Q7-BASE
Technical Reference
Qseven Reference Carrier Board
Revision: 3.00
Revision Date: October 03, 2017
Part Number: 50-1Z180-1020

ii Preface
Preface
Disclaimer
Information in this document is provided in connection with ADLINK products. No license,
express or implied, by estoppel or otherwise, to any intellectual property rights is granted by
this document. Except as provided in ADLINK´s Terms and Conditions of Sale for such prod-
ucts, ADLINK assumes no liability whatsoever, and ADLINK disclaims any express or implied
warranty, relating to sale and/or use of ADLINK products including liability or warranties relat-
ing to fitness for a particular purpose, merchantability, or infringement of any patent, copy-
right or other intellectual property right. If you intend to use ADLINK products in or as medical
devices, you are solely responsible for all required regulatory compliance, including, without
limitation, Title 21 of the CFR (US), Directive 2007/47/EC (EU), and ISO 13485 & 14971, if
any. ADLINK may make changes to specifications and product descriptions at any time, with-
out notice.
Trademarks
Product names mentioned herein are used for identification purposes only and may be trade-
marks and/or registered trademarks of their respective companies.
Revision History
© Copyright 2015, 2016, 2017 ADLINK Technology, Incorporated
www.adlinktech.com
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or other
means in any form without prior written permission of the manufacturer.
Audience
This manual provides reference only for computer design engineers, including but not limited
to hardware and software designers and applications engineers. ADLINK Technology, Inc.
assumes you are qualified to design and implement prototype computer equipment.
Revision Date Description of Change(s)
1.00 April 2015 Initial Release
2.00 8/26/2016 Revised content to reflect new board layout
3.00 10/03/2017 Revised content to reflect Version 2.1 of the Qseven Specification

Preface iii
Q7-BASE
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global environmental preservation
through compliance with the European Union's Restriction of Hazardous Substances (RoHS)
directive and Waste Electrical and Electronic Equipment (WEEE) directive. Environmental
protection is a top priority for ADLINK. We have enforced measures to ensure that our prod-
ucts, manufacturing processes, components, and raw materials have as little impact on the
environment as possible. When products are at their end of life, our customers are encour-
aged to dispose of them in accordance with the product disposal and/or recovery programs
prescribed by their nation or company.
Important Safety Instructions
For user safety, please read and follow all Instructions, WARNINGs, CAUTIONs, and
NOTEs marked in this manual and on the associated equipment before handling/operating
the equipment.
Read these safety instructions carefully.
Keep this manual for future reference.
Read the specifications section of this manual for detailed information on the operating
environment of this equipment.
Turn off power and unplug any power cords/cables when installing/mounting or un-install-
ing/removing equipment.
To avoid electrical shock and/or damage to equipment:
Keep equipment away from water or liquid sources;
Keep equipment away from high heat or high humidity;
Keep equipment properly ventilated (do not block or cover ventilation openings);
Make sure to use recommended voltage and power source settings;
Always install and operate equipment near an easily accessible electrical socket-
outlet;
Secure the power cord (do not place any object on/over the power cord);
Only install/attach and operate equipment on stable surfaces and/or recommended
mountings; and,
If the equipment will not be used for long periods of time, turn off the power source and
unplug the equipment.

iv Preface
Conventions
The following conventions may be used throughout this manual, denoting special levels of
information.
This information adds clarity or specifics to text
and illustrations.
This information indicates the possibility of minor
physical injury, component damage, data loss,
and/or program corruption.
This information warns of possible serious physi-
cal injury, component damage, data loss, and/or
program corruption.

v
Q7-BASE
Table of Contents
1 Product Overview............................................................................................................. 1
1.1 Carrier Description................................................................................................................. 1
1.2 Features................................................................................................................................. 2
1.3 Ordering Information.............................................................................................................. 3
1.4 Block Diagram........................................................................................................................ 3
1.5 Specifications......................................................................................................................... 4
1.5.1 Physical ............................................................................................................................4
1.5.2 Electrical ............................................................................................................................4
1.5.3 Environmental....................................................................................................................4
1.5.4 Mechanical ........................................................................................................................5
2 Hardware........................................................................................................................... 7
2.1 Interface Headers, Jumper Headers, Switches, LEDs, and Connectors............................... 7
2.2 Standard Hardware References .......................................................................................... 16
2.2.1 Audio IO Jack ..................................................................................................................16
2.2.2 PCIe Mini Card Slot.........................................................................................................17
2.2.3 SD Card Slot....................................................................................................................17
2.2.4 Battery Socket .................................................................................................................18
3 Interfaces ........................................................................................................................ 19
3.1 ATX Power (CN1)................................................................................................................ 19
3.2 Manufacturing (CN2)............................................................................................................ 20
3.3 ATX / BattMan +5V Standby Mode Select (CN3) ................................................................ 20
3.4 ATX / BattMan +5V Power Good Mode Select (CN4) ......................................................... 20
3.5 Smart Battery (BattMan) Interface (CN5)............................................................................. 21
3.6 Post Code Enable (CN8) ..................................................................................................... 21
3.7 eDP Display......................................................................................................................... 22
3.7.1 eDP0 (CN10)...................................................................................................................22
3.7.2 eDP1 (CN11)...................................................................................................................23
3.8 PS/2 Power Source Select (CN20)...................................................................................... 24
3.9 COM1 / COM2 (CN39)......................................................................................................... 25
3.10 PCI Express x1 (CN42, CN44, CN45)................................................................................. 26
3.11 Digital Audio (CN46)............................................................................................................ 26
3.12 USB Signals......................................................................................................................... 27
3.12.1 Standard USB Interfaces................................................................................................27
3.12.2 USB1 ..............................................................................................................................27
3.12.3 USB2 ..............................................................................................................................27
3.12.4 USB3 ..............................................................................................................................27
3.13 CAN (Controller Area Network - CN50)............................................................................... 28
3.14 CAN Termination (CN51)..................................................................................................... 28
3.15 CPLD Programming (CN52)................................................................................................ 29
3.16 FAN Control (CN53)............................................................................................................. 29
3.17 Battery Enable (CN57)......................................................................................................... 29
3.18 Backlight Voltage Select (CN59).......................................................................................... 30
3.19 Keyboard Controller Enable (CN61).................................................................................... 30

vi
3.20 LCD Supply Voltage Select (CN62) .................................................................................... 30
3.21 ATX PS_ON Selection (CN63)............................................................................................ 31
3.22 USB0 Voltage Select (CN64).............................................................................................. 31
3.23 LVDS Backlight (CN65)....................................................................................................... 31
3.24 LVDS Interface (CN66) ....................................................................................................... 32
3.25 SIO Enable (CN69) ............................................................................................................. 33
3.26 UART Interface (CN70)....................................................................................................... 33
3.27 LPT Interface (CN71).......................................................................................................... 34
3.28 System Interface (CN73)..................................................................................................... 34
3.29 CAN 5-Volt Enable (CN77).................................................................................................. 35
3.30 LPC / TPM Interface (CN78)............................................................................................... 35
3.31 Fan Voltage Select (CN79) ................................................................................................. 35
3.32 USB1 Voltage Select (CN80).............................................................................................. 36
3.33 ATX_PWRGD Mode Select (CN81).................................................................................... 36
3.34 DisplayPort (CN84) ............................................................................................................. 36
3.35 Display Mode Select (CN85)............................................................................................... 37
3.36 I2S (CN86) .......................................................................................................................... 37
3.37 HDA_SYNC / I2S_WS Select (CN87)................................................................................. 37
3.38 HDA_RST# / I2S_RST# Select (CN88) .............................................................................. 38
3.39 HDA_BITCLK / I2S_CLK Select (CN89)............................................................................. 38
3.40 HDA_SDO / I2S_SDO Select (CN90)................................................................................. 38
3.41 HDA_SDI / I2S_SDI Select (CN91)..................................................................................... 38
3.42 EN_V3P3S Select (CN92)................................................................................................... 39
3.43 USB3_CN_p / USB3_mPCIe_p Select (CN93)................................................................... 39
3.44 USB3_CN_n / USB3_mPCIe_n Select (CN94)................................................................... 39
3.45 USB OTG Power Control (CN95)........................................................................................ 39
3.46 USB_VBUS Source Select (CN96)..................................................................................... 40
3.47 PWM Backlight Voltage Select (CN97)............................................................................... 40
3.48 eDP1 Backlight Control (CN98)........................................................................................... 40
3.49 eDP1 Backlight Enable (CN99)........................................................................................... 40
3.50 I2C EEPROM Address Select Switch (SW6)...................................................................... 41
3.51 SPI EEPROM Select Interface Switch (SW9)..................................................................... 41
3.52 DP Control Switch (SW11).................................................................................................. 41
3.53 DP Enable Switch (SW12) .................................................................................................. 42
3.54 eDP0 Enable Switch (SW14) .............................................................................................. 42
3.55 eDP0 Operation Switch (SW15).......................................................................................... 42
3.56 eDP0 Control Switch (SW16).............................................................................................. 43
3.57 eDP1 Enable Switch (SW17) .............................................................................................. 43
3.58 eDP1 Operation Switch (SW18).......................................................................................... 43
3.59 eDP1 Control Switch (SW19).............................................................................................. 44
3.60 I2C EEPROM Address Interface Select Switch (SW20)..................................................... 44
Appendix A Technical Support .........................................................................................45

Product Overview 1
Q7-BASE
1 Product Overview
This chapter presents a general overview of the Q7-BASE carrier. After reviewing this chapter
you should understand the following features of the Q7-BASE carrier board.
Carrier Description
I/O Features
Functional Block Diagram
Carrier Specifications
1.1 Carrier Description
The ADLINK Q7-BASE is the host carrier board for ADLINK’s Qseven modules and serves as
design reference for systems based on the Qseven form factor. The Qseven module plugs
directly into the Q7-BASE, where the carrier board becomes a design platform for testing and
developing your applications. Figure 1-1 provides an overview photo of the Q7-BASE interface
hardware. The proceeding sections and chapters in this manual present these features in fur-
ther detail.
Figure 1-1: Q7-BASE IO Overview
The ADLINK Q7-BASE supports the features of Qseven Hardware Specification Version 2.1.
The following section presents a list of features of the Q7-BASE.

2Product Overview
1.2 Features
Qseven interface MXM connector
PCI Express Bus
4x PCIE x1 links
3x PCIE x1 slots
1x PCIE Mini slot
Serial Port UART interfaces (2)
Null Modem RS-232 on serial ports COM1 / COM2
4-wire connectors
COM1 / COM2 interfaces on two 9-pin, DB9 connectors
USB interfaces
One USB, 4-connector stack for ports 2 through 5 (USB 2.0)
One USB dual connector for ports 0, 1, 6, and 7 (USB 2.0/3.0)
One mini-USB for USB 2.0 OTG or client
Gigabit Ethernet interface
One standard RJ-45 connector
Activity/Link and Speed LED on Ethernet connector
SDMMC interface
One SDMMC slot, 4.x (for SD card)
Audio interfaces
Supports HD Audio and AC'97
One 3-in-1 stack audio jack for HD audio with Line In-Out / MIC
One 4-pin, digital audio header for SPDIF Input / Output
One I2S audio header
Video interfaces
One dual-channel LVDS header (18/24-bit)
One LVDS backlight header
One standard DisplayPort connector
One standard HDMI connector
Two optional eDP connectors
Power interface
One ATX Power In connector (all standard voltages available to baseboard headers)
+5 Volts needed to power Qseven module
One header for BattMan smart battery
Fan interfaces
One fan power header
One fan function header
SATA interfaces
Two standard SATA3 connectors
One SATA power LED
CAN interface
One CAN header
SPI System interfaces
One SPI System header

Product Overview 3
Q7-BASE
Miscellaneous
Smart Battery
RTC Battery Socket
Control Buttons and Switches
1.3 Ordering Information
1.4 Block Diagram
Figure 1-2 presents a functional representation of the carrier.
Figure 1-2: Functional Block Diagram
Table 1-1: Q7-BASE Models
Model Number Description
Q7-BASE LVDS
(91-77A02-000E or higher) Qseven Reference Carrier for Qseven compliant modules, featuring
an MXM2 230-pin module interface with LVDS display support.
Q7-BASE eDP
(91-77A02-010E or higher) Qseven Reference Carrier for Qseven compliant modules, featuring
an MXM2 230-pin module interface with eDP display support.
Qseven
Module
(MXM2
Connector)
4x
USB2.0
Super I/O
USB po rts a,b,c,d
HDA
2x
USB3.0
USB po rts x, y
Ethernet
RJ45
GbE
HDA Codec
ALC888
Mini USB
(device)
USB po rt1
Pin
Header
2x10
SO8
socket
SD/MMC
Socket
CAN
(D -Su b9 )
Pin
Header
2x4
Pin
Header
2x17
2x COM
LPT
2x PS2
LPC/TPM connector
POST Code
CPLD
7 Segment
Display
LPC
Line in/out, Mic
S/PDIF in/out
HDMI or DP
HDMI/DP
eDP
40pin
header
eDP
40pin
header
eDP
eDP
DIL8
Socket
SAT A
SAT A
PCI e x 1
Pin
Header
2x17
PCI e x 1
PCI e x 1
UART
PCIe port4
PCIe port3
PCIe port1
SATA1
SATA0
I2C
Du al Cha nnel LVDS
Backlight
CAN
SDIO 4bit
PCI e
MiniCard
PCIe port2
Misc
SMB
SPI
USB po rt3
Q7-BASE R1_B2_blk_diag_d

4Product Overview
1.5 Specifications
1.5.1 Physical
Table 1-2 lists the physical dimensions of the baseboard.
1.5.2 Electrical
Table 1-3 specifies the voltage input characteristics of the carrier.
1.5.3 Environmental
Most components on the Q7-BASE carrier are selected as extended temperature range parts
(-40°C to +85°C). Some components are not available in this temperature range. In these
cases, the component temperature ranges are narrower. The Q7-BASE is validated in the -40°C
to +85°C range.
The overall system performance depends on the combination of module and carrier subsys-
tems. Some Qseven modules are available in the industrial temperature range. Others are com-
mercial temperature range parts. Similar considerations apply to any of the add-on cards or
peripherals that are used with the Q7-BASE.
Table 1-4 defines the environmental conditions under which the carrier is qualified to operate
and to be stored.
Table 1-2: Weight and Footprint Dimensions
Item Dimension Overall height is measured from the upper board
surface to the top of the highest permanent
component on the upper board surface. This
measurement does not include the cooling solution,
which can vary. The cooling solution will probably
increase this dimension.
Weight 0.32 kg
Height (overall) 38.00 mm
PCB thickness 2.00 mm
Width 170.00 mm
Length 237.00 mm
Table 1-3: Carrier Voltage Inputs
Parameter Value
Standard 12V +/-5% and 5V +/-5% from ATX connector
RTC Battery 3.0V, 2.4V to 3.3V (battery), +/-20mV ripple
BattMan Supply 12V +/-5% (3A max), 5.0V +/-5% (4A max), +/-50mV ripple
Table 1-4: Validated Temperature and Humidity Ranges
Parameter Temperature
Temperature
Standard
Storage -40°C to +85°C
-55°C to +85°C
Humidity
Operating
Non-operating 5% to 90% relative humidity, non-condensing
5% to 95% relative humidity, non-condensing

Product Overview 5
Q7-BASE
1.5.4 Mechanical
Figure 1-3 provides the mechanical dimensions and mounting hole sizes of the Q7-BASE. The
Q7-BASE can be mounted to a chassis using M4, B-head screws. Mezzanine cards can be
mounted to the carrier using female-female standoffs with M2.5 threads and M2.5, B-head
screws.
Figure 1-3: Mechanical Dimensions (Top Side)
34
2xM2.5
2 x M2.5
237.5
2.35
177.97
17.90
73.25
9.42
64.8
170
24.18
33.91
69.72
237
54
165.10
33.02
10.16
6x
(TopandBottom)
13.71
230.73
5.5
2.7
5
2x
2x
7.5
7.5
3.2
(Topa
nd Bottom)
7x
123.55
5.2
4
64
6
2x
58.42
87.81
185.88
Q7-BASE R1_B2_Carrier_Mech_Dmn_c
2
2

6Product Overview
This page intentionally left blank.

Hardware 7
Q7-BASE
2 Hardware
This chapter describes the physical specifications of the interface connectors, headers, LEDs,
and switches on the Q7-BASE. The third section of this chapter further describes the industry
standard IO hardware on the carrier.
2.1 Interface Headers, Jumper Headers, Switches, LEDs, and Connectors
Table 2-1 describes the headers, switches, LEDs, and connectors for the Q7-BASE carrier
shown in Figure 2-1 and Figure 2-3
Table 2-1: Header, Connector, Switch, and LED Descriptions
Header /
Connector# Signal / Device Description
AJ1 Audio Jack 13-pin standard audio jack for three HD audio signals: Line
In (Blue), Line Out (Green), and MIC In (Pink)
[FOXXCONN, JA33331-HA1P-4F]
BT1 Battery Socket 3-pin, 220V socket for CR2032 battery that runs at 3V
[LOTES, AAA-BAT-038-K01]
CN1 ATX Power 24-pin, 0.165"(4.2mm) ATX standard shrouded connector
for ATX power signals
[ALEX, 9359-24]
CN2 Manufacturing 6-pin, 2mm jumper header reserved for manufacturing use
[JIHVEI, 27S1001-OPS35-01G-B, BLACK]
CN3 ATX / BattMan +5V
Standby Select 3-pin, 2.0mm jumper header for selecting ATX or BattMan +5V Standby mode
[JIH21N12050-03S10B-01G-4/2.8-G]
CN4 ATX / BattMan +5V
Power Good Select 2-pin, 2.0mm jumper header for selecting ATX or BattMan +5V Power Good mode
[JIH21N12050-02S10B-01G-4]
CN5 Smart Battery 10-pin, 2.54 box header for BattMan signals
[JIHVEI, 23N6960-10S10B-01G-G, BLACK]
CN8 Post Code Enable 3-pin, 2.0mm jumper header for enabling or disabling Post
Code 80h / 81h
[JIH21N12050-03S10B-01G-4/2.8-G]
CN10 eDP0 40-pin, 0.5mm right-angle connector for embedded Display
Port I/O (Featured on only the eDP version of the carrier)
[I-PEX, 20455-040E-12]
CN11 eDP1 40-pin, 0.5mm right-angle connector for embedded Display
Port I/O (Featured on only the eDP version of the carrier)
[I-PEX, 20455-040E-12]
CN20 PS/2 Power Source
Select 3-pin, 2.0mm jumper header for selecting PS/2 WAKE power source
[JIH21N12050-03S10B-01G-4/2.8-G]
CN39 COM1/COM2 Dual 9-pin, 0.109"(2.77mm) standard DB9 connectors for
COM1 and COM2 serial ports
[FOXXCONN, DM10151-H531-4F]
CN42, CN44,
CN45 PCI Express 36-pin, 0.039"(1mm) standard edge connector for PCI
Express x1 interface
[FOXXCONN, 2EG01817-D2D-DF]
CN46 Digital Audio 4-pin, 0.079" (2mm) header for incoming and outgoing
SPDIF digital audio signals
[SAMTEC, TMM-102-01-T-D-SM]

8Hardware
CN50 CAN 10-pin, 0.100"(2.54mm) shrouded header for transmitting
and receiving Controller Area Network signals
[JIHVEI, 23N6960-10S10B-01G-G]
CN51 CAN Termination 2-pin, 0.079" (2mm) jumper header for terminating the
CAN interface with 120 ohms
[JIH, 21N12050-02S10B-01G-4/2.8-G]
CN52 CPLD Programming 10-pin, 0.100"(2.54mm) header for CPLD programming
signals
[SAMTEC, TSM-105-01-S-DV]
CN53 Fan Control 4-pin, 0.100"(2.54mm) header for system fan +12V power,
power management, and tachometer
[JVE, 24W1163-04S10-01T-02]
CN57 Battery Termination 2-pin, 0.079" (2mm) jumper header for connecting or
disconnecting the battery in the BT1 socket
[JIH, 21N12050-02S10B-01G-4/2.8-G]
CN59 Backlight Voltage Select 3-pin, 2.0mm jumper header for selecting +5V or +12V
ATX Power On voltage to the LCD backlight
[JIH21N12050-03S10B-01G-4/2.8-G]
CN61 Keyboard Controller
Enable 2-pin, 0.079" (2mm) jumper header for selecting the
keyboard controller SIO address
[JIH, 21N12050-02S10B-01G-4/2.8-G]
CN62 LCD Voltage Select 6-pin, 0.079" (2mm) jumper header for LCD display power
management to select 3V3, 5V, or 12V
[NELTRON, 2208SM-06G-CR]
CN63 ATX PS_ON 6-pin, 0.079" (2mm) jumper header for setting Power
Signal_ON for the ATX connector
[NELTRON, 2208SM-06G-CR]
CN64 USB0 Voltage Select 3-pin, 0.079" (2mm) jumper header for selecting USB0
voltage source: Standby or Voltage In
[JIH, 21N12050-03S10B-01G-4/2.8-G]
CN65 LVDS Backlight
Interface 8-pin, 0.100" (2.54mm) shrouded header for LVDS
backlight
[JIHVEI, 23N6960-08S10B-01G-G]
CN66 LVDS Interface 34-pin, 0.079" (2mm) header for LVDS video
[JIHVEI, 23N6850-34S10B-01G-G]
CN69 SIO Enable 3-pin, 0.079" (2mm) jumper header for enabling or
disabling the SIO (1-2 = Enable; 2-3 = Disable)
[JIH, 21N12050-03S10B-01G-4/2.8-G]
CN70 UART Interface 10-pin, 0.100" (2.54mm) shrouded header for
high-speed, four-wire RS232 serial signals
[JIHVEI, 23N6960-10S10B-01G-G]
CN71 LPT Interface 26-pin, 0.100" (2.54mm) shrouded header for parallel
signals
[JIHVEI, 23N6960-26S10B-01G-G]
CN73 System Interface 20-pin, 0.100" (2.54mm) shrouded header for system
management signals
[JIHVEI, 23N6960-20S10B-01G-G]
CN74 PCIe Mini 52-pin, 0.032" (0.80mm) standard socket for PCIe Mini
cards
[ATTEND, 119A-80A00-R02]
Table 2-1: Header, Connector, Switch, and LED Descriptions (Continued)
Header /
Connector# Signal / Device Description

Hardware 9
Q7-BASE
CN75, CN76 PCIe Mini Latch Dual latches for PCIe Mini card socket
[ATTEND, 119A-LATCH-80]
CN77 CAN Enable 5V 2-pin, 0.079" (2mm) jumper header for enabling 5V on
pin 9 of the CAN interface
[JIH, 21N12050-02S10B-01G-4/2.8-G]
CN78 LPC / TPM Interface 20-pin, 0.100" (2.54mm) shrouded header for TPM
signals
[JIH, 21N22564-20S10B-01G-6]
CN79 FAN Voltage Select 3-pin, 0.079" (2mm) jumper header for selecting +5V
or +12V ATX power for the system fan
[JIH, 21N12050-03S10B-01G-4/2.8-G]
CN80 USB1 Voltage Select 3-pin, 2.0mm jumper header for selecting USB1 voltage
source: Standby or Voltage In
[JIH21N12050-03S10B-01G-4/2.8-G]
CN81 ATX_PWRGD Mode
Select 3-pin, 2.0mm jumper header for selecting the mode of ATX Power Good (ATX or BattMan)
[JIH21N12050-03S10B-01G-4/2.8-G]
CN84 DisplayPort, Standard 20-pin standard, right-angle connector for DisplayPort
signals
[FOXCONN, 3VD51203-D7JJ-7H, BLACK]
CN85 Display Mode Select,
DP / HDMI 3-pin, 2.0mm jumper header for selecting between HDMI B and DP display mode
[JIH21N12050-03S10B-01G-4/2.8-G]
CN86 I2S 10-pin, 2.54mm shrouded header for I2S signals
[JIHVEI, 23N6960-10S10B-01G-G, BLACK]
CN87 HDA_SYNC / I2S_WS
Select 3-pin, 2.0mm jumper header for selecting between HDA_SYNC and I2S_WS
[JIH21N12050-03S10B-01G-4/2.8-G]
CN88 HDA_RST#/I2S_RST#
Select 3-pin, 2.0mm jumper header for selecting between HDA_RST and I2S_RST
[JIH21N12050-03S10B-01G-4/2.8-G]
CN89 HDA_BITCLK /
I2S_CLK Select 3-pin, 2.0mm jumper header for selecting between HDA_BITCLK and I2S_CLK
[JIH21N12050-03S10B-01G-4/2.8-G]
CN90 HDA_SDO / I2S_SDO
Select 3-pin, 2.0mm jumper header for selecting between HDA_SDO and I2S_SDO
[JIH21N12050-03S10B-01G-4/2.8-G]
CN91 HDA_SDI / I2S_SDI
Select 3-pin, 2.0mm jumper header for selecting between HDA_SDI and I2S_SDI
[JIH21N12050-03S10B-01G-4/2.8-G]
CN92 EN_V3P3S Mode
Select 3-pin, 2.0mm jumper header for selecting between ATX mode and SUS_S3#
[JIH21N12050-03S10B-01G-4/2.8-G]
CN93 USB3_CN_p /
USB3_mPCIe_p
Select
3-pin, 2.0mm jumper header for selecting between
USB3_CN_p and USB3_mPCIe_p
[JIH21N12050-03S10B-01G-4/2.8-G]
CN94 USB3_CN_n /
USB3_mPCIe_n
Select
3-pin, 2.0mm jumper header for selecting between
USB3_CN_n and USB3_mPCIe_n
[JIH21N12050-03S10B-01G-4/2.8-G]
CN95 USB OTG Power
Control Select 3-pin, 2.0mm jumper header for selecting between USB_DRIVE_VBUS and USB_ID for OTG power
[JIH21N12050-03S10B-01G-4/2.8-G]
Table 2-1: Header, Connector, Switch, and LED Descriptions (Continued)
Header /
Connector# Signal / Device Description

10 Hardware
CN96 USB_VBUS Source
Select 3-pin, 2.0mm jumper header for selecting between USB_VBUS and USB_CC
[JIH21N12050-03S10B-01G-4/2.8-G]
CN97 PWM Backlight Voltage
Select 3-pin, 2.0mm jumper header for selecting PWM backlight voltage level
[JIH21N12050-03S10B-01G-4/2.8-G]
CN98 eDP1 Backlight Control 2-pin, 2.0mm jumper header for controlling eDP1 backlight
[JIH21N12050-02S10B-01G-4/2.8-G]
CN99 eDP1 Backlight Enable 2-pin, 2.0mm jumper header for enabling eDP1 backlight
[JIH21N12050-02S10B-01G-4/2.8-G]
CN100 SD-Card Slot 9-pin, 0.11" (2.8mm) standard, right-angle socket for
SD cards
[TYCO, 1939115-1, BLACK]
CN101 USB5_CN_p /
USB5_20_p
Select
3-pin, 2.0mm jumper header for selecting between
USB3_CN_p and USB3_20_p
[JIH21N12050-03S10B-01G-4/2.8-G]
CN102 USB5_CN_n /
USB5_20_n
Select
3-pin, 2.0mm jumper header for selecting between
USB3_CN_n and USB3_20_n
[JIH21N12050-03S10B-01G-4/2.8-G]
CN103 USB 3.0 Voltage Select 3-pin, 2.0mm jumper header for selecting USB 3.0
voltage source: Standby or Voltage In
[JIH21N12050-03S10B-01G-4/2.8-G]
CN104 LRESET# Source
Select 3-pin, 2.0mm jumper header for selecting between
CB_RESET# and R/C
[JIH21N12050-03S10B-01G-4/2.8-G]
CN105 ACT/LINK LED Source
Select 3-pin, 2.0mm jumper header for selecting between
GBE_LINK# and GBE_ACT#R/C
[JIH21N12050-03S10B-01G-4/2.8-G]
CN106 ACT/LINK LED Anode
Select 3-pin, 2.0mm jumper header for selecting between
+V3P3A and GBE_ACT#
[JIH21N12050-03S10B-01G-4/2.8-G]
CN107 1000Mbit Anode Select 3-pin, 2.0mm jumper header for selecting between
GBE_LINK1000# and +V3P3A
[JIH21N12050-03S10B-01G-4/2.8-G]
CN108 100Mbit Anode Select 3-pin, 2.0mm jumper header for selecting between
GBE_LINK100# and +V3P3A
[JIH21N12050-03S10B-01G-4/2.8-G]
CN109 ATX_PWRGD Source
Select 3-pin, 2.0mm jumper header for selecting the source of ATX Power Good (+V5P0_SBY or +V5_IN#)
[JIH21N12050-03S10B-01G-4/2.8-G]
CN110 SMB_ALERT_5V#
Source Select 3-pin, 2.0mm jumper header for selecting between
SMB_ALERT_5V# and SMB_ALERT#
[JIH21N12050-03S10B-01G-4/2.8-G]
CN111 SMB_CLK_5V# Source
Select 3-pin, 2.0mm jumper header for selecting between
SMB_CLK_5V# and SMB_CLK#
[JIH21N12050-03S10B-01G-4/2.8-G]
CN112 SMB_DATA_5V#
Source Select 3-pin, 2.0mm jumper header for selecting between
SMB_DATA_5V# and SMB_DATA#
[JIH21N12050-03S10B-01G-4/2.8-G]
CN113 USB 2.0 OC# Target
Select 3-pin, 2.0mm jumper header for selecting the OC target (USB45_OC# or USB67_OC#)
[JIH21N12050-03S10B-01G-4/2.8-G]
Table 2-1: Header, Connector, Switch, and LED Descriptions (Continued)
Header /
Connector# Signal / Device Description

Hardware 11
Q7-BASE
CN114 USB 3.0 OC# Target
Select 3-pin, 2.0mm jumper header for selecting the OC target (USB01_OC# or USB67_OC#)
[JIH21N12050-03S10B-01G-4/2.8-G]
HDMI1 HDMI Interface 19-pin, 0.019" (0.50mm) standard connector for HDMI
video signals
[TechBest, HDMI-KRPS00-A30N2A-L]
LED1 PCIe Mini WWAN Yellow Activity LED for Wireless Wide Area Network (ON =
low level)
[LIGITEK, LG-170HY-CT]
LED2 PCIe Mini WLAN Yellow Activity LED for Wireless Local Area Network (ON =
low level)
[LIGITEK, LG-170HY-CT]
LED3 PCIe Mini WPAN Yellow Activity LED for Wireless Personal Area Network
[LIGITEK, LG-170HY-CT] (ON = low level)
LED4 SDIO Yellow Power LED for SD card socket (ON = high level)
[LIGITEK, LG-170HY-CT]
LED5 SATA Yellow Power LED for SATA interface (ON = low level)
[LIGITEK, LG-170HY-CT]
LED6 POST 80 High Seven-segment display LED for 80H POST codes (high
nibble of address 80h)
[Kingbright, KCSA02-101]
LED7 POST 80 Low Seven-segment display LED for 80L POST codes (low
nibble of address 80h)
[Kingbright, KCSA02-101]
LED8 POST 81 High Seven-segment display LED for 81H POST codes (high
nibble of address 81h)
[Kingbright, KCSA02-101]
LED9 POST 81 Low Seven-segment display LED for 81H POST codes (low
nibble of address 81h)
[Kingbright, KCSA02-101]
LED11 S3 Suspend Yellow Activity LED for S3 sleep state (ON = high level)
[LIGITEK, LG-170HY-CT]
LED12 S5 Suspend Yellow Activity LED for S5 sleep state (ON = high level)
[LIGITEK, LG-170HY-CT]
LED13 Thermal Trip Red Activity LED for thermal management (ON = low level)
[Ligitek, LG-170HR-CT]
LED14 Watchdog Red Activity LED for Watchdog Timer (ON = high level)
[Ligitek, LG-170HR-CT]
PS1 Keyboard and Mouse 6-pin, dual standard, mini-DIN connector for PS/2 keyboard
(bottom) and mouse (top) I/O
[FOXCONN, MH11061-P36-4F]
RJ451 Gb Ethernet 16-pin standard, RJ45 connector with transformer and LED
for Gigabit Ethernet
[UDE, RT7-174AAM1A, BLACK]
SATA0 SATA 7-pin, 0.050" (1.27mm) standard connector for
SATA0 interface
[WIN WIN, WATM-07ABN4A3B8UW]
SATA1 SATA 7-pin, 0.050" (1.27mm) standard connector for
SATA1 interface
[WIN WIN, WATM-07ABN4A3B8UW]
Table 2-1: Header, Connector, Switch, and LED Descriptions (Continued)
Header /
Connector# Signal / Device Description

12 Hardware
SW1 Reset Button 4-pin, 0.170" (4.3mm) push-button switch for asserting
warm reset to the module
[DIPTRONIC, DTSM-61N-V-T]
SW2 Sleep Button 4-pin, 0.170" (4.3mm) push-button switch for asserting
sleep state to the module
[DIPTRONIC, DTSM-61N-V-T]
SW3 Power Button 4-pin, 0.170" (4.3mm) push-button switch for turning
on power to the Qseven module
[DIPTRONIC, DTSM-61N-V-T]
SW4 LID Button 4-pin, 0.170" (4.3mm) push-button switch for asserting
LID to the Qseven connector
[DIPTRONIC, DTSM-61N-V-T]
SW5 WAKE Button 4-pin, 0.170" (4.3mm) push-button switch for asserting
wake signal to the Qseven module
[DIPTRONIC, DTSM-61N-V-T]
SW6 I2C EEPROM Address
Select 4-pole, 0.050" (1.27mm)dip switch for configuring and
write protecting I2C EEPROM address
[DIPTRONICS, DHNF-04-T-Q-T]
SW9 SPI EEPROM 4-pole, 0.050" (1.27mm)dip switch for selecting SPI
EEPROM interface
[DIPTRONICS, DHNF-04-T-Q-T]
SW11 DP Control 4-pole, 0.050" (1.27mm)dip switch for configuring
DisplayPort control
[DIPTRONICS, DHNF-04-T-Q-T]
SW12 DP Enable 4-pole, 0.050" (1.27mm)dip switch for configuring
DisplayPort enable
[DIPTRONICS, DHNF-04-T-Q-T]
SW13 DP Operation 4-pole, 0.050" (1.27mm)dip switch for configuring
DisplayPort operation
[DIPTRONICS, DHNF-04-T-Q-T]
SW14 eDP0 Enable 4-pole, 0.050" (1.27mm)dip switch for configuring eDP0
enable
[DIPTRONICS, DHNF-04-T-Q-T]
SW15 eDP0 Operation 4-pole, 0.050" (1.27mm)dip switch for configuring eDP0
operation
[DIPTRONICS, DHNF-04-T-Q-T]
SW16 eDP0 Control 4-pole, 0.050" (1.27mm)dip switch for configuring eDP0
control
[DIPTRONICS, DHNF-04-T-Q-T]
SW17 eDP1 Enable 4-pole, 0.050" (1.27mm)dip switch for configuring eDP1
enable
[DIPTRONICS, DHNF-04-T-Q-T]
SW18 eDP1 Operation 4-pole, 0.050" (1.27mm)dip switch for configuring eDP1
operation
[DIPTRONICS, DHNF-04-T-Q-T]
SW19 eDP1 Control 4-pole, 0.050" (1.27mm)dip switch for configuring eDP1
control
[DIPTRONICS, DHNF-04-T-Q-T]
SW20 I2C EEPROM Interface
Select 4-pole, 0.050" (1.27mm)dip switch for configuring I2C
EEPROM interface select
[DIPTRONICS, DHNF-04-T-Q-T]
Table 2-1: Header, Connector, Switch, and LED Descriptions (Continued)
Header /
Connector# Signal / Device Description

Hardware 13
Q7-BASE
Figure 2-1: Connector Locations (Top Side)
USB1 USB 2.0 16-pin, 0.138" (3.50mm) quadruple-stacked, standard
connector for USB 2.0 signals (ports 2, 3, 4, 5)
[FOXCONN,UB1112C-QHDF-4F]
USB2 Mini USB 2.0 5-pin, 0.80mm standard Mini USB connector for USB
2.0 device (OTG or client) signals (port1)
[AMP, 1734035-4, BLACK]
USB3 USB 3.0/2.0 [top]
USB 2.0 [bottom] 18-pin, standard dual USB 3.0 / 2.0 connectors for USB interface ports 0, 1, 6, and 7
[Amphenol, GSB3112311HR, BLUE]
Table 2-1: Header, Connector, Switch, and LED Descriptions (Continued)
Header /
Connector# Signal / Device Description
CN1
CN84
CN8 CN86 CN70
CN10
CN11
CN66
CN100
CN52
CN27
CN85
SW4 SW3 SW5 SW2SW1
SW11
SW12
SW13
SATA0 SATA1
LED8 LED9 LED6 LED7
LED3 LED2 LED1 LED13 LED14
SW19 SW17
HDMI1
RJ451
AJ1
USB3
CN39
CN50
PS1
USB2
USB1
CN71
LED11 LED12 LED4
CN50
CN2
CN46
CN108
CN107
CN106
CN105
CN103
CN51
CN61
CN78 CN69
CN57
BT1
SW9
SW15
SW20
CN97
CN5
CN109
CN4
CN99
CN92 CN79
CN89
CN88 CN87
SW6 CN63
CN59 SW14
CN91 CN90
CN64
CN95
CN96
CN80
CN74
CN45
CN44
CN42
CN76
CN75
CN20
CN104
GF1
CN94
CN93
CN111
CN112
CN110
CN102
CN81
CN114
CN113
CN101
SW18
CN3
SW16
CN53
CN98
CN77
CN62
2
2

14 Hardware
Figure 2-2: Reference Key for Headers, Connectors, Switches, and LEDs
Q7-BASE R1_B2_top_conn_refkey_a
CONNECTORS:
AJ1 - Audio Jack
BT1 - Battery Socket
CN1 - ATX Power
CN2 - Manufacturing
CN3 - BattMan / ATX Power Mode Select
CN4 - BattMan / ATX Power Mode Select
CN5 - Smart Battery
CN8 - Post Code Enable
CN10 - eDP 0
CN11 - eDP 1
CN20 - PS/2 Power Source Select
CN39 - COM1/COM2 (standard connector)
CN42 - PCI Express (slot 1)
CN44 - PCI Express (slot 2)
CN45 - PCI Express (slot 3)
CN46 - Digital Audio
CN50 - CAN Interface
CN51 - CAN Termination
CN52 - CPLD Programming
CN53 - FAN control
CN57 - Battery Termination
CN59 - Backlight Voltage Select
CN61 - Enable Keyboard Controller
CN62 - LCD Voltage Select
CN63 - ATX PS_ON Select
CN64 - USB0 Voltage Select
CN65 - LVDS Backlight
CN66 - LVDS Interface
CN69 - SIO Enable
CN70 - UART Interface
CN71 - LPT Interface
CN72 - SD/MMC 4.x Slot
CN73 - System Interface
CN74 - PCIe Mini Card Slot
CN75 - PCIe Mini Latch
CN76 - PCIe Mini Latch
CN77 - CAN Enable 5V
CN78 - LPC / TPM Interface
CN79 - FAN Power Select
CN80 - USB1 Voltage Select
CN81 - ATX_PWRGD Mode Select
CN84 - DP Interface
CN85 - Display Mode Select
CN86 - I2S Interface
CN87 - HDA_SYNC or I2S_WS Select
CN88 - HDA_RST or I2S_RST Select
CN89 - HDA_BITCLK or I2S_CLK Select
CN90 - HDA_SDO or I2S_SDO Select
CN91 - HDA_SDI or I2S_SDI Select
CN92 - EN_V3P3S Mode Select
CN93 - USB3_CN_p or USB3_mPCIe_p Select
CN94 - USB3_CN_n or USB3_mPCIe_n Select
CN95 - USB OTG Control Select
CN96 - USB_VBUS Source Select
CN97 - Backlight Voltage Select
CN98 - eDP Backlight Control
CN99 - eDP Backlight Enable
CN100 - SD Card Slot
CN101 - USB5_CN_p or USB5_20_p Select
CN102 - USB5_CN_n or USB5_20_n Select
CN103 - USB 3.0 Voltage Select
CN104 - LRESET# Source Select
CN105 - ACT/LINK LED Source Select
CN106 - ACT/LINK LED Anode Select
CN107 - 1000Mbit Anode Select
CN108 - 100Mbit Anode Select
CN109 - ATX_PWRGD Source Select
CN110 - SMB_ALERT_5V# Source Select
CN111 - SMB_CLK_5V# Source Select
CN112 - SMB_DATA_5V# Source Select
CN113 - USB 2.0 OC# Target Select
CN114 - USB 3.0 OC# Target Select
HDMI1 - HDMI Socket
PS1 - PS/2 Keyboard and Mouse
RJ451 - Gb Ethernet (Standard)
SATA0 - SATA (Standard)
SATA1- SATA (Standard)
USB1 - USB 2.0 (Standard)
USB2 - Mini USB (Standard
USB3 - USB 3.0 / USB 2.0 (Standard)
SWITCHES:
SW1 - Reset Button
SW2 - Sleep Button
SW3 - Power Button
SW4 - LID Button
SW5 - Wake Button
SW6 - I2C EEPROM Address
SW9 - SPI EEPROM Interface Select
SW11 - DP Control
SW12 - DP Enable
SW13 - DP Operation
SW14 - eDP0 Enable
SW15 - eDP0 Operation
SW16 - eDP0 Control
SW17 - eDP1 Enable
SW18 - eDP1 Operation
SW19 - eDP1 Control
SW20 - I2C EEPROM Interface Select
LEDs:
LED1 - PCIe Mini WWAN
LED2 - PCIe Mini WLAN
LED3 - PCIe Mini WPAN
LED4 - SD/MMC
LED5 - SATA Activity
LED6 - POST 80 High
LED7 - POST 80 Low
LED8 - POST 81 High
LED9 - POST 81 Low
LED11 - S3 Suspend
LED12 - S5 Suspend
LED13 - Thermal Trip
LED14 - Watchdog
