ADDAC System ADDAC900PD User manual
February.2023
ADDAC900PD Assembly Guide
ADDAC SYSTEM page 2
ADDAC SYSTEM page 3
ADDAC900PD Assembly Guide
STEP 1:
Start by placing and solder the 90 degree 1x3 pinheaders
STEP 2:
Locate the 2x10 pinheader and using pliers pull the 4 legs at both edges like shown below.
As we use Boxed Headers in all our Busboards the extra length of this connector will prevent an offsetted
connection that could cause a short circuit in the psu.
STEP 3:
Place and solder the 2x8 modified pinheader.
ADDAC SYSTEM page 4
ADDAC900PD Assembly Guide
ADDAC SYSTEM page 5
STEP 4:
Place and solder the 2x8 boxed pinheader like shown below, notice the indent orientation.
STEP 5:
Finish by placing the jumpers as you please.
ADDAC900PD Assembly Guide
ADDAC SYSTEM page 6
You’re all done!
Happy patching!
ADDAC900PD Assembly Guide
For feedback, comments or problems please contact us at:
ADDAC900PD ASSEMBLY GUIDE
February.2023Revision.01
