ACTi ACM-4200 series User manual

Megapixel IP Cube Camera
ACM-4200 series
Ver. 071218
Quick Installation Guide

0-1
0Getting Started
1.1 PACKAGE CONTENTS
ACM-4200 series Power Adaptor (Option)
Product CD Camera Stand
Warranty Card
1

0-2
1.2 PHYSICAL DESCRIPTION
1. Action LED Indicator
The LED will light up after IP camera has successfully completed
the boot process
2. Built-in Microphone
Sensitivity: -42dB ±3dB(0dB=1V/Pa at 1KHz)
S/N Ratio: More than 58dB
Directivity: Omni-directional

0-3
3. Power Input
Please use power supply of input DC 3.3V only.
4. Reset Button
Step 1: Switch off Megapixel IP Cube Camera by disconnecting
the power cable
Step 2: Press and continue to hold the Reset Button. Reconnect
the power cable while continuing to hold the reset button.
Step 3: Keep holding the reset button depressed around 6 seconds,
then release the reset button. The unit will start up with factory
default settings.
5. Audio Output
The Megapixel IP Cube Camera supports audio output with
earphone jack
6. Ethernet Port
The Megapixel IP Cube Camera connects to the Ethernet via a
standard RJ45 connector. Supporting NWAY, this Megapixel IP
Cube Camera can auto detect the speed of local network segment
(10Base-T/100Base-TX Ethernet).

0-4
1.3 BASIC CONNECTIONS
Follow the procedures below to connect the Megapixel IP Cube Camera to
the respective apparatuses.
1. Connect the power adaptor to Megapixel IP Cube Camera
2. Connect Megapixel IP Cube Camera’s ethernet port to an Ethernet (RJ45
connectors). If your Megapixel IP Cube Camera has PoE built-in, you can
regard it as a PD and connect it directly to a PSE device like PoE switch.
3. Connect a PC to the Ethernet hub (RJ45 connectors)
1
NOTE: You may find a support package for help you getting familiar
with PoE. Please visit our web site, and get the support document
TS-00040.

1-5
1Quick Tour
This section guides you with a quick tour on this Megapixel IP Cube Camera.
2.1 Configure this Megapixel IP Cube Camera
2.1.1 Make sure network environment
Default IP of this Megapixel IP Cube Camera is 192.168.0.100. Please make sure this
Megapixel IP Cube Camera and your PC are on the same network segment before
running the installation.
2
Please set the settings as below.
IP address: 192.168. 0.xxx
Subnet mask: 255.255.255. 0
(NOTE: xxx should be a number
from 1 to 254, but 100 is
excepted.)

1-6
2.1.2 Open Internal Explorer with IP address
NOTE: If your web browser is earlier than IE6, then download IE6 is
recommended.
NOTE: This Megapixel IP Cube Camera default IP address is set to
192.168.0.100
2.1.3 Login with default administrator’s account & password
NOTE: Default administrator account is set to Admin, password is set to
123456, and click button.

1-7
2.1.4 Preview the video

1-8
2.1.5 Set the new IP address
*IP Address : The default IP address is 192.168.0.100.
*Subnet Mask : The default subnet mask is 255.255.255.0
*Click button
NOTE: In your Client PC, please make sure the setting of Network
Connections Type is set to Auto Negotation, since this Megapixel IP Cube
Camera follows MII standard. Otherwise, you might not see the live
image.
IMPORTANT: After the IP address is changed, please record this IP
address. There’s no way to connect to the Megapixel IP Cube Camera if
user forgets the new IP address.
2.1.6 Check Default Video Setting

1-9
NOTE: Please make sure the TV Input (NTSC / PAL) is meet your
requirement, and click button.
2.1.7 Click Save Reboot to restore all settings and please wait about 30 seconds
for system reboot.
