ADJ WiFly QA5 IP User manual

User Instructions
3/14
WiFly QA5 IP
©2013 ADJ Products, LLC all rights reserved. Information,
specications, diagrams, images, and instructions herein are
subject to change without notice. ADJ Products, LLC logo and
identifying product names and numbers herein are trademarks
of ADJ Products, LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information
now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or
registered trademarks of their respective companies and are
hereby acknowledged. All non-ADJ Products, LLC brands and
product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby dis-
claim any and all liabilities for property, equipment, building, and
electrical damages, injuries to any persons, and direct or indi-
rect economic loss associated with the use or reliance of any
information contained within this document, and/or as a result
of the improper, unsafe, unsucient and negligent assembly,
installation, rigging, and operation of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment.
Please turn o all electrical products when they are not in use. To
avoid power consumption in idle mode, disconnect all electrical
equipment from power when not in use. Thank you!

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 3
WiFly QA5 IP Introduction
ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 2
Unpacking: Thank you for purchasing the WiFly QA5 IP by ADJ Prod-
ucts, LLC. Every WiFly QA5 IP has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without rst contact-
ing customer support.
Introduction: The WiFly QA5 IP is an IP65 outdoor rated, DMX intel-
ligent, LED par fixture with ADJ’s WiFly TransCeiver with wireless DMX
built-in. This xture can be used in a stand alone mode or connected in
a Master/Slave conguration. This wash has six operating modes: Auto
Change mode, Auto Fade mode, Auto mode, RGBA mode, Static Color
mode, and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer support
line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
• Mulit-Colors
• Six Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 5 DMX Channel Modes: 4 Channel Mode, 5 Channel Mode,
6 Channel Mode, 10 Channel Mode, & 11 Channel Mode
• Built-In ADJ’s WiFly TransCeiver Wireless DMX
• ADJ RFC compatiable (Not Included)
• Power Cord Daisy Chain (See page 25)
WiFly QA5 IP Warranty Registration
WiFly QA5 IP Features
The WiFly QA5 IP carries a 2 year (730 Days) limited warranty. Please
fill out the enclosed warranty card to validate your purchase. All
returned service items whether under warranty or not, must be freight
pre-paid and accompany a return authorization (R.A.) number. The
R.A. number must be clearly written on the outside of the return pack-
age. A brief description of the problem as well as the R.A. number
must also be written down on a piece of paper included in the ship-
ping carton. If the unit is under warranty, you must provide a copy of
your proof of purchase invoice. You may obtain a R.A. number by con-
tacting our customer support team on our customer support number.
All packages returned to the service department not displaying a R.A.
number on the outside of the package will be returned to the shipper.
The unit should be mounted using a mounting clamp (not provided),
axing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip-
ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
WiFly QA5 IP Installation

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 5
WiFly QA5 IP Safety Precautions
ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 4
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 25 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu-
d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
CAUTION: This unit like any wireless device is highly susceptible
to static electricity. Static electricity can severly damage the unit.
Power Supply: The ADJ WiFly QA5 IP contains a automatic voltage
switch, which will auto sense the voltage when it is plugged into the
power source. With this switch there is no need to worry about the cor-
rect power voltage, this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal proto-
col used as a form of communication between intelligent fixtures and
controllers. A DMX controller sends DMX data instructions from the
controller to the fixture. DMX data is sent as serial data that travels
from fixture to fixture via the DATA “IN” and DATA “OUT” XLR termi-
nals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of
dierent manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compli-
ant. To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX Operation): The
WiFly QA5 IP can be controlled via DMX-512 protocol. The WiFly QA5
IP has 8 DMX channel modes, please see pages 9-10 for the dierent
modes. The DMX address is set on the back panel of the WiFly QA5 IP.
Your unit and your DMX controller require a standard 3-pin XLR connec-
tor for data input and data output (Figure 1). We
recommend Accu-Cable DMX cables. If you are
making your own cables, be sure to use standard
110-120 Ohm shielded cable (This cable may be
purchased at almost all pro lighting stores). Your
cables should be made with a male and female
XLR connector on either end of the cable. Also
remember that DMX cable must be daisy chained
and cannot be split.
WiFly QA5 IP Set Up
Figure 1

Notice: Be sure to follow gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not con-
nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
WiFly QA5 IP Set Up
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 2
Figure 3
1 Ground 1 Ground
XLR Male Socket
XLR Pin Conguration
3 Hot
2 Cold 2 Cold
3 Hot
XLR Female Socket
Pin 3 = Data True (positive)
Pin 2 = Data Compliment (negative)
Pin 1 = Ground
Special Note: Line Termination. When longer runs of cable are
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 4
5-Pin XLR DMX Connectors. Some manufactures use 5-pin DMX-
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Do Not Use
Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 7
ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 6
WiFly QA5 IP Operating Instructions
LED Display On/Off:
To set the LED display to turn off after 60 seconds, press the MODE but-
ton until “don” is displayed, press the UP button to display “doff”. Now
the display will disappear after 60s. Press any button to turn the display
on again. Be advised though that the display will turn off automatically
after 10 seconds.
To set the display press the MODE button until “dXX” is displayed. Use
the UP or DOWN buttons to select either:
“don” = LED display on at all times.
“doFF” = LED display shuts off after 60 seconds.
LED Display Inversion:
Follow these instructions to flip the display 180°so that the display can
be read upside down.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents either “on” or “oFF”.
2. Press the SET UP button until “Stnd” or “rev” is displayed.
3. Press the UP or DOWN buttons to reverse the display 180°.
Operating Modes:
The WiFly QA5 IP has six operating modes:
• Static Color Mode - There are 64 colors to choose from.
• RGBA Dimmer Mode - Choose one of the four colors to remain
static or adjust the intensity of each color to make your desired
color.
• Auto Change Mode - The unit will run 1 of 16 color change pro-
grams at your desired speed.
• Auto Fade Mode - The unit will run 1 of 16 color fade programs at
your desired speed.
• Auto Mode - The unit will run both color change and color fade at
your desired speed.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller such as
as the ADJ Show Designer™.
RGBA Dimmer Mode:
1. Plug the fixture in and press the MODE button until:
2. When “r.XXX” is displayed you are in Red dimming mode. Press
the UP and DOWN buttons to adjust intensity.

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 9
ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 8
WiFly QA5 IP Operating Instructions
3. When “G.XXX” is displayed you are in Green dimming mode.
Press the UP and DOWN buttons to adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode. Press
the UP and DOWN buttons to adjust intensity.
5. When “A.XXX” is displayed you are in Amber dimming mode.
Press the UP and DOWN buttons to adjust intensity.
6. After you have adjusted the RGBA colors to make your desired
color you can then activate strobing by pressing the SET UP but-
ton to enter the Flash (strobe) mode.
7. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Auto Change Mode:
1. Plug the fixture in and press the MODE button until “AJXX” is
displayed. “XX” is the displayed Color Change program that is
running.
2. Use the UP and DOWN button to scroll through the different pro-
grams.
3. After you have chosen your desired program press the SET UP
button. “SP.XX” will be displayed. When this is displayed you
can adjust the running speed of your selected program. Use the
UP or DOWN button to adjust the speed between “SP.01” (slow-
est) and “SP.16” (fastest). Once you have set your desired running
speed, press the SET UP button to return to your selected Auto
Change Mode.
Auto Fade Mode:
1. Plug the fixture in and press the MODE button until “AFXX” is
displayed. “XX” is the displayed Color Change program that is
running.
2. Use the UP and DOWN button to scroll through the different pro-
grams.
3. After you have chosen your desired program press the SET UP
button. “SP.XX” will be displayed. When this is displayed you
can adjust the running speed of your selected program. Use the
UP or DOWN button to adjust the speed between “SP.01” (slow-
est) and “SP.16” (fastest). Once you have set your desired running
speed, press the SET UP button to return to your selected Auto
Fade Mode.
WiFly QA5 IP Operating Instructions
Auto Run Mode:
1. Plug the fixture in and press the MODE button until “Auto” is
displayed.
2. To adjust the running speed of the Auto mode press the SET UP
button. “SP.XX” will be displayed. When this is displayed you
can adjust the running speed of your selected program. Use the
UP or DOWN button to adjust the speed between “SP.01” (slow-
est) and “SP.16” (fastest). Once you have set your desired running
speed, press the SET UP button to return to Auto Run Mode.
Static Color Mode:
1. Plug the fixture in and press the MODE button until “CLXX” is
displayed. “XX” represents the current color number displayed.
2. There are 64 colors to choose from. Select your desired color by
pressing the UP and DOWN buttons. After you have selected
your desired color you can activate strobing by pressing the SET
UP button to enter the Flash (strobe) mode.
3. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
DMX Mode:
Operating through a DMX controller gives the user the freedom to
create their own programs tailored to their own individual needs.
This function also allows you to use your fixtures as spot lights. The
WiFly QA5 IP has 5 DMX modes: 4 Channel mode, 5 Channel mode,
6 Channel mode, 10 Channel mode, and a 11 Channel mode. See
pages 18-23 for each modes’ DMX traits.
1. This function will allow you to control each individual fixture’s
traits with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
“d.XXX” is displayed. “XXX” represents the current displayed ad-
dress. Use the UP or DOWN buttons to select your desired DMX
address. then press the SET UP button to select your DMX
Channel mode.
3. When you press SET UP “ChXX” should be displayed. “XX” repre-
sent the current DMX Channel Mode.
4. Use the UP or DOWN buttons to scroll through the DMX Channel

WiFly QA5 IP Operating Instructions
modes. The Channel modes are listed below:
To run the 4 Channel Mode, press the MODE button until “Ch04”
is displayed. This is the 4 Channel DMX Mode.
To run the 5 Channel Mode, press the MODE button until “Ch05”
is displayed. This is the 5 Channel DMX Mode.
To run the 6 Channel Mode, press the MODE button until “Ch06”
is displayed. This is the 6 Channel DMX Mode.
To run the 10 Channel Mode, press the MODE button until “Ch10”
is displayed. This is the 10 Channel DMX Mode.
To run the 11 Channel Mode, press the MODE button until “Ch11”
is displayed. This is the 11 Channel DMX Mode.
5. Please see pages 18-23 for DMX values and traits.
6. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX control-
ler.
Default Running Mode:
This is a default running mode. When this mode is activated all modes
will return to their default settings.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents either “on” or “oFF”.
2. Press the SET UP button until “dEFA” is displayed.
3. Press the UP and DOWN buttons simultaneously. Press the
MODE button to exit.
ADJ RFC:
This function is used to activate and deactivate the ADJ RFC (Remote
Control). When this function is activated you can control the fixture
using the ADJ RFC. Please see the next page for ADJ RFC controls
and functions.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents “on” or “off”.
2. Press the SET UP button until “rFXX” is displayed. “XX” repre-
sents either “on” or “oF”.
3. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
WiFLY On/Off:
This function is used to turn the WiFly function on and off.
ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 11
ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 10
1. Plug the fixture in and press the MODE button until “rCXX” is dis-
played. “XX” represents a number between 00-15.
2. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
WiFLY Address:
This function is used to set the WiFly address. This address must
match the address that is set to WiFly TransCeiver or WiFly controller.
1. Plug the fixture in and press the MODE button until “rCXX” is dis-
played. “XX” represents a number between 00-15.
2. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
Dimmer Curve Setting:
1. Plug the fixture in and press the MODE button until “d.XXX” is dis-
played (DMX address setting). Press the SET UP button until
“dr-X” is displayed, “X” representing a number between 0-4.
2. There are 5 dimmer curve settings to choose from. Please see the
Dimmer Curve Diagram Chart on page 24 to see the settings and
their respective beginning and ending fade times.
WiFly QA5 IP Operating Instructions

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 13ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 12
WiFly QA5 IP Master-Slave Configuration
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave
mode. In Master-Slave operation one unit will act as the controlling unit
and the others will react to the controlling units built-in programs. Any
unit can act as a Master or as a Slave however, only one unit can be pro-
grammed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Set the “Master” unit to your desired mode of operation.
3. On the “Slave” units press the MODE button until “SLAu” is dis-
played. The unit is now set as the “Slave” unit. Each slave unit
must be set to the same setting.
4. Connect the rst “Slave” unit to the “Master”, and the “Slave” unit
should now start follow the “Master”.
WiFly QA5 IP WiFly Set Up
WiFly QA5 IP WiFly Master-Slave Set Up
With this feature you are able to control the unit with DMX without the need
of XLR cables. Your DMX controller must be connected to a ADJ WiFly
TransCeiver to use this function. You are able to communicate up to 400 feet
(open line of sight)
NOTE: The ADJ RFC control must be set to OFF to use this function.
See pages 10-11 to turn OFF ADJ RFC.
1. Turn on the WiFly function using the instructions on page 11.
2. Follow the instructions on page 11 to set the Wireless address. The
address must match the address set on the WiFly Transceiver.
3. After you have set the WiFly address, follow the DMX instructions on
pages 9-10 to select your desired DMX Channel mode and set your
DMX address.
4. Apply power to the ADJ WiFly Transceiver. The fixture must be set up
first before you apply power to WiFly Transceiver.
Note: If the sync does not work, switch the WiFly power off then on again.
This feature will let you link units to run in a master-slave mode without the
use of XLR cables.
NOTE: The ADJ RFC control must be set to OFF on all the units to use
this function. See pages 10-11 to turn OFF ADJ RFC.
1. Follow the instructions on page 11 to set the Wireless address. The
addresses on each fixture must be the same.
2. After you have set the WiFly address, select your master unit and set
your desired operating mode.
3. Turn on the WiFly function using the instructions on page 11.
4. For the Slave units, put the unit in Slave mode. See page 15 Master-
Slave configuration when setting the unit as a Slave. Then switch ON the
WiFly power switch.
NOTE: If they do not sync up master-slave, switch the Master fixtures
WiFly power switch off then on again.

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 15
WiFly QA5 IP ADJ RFC Operation
The ADJ RFC remote (sold seperately) has many different functions and
allows you to control your WiFly QA5 IP from long distance. The ADJ
RFC remote can control your system up to 150 ft. To use the RFC you
must first activate the fixtures receiver, to activate the receiver please
see the instructions on page 14.
BLACKOUT - Pressing this button will blackout the fixture.
AUTO RUN -This button will run an automatic program. There are 3
Auto Run programs to choose from. Each press of the button will switch
between the different modes. You can control the speed of the Auto Run
modes by pressing the SPEED button and then pressing the “+” and “-”
buttons.
• AFXX = Color Fade mode, there are 16 Color Fade modes to choose
from. Use the UP or DOWN buttons to scroll through the different
Auto Fade modes.
• AJXX = Color Change mode, there are 16 Color Change modes to
choose from. Use the UP or DOWN buttons to scroll through the
different Auto Change modes.
• A-JF = Both Color Fade and Color Change modes running.
PROGRAM SELECTION - Press this button to switch between Static
Color mode and Slave mode. Each press of this button will switch be-
tween the two modes. When in Static Color mode, use the “+” or “-” to
scroll through the 64 colors. Once you have found your color, you can
press the FLASH button to activate strobing and use the “+” or “-” to ad-
just the Flash rate.
FLASH - This button will activate the flash (strobe) effect. You can con-
trol the flash speed by pressing the “+” and “-” buttons.
SPEED - Press this button and use the “+” & “-” buttons to adjust the
speed of the Auto run mode.
R G B W/A - Press either one of these buttons and the press the “+” or
“-” to adjust the brightness. Press the FLASH button to activate strobing
and use the “+” or “-” to adjust the Flash rate.
“+” and “-” - Use these buttons to adjust the flash rate, speed of the
Auto Run mode, Auto Run program selection, sound sensitivity, and
color select.
ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 14
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
WiFly QA5 IP 5 Channel - DMX Values & Functions
WiFly QA5 IP 4 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 17ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 16
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
6 STROBING
0 OFF
1 - 255 STROBING SLOW - FAST
WiFly QA5 IP 6 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
6 STROBING
0 OFF
1 - 255 STROBING SLOW - FAST
7 PROGRAM SELECTION MODE
0 - 51 DIMMING MODE
52 - 102 COLOR MACRO MODE
103 - 153 COLOR CHANGE MODE
154 - 204 COLOR FADE MODE
205 - 255 AUTO RUN MODE
8 COLOR MACROS/PROGRAMS/
0 - 255 COLOR MACRO MODE
(See 1 Channel DMX mode for colors)
COLOR CHANGE MODE
0 - 15 COLOR CHANGE 1
16 - 31 COLOR CHANGE 2
32 - 47 COLOR CHANGE 3
48 - 63 COLOR CHANGE 4
64 - 79 COLOR CHANGE 5
80 - 95 COLOR CHANGE 6
96 - 111 COLOR CHANGE 7
112 - 127 COLOR CHANGE 8
128 - 143 COLOR CHANGE 9
144 - 159 COLOR CHANGE 10
WiFly QA5 IP 10 Channel - DMX Values & Functions

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 19ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 18
When Channel 7 is between the values of 0-51, Channels 1-4 are
used, and Channel 6 will control strobing.
When Channel 7 is between the values of 52-102, Channel 8 is in
Color Macros Mode, and Channel 6 will control strobing.
When Channel 7 is between the values of 103-153, Channel 8 is in
Color Change Mode, and Channel 9 will control the color change
speed.
When Channel 7 is between the values of 154-204, Channel 8 is
in Color Fade Mode, and Channel 9 will control the color fade
speed.
When Channel 7 is between the values of 205-255, Channel 8 is in
Auto Run Mode, and Channel 9 will control the auto run speed.
Channel Value Function
10 DIMMER CURVES
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATER
101 - 255 DEFAULT TO UNIT CURVE SETTING
WiFly QA5 IP 10 Channel - DMX Values & Functions
Channel Value Function
8 COLOR CHANGE MODE CONT.
160 - 175 COLOR CHANGE 11
176 - 191 COLOR CHANGE 12
192 - 207 COLOR CHANGE 13
208 - 223 COLOR CHANGE 14
224 - 239 COLOR CHANGE 15
240 - 255 COLOR CHANGE 16
COLOR FADE MODE
0 - 15 COLOR FADE 1
16 - 31 COLOR FADE 2
32 - 47 COLOR FADE 3
48 - 63 COLOR FADE 4
64 - 79 COLOR FADE 5
80 - 95 COLOR FADE 6
96 - 111 COLOR FADE 7
112 - 127 COLOR FADE 8
128 - 143 COLOR FADE 9
144 - 159 COLOR FADE 10
160 - 175 COLOR FADE 11
176 - 191 COLOR FADE 12
192 - 207 COLOR FADE 13
208 - 223 COLOR FADE 14
224 - 239 COLOR FADE 15
240 - 255 COLOR FADE 16
0 - 255 AUTO RUN MODE
9 PROGRAM SPEED
0 - 255 SPEED CONTROL SLOW - FAST
WiFly QA5 IP 10 Channel - DMX Values & Functions
See the next page for Channel 10 values and traits.

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 21ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 20
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
6 STROBING
0 OFF
1 - 255 STROBING SLOW - FAST
7 PROGRAM SELECTION MODE
0 - 51 DIMMING MODE
52 - 102 COLOR MACRO MODE
103 - 153 COLOR CHANGE MODE
154 - 204 COLOR FADE MODE
205 - 255 AUTO RUN MODE
8 COLOR MACROS/PROGRAMS/
0 - 255 COLOR MACRO MODE
(See 1 Channel DMX mode for colors)
COLOR CHANGE MODE
0 - 15 COLOR CHANGE 1
16 - 31 COLOR CHANGE 2
32 - 47 COLOR CHANGE 3
48 - 63 COLOR CHANGE 4
64 - 79 COLOR CHANGE 5
80 - 95 COLOR CHANGE 6
96 - 111 COLOR CHANGE 7
112 - 127 COLOR CHANGE 8
128 - 143 COLOR CHANGE 9
144 - 159 COLOR CHANGE 10
WiFly QA5 IP 11 Channel - DMX Values & Functions
Channel Value Function
8 COLOR CHANGE MODE CONT.
160 - 175 COLOR CHANGE 11
176 - 191 COLOR CHANGE 12
192 - 207 COLOR CHANGE 13
208 - 223 COLOR CHANGE 14
224 - 239 COLOR CHANGE 15
240 - 255 COLOR CHANGE 16
COLOR FADE MODE
0 - 15 COLOR FADE 1
16 - 31 COLOR FADE 2
32 - 47 COLOR FADE 3
48 - 63 COLOR FADE 4
64 - 79 COLOR FADE 5
80 - 95 COLOR FADE 6
96 - 111 COLOR FADE 7
112 - 127 COLOR FADE 8
128 - 143 COLOR FADE 9
144 - 159 COLOR FADE 10
160 - 175 COLOR FADE 11
176 - 191 COLOR FADE 12
192 - 207 COLOR FADE 13
208 - 223 COLOR FADE 14
224 - 239 COLOR FADE 15
240 - 255 COLOR FADE 16
0 - 255 AUTO RUN MODE
9 PROGRAM SPEED
0 - 255 SPEED CONTROL SLOW - FAST
10 COLOR TEMPERATURE
0 - 28 3200K
29 - 57 3700K
58 - 86 4200K
87 - 114 4700K
115 - 142 5200K
WiFly QA5 IP 11 Channel - DMX Values & Functions

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 23ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 22
Channel Value Function
10 COLOR TEMPERATURE
143 - 170 5700K
171 - 198 6200K
199 - 226 6700K
227 - 255 7200K
11 DIMMER CURVES
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATER
101 - 255 DEFAULT TO UNIT CURVE SETTING
WiFly QA5 IP 11 Channel - DMX Values & Functions
When Channel 7 is between the values of 0-51, Channels 1-4 are
used, and Channel 6 will control strobing.
When Channel 7 is between the values of 52-102, Channel 8 is in
Color Macros Mode, and Channel 6 will control strobing.
When Channel 7 is between the values of 103-153, Channel 8 is in
Color Change Mode, and Channel 9 will control the color change
speed.
When Channel 7 is between the values of 154-204, Channel 8 is
in Color Fade Mode, and Channel 9 will control the color fade
speed.
When Channel 7 is between the values of 205-255, Channel 8 is in
Auto Run Mode, and Channel 9 will control the auto run speed.
WiFly QA5 IP Color Macro Chart
Color No. DMX
VAULE
RGBA COLOR INTENSITY Color No. DMX
VAULE
RGBA COLOR INTENSITY
RED GREEN BLUE AMBER RED GREEN BLUE AMBER
Color1(off) 0 0 0 0 0 Color34 129-132 255 206 143 0 Color2 1-4 80 255 234 80 Color35 133-136 254 177 153 0 Color3 5-8 80 255 164 80 Color36 137-140 254 192 138 0 Color4 9-12 77 255 112 77 Color37 141-144 254 165 98 0 Color5 13-16 117 255 83 83 Color38 145-148 254 121 0 0 Color6 17-20 160 255 77 77 Color39 149-152 176 17 0 0 Color7 21-24 223 255 83 83 Color40 153-156 96 0 11 0 Color8 25-28 255 243 77 77 Color41 157-160 234 139 171 0 Color9 29-32 255 200 74 74 Color42 161-164 224 5 97 0 Color10 33-36 255 166 77 77 Color43 165-168 175 77 173 0 Color11 37-40 255 125 74 74 Color44 169-172 119 130 199 0 Color12 41-44 255 97 77 74 Color45 173-176 147 164 212 0 Color13 45-48 255 71 77 71 Color46 177-180 88 2 163 0 Color14 49-52 255 83 134 83 Color47 181-184 0 38 86 0 Color15 53-56 255 93 182 93 Color48 185-188 0 142 208 0 Color16 57-60 255 96 236 96 Color49 189-192 52 148 209 0 Color17 61-64 238 93 255 93 Color50 193-196 1 134 201 0 Color18 65-68 196 87 255 87 Color51 197-200 0 145 212 0 Color19 69-72 150 90 255 90 Color52 201-204 255 0 0 0 Color20 73-76 100 77 255 77 Color53 205-208 0 255 0 0 Color21 77-80 77 100 255 77 Color54 209-212 0 83 115 0 Color22 81-84 67 148 255 67 Color55 213-216 0 97 166 0 Color23 85-88 77 195 255 77 Color56 217-220 1 100 167 0 Color24 89-92 77 234 255 77 Color57 221-224 0 40 86 0 Color25 93-96 158 255 144 144 Color58 225-228 209 219 182 0 Color26 97-100 255 251 153 153 Color59 229-232 42 165 85 0 Color27 101-104 255 175 147 147 Color60 233-236 0 46 35 0 Color28 105-108 255 138 186 138 Color61 237-240 8 107 222 0 Color29 109-112 255 147 251 147 Color62 241-244 107 156 231 0
Color30 113-116 151 138 255 138 Color63 245-248 165 198 247 0 Color31 117-120 151 138 255 138 Color64 249-252 0 0 255 0 Color32 121-124 138 169 255 138 Color65 253-255 0 0 0 255 Color33 125-128 255 255 255 255

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 24 ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 25
WiFly QA5 IP Dimmer Curve Chart
100
100
100
100 %
%
%
%
50
50
50
50 %
%
%
%
0
0
0
0
10
10
10
10 %
%
%
%
T ris e
T dow n
t
t
t
t
(
(
(
(
ms
ms
ms
ms )
)
)
)
Dimmer
Dimmer
Dimmer
Dimmer
Delay mode
DMX delay Trise(ms) Tdown(ms)
dr-0 0 0
dr-1 800 1300
dr-2 1010 1560
dr-3 1200 1950
dr-4 1280 2600
WiFly QA5 IP Trouble Shooting
Listed below are a few common problems the user may encounter,
with solutions.
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are
wired correctly (pin 3 is “hot”; on some other DMX devices
pin 2 may be ‘hot’). Also, check that all cables are connected
to the right connectors; it does matter which way the inputs
and outputs are connected.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
2. Make sure that Sound Active mode is activated.
WiFly QA5 IP Cleaning
Due to fog residue, smoke, and dust cleaning the internal and exter-
nal optical lenses must be carried out periodically to optimize light
output.
1. Use normal glass cleaner and a soft cloth to wipe down the
outside casing.
2. Clean the external optics with glass cleaner and a soft cloth
every 20 days.
3. Always be sure to dry all parts completely before plugging
the unit back in.
Cleaning frequency depends on the environment in which the fixture
operates (i.e. smoke, fog residue, dust, dew).
WiFly QA5 IP Photometric Chart
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 15 xtures maximum. After the maximum xtures
has been reached you will need to use a new power outlet. They
must be the same xtures. DO NOT mix xtures.
WiFly QA5 IP Power Cord Daisy Chain

ADJ Products, LLC - www.adj.com - WiFly QA5 IP User Manual Page 26
WiFly QA5 IP Specifications
Model: WiFly QA5 IP
Voltage: 100V ~ 240V/50~60Hz
LEDs: 5 x 5W Quad LEDs (RGBA 4-in-1)
IP Rating: 65
Beam Angle: 40 Degrees
Working Position: Any safe working position
Power Draw: 35W
Power Cord Daisy Chain: 15 Fixtures Max.
Weight: 10lbs./ 4.2Kgs.
Dimensions: 10” (L) x 7.5” (W) x 12” (H)
250 x 190 x 300mm
Colors: RGBA Color Mixing
DMX Channels: 5 DMX Modes: 4 Channel Mode, 5
Channel Mode, 6 Channel Mode,
10 Channel Mode, & 11 Channel
Mode
Warranty: 2 Year (730 days)
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: [phone] / Fax: [phone]
Web: www.adj.com / E-mail: [email protected]
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
Netherlands
[email protected] / www.adj.eu
Tel: [phone] / Fax: [phone]
WiFly QA5 IP Warranty
MANUFACTURER’S LIMITED WARRANTY
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products
to be free of manufacturing defects in material and workmanship for a prescribed period from
the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the
product is purchased within the United States of America, including possessions and
territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#) before sending back the
product–please contact ADJ Products, LLC Service Department at 800-322-6337. Send the product
only to the ADJ Products, LLC factory. All shipping charges must be pre-paid. If the requested repairs or
service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay
return shipping charges only to a designated point within the United States. If the entire instrument is
sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If
any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for
loss of or damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modified in any
manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the
product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior
written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because
not properly maintained as set forth in the instruction manual.
D. This is not a service contract, and this warranty does not include maintnance, cleaning or periodic check
up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense
with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by
reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this
warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole
discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August
15, 2012, and bear indentifying marks to that effect.
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products
without any obligation to include these changes in any products theretofore manufactured.
No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with
products described above. Except to the extent prohibited by applicable law, all implied warranties made
by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness,
are limited in duration to the warranty period set forth above. And no warranties, whether expressed or
implied, including warranties of merchantability or fitness, shall apply to this product after said period
has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is
expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or
damage, direct or consequential, arising out of the use of, or inability to use, this product.
This warranty is the only written warranty applicable to ADJ Products, LLC Products and
supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore
published.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
 •LightingProducts=1-year(365days)LimitedWarranty(Such as: Special Effect Lighting, Intelligent
Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing,
Lighting Stands etc. excluding LEDs and lamps)
 •LaserProducts=90-DayLimitedWarranty
 •L.E.D.Products=2-year(730days)LimitedWarranty(excluding motors, PCB boards, and power
supplies, which have a 1-year (365 day Limited Warranty) and batteries which have a 180 day
limited warranty).
