ADJ 32 HEX PANEL IP User manual

32 HEX PANEL IP
User Manual

2
Date Document
Version
Software
Version DMX Channels Notes
12/17/2018 1.0 1.08 6/10/11/16/48/96 Initial release
03/14/2019 1.2 1.09 6/10/11/16/48/57/96 57 channel mode added
07/09/2019 1.3 1.11 N/C Strobe mode added
11/25/2020 1.4 1.14 6/8/10/11/16/48/57/96 Updated primary/secondary
modes, DMX traits, system menu
02/19/2021 1.5 1.15 N/C Updated system menu
06/24/2021 1.6 N/C N/C Approvals / rating updated
12/13/2022 1.7 N/C N/C Added RDM; updated Dimmer
Curve Chart, Specifications
©2022 ADJ Products, LLC all rights reserved. Information, specications, diagrams, images, and
instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying product
names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection claimed includes
all forms and matters of copyrightable materials and information now allowed by statutory or judicial
law or hereinafter granted. Product names used in this document may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged. All non-ADJ Products, LLC
brands and product names are trademarks or registered trademarks of their respective companies.
ADJ Products, LLC and all afliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as a
result of the improper, unsafe, insufcient and negligent assembly, installation, rigging, and operation
of this product.
ADJ PRODUCTS LLC World Headquarters
6122 S. Eastern Ave. | Los Angeles, CA 90040 USA
Tel: [phone] | Fax: [phone] | www.adj.com |[email protected]
ADJ Supply Europe B.V.
Junostraat 2 | 6468 EW Kerkrade | Netherlands
Tel: [phone] | Fax: [phone] | www.americandj.eu | [email protected]
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the environment. Please turn off all electrical products
when they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment
from power when not in use. Thank you!
DOCUMENT VERSION
Due to additional product features and/or enhancements, an updated version of this
document may be available online.
Please check www.adj.com for the latest revision/update of this manual before
beginning installation and/or programming.

3
Introduction 4
Limited Warranty (USA Only) 5
Warranty Registration | Features 6
Safety Guidelines 7
IP Notice 9
Overview 10
Installation 11
Connections 12
Accessory Installation 13
Remote Device Management (RDM) 14
System Menu 15
DMX Setup 24
DMX Traits 25
Color Macros Chart 29
Primary-Secondary Configuration | Pixel Zones 31
Dimmer Curve Chart 32
Dimensional Drawings 33
Multiple Unit Power Linking | Trouble Shooting | Cleaning 35
Specifications 36
CONTENTS

4
Introduction: The 32 Hex Panel IP/32 Hex Panel IP Pearl is a DMX intelligent, IP rated LED wash
xture that can be used in a stand alone mode or connected in a Primary/Secondary conguration. This
xture has ve operating modes: RGBWA + UV dimmer mode, Static Color mode, Auto Run mode,
Color Macro mode, and DMX control. This product is intended to be used by professionally trained
personnel only and is not suitable for private use.
Unpacking: Every device has been thoroughly tested and has been shipped in perfect operating
condition. Carefully check the shipping carton for damage that may have occurred during shipping. If
the carton is damaged, carefully inspect the device for damage, and be sure all accessories necessary
to install and operate the device have arrived intact. In the event damage has been found or parts are
missing, please contact our customer support team for further instructions. Please do not return this
device to your dealer without rst contacting customer support. Please do not discard the shipping
carton in the trash. Please recycle whenever possible.
Parts: To purchase parts online visit:
http://parts.adj.com (US)
http://www.adjparts.eu (EU)
ADJ SERVICE USA - Monday - Friday 8:00am to 4:30pm PST
Voice: 800-322-6337 | Fax: [phone] | [email protected]
ADJ SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
Voice: [phone] | Fax: [phone] | [email protected]
ADJ PRODUCTS LLC USA
6122 S. Eastern Ave. Los Angeles, CA. 90040
323-582-2650 | Fax [phone] | www.adj.com | [e-mail]
ADJ SUPPLY Europe B.V
Junostraat 2 6468 EW Kerkrade, The Netherlands
[phone] | Fax [phone]
www.americandj.eu | [email protected]
ADJ PRODUCTS GROUP Mexico
AV Santa Ana 30 Parque Industrial Lerma, Lerma, Mexico 52000
[phone]
CAUTION! There are no user serviceable parts inside this unit. Do not attempt any repairs
yourself, as doing so will void your manufacturer’s warranty. In the unlikely event your unit may
require service, please contact ADJ Products, LLC.
INTRODUCTION

5
LIMITED WARRANTY (USA ONLY)
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products to be free of manufacturing
defects in material and workmanship for a prescribed period from the date of purchase (see specic warranty period
on reverse). This warranty shall be valid only if the product is purchased within the United States of America, including
possessions and territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.
B. For warranty service, you must obtain a Return Authorization number (RA#) before sending back the product-please
contact ADJ Products, LLC Service Department at 800-322-6337. Send the product only to the ADJ Products, LLC
factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are
within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within
the United States. If the entire instrument is sent, it must be shipped in its original package. No accessories should be
shipped with the product. If any accessories are shipped with the product, ADJ Products, LLC shall have no liability
whatsoever for loss of or damage to any such accessories, or for the safe return thereof.
C. This warranty is void of the serial number has been altered or removed; if the product is modied in any manner which
ADJ Products, LLC concludes, after inspection, affects the reliability of the product, if the product has been repaired or
service by anyone other than ADJ Products, LLC factory unless prior written authorization was issued to purchaser by
ADJ Products, LLC; if the product is damaged because not properly maintained as set forth in the instruction manual.
D. This is not a service contact, and this warranty does not include maintenance, cleaning or periodic check up. During
the period specied above, ADJ Products, LLC will replace defective parts at its expense with new or refurbished parts,
and will absorb all expenses for warrant service and repair labor by reason of defects in material or workmanship. The
sole responsibility of ADJ Products, LLC under this warranty shall be limited to the repair of the product, or replacement
thereof, including parts, at the sole discretion of ADJ Products, LLC. All products covered by this warranty were
manufactured after August 15, 2012, and bear identifying marks to that effect.
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products without any
obligation to include these changes in any products theretofore manufactured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with products
described above. Except to the extent prohibited by applicable law, all implied warranties made by ADJ Products, LLC
in connection with this product, including warranties of merchantability or tness, are limited in duration to the warranty
period set forth above. And no warranties, whether expressed or implied, including warranties of merchantability or
tness, shall apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy shall be
such repair or replacement as is expressly provided above; and under no circumstances shall ADJ Products, LLC be
liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product.
G. This warranty is the only written warranty applicable to ADJ Products, LLC Products and supersedes all prior warranties
and written descriptions of warranty terms and conditions heretofore published.
LIMITED WARRANTY PERIODS
• Non L.E.D. Lighting Products = 1-year (365 days) Limited Warranty (Such as: Special Effect Lighting, Intelligent
Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing, Lighting Stands etc.
excluding LED and lamps)
• Laser Products = 1 Year (365 Days) Limited Warranty (excludes laser diodes which have 6 month limited warranty)
• L.E.D. Products = 2-year (730 days) Limited Warranty (excluding batteries which have a 180 day limited warranty)
Note: 2 Year Warranty only applies to purchases within the United States.
• StarTec Series = 1 Year Limited Warranty (excluding batteries which have a 180 day limited warranty)
• ADJ DMX Controllers = 2 Year (730 Days) Limited Warranty

6
The 32 Hex Panel IP/32 Hex Panel IP Pearl carries a 2 year limited warranty. Please fill out the
enclosed warranty card to validate your purchase. All returned service items whether under warranty
or not, must be freight pre-paid and accompany a return authorization (R.A.) number. The R.A. num-
ber must be clearly written on the outside of the return package. A brief description of the problem as
well as the R.A. number must also be written down on a piece of paper included in the shipping car-
ton. If the unit is under warranty, you must provide a copy of your proof of purchase invoice. You may
obtain a R.A. number by contacting our customer support team on our customer support number.
All packages returned to the service department not displaying a R.A. number on the outside of the
package will be returned to the shipper.
WARRANTY REGISTRATION
• Multiple Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• DMX-512 Protocol
• IP65 Locking 5-pin XLR Connections In/Out
• Multiple DMX Channel Modes
• Multiple Unit Power Linking (see Multi Unit Power Linking section of this manual)
INCLUDED ITEMS
• IP65 Locking Power Cable (x1)
• Magnetic Removable Frost Filter (x1)
FEATURES

7
SAFETY PRECAUTIONS
FOR YOUR OWN PERSONAL SAFETY, PLEASE READ AND UNDERSTAND THIS MANUAL
COMPLETELY BEFORE ATTEMPTING INSTALLATION OR OPERATION OF THIS UNIT!
• There are no user serviceable parts inside this unit. Do not attempt any repairs yourself, as
doing so will void your manufacturer’s warranty. Damages resulting from modications to
this xture and/or the disregard of safety instructions and guidelines in this manual void
the manufacturer’s warranty and are not subject to any warranty claims and/or repairs.
• Do not plug this xture into a dimmer pack!
• Never open this xture while in use!
• Unplug power before servicing!
• Never touch the xture during operation, as the surface of the xture may be hot!
• Keep ammable materials well away from the xture!
• Ensure all connections and end caps are properly sealed with dielectric grease (available
at most electrical supply stores) in order to prevent water corrosion and/or short circuiting.
• If the xture is exposed to environmental temperature changes, such as a relocation from a
cold outdoor setting to a warm indoor setting, do NOT power the xture on immediately! In-
ternal condensation resulting from environmental temperature changes can cause internal
xture damage. Leave the xture powered off, and allow the xture to reach room tempera-
ture before switching the power on.
• Never look directly into the light source! Doing so presents a serious risk of retina injury,
and can result in blindness! Sensitive persons may also suffer an epileptic shock!
• Ensure that the power outlet is rated for the same voltage that your unit requires.
• Do not attempt to operature this unit its the power cord is frayed or broken.
• Do not attempt to remove or break off the ground prong from the electrical cord. This prong is
used to reduce the risk of electrical shock and re in the event of an internal short.
• Disconnect from power before making any type of connection.
• Do not remove the cover for any reason. There are no user serviceable parts inside.
• Never operate this unit with the cover removed.
• Always mount this unit in an area that will allow for proper ventilation. Allow about 6” (15cm) be-
tween this device and any nearby walls.
• Do not attempt to operate this unit if it has been damaged in any way.
• Always mount this unit in a safe and stable manner.
• Power supply dcords should be routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to cords at plugs, convenience re-
ceptacles, and the point where they exit from the device.
• Cleaning - The xture should be cleaned only as recommended by the manufacturer. See the
Cleaning section of this manual for details.
• Heat - This xture should be situated away from heat sources such as radiators, heat registers,
stoves, or other appliances (including ampliers) that produce heat.
• The xture should be serviced by qualied service personnel when the appliance does not appear
to operate normally or exhibits a marked change in performance.

8
SAFETY PRECAUTIONS
RISK GROUP 3 - RISK OF EXPOSURE TO ULTRAVIOLET (UV) RADIATION!
FIXTURE EMITS HIGH INTENSITY ULTRAVIOLET (UV) LIGHT FROM THE UV LED.
WEAR PROPER EYE AND SKIN PROTECTION.
AVOID PROLONGED PERIODS OF EXPOSURE TO THE UV LED.
AVOID WEARING WHITE COLOR CLOTHING AND/OR USING (UV) PAINTS ON SKIN.
AVOID DIRECT EYE AND/OR SKIN EXPOSURE AT DISTANCES SHORTER THAN 11 feet (3.3m).
DO NOT OPERATE FIXTURE WITH DAMAGED OR MISSING EXTERNAL COVER.
DO NOT LOOK DIRECTLY INTO THE (UV) LIGHT AND/OR VIEW (UV) LIGHT DIRECTLY WITH
OPTICAL INSTRUMENTS THAT MAY CONCENTRATE THE LIGHT/RADIATION OUTPUT.
INDIVIDUALS SUFFERING FROM A RANGE OF EYE CONDITIONS, SUNLIGHT EXPOSURE DIS-
ORDERS, OR INDIVIDUALS USING PHOTOSENSITIVE MEDICATION, MAY EXPERIENCE DIS-
COMFORT IF EXPOSED TO THE ULTRAVIOLET (UV) LIGHT EMITTED FROM THIS FIXTURE.

9
IP NOTICE
An IP rated lighting xture is designed for installation in outdoor environments, and use a special en-
closure that effectively protects against the entry of external foreign objects, such as dust and water.
The Ingress Protection (IP) rating system is commonly expressed as “IP” followed by a pair of num-
bers (i.e. IP65), where the numbers signify the degree of protection. The rst digit (foreign bodies pro-
tection) indicates the extent of protection against the entry of particles, while the second digit (water
protection) indicates the extent of protection against the entry of water. In IP65 rated xture, such as
this one, has been designed and tested to protect completely against all ingress of dust (6) as
well as water sprayed by a nozzle from any direction (5).
Please note: although the xture is IP65 rated, it is intended only for temporary outdoor us-
age!
MARINE/COASTAL ENVIRONMENT INSTALLATIONS
This xture is NOT suitable for marine and/or coastal environment installations. Installing this
xture in a marine and/or coastal environment may cause corrosion and/or excessive wear to the
interior and/or exterior components of the xture. Damages and/or performance issues resulting from
installation in a marine and/or coastal setting will void the manufacturer’s warranty and will NOT be
subject to any warranty claims and/or repairs.

10
OVERVIEW
LCD Screen
Mode Button
Up Button
Down Button
Enter Button
IP65 Locking Power Connector In
IP65 Locking 5-Pin XLR Connector In
IP65 Locking Power Connector Out
IP65 Locking 5-Pin XLR Connector Out
Safety Cable
Attachment Point
Safety Cable
Attachment Point
Gore Valve

11
INSTALLATION
The 32 Hex Panel IP is fully operational in three different mounting positions: hanging upside-down,
mounted sideways on trussing, or set on a at level surface. Be sure this xture is kept at least 12m
(40ft) away from any ammable materials (decoration etc.). ALWAYS use and install and appropriately
rated safety cable as a safety measure to prevent accidental damage and/or injury in the event that
the clamp fails.
Screw one clamp into the Omega bracket with an M12 screw and nut. Insert the quick-lock fasteners
of the Omega bracket into the matching holes of the adjustable mounting bracket. Tighten the quick-
lock fasteners fully clockwise. Pull the safety-cable through the openings located on the rear of the
unit and over the trussing system or a safe xation spot. Insert the end in the carabine and tighten the
safety screw.
Always ensure that the unit is rmly xed to avoid vibration and slipping during operation. Always en-
sure that the structure to which you are attaching the unit is secure and is able to support at least 10
times the unit’s weight. ALWAYS use safety cables that can hold 12 times the weight of the unit when
installing the xture.
This equipment must be installed by a professional, and it must be installed out of the reach of the
general public.
Ensure ALL connections and end caps are properly sealed with a non-conductive dielectric
grease (available at most electrical supply stores) to prevent water ingress/condensation and/
or corrosion.
OPTIONAL CLAMP (Not Included)
1
ADJUSTABLE MOUNTING BRACKET
2
OPTIONAL OMEGA BRACKET (Not Included)
3

12
CONNECTIONS
ENSURE ALL CONNECTIONS AND END CAPS ARE PROPERLY SEALED WITH A DIELECTRIC
GREASE (AVAILABLE AT MOST ELECTRICAL SUPPLIERS) TO PREVENT WATER CORROSION
AND/OR ELECTRICAL SHORT CIRCUIT.
TO MAINTAIN IP65 RATING INTEGRITY AND PREVENT WATER FROM ENTERING THE FIX-
TURE, ALL CONNECTION RUBBER CAPS MUST BE SEALED WHEN NOT IN USE.

13
ACCESSORY INSTALLATION
BARNDOORS
Please note: Barndoors are an optional accessory that must be purchased separately.
1. Install and secure the included
magnetic LED array cover. (Note:
Not required when using Barn-
doors)
2. Place the Barndoor attachment
over the front of the unit. Align
and insert the 4 barndoor thumb-
screws into the matching holes
located on each side of unit (2 on
each side). Tighten the thumb-
screws to secure the barndoors in
place. DO NOT overtighten.
Barn DoorInstallation
Barn Doors
32 Hex Panel IP
LED Array Cover

14
REMOTE DEVICE MANAGEMENT (RDM)
NOTE: In order for RDM to work properly, RDM enabled equipment must be used throughout
the entire system, including DMX data splitters and wireless systems.
Remote Device Management (RDM) is a protocol that sits on top of the DMX512 data standard
for lighting, allowing the DMX systems of the fixtures to be modified and monitored remotely. This
protocol is ideal for instances in which a unit is installed in a location that is not easily accessible.
With RDM, the DMX512 system becomes bi-directional, allowing a compatible RDM enabled
controller to send out a signal to devices on the wire, as well as allowing the fixture to respond
(known as a GET command). The controller can then use its SET command to modify settings that
would typically have to be changed or viewed directly via the unit’s display screen, including the DMX
Address, DMX Channel Mode, and Temperature Sensors.
FIXTURE RDM INFORMATION:
RDM Code Device ID Device Model ID Personality ID
1900 xxxx xxxx 1
001 - 6Ch
002 - 8Ch
003 - 10Ch
004 - 11Ch
005 - 16Ch
006 - 48Ch
007 - 57Ch
008 - 96 Ch
Please be aware that not all RDM devices support all RDM features, and therefore it is important
to check beforehand to ensure that the equipment that you are considering includes all of the features
that you require.
The following parameters are accessible in RDM on this device:
Sensor Denition
Sensor Value
Device Model Description
Manufacturer Label
Device Label
DMX Personality
DMX Personality Description
Device Hours

15
SYSTEM MENU
The xture features an easy to navigate system menu control panel display where all necessary set-
tings and adjustments can be made (see illustration below). During normal operation, pressing the
MENU button once will access the xture’s main menu. Once in the main menu, you can navigate
through the different functions and access the sub-menus with the UP and DOWN buttons. When you
reach a eld that requires adjusting, press the ENTER button to access that eld, then use the UP
and DOWN buttons to adjust the eld. Pressing the ENTER button once more will conrm your set-
ting. You may exit the main menu at any time without making any adjustments by pressing the MENU
button.
LCD CONTROL PANEL LOCKOUT
When the Key Lock function is activated, the control panel will automatically lock after a period of
inactivity that can be set under the LCD Set > Backlight menu.
• When the Key Lock function is set to ON, the control panel will lock and the display will show
“LOCKED*****”. Press and hold the MODE button for 3 seconds to unlock.
• When the Key Lock function is set to ON1, the control panel will lock and the display will show
“LOCKED*****”. To unlock the display, press UP, DOWN, UP, DOWN, ENTER.
If the button sequence was entered correctly, the display and control panel will unlock. If the button
sequence was entered incorrectly, the display will return to the DMX addess display.

16
SYSTEM MENU
MENU SUBMENU OPTIONS / VALUES DESCRIPTION
DISPLAY
MENU
Update Wait
ADJ
Vx.xx
SET ADDR 001 - 509 DMX addressing
USER MODE
CH06
DMX channel mode
CH08
CH10
CH11
CH16
CH48
CH57
CH96
FUNCTION
Dim Curve
Standard
Dimmer curve setting
Stage
TV
Architec
Theatre
No DMX
Hold
Lost DMX settingBlackout
Program
Auto Run FQN 01 - FQN 99 Auto run programs
1. Statc
R
F000 - F255 Static color mode
G
B
RG
GB
RB
RGB
BLAC
2. Chang SP01 - SP99 F000 - F255 15 color change mode
3. Chang SP01 - SP99 F000 - F255 30 color change mode
4. Fade SP01 - SP99 F000 - F255 Color fade mode
Macros 00 - 64 Color macro mode
LCD Set
Backlight 05min - 60min
LCD display settingsKey Lock
On
On1
Off
Dis Flash On / Off
DF Set On / Off Reset to default settings
CONTINUED ON NEXT PAGE

17
SYSTEM MENU
MENU SUBMENU OPTIONS / VALUES DESCRIPTION
FUNCTION
(continued)
Temp Fahren / Celsius Temperature display units
Settings White Bal
Red 000 - 255
White balance setting
Green 000 - 255
Blue 000 - 255
White 000 - 255
Amber 000 - 255
UV 000 - 255
Fan Mode
Auto
Fan settingLow
High
Fre Hz
900 Hz, 1000 Hz, 1100 Hz, 1200
Hz, 1300 Hz, 1400 Hz, 1500 Hz,
2500 Hz, 4000 Hz, 5000 Hz, 10
KHz, 15 KHz, 20 KHz, 25 KHz
Set LED refresh rate
Dim Curve
Linear
Set dimmer curve
S-Curve
Inv Square
Square
INFO
Time Info
Current Current running time
(hours)
Total Tim Total running times
(hours)
Last Clea Last time running times
was cleared (hours)
Timer PIN
Current Time
Clear
Password = 050
Total Time Clear
Password = 060
Temp Info xxx Current running tempera-
ture
Model Inf 32 Hex Panel Model name
Software Uxxx Current software version
SECONDARY Secondry Secondary mode setting
STROBE
MODE
Random 1
(All LED Strobing) Strobing
Random 2
(Zone Strobing)
CONTINUED ON NEXT PAGE

18
SYSTEM MENU
MENU SUBMENU OPTIONS / VALUES DESCRIPTION
MANUAL
Dimmer 000 - 255
Manual Control
All Red 000 - 255
All Green 000 - 255
All Blue 000 - 255
All White 000 - 255
All Amber 000 - 255
All UV 000 - 255
Red 1 000 - 255
Green 1 000 - 255
Blue 1 000 - 255
White 1 000 - 255
Amber 1 000 - 255
UV 1 000 - 255
Red 2 000 - 255
Green 2 000 - 255
Blue 2 000 - 255
White 2 000 - 255
Amber 2 000 - 255
UV 2 000 - 255
... ...
Red 8 000 - 255
Green 8 000 - 255
Blue 8 000 - 255
White 8 000 - 255
Amber 8 000 - 255
UV 8 000 - 255
Strobing 000 - 255

19
SYSTEM MENU
DMX Addressing:
Operating through a DMX controller gives the user the freedom to create custom programs tailored to
their own individual needs.
1. To run your xture in DMX mode, press the MODE button. Use the UP or DOWN buttons to scroll
to “Set Addr” and press ENTER. The current DMX address will now be displayed.
2. Use the UP or DOWN buttons to nd your desired DMX address, and press ENTER.
DMX Channel Modes:
Use this function to select your desired DMX channel mode. The 32 Hex Panel IP/32 Hex Panel IP
Pearl has 7 DMX channel modes: 6/10/11/16/48/57/96.
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons until “User
Mode” is displayed and press ENTER to conrm. The current DMX channel mode will now be
displayed.
2. Press the UP or DOWN buttons to scroll through the 7 DMX channel modes. When you have
found your desired DMX channel mode, press ENTER to conrm your selection or press the
MODE button to exit. Refer to the DMX Traits section of this manual for detailed information.
Dimmer Curve Setting:
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons until “Menu
Function” is displayed, then press ENTER. Press the UP or DOWN buttons until “DimCurve” is
displayed, and press ENTER.
2. Use the UP or DOWN buttons to scroll through the dimmer curves. Press ENTER to conrm your
selection, or press the MODE button to exit.
3. There are 5 dimmer curve settings to choose from. Refer to the Dimmer Curve Chart section of
this manual for detailed information.
DMX Lost Setting:
This mode is used to dene how the unit reacts when the DMX signal is lost or interrupted. It can also
be used to set the operating mode that the unit will default to when powered up.
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons until “Menu
Function” is displayed, and press ENTER. Press the UP or DOWN buttons until “NODMX” is dis-
played and press ENTER.
2. Use the UP and DOWN buttons to scroll through the 3 DMX standing states.
• “Hold” - The xture will stay in the last DMX set up.
• “Blackout” - The unit will automatically go into stand by mode.
• “Program” - The unit will automatically go into Auto Run mode.
3. Use the UP and DOWN buttons to nd your desired DMX state and press ENTER to conrm your
selection, or press the MODE button to exit without making changes.
Auto Run Mode:
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons so that “Menu
Function” is displayed, and press ENTER. Press the UP or DOWN buttons until “AUTO RUN
FQN” is displayed and press ENTER.
2. Use the UP or DOWN buttons to scroll through the 99 Auto Run programs. Press ENTER to con-
rm your selection or press the MODE button to exit.

20
SYSTEM MENU
Static Color Mode, Color Change Mode, and Color Fade Mode:
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons to scroll to
“Menu Function” and press ENTER. Press the UP or DOWN buttons until ONE of the following
running modes is displayed:
• “1. STATC” - Static Color Mode (Color adjustment and strobing)
• “2. CHANG” - 15 Color Change Mode (Color changing, change speed adjustment, & strobing)
• “3. CHANG” - 30 Color Change Mode (Color changing, change speed adjustment, & strobing)
• “4. FADE” - Color Fade Mode (Color fading, fade speed adjustment, & strobing)
2. Press the ENTER button to select your desired running mode. Use the UP and DOWN buttons
to make your desired adjustments. Press the ENTER button each time you are nished making
adjustments in the current running mode.
Color Macro Mode:
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons until “Menu
Function” is displayed, and press ENTER.
2. Press the UP or DOWN buttons until “Macros” is displayed and press ENTER.
3. There are 64 colors to choose from. Use the UP and DOWN buttons for nd your desired color.
4. Once you have found your desired color, press the ENTER button. Press the MODE button to exit.
LCD Display Settings:
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons until “Menu
Function” is displayed, and press ENTER.
2. Press the UP or DOWN buttons until “LCD.Set” is displayed and press ENTER.
3. Use the UP and DOWN buttons to scroll through the options, and press ENTER to make your
selection.
• Backlight - Set how long the backlight display will stay on.
• Key Lock - Control the key lock feature.
-“OFF” - The keypad is unlocked, simply press the MODE button to activate the keypad.
-“ON” - This is a simple keypad lock. “LOCKED *****” will be displayed. Press and hold the
MODE button for at least 5 seconds to unlock the keypad.
-“ON1” - This setting is used to prevent the accidental unlocking of the keypad. To unlock
the keypad you will have to enter a passcode. “LOCKED *****” will be displayed. To unlock
the keypad press UP, DOWN, UP, DOWN, & ENTER in that order.
• DisFlash - In this function you can activate the display ash.
Default Running Mode:
In this mode you can reset all function settings to their default modes.
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons until “Menu
Function” is displayed and press ENTER.
2. Press the UP or DOWN buttons until “DFSET” displayed, and press ENTER.
3. Use the UP or DOWN button to toggle between “ON’ and “OFF”. To reset to the default settings,
select “ON” and press ENTER.
