ADDONICS TECHNOLOGIES
Model: AEMK35CB
Installation Guide
1. Connect the other end of the dual connector IDE
ribbon cable to the IDE connector on the Desktop
Card Drive reader.
2. Connect one end of the dual connector IDE ribbon
cable to the IDE connector on the PCI controller.
3. Plug-in the PCI controller on a PCI bus slot.
4. ount the Desktop Card Drive reader on a 3.5”
drive bay. Using the screws provided, secure the
reader to the drive bay.
Types o Bus Slots
Note: The AE K35CB PCI controller connects to a PCI
bus slot.
Product Features
•Kit includes Card Drive, PCI controller and
connecting cables
•Card Drive Installs into standard 3.5" drive bay to
be accessible from the front of the computer, just
like a floppy drive!
•Supports both 32-bit Cardbus and 16-bit PC CIA
devices
•Compatible with any CardBus/ PC CIA device
such as Wireless Broadband cards, Wireless
modem, Panasonic P2 card, ATA Flash, sound
card, video capture card, Addonics family of
CardBus adapters
•Drive activity LED on Card drive
•Simple plug and play, no drivers required
•Compatible with Windows XP
•RoHS Compliant
TECHNICAL SUPPORT
Email: http://www.addonics.com/sales/query/
Internet: http://www.addonics.com
Technical Support (8:30 am to 6:00 pm PST)
Phone: [phone]
Email: http://www.addonics.com/support/query/
Drive activity LED
PCI ControllerDesktop Card Drive reader
Cardbus and PC CIA
devices slot
Dual connector IDE
ribbon cable
Eject Button
PCI
PCI
