ACT 612 User manual

Advanced Charger Technology, Inc.
5500 Oakbrook Parkway
Suite 1330
Norcross, GA 30093
USA
770-263-6337 Phone
770-263-9155 Fax
www.actcharge.com
iCHARGE Model 612
Congratulations on your purchase of the ACT Model i612
conditioning charger, the most advanced LiIon charger
available.
Warning: This unit is designed for use with LiIon
batteries only. The use of this unit with any other battery
chemistry may result in damage or fire.
Model i612

Instructions / Set Up
1. Remove i612 and power cord from shipping carton. Retain
shipping carton for further use should you need to ship the
charger to another location, or for service.
2. Most iCharge products are sold with the battery adapters
installed. However, if you need to install or replace the
adapters simply place the adapter on the charger taking
care to align the connector on the adapter to the connector
on the charger and install the two securing screws.
3. Confirm that the power switch on the side of the charger is
set to the correct voltage (110v USA) and plug the power
cord into the charger, and into a wall outlet.
4. With power going to the charger the LED’s will flash Red
indicating that the charger is on and waiting for a battery to
be installed.
5. Place batteries on the adapters. The LED’s will change to
Green (solid while the battery is charging- flashing when
the charge is complete and the battery is ready).
Warnings
1. Do not short circuit the contact on the charger adapters
2. Do not charge batteries other than the batteries for which
the adapter has been designed.
3. The unit is a microprocessor controlled electronic device,
which may be damaged if dropped or handled roughly.
Specifications
•Input: 120/240V AC 50/60 HZ
•Temperature 0C to 40C
•Humidity 90% non-condensing
•Weight 15lbs
Model i612 LED’s Summary
Red Flashing = Ready to Charge
Green Solid = Charging
Green Flashing = Battery Ready (fully charged)
Warranty
Your iCHARGE product has a one-year limited warranty from date of
purchase against defects in material and workmanship. Under this
warranty, you may return a faulty product to ACT and ACT will either
repair or replace the faulty product free of charge. To return a faulty
product for repair or replacement, please call ACT at 1-800-606-6452 to
obtain a Return Material Authorization number. This warranty covers
only defects in material or workmanship in normal use and not damage
from negligent handling, misuse, charging of batteries other than those
the iCHARGE was specified and designed to charge, or lack of proper
care. Important: Opening of the charger will void
this warranty. This warranty gives you specific legal rights. You
may also have other rights, which vary from state to state.
OTHER THAN AS EXPRESSLY SET FORTH
ABOVE, ACT DOES NOT MAKE ANY EXPRESS
OR IMPLIED WARRANTIES OR
REPRESENTATIONS REGARDING THEIR
PRODUCTS. ANY IMPLIED WARRANTIES OF
MERCHANTABILITY, NONINFRINGEMENT, AND
FITNESS FOR A PARTICULAR PURPOSE ARE
EXPRESSLY EXCLUDED AND DISCLAIMED.
ACT shall not be liable or responsible for any loss, damage, or injury
caused by any failure of it’s products to operate properly or promptly.
7/27/04
