight le
REPEAT Press to set repeat mode: One, All, Shue
and cancel repeat function
RETURN Return to the upper directory, and the
playback le will not be stopped
Play/Pause Play/Pause
Stop Stop playback
FF/FR Fast forward/fast reward at
2X\4X\8X\16X\32X
PREVIOUS/NEXT Play PREVIOUS/NEXT
Playlist
Keys Functions
RIGHT Mark the media le in playlist to delete when
exit the playlist feature
REPEAT Press to set repeat mode: One, All, Shue
and cancel repeat function
RETURN
Return to the previous menu, and if any le
in the playlist is marked, a dialogue would be
pop-up to ask whether to delete it or not.
Red Select all/Inverse/Clear
Blue Select to go to the selected time point
Play/Pause Play/Pause
Stop Stop playback
FF/FR Fast forward/fast reward at 2X\4X\8X\16X\32X
PREVIOUS/NEXT PREVIOUS/NEXT
Movie
File playback in preview window
Keys Functions
Enter
Press once to play in preview window, twice to play
in full screen(if preview is settled to OFF in setup,
then press to full screen mode directly)
Play/
pause
Full screen playback/ pause
Green
Press once to mark the start point of the repeated
clip, press again to mark the end point of the
repeated clip.
Red Press to switch between preview playback and full
screen playback
Tv sys Switch the signal resolution among: 480P/576P,
720P, 1080I, 1080P, etc.
Blue Press to go to the pointed time point
Stop Stop
FF/FR Fast forward/fast reward at 2X\4X\8X\16X\32X
Now you can play the movie from the settled Start Point to End Point repeatly

14
GB
Full screen playback page:
Keys Functions
Subtitle
Press once to display the subtitle options,
twice to display subtitle individuation
selection bar, in which font(grounding,
boldface,etc), type size, location can be settled
INFO Press to display/ close video information, as
movie resolution, bit stream, etc
REPEAT
Press once to play in preview window, twice to
play in full screen(if preview is settled to OFF in
setup, then press to full screen mode directly)
Green
Press once to mark the start point of the
repeated clip, press again to mark the end
point of the repeated clip.
RETURN Stop playback and return to le page
Stop Stop
Red Press to switch between preview playback and
full screen playback
Zoom Press to ZOOM in/out 2X, 4X, 8X, 1/2X, 1X
PREVIOUS/NEXT PREVIOUS/NEXT
FF/FR Fast forward/fast reward at 2X\4X\8X\16X\32X
Blue Press to go to the pointed time point
Audio Changing the audio track
File
Keys Functions
Play/Pause Play/Pause playback
Stop Stop
Subtitle Press once to display the subtitle options, twice
to display subtitle individuation selection bar, in
which font(grounding,etc), type size, location can
be settled
Blue Press to go to the pointed time point
Device
You can decide which portable device be chosen as default device,
and the player also supports loading the content in one portable
multi-media storage simultaneously
You can quickly switch to this page by pressing the DEVICE button on
remote control
Keys Functions
up/down Move cursor in device list
enter Choose the device with cursor

15
GB
Firmware Upgrade
The rmware is the operation system (OS) installed on the device.
Firmware upgrade can bring new features, improvements and bug
xes.
To upgrade your rmware, please according to the follows:
• Prepare the USB Pen Drive directory of our USB Pen Drive.
• Connect the USB Pen Drive
• Plug the USB Pen Drive into one of the USB HOST ports of the
player.
• Select the rmware in FILE option, then press the ENTER button,
a blue upgrade page will appear on the TV screen.
Note: Do not turn o the power during upgrading. The USB Pen Drive is not allowed to be unplugged during upgrading.
Appendixes
Product Specications
I/O INTERFACES SUPORTED:
• USB 2.0 HOST port (compatible to USB 1.1)
• Composite (CVBS) A/V jack
• Component Y/Pb/Pr jack
• HDMI V1.2 interface
• S/PDIF optical jack
FILE SYSTEM SURPORTED:
• FAT32/NTFS
CONTENT FORMATS SUPPORTED:
• AVI/MKV/TS/MPG/MP4/MOV/VOB /DAT /M2TS/DIVX/TP/TRP, resolution up to 1080p
• MP3 /WMA
• HD JPEG/BMP/PNG, with unlimited resolution
VIDEO CODECS SURPORTED:
• H.264
• HD MPEG-1/2/4
• Divx
• Xvid
AUDIO CODECS SURPORTED:
• MP2/3, WMA
SUBTITLE FORMATS SURPORTED:
• SRT,SSA,SUB
Copyrights and Trademarks
Copyrights
All rights reserved. No part of this manual may be reproduced, or transmitted in any form or by any means, whether by
electronically or mechanically, without the express written permission from the copyright holder.
Copyrightedmaterials,suchassoftware,musicles,ormovies,areprotectedbylocallaw,andmaynotbeillegally
copied or used without permission from the copyright owner.
Trademarks
Microsoft and Windows are registered trademarks of Microsoft Corporation.
All other trademarks are property of their respective holders.

16
LT
TURINYS
ĮŽANGA.......................................................................................................................17
Įvadas .............................................................................................................................17
Pakuotės sudėtis ......................................................................................................17
Įspėjimai........................................................................................................................17
Atsargumo priemonės naudojant..........................................................17
Maitinimas.......................................................................................................17
Radijo trikdžiai ...............................................................................................17
Taisymas...........................................................................................................18
Kitos priemonės.............................................................................................18
Apie prietaisą..............................................................................................................18
Priekinis skydelis ...........................................................................................18
Užpakalinis skydelis .....................................................................................18
Prijungimas prie televizoriaus ...........................................................................19
Prijungimas prie televizoriaus..................................................................19
USB prietaiso prijungimas .........................................................................21
Maitinimo įjungimas....................................................................................21
Įjungimas ir išjungimas..........................................................................................22
Įjungimas .........................................................................................................22
Išjungimas .......................................................................................................22
Nuotolinio valdymo pultas ..................................................................................22
DIDELĖS GEBOS MEDIJOS LEISTUVO NAUDOJIMAS............23
Pagrindinis puslapis................................................................................................23
Sąrankos puslapis.....................................................................................................24
Nuotraukos ..................................................................................................................25
Muzika............................................................................................................................25
Grojaraštis........................................................................................................25
Filmai .............................................................................................................................25
FAILAI .............................................................................................................................26
PRIETAISAI....................................................................................................................26
MIKROPROGRAMOS PLĖTOJIMAS.......................................................27
Priedai ............................................................................................................................27
Gaminio specikacijos ...........................................................................................27
Autoriaus teisės ir prekių ženklai......................................................................27
ACME skaitmeninės namų kino teatro
sistemos naudojimo instrukcija

17
LT
Įžanga
Įvadas
Brangus vartotojau!
Dėkojame, kad įsigijote ACME skaitmeninę namų kino sistemą. Šiuo skaitmeniniu laikotarpiu šis gaminys yra puikus pagalbininkas
rengiant pramogas namuose. Naudodamiesi šiuo puikaus dizaino prietaisu galite žiūrėti lmus, klausytis muzikos ir žiūrėti
nuotraukas, kuriose užksuotos svarbios akimirkos.
Leistuvo funkcijos
Filmų peržiūra - Palaiko AVI, MP4, MOV, M2TS, MKV, TS, TRP, MPG, VOB formatus.
Muzikos
perklausa - Palaiko MP3, WMA formatus.
Nuotraukų
peržiūra - Palaiko skaitmeninių fotoaparatų JPEG, BMP, JPEG / PNG formato failus.
USB - Palaiko USB 2.0 prievadus.
HDMI - Didelės gebos multimedijos sąsaja aukščiausios kokybės vaizdas ir garsas perduodamas tik vienu
kabeliu, taip užtikrinama paprasta kabelių sistema ir aukštos kokybės namų kino teatro funkcija.
Pakuotės sudėtis
• ACMEdidelėsgebosleistuvasDP-01
• A/Vkabelis
• Nuotoliniovaldymopultas
• 2nuotoliniovaldymopultobaterijos
• AC/DCadapteris
• Maitinimolaidas
• Naudojimoinstrukcija(spausdinta)
Pastaba!
Pakuotės turinys gali skirtis nuo šioje instrukcijoje pateikiamo pakuotės turinio sąrašo.
Įspėjimai
Leistuvas suprojektuotas ir pagamintas atsižvelgiant į jūsų saugą. Kad naudotumėtės grotuvu saugiai ir efektyviai, prieš
naudodamiesi perskaitykite toliau pateikiamą instrukciją.
Atsargumo priemonės naudojant
Nemodikuokite leistuvo. Jei naudojamas komercinis standusis diskas, aplinkos temperatūra turi būti nuo + 5 °C iki + 35 °C.
Maitinimas
Leistuvo maitinimo įtampa – DC 5 V.
Naudodami šį leistuvą į leistuvo maitinimo lizdą įjunkite pridėtą AC adapterį arba AC adapterio kabelį. Jungdami adapterio
kabelį įsitikinkite, kad jis nebus pažeistas arba slegiamas. Norėdami sumažinti elektros šoko riziką, prieš valydami pirma
atjunkite adapterį. Niekada nejunkite adapterio prie leistuvo drėgnoje arba dulkėtoje vietoje. Nekeiskite adapterio kabelio
laido arba kištuko.
Radijo trikdžiai
- Netinkamai apsaugoti beveik visi elektroniniai prietaisai gauna radijo trikdžių. Tam tikromis sąlygomis jūsų leistuvas taip pat
gali gauti trikdžių.
- Šio leistuvo dizainas atitinka FRK / CE standartą ir šias taisykles:
(1) šis leistuvas negali kelti žalingų trikdžių;
(2) šis prietaisas gali priimti bet kokius gaunamus trikdžius, įskaitant trikdžius, galinčius sukelti nepageidaujamas operacijas.

18
LT
Taisymas
Jei grotuvas sugenda, reikia jį nugabenti į paskirtą remonto centrą ir pavesti taisymo darbus specialistams. Niekada netaisykite
leistuvo patys, nes galite pažeisti leistuvą ir rizikuoti savo sveikata bei prietaise esančia informacija.
Kitos priemonės
Saugokite leistuvą nuo kontakto su vandeniu ar kitokiu skysčiu. Jei ant leistuvo netyčia išpilama vandens, sugerkite vandenį
sausa šluoste.
Elektroniniai gaminiai yra pažeidžiami, todėl naudodami nekratykite ir netrankykite leistuvo ir per stipriai nespauskite
mygtukų.
• Neleiskite, kad ant grotuvo patektų vandens ar kito skysčio.
• Neardykite, netaisykite ir nekeiskite leistuvo dizaino, nes bet kokia tokių veiksmų metu žala nebus įtraukta į taisymo politiką.
• Nespauskite leistuvo mygtukų per stipriai.
• Netrankykite leistuvo sunkiais objektais, nekratykite jo ir nelaikykite arti magnetinių laukų.
• Elektrostatinės iškrovos ir stiprių elektromagnetinių laukų atveju gaminys blogai veiks. Tokiu atveju atjunkite maitinimo
kabelį, ir prietaisas kitą kartą įjungtas veiks normaliai.
Apie prietaisą
Priekinis skydelis
1. Maitinimo mygtukas
2. USB indikatorius
3. Infraraudonųjų spindulių imtuvas
1. DC lizdas
2. Y /Pb / Pr išvesties lizdas
3. A / V išvesties lizdas
4. HDMI lizdas
5. USB prievadas
6. S / PDIF optinis lizdas
Užpakalinis skydelis

19
LT
Prijungimas prie televizoriaus
Prijungimas prie televizoriaus
Prijungę toliau pateikiamais jungimo būdais galėsite mėgautis aukštos kokybės lmais, muzika ir nuotraukomis.
Standartinei jungčiai naudojamas AV kabelis.
Aukščiausios kokybės jungčiai naudojamas HDMI kabelis.
Pastaba! HDMI ir „Toslink“ (optinis) kabeliai parduodami atskirai.
A / V išvestis (standartinis ryškumas)
(1) Pagal paveikslą prijunkite 3 spalvų jungtį prie leistuvo A / V išvesties lizdo.
(2) Pagal paveikslą prijunkite 3 spalvų jungtį prie televizoriaus A / V įvesties lizdo.
(3) Pasirinkite tinkamą televizoriaus įvesties šaltinį.
Y / Pb / Pr komponento išvestis
(1) Pagal paveikslą prijunkite 3 spalvų jungtį prie leistuvo Y / Pb / Pr lizdo.
(2) Pagal paveikslą prijunkite 3 spalvų jungtį prie televizoriaus Y / Pb / Pr lizdo.
Y / Pb / Pr kabeliu jungiama tik vaizdo išvestis, garso išvesčiai reikia AV kabelio arba S / PDIF (bendraašio arba optinio) kabelio.

20
LT
Garso jungties metodas
Pirmas metodas: naudokite garso išvestį iš A / V išvesties lizdo.
Antras metodas: naudokite garso išvestį iš S / PDIF optinio lizdo.
HDMI išvestis (didelė geba)
HDMI jungtimi galima padidinti vaizdo kokybę iki 1080 p.
(1) Pagal paveikslą prijunkite vieną HDMI kabelio jungtį prie leistuvo HDMI lizdo.
(2) Pagal paveikslą prijunkite kitą HDMI kabelio jungtį prie televizoriaus HDMI lizdo.
(3) Pasirinkite tinkamą televizoriaus įvesties šaltinį.
Tokiu būdu taip pat galite mėgautis lmais, muzika ir
nuotraukomis, esančiais leistuve, per televizorių.
