ADEMCO 4110DL User manual

S
Se ec cu ur ri it ty y
S
Sy ys st te em m
User's Manual
4110DL/4110XM
N5100V5 9/96
www.PDF-Zoo.com

–2–
TABLE OF CONTENTS
SYSTEM OVERVIEW.......................................................................................................................................4
Keypads...................................................................................................................................................4
Zones.......................................................................................................................................................4
Alarms......................................................................................................................................................5
Fire Protection............................................................................................................................................5
Burglary Protection .....................................................................................................................................5
Memory of Alarm.........................................................................................................................................5
Pager Notification .......................................................................................................................................5
ABOUT THE KEYPADS ....................................................................................................................................6
Keypad Types ...........................................................................................................................................6
Keypad Styles ...........................................................................................................................................6
SUMMARY OF SYSTEM STATUS DISPLAYS ........................................................................................................7
SUMMARY OF KEYPAD FUNCTIONS ..................................................................................................................8
SECURITY CODES.........................................................................................................................................10
Duress Code.............................................................................................................................................10
Quick Arming ............................................................................................................................................10
Assigning/Changing/Deleting User Codes (Using the 8 CODE Key) ....................................................................11
ENTRY/EXIT DELAYS.....................................................................................................................................12
CHECKING FOR OPEN ZONES (Using the ✴READY Key) ...................................................................................13
BYPASSING PROTECTION ZONES...................................................................................................................14
Using The 6 BYPASS Key..........................................................................................................................14
Quick Bypass...........................................................................................................................................15
ARMING PERIMETER ONLY, WITH ENTRY DELAY ON (Using The 3 STAY Key) .......................................................16
ARMING PERIMETER ONLY, WITH ENTRY DELAY OFF (Using The 7 INSTANT Key ) ................................................17
ARMING ALL PROTECTION, WITH ENTRY DELAY ON (Using The 2 AWAY Key).......................................................18
ARMING ALL PROTECTION, WITH ENTRY DELAY OFF (Using The 4 MAXIMUM Key) ................................................19
DISARMING THE SYSTEM AND SILENCING ALARMS (Using the 1 OFF Key)...........................................................20
www.PDF-Zoo.com

–3–
(continued) TABLE OF CONTENTS
USING THE KEYSWITCH.................................................................................................................................21
CHIME MODE (Using the 9 CHIME Key) ............................................................................................................22
PANIC KEYS.................................................................................................................................................22
TESTING THE SYSTEM (Using the 5 TEST Key) .................................................................................................24
TROUBLE CONDITIONS..................................................................................................................................26
"Check" and "Battery" Displays.....................................................................................................................26
Power Failure ............................................................................................................................................27
Other Displays ..........................................................................................................................................28
FIRE ALARM SYSTEM, IF INSTALLED................................................................................................................29
In Case of Fire Alarm...................................................................................................................................29
Silencing Fire Alarms ..................................................................................................................................30
NATIONAL FIRE PROTECTION ASSOCIATION RECOMMENDATIONS ON SMOKE DETECTORS...................................31
EMERGENCY EVACUATION ............................................................................................................................32
QUICK GUIDE TO ALARM SYSTEM FUNCTIONS..................................................................................................33
SUMMARY OF AUDIBLE/VISUAL NOTIFICATION ................................................................................................34
PROTECTION ZONES LIST..............................................................................................................................35
OWNER'S INSURANCE PREMIUM CREDIT REQUEST...........................................................................................37
CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC) STATEMENT....................................................................39
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENTS .........................................................................40
IN THE EVENT OF TELEPHONE OPERATIONAL PROBLEMS .................................................................................41
THE LIMITATIONS OF THIS ALARM SYSTEM ......................................................................................................42
SERVICING INFORMATION .............................................................................................................................43
WARRANTY .....................................................................................................................................Back Cover
This manual is a step-by-step guide that will aquaint you with the system's features and benefits. It defines the
components and their functions, describes their operation, and instructs you with normal and emergency procedures.
Keep this manual in a convenient place so that you can refer to it as necessary.
www.PDF-Zoo.com

–4–
SYSTEM OVERVIEW
General Congratulations on your ownership of an Ademco Security System.
You've made a wise decision in choosing it, for it represents the latest in
security protection technology today, including microcomputer technology to
monitor all system status. Ademco is the world's largest manufacturer of
security systems and millions of premises are protected by Ademco
systems.
Basically, this system offers you three forms of protection: burglary, fire
and emergency. Your system may consist of at least one keypad which
provides full control of system operation, various sensors such as motion
detectors and door and window sensing devices, plus a selected number
of strategically placed smoke or combustion detectors designed to provide
early warning in case of fire. Your system may also have been pro-
grammed to automatically transmit alarm or status messages over the
phone lines to a central alarm monitoring station.
Keypads All system functions are controlled by your keypad(s). The keypads
feature a telephone style (digital) keypad and a Liquid Crystal Display
(LCD) which shows the nature and location of all occurrences. Their built-in
sounder will sound during alarm and trouble conditions.
For additional information, see the following section:
ABOUT THE
KEYPADS.
Zones Your system's sensing devices have been assigned to various zones. For
example, the sensing device on your Entry/Exit door may have been
assigned to zone 01, sensing devices on windows in the master bedroom
to zone 02, and so on. These zone numbers will appear on the display
when an alarm or trouble condition occurs.
www.PDF-Zoo.com

–5–
(continued) SYSTEM OVERVIEW
Alarms When an alarm occurs, both the keypad and external sounders will sound,
and a message at the keypad will identify the zone(s) causing the alarm. In
addition, if your system is connected to a central monitoring station, an
alarm message will be sent. To stop the alarm sounding, you simply disarm
the system.
Fire Protection The fire protection portion of your security system (if used) is always on
and will sound an alarm if a fire condition is detected. Refer to the
FIRE
ALARM SYSTEM section for important information concerning fire pro-
tection, smoke detectors and planning emergency exit routes from your
premises.
Burglary Protection The burglary protection portion of your system must be turned on or
"armed" before it will sense burglary alarm conditions and sound an alarm.
Your system can be armed in one of four modes: STAY, AWAY, INSTANT
and MAXIMUM. Refer to the
ARMING THE SYSTEM sections for
instructions in using these modes of operation.
Your system also provides a CHIME mode for alerting you to the opening
and closing of doors and windows while the system is disarmed.
Memory Of Alarm When an alarm or trouble condition occurs, the keypad displays the
number(s) of the zone(s) that caused the problem, and displays the type
of alarm or trouble (ex. FIRE, ALARM, CHECK). The display remains until it
is cleared by entering the OFF sequence (security code + OFF key) twice.
Pager Notification If you have chosen to be notified of alarms or other system conditions by
pager, the following codes will be sent to your pager by the control:
1811=Trouble 1911=Alarm
1001=Open 1002=Close
www.PDF-Zoo.com

–6–
ABOUT THE KEYPADS
Keypad Types All commands and procedures described herein are illustrated for Fixed-
Word Display Keypads. However, an Alpha Display Keypad (with a 2-
line LCD display for more detailed protection point identification and system
status, but with similar commands and procedures) is available and might
have been used instead.
Keypad Styles
Unless noted oth-
erwise, all proce-
dures in this man-
ual apply equally to
all keypad types
and styles.
Fixed-Word keypads are available in two styles, A and B, either of which
may have been used in your system. Although different in appearance,
both styles are functionally similar. The keypads on style B keypads are
located behind a flip-down door which can be removed, if desired. Words
displayed on all Fixed-Word keypads are the same, except that their
location in the display window differs slightly with each style.
Note: Some Style B keypads are equipped with a READY indicator in
place of the POWER indicator on Style A keypads. The READY indicator
is lit when the system is ready for arming (no protection zones open).
While the system is disarmed, this indicator will go on and off as protection
zones are opened and closed.
STYLE A FIXED-WORD KEYPADS STYLE B FIXED-WORD KEYPADS
00
ALARM
CHECK
FIRE
AWAY
STAY
INSTANT
BYPASS
NOT READY
NO AC
CHIME
BAT
PANIC
123
456
789
*
0
#
OFF AWAY STAY
MAX TEST BYPASS
INSTANT CODE CHIME
READY
ARMED
POWER
1 2 3
A
4 5 6
B
7 8 9
C
*
0
#
D
OFF AWAY STAY
MAX TEST BYPASS
INSTANT CODE CHIME
READY
PANIC
ARMED
READY
00
ALARM
CHECK
FIRE
AWAY
STAY
INSTANT
BYPASS
NOT READY
NO AC
CHIME
BAT
D
DIAGRAM
A
B
C
SHOWN WITH DOOR REMOVED
www.PDF-Zoo.com

–7–
SUMMARY OF SYSTEM STATUS DISPLAYS
AWAY All burglary zones, interior & perimeter,
are armed.
STAY Perimeter burglary zones, such as windows
and doors are armed.
INSTANT Perimeter burglary zones armed and
entry delay is turned off.
BYPASS One or more burglary protection zones
have been bypassed.
NOT READY Appears when burglary portion of the system
is not ready for arming (due to one or more
open protection zones).
READY The burglary portion of the system
is ready to be armed.
NO AC Appears when AC power has been cut off.
System is operating on backup battery power.
AC Appears when AC power is present.
CHIME Appears when the CHIME feature is ON.
BAT Low system battery
(if no zone number is shown), or
Low battery condition in a wireless sensor
(if zone number is also shown).
00
ALARM
CHECK
FIRE
AWAY
STAY
INSTANT
BYPASS
NO AC
CHIME
BAT
NOT READY
00
00
STYLE A
00
ALARM
FIRE
AWAY
BYPASS
STAY
CHECK INSTANT
NO AC
NOT READY
CHIME BAT
00 STAY
FIRE
ALARM
AWAY
STYLE B
FIXED-WORD KEYPAD DISPLAYS
ALARM Appears when an intrusion has been detected and the system is armed (also appears
during a fire alarm). Accompanied by the ID # of the protection zone in alarm.
CHECK Appears when a malfunction is discovered in the system at any time or if a fault is
detected in a FIRE zone at any time or in a DAY(Trouble)/NIGHT(Alarm) burglary zone
during a disarmed period. Accompanied by a display of zone number in trouble.
FIRE Appears when a fire alarm is present. Accompanied by a display of the zone in alarm.
www.PDF-Zoo.com

–8–
SUMMARY OF KEYPAD FUNCTIONS
1. DISPLAY WINDOW: Displays protection zone
ID and system status messages.
2. 1OFF KEY: Disarms burglary portion of the
system, silences alarms and audible trouble
indicators, and clears visual display after
problem's correction.
3. 2AWAY KEY: Arms the entire burglary sys-
tem, perimeter and interior.
4. 3STAY KEY: Arms perimeter portion of bur-
glary system only. Interior protection is not
armed, which allows movement within
premises without causing alarm.
5. 4MAXIMUM KEY: Arms in manner similar to
AWAY mode, but without the entry delay
feature, thus providing maximum protection.
An alarm will occur immediately upon opening
any protection point, including the entry/exit
door.
6. 5TEST KEY: Tests the system and alarm
sounder if disarmed. Refer to TESTING THE
SYSTEM section for test procedures.
7. 6BYPASS KEY: Removes individual pro-
tection zones from being monitored by the
system.
8. 7INSTANT KEY: Arms in manner similar to
STAY mode, but without the entry delay
feature. Entering via the entry/exit door will
cause an instant alarm.
9. 8CODE KEY: Used to assign additional user
codes for other users of the system.
10. 9CHIME KEY: Turns CHIME mode on and
off. When on, the opening of windows or
doors while the system is disarmed will sound
3 beeps at the keypad(s).
11. ✴READY KEY: Displays all open protection
zones.
12. #KEY: "Quick Arm" key permits ARMING of
the system without use of a security code (if
so programmed).
13. KEYS 0–9†:Used to enter your security code(s).
14. READY INDICATOR: (GREEN) Lit when the
system is ready to be armed (no faults present).
While the system is disarmed, this indicator will go
on and off as protection zones are closed and
opened.
Note: On some keypads there is, instead, a
POWER INDICATOR (GREEN) which is
lit when AC power is present. If the
indicator is off, the system may still be
operating, but on its backup battery
power. See Power Failure in TROUBLE
CONDITIONS section.
†
Note: Keys 1 through 9 each perform their associated companion functions (OFF, AWAY, STAY,
etc.) when preceded by an entry of the security code (as described later).
www.PDF-Zoo.com

–9–
15. ARMED INDICATOR: (RED) Lit when
the system has been armed (STAY,
AWAY, INSTANT or MAXIMUM).
16. INTERNAL SOUNDER: The built-in
keypad sounder mimics the alarm
sounder during alarms, and will also
"beep" during certain system functions.
(see SUMMARY OF AUDIBLE/ VISUAL
NOTIFICATION ).
17. EMERGENCY KEYS:
Individual keys A, B, and C(key D not
used).
On some keypads, these keys are not
present, and the following key pairs may
be available, instead, for emergency
functions:
✴&#, ✴& 1 , # & 3
Some or all of these keys/pairs may be
programmed for panic functions by your
installer (see PANIC KEYS section).
IMPORTANT!: When entering codes and
commands, sequential key depressions must be
made within 2 seconds of one another. If 2 seconds
elapses without a key depression, the entry is
aborted and must be repeated from its beginning.
ARMED
READY
A
B
C
ALARM
FIRE
AWAY
BYPASS
STAY
CHECK INSTANT
NO AC
NOT READY
CHIME BAT
OFF AWAY STAY
MAX TEST BYPASS
INSTANT CODE CHIME
READY
123
456
*
98
7
#0
PANIC
15315
4
14
2
811 913
12
10
7
6
17
16
STYLE B KEYPAD
www.PDF-Zoo.com

–10–
SECURITY CODES
General At the time of installation, your installer programmed a personal four-digit
Master code, known only to you and yours. This code is used to perform
most system functions, including arming and disarming of the system. As an
additional safety feature, temporary user codes can be assigned (see next
page) for use by those not having a need to know the Master code. Note
that the Master code remains in effect even when other user codes are
assigned.
Duress Code
Ask your installer if
"Duress" is active for
your system, and if so,
check here:
This feature is intended for use when you are forced to disarm or arm the
system under threat. When used, the system will act normally, but can
silently notify the central station of your situation, if that service has been
provided.
The Duress code is defined as user number 8.
Important: The Duress code is useful only when connected to a central
station.
Quick Arming
Ask your installer if
"Quick Arming" is active
for your system, and if
so, check here:
If your system supports "Quick Arming", the "#" key can be pressed in
place of the security code when arming the system. The security code is
always required, however, when disarming the system. accept
www.PDF-Zoo.com
