USER INSTRUCTIONS
NRS DOUBLE EASYFIT BEDGUARD
P78222 NRS Double EasyFit Bedguard
General Safety Warning
Please make sure that you read and follow these
instructions carefully. Keep these instructions in a
safe place for future reference.
1.0 INTENDED USE
The NRS Double EasyFit Bedguard is designed to
prevent users from rolling out of bed.
The bedguard has adjustable sliding guard
mechanisms, which can be extended or retracted
for easy access on and offeither side of the bed.
The bedguard can be used on divan and slatted
beds, from single to king size.
The bedguard rail sections can be removed to
make bed making easy.
2.0 SAFETY
318mm
Min
Minimum
distance from
headboard or
footboard
WARNING: The bedguard must be positioned at
least 318mm (12.5”) away from the headboard.
The bedguard must always be positioned as
close as possible to the mattress, to prevent user
entrapment.
Do not fit this product to height adjustable or
profiling beds.
The Bedguard is not designed to be used as a bed
rail. It will not support the users bodyweight.
Not suitable for use by children.
Some tasks within these instructions may require
two people.
3.0 UNPACKING
1
4
3
2
2
5
5
3
Remove the packaging and check all parts
carefully. Contact your supplier immediately if
parts are missing or damaged and do not try and
assemble.
Contents:
1. Base-frame
2. Bedguard Rail x 2
3. Bedguard Extension Rail x 2
4. Base Adjustment Rail
5. Mesh Cover x 2

2
4.0 ASSEMBLY AND INSTALLATION
4.1 Fitting the Bedguard Rail
The bedguard is packaged in three parts. To
assemble, attach the bedguard rails to the base-
frame assembly as follows:
1
1
2
22
1
1
2
22
1. Slot the bedguard rail into the base-frame
assembly.
2. Push and hold the bedguard rail button-clips,
then push the bedguard rail into the base-frame
assembly until the button-clips click into position
in the base frame holes.
3. Repeat the steps for the opposite side.
Note: Make sure that the button-clips have fully
engaged into the holes.
4.2 Adjusting the base width:
Note: The following steps may require two people.
1
2
2
2
1
A
BCD
Standard
Single
Small
Double
Standard
Double
King
Size
Bed Width 900mm 1200mm 1350mm 1500mm
Position ABCD
1. Push and hold the button-clips on the base
adjustment rail.
2. Slide the base adjustment rail out from the base-
frame until the button-clips click into the required
hole positions for your bed.
Note: Some wood framed beds may not allow the
adjustment rail to extend fully for the button-
clips to engage, this will not affect the safety
of the bedguard.
4.3 Fitting the Bedguard to the bed:
Note: The following steps may require two people.
1. Remove the mattress and place the bedguard
on the bed base.
2. Replace the mattress on top of the bedguard.
WARNING: The bedguard must always be
positioned with the extending bedguard rails
facing away from the headboard.
WARNING: The bedguard must be positioned at
least 318mm (12.5”) away from the headboard.

3
5.0 OPERATION AND USE
5.1 Extending the Bedguard Rails
The bedguards can be extended to give the user
better protection from bed roll-out.
1
1
Button
-clip
1. To extend the bedguards, pull the bedguard
extension rail out from the main bedguard rail
until the bedguard extension rail button-clip
clicks into position.
Note: Make sure that the button-clip has fully
engaged into the hole.
5.2 Retracting the Bedguard Extension Rail
The bedguard extension rail must be closed to let
the user exit the bed.
1. To close the bedguard extension rail, press and
hold the button-clip, then slide the bedguard
extension into the main bedguard rail.
5.3 Remove the Bedguard Rail
The bedguard rails can be removed to enable the
user to make the bed.
2
3
3
1
1. Push and hold the right-hand side bedguard rail
button-clip, then pull the bedguard rail until the
button-clip disengages from the hole.
2. Repeat step 1 for the left-hand side.
3. Make sure both button-clips have disengaged
from the holes, then pull the bedguard rail out
from the base frame.
4. To refit the bedguard rail, refer to Section 4.1.
5.4 Remove the Mesh Cover
The bedguard is supplied with the mesh cover
fitted to the bedguard rails, to remove for cleaning,
please do the following:
1. Undo the Velcro fastener and slide the mesh
cover offthe bedguard rail.
5.5 Refit the Mesh Cover
1. Slide the mesh cover onto the bedguard rail and
secure with the Velcro fastener.
2. Make sure that the mesh cover is fully secure
before use.
6.0 CLEANING
6.1 Cleaning the Bedguard
1. Clean regularly using a general purpose, neutral
detergent and warm water.
2. To disinfect, wipe with a dilute bleach solution
and rinse with fresh water.
Note: Please check the suitability of the cleaning
products before use. Do not use abrasive
cleaners or cloths as these could permanently
damage the surface and invalidate any
warranty.
3. Allow the product to dry fully before use or
storage.
6.2 Cleaning the Mesh Covers
1. Hand-wash the mesh covers using a mild fabric
detergent and warm water.

4
NRS HEALTHCARE Sherwood House, Cartwright Way, Forest Business Park, Bardon Hill, Coalville,
Leicestershire, LE67 1UB, UK.
Tel. Customer Services: 0345 121 8111
Email: [email protected]
NRS Healthcare is a Leading Supplier of Community Equipment and Daily Living Aids, to
view our full range, visit our website:
www.nrshealthcare.co.uk P78222-UI-1 06-11-2020
2. Rinse the mesh covers with warm water.
3. Allow the product to dry fully before use or
storage.
7.0 MAINTENANCE
1. Check the bedguard is correctly positioned and
that all button-clips have engaged securely.
2. Inspect the product for signs of wear or damage
at regular intervals. Any suspected faults or
damage must be reported to the supplier and
the product taken out of use immediately.
8.0 ACCESSORIES & SPARE PARTS
P42744 – Spare Mesh Cover (white).
For more details please visit our website:
www.nrshealthcare.co.uk or call Customer
Services.
9.0 PRODUCT DISPOSAL
This product should be thoroughly cleaned prior to
disposal.
This product is manufactured from metal and
plastic and can be disposed of through Local
Authority Household Waste and Recycling Centres
or through Local Trade Waste Collectors.
10.0 PRODUCT GUARANTEE
NRS Healthcare guarantee this product for a period
of 12 months, from the date of purchase, against
faulty materials and workmanship. This guarantee
does not cover; abuse, misuse, interference or
tampering with any part of the product.
Any guarantee issued by NRS Healthcare does not
affect your statutory rights.
