ADAPT SOLUTIONS XL-SEAT User manual

XL-SEAT
INSTALLATION MANUAL
XLS-F150S09L
FORD F150 SUPER CAB 2009-2014
DRIVER

10
15
7
9
1
16 11
19
17
1 of 7
SCALE 1:6
SCALE 1:6
18
ITEM PART NUMBER QTY DESCRIPTION
1 XLS100-03L 1 XL-SEAT Slider 3 -Left-
2 XLS122-02 1 Fixture Spring Assembly
3 PRD 149-132 1 Socket set screws cup point 1/4-20 x 1/4
4 XLS200-01 1 Actuator Fixing
5 PRD 332-159P 4 Socket Head Cap Screw Zinc Plated 3/8-16 x 1/2
6 XLS211-01 1 XL-SEAT Fixation plaque
7 XLS300-03 1 XL-SEAT Safety Right Arm
8 XLS400-01L 1 XL-SEAT Transfert Board -Left-
9 XLS430B-01L 1 Transfer Plate Cushion -Left- Black
10 XLS500-07L 1 07 Pillar XL-SEAT
11 XLS800-133 1
Electrical Actuator 12 Volts -11.000'' Stroke - Type "C" Kob with Ø3/8'' Hole -
Left Handed
12 PRD 149-151 1 Socket set screws cup point 5/16-18 x 3/4
13 XLS811-01 1 Shock Ring
14 PRD 192-622 1 Spring Pin Ø1/4'' x 1-3/8'' Lg.
15 XLS600B-05L 1 Endless Screw Cover -Left- Black
16 COVB-01 1 Motor cover
17 XLS700-AL 1 Electrical Kit
18 XLS-F150S09LB-05 1 Replacement Molding -Left- Black
19 XLS-F150S09L-00 1 Installation Kit -Left-
XLS-F150S09L
ADAPT SOLUTIONS
|[email protected]|866.641.0419|418.889.9838 fax
PART NUMBER
Kit XL-Seat Ford F-150 Super Cab 2009 - 2014 -Left-
DESCRIPTION
KIT XL-SEAT FORD F-150 SUPER CAB 2009 - 2014

15
10
7
9
1
20 19
16 11
24
23
17
SCALE 1:6
18
22
2 of 7
ITEM PART NUMBER
QTY
DESCRIPTION
1 XLS100-03L 1 XL-SEAT Slider 3 -Left-
2 XLS122-02 1 Fixture Spring Assembly
3 PRD 149-132 1 Socket set screws cup point 1/4-20 x 1/4
4 XLS200-01 1 Actuator Fixing
5 PRD 332-159P 4 Socket Head Cap Screw Zinc Plated 3/8-16 x 1/2
6 XLS211-01 1 XL-SEAT Fixation plaque
7 XLS300-03 1 XL-SEAT Safety Right Arm
8 XLS400-01L 1 XL-SEAT Transfert Board -Left-
9 XLS430B-01L 1 Transfer Plate Cushion -Left- Black
10 XLS500-07L 1 07 Pillar XL-SEAT
11 XLS800-133 1
Electrical Actuator 12 Volts -11.000'' Stroke - Type "C" Kob
with Ø3/8'' Hole - Left Handed
12 PRD 149-151 1 Socket set screws cup point 5/16-18 x 3/4
13 XLS811-01 1 Shock Ring
14 PRD 192-622 1 Spring Pin Ø1/4'' x 1-3/8'' Lg.
15 XLS600B-05L 1 Endless Screw Cover -Left- Black
16 COVB-01 1 Motor cover
17 XLS700-AL 1 Electrical Kit
18 XLS-F150S09LB-05 1 Replacement Molding -Left- Black
19 XLS-F150S09L-01 1 Floor Adapter -Left-
20 XLS-F150S09L-02 1 Fixture Arm -Left-
21 XLS-F150S09-02D 2 Cylindrical Support
22 XLS-F150C09L-07 1 Seat Switch Adapter -Left-
23 HANDLE-04 1 Handle-04
24 PRD 125-110 5 Hex self-tapping screw #8 x 1/2
25 PRD 125-117 1 Hex self-tapping screw #10 x 3/4'' Lg.
26 PRD 304-243P 2 Hex Cap Bolt Zinc Plated 1/2-13 x 1 1/2 G8
27 PRD 338-230P 3 Flat Socket Cap Screw Zinc Plated 7/16-14 x 3/4
28 PRD 339-139P 1 Socket Shoulder Screw Zinc 3/8 x 3/4 x 5/16-18 THD
29 PRD 339-168P 1 Socket Shoulder Screw Zinc 1/2 x 1 1/4 x 3/8-16 THD
30 PRD 341-109P 3 Flat Washer Zinc Plated I.D. 7/16 USS
31 PRD 342-121P 2 Spring Lockwasher Zinc Plated 1/2
32 PRD 20275P 1 Hex Cap Bolt Zinc Plated M12-1.75 x 50mm G8.8
33 CP RC-1015-1 1
Black Ribbed Insert Cap for Rect. Tubing 1" × 1-1/2" 14-20
ga
34 XLS810-01 1 Ring Shock Motor
XLS-F150S09L
ADAPT SOLUTIONS
|[email protected]|866.641.0419|418.889.9838 fax
PART NUMBER
Kit XL-Seat Ford F-150 Super Cab 2009 - 2014 -Left-
DESCRIPTION
KIT XL-SEAT FORD F-150 SUPER CAB 2009 - 2014

1
3
911 6
5
7
4
10
3 of 7
SCALE 1:4
SCALE 1:5
2
8
ITEM PART NUMBER
QTY
DESCRIPTION
1 XLS100-03L 1 XL-SEAT Slider 3 -Left-
2 XLS122-02 1 Fixture Spring Assembly
3 XLS200-01 1 Actuator Fixing
4 XLS211-01 1 XL-SEAT Fixation plaque
5 XLS800-133 1
Electrical Actuator 12 Volts -11.000'' Stroke - Type "C" Kob with Ø3/8'' Hole -
Left Handed
6 XLS811-01 1 Shock Ring
7 COVB-01 1 Motor cover
8 PRD 149-132 1 Socket set screws cup point 1/4-20 x 1/4
9 PRD 149-151 1 Socket set screws cup point 5/16-18 x 3/4
10 PRD 192-622 1 Spring Pin Ø1/4'' x 1-3/8'' Lg.
11 PRD 332-159P 4 Socket Head Cap Screw Zinc Plated 3/8-16 x 1/2
XLS-F150S09L
ADAPT SOLUTIONS
|[email protected]|866.641.0419|418.889.9838 fax
PART NUMBER
Kit XL-Seat Ford F-150 Super Cab 2009 - 2014 -Left-
DESCRIPTION
KIT XL-SEAT FORD F-150 SUPER CAB 2009 - 2014

2
3
1
SCALE 1:3
SCALE 1:4
4 of 7
ITEM PART NUMBER QTY DESCRIPTION
1 XLS-F150S09L-01 1 Floor Adapter -Left-
2 XLS500-07L 1 07 Pillar XL-SEAT
3 PRD 338-230P 3 Flat Socket Cap Screw Zinc Plated 7/16-14 x 3/4
XLS-F150S09L
ADAPT SOLUTIONS
|[email protected]|866.641.0419|418.889.9838 fax
PART NUMBER
Kit XL-Seat Ford F-150 Super Cab 2009 - 2014 -Left-
DESCRIPTION
KIT XL-SEAT FORD F-150 SUPER CAB 2009 - 2014

5
4
3
7 2
1
6
4
5 of 7
SCALE 1:4
ITEM PART NUMBER
QTY
DESCRIPTION
1 XLS-F150S09L-02 1 Fixture Arm -Left-
2 XLS-F150S09-02D 2 Cylindrical Support
3 PRD 304-243P 2 Hex Cap Bolt Zinc Plated 1/2-13 x 1 1/2 G8
4 PRD 341-109P 3 Flat Washer Zinc Plated I.D. 7/16 USS
5 PRD 342-121P 2 Spring Lockwasher Zinc Plated 1/2
6 PRD 20275P 1 Hex Cap Bolt Zinc Plated M12-1.75 x 50mm G8.8
7 CP RC-1015-1 1 Black Ribbed Insert Cap for Rect. Tubing 1" × 1-1/2" 14-20 ga
XLS-F150S09L
ADAPT SOLUTIONS
|[email protected]|866.641.0419|418.889.9838 fax
PART NUMBER
Kit XL-Seat Ford F-150 Super Cab 2009 - 2014 -Left-
DESCRIPTION
KIT XL-SEAT FORD F-150 SUPER CAB 2009 - 2014

2
1
6 of 7
SCALE 1:3
SCALE 1:4
ITEM PART NUMBER QTY DESCRIPTION
1 XLS810-01 1 Ring Shock Motor
2 PRD 339-168P 1 Socket Shoulder Screw Zinc 1/2 x 1 1/4 x 3/8-16 THD
XLS-F150S09L
ADAPT SOLUTIONS
|[email protected]|866.641.0419|418.889.9838 fax
PART NUMBER
Kit XL-Seat Ford F-150 Super Cab 2009 - 2014 -Left-
DESCRIPTION
KIT XL-SEAT FORD F-150 SUPER CAB 2009 - 2014

54
1
6 3
2
7 of 7
SCALE 1:6
ITEM PART NUMBER
QTY
DESCRIPTION
1 XLS300-03 1 XL-SEAT Safety Right Arm
2 XLS400-01L 1 XL-SEAT Transfert Board -Left-
3 XLS430B-01L 1 Transfer Plate Cushion -Left- Black
4 XLS600B-05L 1 Endless Screw Cover -Left- Black
5 PRD 125-117 1 Hex self-tapping screw #10 x 3/4'' Lg.
6 PRD 339-139P 1 Socket Shoulder Screw Zinc 3/8 x 3/4 x 5/16-18 THD
XLS-F150S09L
ADAPT SOLUTIONS
|[email protected]|866.641.0419|418.889.9838 fax
PART NUMBER
Kit XL-Seat Ford F-150 Super Cab 2009 - 2014 -Left-
DESCRIPTION
KIT XL-SEAT FORD F-150 SUPER CAB 2009 - 2014

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 2
1- Unbolt the seat from the floor. Remove the door trim panel.
2- Remove the OEM seat shroud, lumbar crank handle and the recline handle. Replace
the shroud with the one provided in the installation kit. Re-install the OEM lumbar
crank handle. Install the replacement recline handle. NOTE: You will need to bend
down the seat materiel bracket as shown in the pictures.

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 3
3- Slide the floor adaptor XLS-F150S09L-01 under the front and rear of the seat base.
4- Use the OEM floor bolts to position the floor adaptor in place.
NOTE: Do not fully tighten the floor bolts.
5- Attach the adaptor XLS-F150S09L-02 to the floor adaptor using two (2) 1/2-13 UNC ×
1 1/2”Lg bolts.
NOTE: Do not forget to insert the adaptor XLS-F150S09L-02Din the end of the tubing. This
will prevent the tubing from crushing when you tighten the bolts.

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 4
6- Secure the other end over the inside seat leg using the M12-1.75X60mm seat bolt
provided.
7- Tighten all the bolts.
8- Place the XL-SEAT pillar onto the floor adaptor. Secure the XL-SEAT pillar in place
using three (3) 7/16-14 UNC × 3/4”Lg flat head bolts.
9- Slide the XL-SEAT onto the pillar and secure the motor to the pillar base using a 1/2”×
2 3/4”Lg shoulder bolt.
NOTE: Insert shim U-XLSP-F150S09L-03 between the motor and the mounting bracket.

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 5
10-Install the electrical wiring for the XL-SEAT. Follow the instructions found in the
attached document entitled: ELECTRICAL INSTALLATION FOR XL-SEAT
11-Attach the security arm to the XL-SEAT using a 3/8”× 3/4”Lg shoulder bolt. Slide the
transfer board in place. Install the carpet covered safety covers. Use a self-tapping
screw #10 × 1/2”Lg to hold the cover in place.
NOTE: The XL-SEAT transfer board has adjustment if needed. Lift off the cushion. Unbolt
the four (4) flat head bolts, relocate the board to the desired position, and secure it in
place using the four (4) flat head bolts. Once you have completed, reinstall the cushion.

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 6
12-Final inspection:
Make sure all bolts are all properly fastened.
Make sure that XL-SEAT works well with and without a passenger.
Make sure the door closes properly.
(Note: It is normal for the XL-SEAT to touch the door panel trim.)
Make sure the safety guards are fastened in place.
For technical support call 866.641.0419 or email [e-mail]
Please have the serial number of the unit on hand before placing your call.

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 7
ELECTRICAL INSTALLATION
XL-SEAT
1. Thread the lead power cable (red +) under the doorstep moulding and through the
firewall. WARNING: Pass through a grommet in the firewall to prevent the cable from
chaffing.
2. Install the circuit breaker near the battery and then
connect the battery to the circuit breaker.
3. Attach the ground wire (black -) to the vehicle’s frame,
under the doorstep molding using a self-tapping screw.
(NOTE: It is preferable to locate it in a spot where the sheet
metal is doubled-up to insure a better ground.)
4. Connect the power cable (red+) and the ground cable
(black -) to the electronic module (black box). Place the
electronic module under the seat and secure it in place
using “Velcro”. Secure all the wires in a loom. Reconnect
the battery.
5. Thread the flat hand held control wire (black telephone wire) under
the doorstep molding and up under the dash. Secure the wire in place
under the dash with a tie wrap and secure the hand held control on
the dash using “Velcro”.
WARNING: Place the hand held control in a safe place so that the door
does not risk cutting off the wire.

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 8
RED = 12V POWER SUPPLY
BLACK = GROUNDED TO THE
CHASSIS
ELECTRICAL BOX CONNECTIONS
XL-SEAT
ALONE
TWO YELLOW WIRES
TO THE XL-SEAT
ACTUATOR
GREY WIRE TO THE PENDANT
CTRL BOX: XLS710-01
PENDANT: XLS760-01
RED = 12V POWER SUPPLY
BLACK = GROUNDED TO THE
CHASSIS

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 9
WARNING DECALS
After completing the installation of the XL-SEAT, please take time to install the warning
decals. NOTE: The surface must be clean, dry and at ambient temperature for the sticker
to stick to the surface.
Start by locating a position to install the decals.
Clean the surface with the provided alcohol swab.
Peel off the backing of the sticker and then stick it to the cleaned surface.

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 10
TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSES
XL-SEAT
will not run
Bad electrical connections. Check and clean corrosion from all
connections including the car’s battery cable connections.
Hand pendant wire problem. Check hand pendant wire to
make sure it is plugged in properly. Check the wire for any
cuts. If any, replace the wire.
Burnt out switch. Replace pendant.
Bad connection. Check the electronic module under the seat.
Make sure that all the wires are properly connected.
Burnt out electronic module. Contact Adapt Solutions for
replacement module.
Burnt out actuator. Replace actuator.
Power Loss. The XL-SEAT motor is not getting adequate
electrical power because of a loose connection. Check the
XL-SEAT connections for tightness and corrosion
(especially the ground connection).
A partially discharged battery in the vehicle. Check the car’s
battery by trying the car lights or checking the voltage with a
voltmeter (should read 13.2 volts). Clean the car battery posts
and cable clamps thoroughly (remove the battery clamps off
the battery posts and clean them with a wire brush designed
for that purpose). Coat the connection with anticorrosion
spray once reassembled. An automotive battery may be weak,
having enough power to start the car but not enough power
for continuous use.

XL-SEAT 2009-2014 FORD F150 SUPER CAB DRIVER p. 11
ADAPT-SOLUTIONS #1 LTD.
3 YEAR LIMITED WARRANTY
Adapt-Solutions # 1 Ltd. (Adapt Solutions), warrants to the original purchaser of an XL-SEAT that the
equipment is free from defects in material and workmanship for a period of three years from date of
purchase.
During the first year of the warranty, Adapt Solutions will supply the replacement parts as well as a pre-set
monetary amount (determined by Adapt Solutions) for the repair if a defect in materiel or workmanship is
discovered. Labor claims must be approved by Adapt Solutions and an authorisation number (RMA) will
be given. Labor claims must be submitted within six (6) weeks of receiving the RMA to be processed. After
the initial year of this warranty, only parts and components are covered. This warranty does not cover
labor and other services after the initial year. Freight and other related repair charges will be the
responsibility of the original purchaser.
The only remedy for a defect in one of Adapt Solutions products shall be the repair or the replacement, at
the discretion of Adapt Solutions, of the defective part or component. If repair or replacement is not
commercially practical or cannot be timely made, Adapt Solutions may decide to refund the purchase
price of the equipment (XL-SEAT) instead of repairing or replacing the original equipment.
In no event shall Adapt Solutions be responsible for indirect, incidental or consequential damages,
whether such damages arise from claims based on contract, warranty, tort (including negligence), strict
liability or product liability.
All implied warranties, including any warranty of merchantability or fitness for a particular purpose, are
limited in their duration to the length of the warranty stated above for the affected component.
This warranty is to the original purchaser only, and excludes product damage due to installation error,
product misuse, product abuse, accidents, physical damage, damage in shipment, modifications not
made by Adapt Solutions, or repairs undertaken by anyone other than authorized distributors.
To obtain warranty parts and/or reimbursement, you must follow these procedures:
1. Obtain warranty authorization (RMA number) by calling your local Adapt Solutions dealer or Adapt
Solutions directly at 866-641-0419.
2. Return the faulty Adapt Solutions component/equipment, freight prepaid, to the address provided
by your Adapt Solutions dealer or Adapt Solutions with proof of purchase.
Adapt Solutions will pay for shipping back to the purchaser within the continental United States and
Canada if a defect in materiel or workmanship is discovered. Return freight and repair charges will be the
responsibility of the purchaser if the problem is not covered by warranty.
This warranty gives you specific legal rights, and you may also have other rights that vary from state to
state/ province to province. Adapt Solutions specifically does not authorize any person to extend the time
or scope of this warranty. For further information regarding this limited warranty, please contact us by
calling 1-866-641-0419 or by writing at the following address:
Adapt Solutions / Warranty Department
145 Damase-Breton
St-Lambert-de-Lauzon, Québec
G0S 2W0 Canada
