ACME DP-02 User manual
Digital Home
Multimedia
Center
Model: DP-02
www.acme.eu
3
GB
GB 4 User’s manual 193 Warranty card
RU 64 Инструкцияпользователя 194 Гарантийныйталон
LT 114 Vartotojo gidas 195 Garantinis lapas
LV 127 Lietošanas instrukcija 196 Garantijas lapa
EE 140 Kasutusjuhend 197 Garantiileht
DE 153 Bedienungsanleitung 198 Garantieblatt
PL 166 Instrukcjaobsługi 199 Kartagwarancyjna
RO 180 Manualdeutilizare 200 Fişadegaranţie
4
GB
1 USER INFORMATION
Preface
Dear Customer,
Thank you very much for purchasing the ACME digital home multimedia center. In the
digital era, this product is a great home entertainment partner. With the outstanding
design,youcanenjoymoviesandmusic,viewphotosofpreciousmoments
Cautions
This player’s design and manufacture has your safety in mind. In order to safely and
effectivelyusethisplayer,pleasereadthefollowingbeforeusage.
Usage Cautions
User should not modify this player. If commercial hard disk is being used, the
environmentaltemperatureshouldbewithin+5°~+35°.
Power
Theplayer’spowervoltage:DC12V.
When using this player, please connect the supplied AC adapter or AC adapter cable
totheplayer’spowerjack.Whenplacingtheadaptercable,makesureitcannotget
damaged or be subject to pressure. To reduce the risk of electric shock, unplug the
adapter first before cleaning it. Never connect the adapter to the player in a humid or
dustyarea.Donotreplacetheadapterorcable’swireorconnector.
Radio Interference
-Ifnotproperlyshielded,almostallelectronicdeviceswillgetradiointerference.
Under some conditions, your player might get interference.
-ThedesignofthisplayerhasfollowedtheFCC/CEstandard,andhasfollowedthe
followingrules:
(1) This player may not cause harmful interference;
(2) This player could accept some interference received including interference that
may cause undesired operation.
5
GB
Repair
If the player has a problem, you should take it to an appointed repair center and let
the specialists do the repair, never repair the player yourself, you might damage the
player or endanger yourself or your data.
Others
Whenusingthisplayer,pleasedonotlettheplayercomeintocontactwithwateror
otherliquid,ifwaterisaccidentallyspilledontheplayer,pleaseuseadryclothto
absorb the spillage.
Electronicproductsarevulnerable,whenusingpleaseavoidshakingorhittingthe
player, and do not press the buttons too hard.
• Donotlettheplayercomeintocontactwithwaterorotherliquid.
• Do not disassemble the player, repair the player or change the design of the player,
anydamagedonewillnotbeincludedintherepairpolicy.
• Do not press the buttons of the player too hard.
• Avoidhittingtheplayerwithhardobject,avoidshakingtheplayer,andstayaway
frommagneticelds.
During electrostatic discharge and the strong electromagnetic field, the product
willmalfunction,thenunplugthepowercableandtheproductwillreturntonormal
performancenexttimeitispoweredon.
2 PRODUCT INTRODUCTION
2.1 Product Overview
Network Feature
• A/Vstreaming/transmissionviaEthernet(10M/100M) & WLAN(802.11b/g/n)
• A/VstreamingviaUPnPMediaServer
• FilesharingviaSambaserver
• FTPServer
• UPnPServer
• NFSClient
• InternetRadio(SHOUTcast)
• BTdownload
• Transmission
• Video podcast
• Webbrowser
• Remote management
6
GB
DVB-T TV
• supports Digital Video Broadcasting Terrestrial (DVB-T) TV reception
• supports Electronic Program Guide (EPG), Teletext and subtitle.
• supports loop out the DVB-T signal received from Aerial.
Video Recording
• supports one touch recording and scheduled recording, can easily record DVB-T
programs and save as MPEG-2/MPEG-4(.ts)format;
• supports time shifting function
Media Library
• Quick-Search,searchlesbykeywords.
• Apowerfulsearchengine,allowsyoutobrowsemultimedialesinmosteasyways
Movie Playback
• Fastforward/rewind
• Viewsubtitle
• Supportsmajoraudioformats(1080pHDvideodecoding)
• Subtitlecontrol:colour/offset/size
• Movie format: AVI/MKV/TS/TP/TRP/M2TS/MPG/MP4/M4V/MOV/VOB/ISO/IFO/
DAT/WMV/ASF/RM/RMVB/FLV
Music Playback
• Fastforward/rewind
• Shufe
• Repeat
• Musicformat:MP3/OGG/WMA/WAV/FLAC/APE
Photo Viewing
• Youcanviewphotosinslideshowmodewithbackgroundmusic.
• Zoomin/out,Rotate
• Photoformat:HDJPEG/BMP/GIF/TIF/PNG
USB 3.0 &2.0 Support
• USB3.0DEVICEport(forcomputerconnection,compatibletoUSB2.0)
• USB2.0HOSTport(forUSBstoragedevices)
Card Reader
• SD/MMC
7
GB
File Copy
• Supportscopying&movinglesbetweenUSBandHDD.
Note: All the information contained in this manual was correct at the time of
publication. However, as our engineers are always updating and improving the
product,yourdevice’ssoftwaremayhaveaslightlydifferentappearanceormodified
functionality than presented in this manual.
2.2 Package Contents
Part Quantity
Player 1
Remote Control 1
Remote Control Battery 2
AC/DCadaptor 1
Note: The actual contents in the package might be different from the contents list in
this manual.
2.3 Connection
2.3.1 Power Connection
(1) Refer to the picture and connect the AC adaptor to the player’s DC IN jack;
(2)RefertothepictureandplugintheACadaptortothepoweroutlet.
8
GB
2.3.2 Connect to Computer
(1)Makesuretheplayerispoweredon;
(2)PlugintheconnectoroftheUSB3.0cabletothisplayer’sUSBDEVICEport;
(3)PlugintherectangularconnectoroftheUSB3.0cabletocomputer.
2.3.3 USB Mass Storage Device (like USB stick, USB HDD etc.)
Connection
(1)Makesuretheplayerispoweredon;
(2)PlugintheUSBstickorUSBHDDetc.tooneoftheUSBhostportsofthisplayer.
2.3.4 Connecting a Memory Card
A memory card can be used by inserting it into the card slot
(1) Refer to the picture to insert the memory card to the card slot properly;
(2)Insertthecardbyreferringtothearrowpointerinthepicture.
9
GB
2.3.5 TV Connection
2.3.5.1 A/V OUT
(1) Refer to the picture and plug in the 3 colour connector to the player’s A/V OUT jack;
(2) Refer to the picture and plug in the 3 colour connector to the TV’s A/V IN jack.
In this way, you can enjoy the content in the player on TV or other display devices.
2.3.5.2 Y/Pb/Pr Component OUT
(1)RefertothepictureandplugintheconnectoroftheYUVcabletotheplayer’sY/
Pb/Prjack;
(2)Refertothepictureandpluginthe3colourconnectortotheTV’sY/Pb/Prjack.
AudioConnectionwhileusingY/Pb/PrVideoout:
First method: use the audio output from the A/V OUT jack;
Second method: use the audio output from the S/PDIF Coaxial or Optical jack.
Inthisway,youcanalsoenjoyvideos,music,andphotosintheplayeronTV.
10
GB
2.3.5.3 HDMI OUT
(1)RefertothepictureandplugoneconnectoronyourHDMIcabletotheplayer’s
HDMIjack;
(2)RefertothepictureandplugtheotherconnectoronyourHDMIcabletotheTV’s
HDMIjack.
Inthisway,youcanhavethehighestqualityvideoandaudioviaasinglecable.
2.3.6 Digital Audio Device Connection
(1) Refer to the picture and plug in the RCA connector on your coaxial cable to the
player’sS/PDIFCoaxialjack.Orifyouuseopticalfibre,pleaseplugintheToslink
connectoronyouropticalfibretotheplayer’sS/PDIFOpticaljack;(notsupplied)
(2) Refer to the picture and plug in the other connector on your coaxial cable or
optical fibre to the digital audio device. (not supplied)
11
GB
2.3.7 Connecting to a LAN
ToconnecttoaLAN(LocalAreaNetwork)yourequireacat5,cat5eorcat6network
cable (not supplied).
(1) Connectoneofthecrystalplugsonthecabletotheplayer’sRJ45LANsocket;
(2)ConnecttheothercrystalplugonthecabletoaRJ45LANportonyourrouter,
switch,orhubdevices.
12
GB
2.3.8 DVB-T Signal Input
Refer to the picture and plug a TV Aerial to the ANT. / RF IN socket;
2.3.9 DVB-T Signal Output
The player can loop out the DVB-T signal to other TV receiver device.
(1)Makesuretheplayerisconnectingtopowersupply;
(2)MakesureaTVAerialisconnectingtotheANT./RFINsocket;
(3)RefertothepictureandplugaTVcabletotheANT./RFOUTsocketthenplug
the cable to a TV or other TV receiver.
13
GB
2.4 Front Panel
1.Infraredreceiverwindow 2.Powerindicator
2.5 Side Panel
1. Memory Card slot
2.USB2.0HOSTport
3.USB3.0Deviceport
14
GB
2.6 Back Panel
1.Resetbutton 2.A/VOUTjack
3.Y/Pb/PrOUTjack 4.HDMIjack
5.RJ45LANsocket 6.S/PDIFCoaxialjack
7.S/PDIFOpticaljack 8.DC-IN
9.ANT./RFINsocket 10.ANT./RFOUTsocket
11.ANT./WIFIport
2.7 First Time Usage
2.7.1 Power On / Off
Power On
AfterconnectingtheDCINjackandpressthepowerbuttonontheremotecontrol,
theplayerwillsoonenterthehomescreen,andthepowerindicatorwillshowblue.
Power Off
Pressthepowerbuttonontheremotecontrol,theplayerwillsoonenterstandby
mode,andthepowerindicatorwillshowred.Thenunplugthepowercordtocutoff
thepowersupply.
15
GB
2.7.2 Menu Language
The system language of this player can be set to English or other languages. Change
thelanguage youwish inthe setup menu,theselected language willtakeeffect
immediately.
2.7.3 HDD Format
ForuserswhowishtoinstallanewSATAHDDintotheplayer,rstyouneedformat
theharddiscontheplayerbeforeusage.Otherwisemanyfunctionscan’tbeused,
suchas BTdownload,Transmission. Pleasereferto thefollowingprocedures to
format the hard disc.
Step1:SelectOKontheWarningpage,pressOKtoconrm.
Note: ThispagecanbealsoaccessedviaSetup->System->Formatmenu.
A passwordneededwhenyoutrytoformattheHDD,pleasereferto‘3.1.6MISC’for
moredetailsaboutthepassword.
Step2:Presstheup/downbuttontoadjustthecapacityoftimeshiftbuffer.
Presstheleft/rightbuttontoselectNext,andtheOKbuttontoconrm.
16
GB
- Step3:SelectFormat,pressOK,andthenharddiscformatwillstart.
Theformattingprocedurewillbefinishedwithinafewminutes.Andthenyoucanuse
the hard disc properly on the player.
Note:HDDformatwillremovealldatastoredontheharddiscdrive.Pleasetake
care and backup your data in advance!
17
GB
2.8 Remote Control
1.Power 2. Numeric buttons
3.Shufe. 4.VOL-
5. Mute 6. Menu
7.Home 8. Navigational buttons
9.Stop 10.Play/Pause
11. FR 12. FF
13. Red 14. Green(EPG)
15.Setup 16.TVSYSSlow
17. Goto 18.Slow
19. REC 20. Edit
21.Copy 22. Timeshift
23. Angle 24. Zoom
25. Audio 26.Subtitle
27.Yellow(TTX) 28. Blue
29. Prev 30. Next
31. Info 32.OK
33.Back 34.VOL+
35. Repeat 36.Eject
18
GB
No. Button Function
1Power Presstoenterstandbymodeorwakeup.
2Numeric
buttons Press to enter channel numbers or numeric input when changing
settings.
3SHUFFLE Presstoshufethemusic.
4VOL- Press to decrease the volume.
5 Mute Press to mute audio output, and press again to resume.
6 Menu Presstoenabletheoptionmenu,whereyoucanchangethereview
modeoflemanagerandmedialibrary;
Press to display or hide the option menu during playback.
7Home Press to enter the home screen.
8Navigational
buttons Pressthearrowbuttonstoselectmenuoptions,andtheOKbuttonto
conrm.
9Stop Press to stop playback.
10 Play/Pause Presstobegin/pauseplayback.
11 FR Presstofastrewindthecurrentplayback.Pressrepeatedlytoselect
speeds
12 FF Presstofastforwardthecurrentplayback.Pressrepeatedlytoselect
speeds.
13 RED Function is available in virtual keyboard.
14 Green(EPG) Press to enter the Electronic Program Guide which displays an on-
screen list of programs for the whole day when watching Digital
Terrestrial TV.
15 Setup Press to enter the setup menu.
16 TVSYS. PresstoswitchbetweenNTSC,PAL,480P,576P,720P,1080I,and
1080P.
17 Goto Presstojumptoaspecicpointonatitle.SpecifythepointusingTitle,
Chapter and Time.
18 Slow Presstoplaybackinslowmotion.PressthePLAYbuttontoresume
regular playback.
19 REC Press to begin recording.
Pressrepeatedlytosetonetouchrecording(OTR)length(30MIN./60
MIN./90MIN./120MIN./180MIN./240MIN./Off)
20 EDIT Presstoenterleeditingmenuinlemanager.
Presstoenterleselectingmenuinmedialibrary.
21 Copy Presstoenterleselectingmenu.
22 Timeshift
Presstoactivatethetimeshiftfunction.Timeshiftfunctionallowsyouto
pause live TV and resume the program from the point you left it. While
paused,theprogramisrecordedtotheinternalHDDaslongasthere
issufcientmemory.
Press Play button to start to playback the paused live TV program..
Time shift mode remains active until you press the stop button.
23 Angle PresstochangetheviewangleduringDVD(withmulti-angle)playback.
24 Zoom Press to zoom the image (photo or video).
25 Audio Press to select an audio track.
26 Subtitle Presstosetsubtitleoptions.Youcanchangethecolour/size/offset/text
encoding of subtitle.
19
GB
27 Yellow(TTX) PresstoopenTeletextOSDifitisavailableinthebroadcastedstream
of Digital Terrestrial TV.
28 Blue Presstoopen/closeUSBDVD-rom.
29 Prev Presstoviewthepreviousle/pageup.
30 Next Presstoviewthenextle/pagedown.
31 Info Press to display current status.
Press during playback, an onscreen display appears showing track
numberandtimeelapsed/remaining.
32 OK Functionisavailableinvirtualkeyboard.PressOKbuttontoconrm.
33 BACK Presstoreturntothepreviousscreenwhilenavigatingmenus.
34 Vol+ Press to increase the volume.
35 Repeat Press to set repeat option.
36 Eject PresstosafelyremovetheUSBdevice.
3 MAIN FUNCTIONS
3.1 Setup Menu
TheSetupmenuallowsyoutopersonalizeandconfigurethepreferencesforyour
player.
To select a Setup option:
Select the Setup icon on the home screen, or press Setup button on the remote control.
Use the Left/Right navigational buttons to select an option, and then press OK.
There are six setup options, including System,Audio, Video, TV&REC, Network
andMISC.UsetheLeft/Rightnavigationalbuttonstoselectamenu.PressOKto
confirm. Press Return to cancel and display the previous menu screen.
20
GB
3.1.1 Changing System Settings
Use this menu to configure system settings.
Menu Language
- SelecttochoosetheOSD(On-ScreenDisplay)language.
Text Encoding
- Selecttosetthetextencodingoption(subtitledisplay)
Change System Font
- Selecttochangesystemfont.
Createafoldernamed“Resource”intherootdirectoryofyourUSBorHDD,
renameyourfontas‘font.ttf’andthencopyittothefolder.
Change Desktop
- Selecttochangethedesktop.
Createafoldernamed“Resource”intherootdirectoryofyourUSBorHDD,
renameyourphotoas‘desktop.png’andthencopyittothefolder.
Time
- Selecttosetthetime,andselecttherighttimezonetoscheduleRECcorrectly
DVD Auto-Play
- Selecttoturnon/offDVDauto-play.
Screen Saver
- Timing
Selecttochangetimingofscreensaver.
- Options
Selecttochangescreensaver.
Table of contents
Other ACME Media Player manuals
