ADENDORFF MAC AFRIC SDRILC-007 User manual

GENERAL POWER TOOL SAFETY WARNINGS
(For All Power Tools)
WARNING! Read and understand all instructions. Failure to follow all
instructions listed below may result in electric shock, fire and/or serious personal
injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Work Area Safety
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust.
Power tools create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while operating a power tool.
Distractions can cause
you to lose control.
Electrical Safety
4. Power tool plugs must match the outlet. Never modify the plug in anyway. Do not use any
adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce risk of electric shock.
5. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators.
There is an increased risk o electric shock if your body is earthed or
grounded.
6. Do not expose power tools to rain or wet conditions.
Water entering a power tool will
increase the risk of electric shock.
7. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords
increase the risk of electric shock.
8. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a
cord suitable for outdoor use reduces the risk of electric shock.
9. If operating a power in a damp location is unavoidable, use a residual current device (RCD)
protected supply.
Use of an RCD reduces the risk of electric shock.
NOTE: The term “residual current device (RCD)” may be replaced by the term “ground fault
circuit interrupter (GFCI)” or “earth leakage circuit breaker (ELCB)”.
Personal Safety
10. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the influence of drugs, alcohol, or medication.
A
moment of inattention while operating power tools may result in serious personal injury.
11. Use personal protective equipment. Always wear eye protection.
Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
12. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and /or battery pack, picking up or carrying the tool.
Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
13. Remove any adjusting key or wrench before turning the tool on.
A wrench or a key left attached
to a rotating part of the power tool may result in personal injury.
14. Do not overreach. Keep proper footing and balance at all times.
This enables better control of the
power tool in unexpected situations.
15. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing, and gloves
away from moving parts.
Loose clothes, jewellery or long hair can be caught in moving parts.
16. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
Power Tool Use and Care
17. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
18. Do not use tool if switch does not turn it on or off.
Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
19. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools.
Such

preventive safety measures reduce the risk of starting the power tool accidentally.
20. Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool.
Power tools are dangerous
in the hands of untrained users.
21. Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged, have
the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
22. Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
23. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed.
Use of the
power tool for operations different from those intended could result in a hazardous
situation.
Battery Tool Use and Care
24. Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
25. Use power tools only with specifically designated battery packs.
Use of any other battery
packs may create a risk of injury and fire.
26. When battery is not in use, keep it away from other metal objects like: paper clips, coins,
keys, nails, screws, or other small metal objects that can make a connection from one
terminal to another. Shorting the battery terminals together may cause sparks, burns, or a
fire.
27. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
Service
28. Have your power tool serviced by a qualified repair person using only identical replacement
parts.
This will ensure that the safety of the power tool is maintained.
APPLICATIONS
Driving in and loosening screws in wood, metal and plastic.
Drilling in wood, metal and plastic.
SPECIFICATIONS
Power (DC) 18 V
Max. Clamping Capacity 6.35 mm
Max. Screw Diameter 14 mm
Battery Type Li-ion
Capacitor 4.0 Ah 5.0 Ah
Full Charging Time ≈90mins ≈100mins
No Load Speed 0-2000/0-2400RPM
Impact Rates 0-2900/0-3200IPM
Max. Torque
Step L
140 N·m
Step H/ Smart-loosen
Step
175 N·m
Net Weight(with battery) 1.9 kg
※Due to the continuing program of research and development, the specifications herein
are subject to change without prior notice.
ADDITIONAL SAFETY RULES
1. To be safe, disabled, retarded, untrained people or people disable to operate independently,
including young children, are discouraged to operate the tool without supervision. Young
children should be supervised to ensure that they do not play with the tool.
2. Check the tool and battery carefully before putting it into use. Stop operation immediately
when malfunctions be found and send the tool to be repaired by qualified serviceman. Do
not open the tool yourself.
3. Use only original FFBL18-XX type rechargeable Li-Ion battery for this tool and recharge only
with the FFCL18-XX type charger supplied with the tool. Use of other type of battery or
charger, e.g. imitated, modified or with other brand, may result in a risk of battery burst
causing personal injury and property damage.

4. Hold tool by insulated gripping surfaces when performing an operation on wall and floor
where the cutting tool may contact hidden wiring. Contact with a “live” wire will also make
exposed metal parts of the tool “live” and shock the operator.
5. Use appropriate detectors to determine if utility lines, such as electric lines, gas lines and
water lines, are hidden in the work area before screwing or drilling on the wall, floor or
ceiling.
6. Always be sure to hold the tool firmly. It’s possible to appear a brief strong reaction during
tightening and loosening screws.
7. Keep workpiece secure. Use retainer or vise to secure the workpiece. It’s firmer than
holding the workpiece by hands.
8. Always be sure to keep workplace clean. It’s dangerous that different kinds of working dust
mix and cause a chemical reaction. The light metal dust may cause fire and explosion.
9. Never put down the machine before it comes to a complete stop. The thing on the machine
may be clamped between the workpiece, so that you can’t control the machine.
10. Keep hands away from rotating parts.
11. Be sure to have a firm footing and no one is below when using the tool in high locations.
12. Do not touch the drill bit or the workpiece immediately after operation; they may be extremely
hot and could burn your skin.
13. Always wear protective devices to avoid personal injury.
14. The damaged tools, accessories and waste packaging should be sorted for environmentally
friendly recycling and in accordance with local laws.
SAVE THESE INSTRUCTIONS.
WARNING! MISUSE or failure to follow the safety rules stated in this instruction manual may
cause serious personal injury.
IMPORTANT INSTRUCTIONS FOR BATTERY & CHARGER
1. Be sure to set the reversing switch lever to the center position and remove the battery before doing
anything, such as replacing, checking, maintaining, moving, storing tools and so on.
2. Always be sure to install battery securely before using the machine.
3. It’s normal that the battery and charger will become warmer while in charging.
4. Do not charge for damaged battery.
5. When charging finished, unplug the charger firstly and then remove the battery from the
charger. Do not leave the battery in the charger for long time.
6. Do not put the battery in the charger when the tool is not in use.
7. Do not disassemble charger or battery; take it to a qualified serviceman when service or
repair is required, incorrect reassembly may result in a risk of electric shock or fire.
8. Do not short-circuit the battery.
9. Do not incinerate the battery; it can explode in a fire.
10. Be careful not to drop, shake or strike the battery.
11. Never try to use the battery cartridge as a hammer. Striking on the battery may cause
unexpected short-circuit and results in a risk of fire or explosion.
12. Keep battery far from fire and high temperature, THERE IS A DANGER OF EXPLOSION! Never
place battery on radiator or expose it under continuous sun irradiation, it may be damaged by
overheated.
13. Keep workplace well ventilated. The battery which is damaged or not used as required
gives off toxic gas and causes injury.
14. Overheating or overusing of the battery may cause liquid escape and come into contact
with the adjacent components. Clean such parts or replace them, if required. If electrolyte
contacts with your skin, wash the contacted area with soap firstly and then wash with lemon
juice and vinegar. If electrolyte gets into your eyes, rinse them out with clear water and seek
medical attention right away.
15. If operating time with a battery has become excessively shorter after charging, stop
operating immediately and replace with a new one.
16. Store battery in a moistureproof and antifrost area. Never expose battery to water, rain or
snow.
17. Store battery after full charging.
18. Store the battery only within a temperature range between 0℃and 45℃. Too hot or too
cold may damage the battery.
19. Avoid storing battery nearside paper clips, coins, keys, nails, screws, or other small metal
objects that can make a connection from one terminal to another. Shorting the battery

terminals together may cause sparks, burns, or a fire.
20. Do not dispose of damaged or worn out battery into household waste, fire or water.
21. Damaged or worn out battery packs/batteries should be collected, recycled or disposed of
in an environmental-friendly manner.
GENERAL DESCRIPTIONS
1. Locking Cover 5. Battery Indicator Light
2. Work Light 6. Battery
3. Switch Trigger 7. Reversing Switch Lever
4. Torque Setting Panel 8. Belt Buckle
INSTRUCTIONS FOR OPERATION
Installing or Removing Battery
CAUTION:
Only use designated battery. Using other manufacturer’s battery may cause injury and loss of
property because of explosion.
Do not remove the battery forcibly.
Please set the reversing switch lever to the
center position, avoid triggering switch to
cause danger when installing and removing
battery.
To install the battery firmly, insert it properly all
the way until it locks in place with a little click.
If not, it may accidentally fall out of the tool,
causing injury to you or someone around you.
Avoid overexerting or hammering the battery
into the motor housing with the help of other
objects. (Fig. 1)
To remove the battery, press the unlocking
buttons on both sides of the battery and pull
out the battery according to the direction of
arrow. (Fig. 2)
Charging Indicator Light
CAUTION:
If 4 lights flash at the same time, the tool may
be overloaded or overheated. As temperature
recovers or over-load protection is removed,
press the switch and the tool can be started
normally.
Current power of the battery will be indicated by
the battery indicator light when pressing the
battery button or switching on the tool. (Fig. 3)

Four red LED lights are set to indicate the battery power which can be referred to the following table.
Status of Red LED Lights Approx. Battery Power Left
4 lights lit 75%～100%
3 lights lit 50%～75%
2 lights lit 25%～50%
1 light lit 10%～25%
1 light flickered Low level
Battery Charging
1. Battery Charger
Notice:
The charger applies to charge for specified Li-Ion Battery under normal circumstances.
Make sure that the AC voltage of the power source meets the requirement specified on the
nameplate of the charger.
Due to the continuing program of research and development, the specifications herein are
subject to change without prior notice.
2. Charging Operation
1. Plug the battery charger into the proper AC power source. The charging indicator light will
flicker in green color and the charger operates in standby mode.
2. Insert the battery pack fully into the battery charger and the charger starts charging.
The battery charger can detect some sort of failure caused by the battery and indicates by the
statuses of the red and green indicator lights.
When a failure occurs, remove the battery and
then insert it into the charger again. If the
failure continues, change with a new battery. If
the new battery can be charged, then the old
battery maybe damaged. If the charging
indicator lights indicate same failure as before
while changing with a new battery, then the
charger maybe damaged, take the charger to
be repaired by qualified serviceman. (Fig. 4)
The following chart lists the relations between the statuses of charging and charging indicator
lights.
Switch Action
CAUTION:
Before inserting the battery into the tool, always check
to see that
the switch trigger actuates properly and returns to the “OFF” position when released.
Descriptions of
Charging Status Icons
Icons of Charging
Indicator Lights Descriptions of
Charging Indicator
Lights
Green
Light
Red
Light
Plug the charger into
a proper outlet Green light flickers, red
light extinguished
During charging
Green light extinguished,
red light keeps
flickering steadily
Charge complete
Green light keeps up
steadily, red light
extinguished
Abnormity occurs on
the battery
Green and red light
flicker alternately
The temperature of
the battery is under
0℃or higher than
50℃
Green light extinguished,
red light flickers
Model FFCL18-01
FFCL18-03
SCHARG-001
(FFCL18-04)
Input Voltage (AC) 220-240V 110-240V
Charging Current 3.0A
Input Power Frequency 50-60Hz
Applicable Battery Cartridge Voltage
(DC) 18V
Applicable Battery Cartridge Capacity 5.0Ah 4.0Ah
Full Charging Time ≈100min ≈90min
Insulation Grade Double Insulation

Never operating in a low rotation speed for
long time, otherwise it will cause overheat inside the
machine.
To start the tool, simply pull the switch trigger and keep it
pressed. Tool speed can be variably adjusted depending
on how far the switch trigger is pressed. Release the
switch trigger to switch off the tool. (Fig. 5)
Reversing Switch Action
CAUTION:
Always check the direction of rotation before operation.
Operate the reversing switch only after the tool comes to a complete stop. Changing the direction
of rotation before the tool stops may damage the tool.
When not operating the tool, always set the reversing switch lever to the center position.
Never force to pull the switch trigger while the reversing switch lever is set at the center position.
Right/Clockwise Rotation
Depress the reversing switch lever from side B to side A
for clockwise rotation for drilling and driving in screws
(view forwards).(Fig. 6)
Left/Counterclockwise Rotation
Depress the reversing switch lever from side A to side B
for counterclockwise rotation for loosening or
unscrewing screws. (Fig 6)
Installing or Removing Tools
The tool here includes driver bit, drill bit, etc, which differs from the concept of power tools or
machines.
CAUTION:
Before installing or removing the driver bit or drill
bit, always disconnect the battery from the tool
or set the reversing switch lever to the center
position. Never press switch trigger.
Please pull the bit along the arrow direction after
installing and be sure to fix the bit in the sleeve.
To install the bit, pull the locking cover along the
arrow direction and insert the bit to the inner most
of the sleeve, then loosen the sleeve to fix the bit.
(Fig. 7)
To remove the bit, pull the locking cover and pull
out the bit along the arrow direction. (Fig. 8)
Tightening and Moving Screw
CAUTION:
Make sure that the driver bit is inserted straight in
the screw head, or the screw and/or bit may be
damaged.
Make sure that the reversing switch lever is in the
position of counterclockwise rotation when
moving screw.
To tighten screw, place the point of the driver bit
in the screw head and apply pressure to the tool. Start the tool slowly and then increase the
speed gradually. Release the switch trigger as soon as the clutch cuts in. To move screw,
release the switch trigger as soon as the clutch pulls out. (Fig. 9)

Work Light
The white LED work light will be lit after pulling the
switch trigger for illumination of the work area under
unfavorable lighting conditions. (Fig. 10)
Continuous Use
If the tool is operated continuously until the battery
cartridge has discharged, allow the tool to rest for
15minutes before proceeding with a fresh battery.
Setting the Fastening Torque
CAUTION:
Choose proper gear based on different workplaces.
The fastening torque can be adjusted in 3 steps.
According to the requirement of different workplaces, Press the button on the panel to set the torque
among step L, H and Smart-loosen. (Fig. 11)
Smart-loosen Step: Under this special smart-loosen step, to loosen the screw, simply set the
reversing switch lever to counterclockwise position.Once the screw is loosened, the tool will stop
immediately, even if the switch trigger is not released. This gear can be uesd to loosen but not
completely remove the screw. When set the reversing switch lever to clockwise position, the function
is the same as H step.
L Step: Press the switch trigger, and the tool runs continuously at a low speed. The maximum torque
is 240 N·m.
H Step: Press the switch trigger, and the tool runs continuously at a high speed. The maximum
torque is 300 N·m.
MAINTENANCE AND INSPECTION
Inspecting
When the tool is distributed or withdrew, the custodial staff must give it a daily inspection; before
use, users must give it a daily inspection; the companies using the tool must have professionals to
inspect the tool regularly; Inspection cycle should be shortened in the area of humid climate and
changeable temperature or under poor using conditions; Inspect in time before rainy season.
The tool that is inspected to be qualified should be marked with a sticker on which there are words
“identifier, name or identification of the inspecting company, name or identification of the inspector
and effective date.
The tool must be maintained by maintenance companies recognized by original manufacturer. The
end-users and maintenance departments are not allowed to change original parameter of the tool, or
adopt alternate materials whose performance is lower than original ones or spare parts that don not
correspond to the specifications.
Cleaning Ventilation Slots
For safe and proper working, always keep the power tool and its ventilation slots clean. Use a soft,
clean and dry brush to clean the ventilation slots regularly or when they’re clogged.
Inspecting the Mounting Screws
Regularly inspect all mounting screws and ensure that they are properly tightened. Should any of the
screws be loose, retighten them immediately. Failure to do so could result in serious hazard.
Cleaning
Only use soft and dry cloth to wipe the body of the tool. Do not clean the tool with wet cloth, thinner,
gasoline or other volatile solvents.
※To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment
should be performed by authorized service centers, always using original replacement parts.

EXPLANATION OF GENERAL VIEW
1 Circlip for Shaft 27 Driving Gear
2 Washer 28 Ball Bearing
3 Locking Cover 29 Armature Assembly
4 Compression Spring 30 Ball Bearing
5
Pan Head Tapping Screw (with
Spring Washer)
31 Pan Head Tapping Screw
6 Front Cover 32 Hall Plate
7 Spindle Sleeve 33 Stator Assembly
8 Baffle Ring 34 Reversing Switch Lever
9 Washer 35 Torque Setting Board
10 Steel Ball 36 LED Shade
11 Drive Spindle 37 Switch Trigger
12 Steel Ball 38 Switch
13 Impact Block 39 PCB Assembly
14 Steel Ball 40 Terminal Block
15 Washer 41 Left-half Motor Housing
16 Compression Spring 42 Rubber Particle
17 Shim 43 Right-half Motor Housing
18 Spindle 44 Pan Head Tapping Screw
19 Planet Gear 45 Hex Lock Nut
20 Pin 46 Belt Buckle
21 Washer 47 Screw
22 Washer 48 Torque Setting Mark
23 Roundwire Snap Ring 49 Nameplate
24 Inner Gear 50 Brushless Mark
25 Ball Bearing 51 Battery Pack
26 Gear Housing 52 Battery Charger
