ADLINK Technology NuDAQ PCI-9114DG User manual

NuDAQ

PCI-9114DG/HG
Enhanced Multi-Functions
Data Acquisition Card
User’s Guide

@Copyright 1999~2000 ADLink Technology Inc.
All Rights Reserved.
Manual Rev. 1.20: April 12, 2000
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does not
represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability
to use theproduct or documentation, even if advised of the possibility of
such damages.
This document contains proprietary information protected by copyright.
Allrightsarereserved.Nopartofthismanualmaybereproducedbyany
mechanical,electronic,orother means in any form without prior written
permission of the manufacturer.
Trademarks
NuDAQ, NuIPC, DAQBench are registered trademarks of ADLink
Technology Inc. Other product names mentioned herein are used for
identification purposes only and may be trademarks and/or registered
trademarks of their respective companies.

Getting service from ADLink
♦Customer Satisfaction is always the most important thing for ADLink
Tech Inc. If you need any help or service, please contact us and get it.
ADLink Technology Inc.
Web Site http://www.adlink.com.tw
Sales & Service [email protected]
Technical NuDAQ [email protected]
Support NuDAM [email protected]
NuIPC [email protected]
NuPRO [email protected]
Software [email protected]
AMB [email protected]om.tw
TEL [phone] FAX [phone]
Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan, R.O.C.
♦Please inform or FAX us of your detailed information for a prompt,
satisfactory and constant service.
Detailed Company Information
Company/Organization
Contact Person
E-mail Address
Address
Country
TEL FAX
Web Site
Questions
Product Model
Environment to Use  OS
 Computer Brand
 M/B :  CPU :
 Chipset :  Bios :
 Video Card :
 Network Interface Card :
 Other :
Challenge Description
Suggestions for ADLink

Contents • i
Table of Contents
How to Use This Guide............................................v
Chapter 1 Introduction.......................................... 1
1.1 Features..........................................................................2
1.2 Applications....................................................................2
1.3 Specifications.................................................................2
1.4 Software Support............................................................4
1.4.1 Programming Library..................................................................4
1.4.2 PCIS-LVIEW: LabVIEW®Driver...............................................4
1.4.3 PCIS-VEE: HP-VEE Driver.........................................................5
1.4.4 DAQBenchTM: ActiveX Controls...............................................5
1.4.5 DASYLabTM PRO...........................................................................5
1.4.6 PCIS-DDE: DDE Server and InTouchTM.................................5
1.4.7 PCIS-ISG: ISaGRAFTM driver.....................................................5
1.4.8 PCIS-ICL: InControlTM Driver.....................................................5
1.4.9 PCIS-OPC: OPC Server..............................................................6
Chapter 2 Installation............................................ 7
2.1 What You Have ...............................................................7
2.2 Unpacking.......................................................................8
2.3 PCB Layout of PCI-9114...................................................9
2.4 Hardware Installation....................................................10
2.5 Device Installation for Windows Systems......................10
2.6 Connector Pin Assignment............................................11
2.6.1 Pin Assignment of CN1............................................................11
2.6.2 Pin Assignment of CN2 & CN3...............................................12
2.7 Jumper Descriptions.....................................................12
2.7.1 JP1: Analog Signal Input Type Selection..............................12
2.7.2 JP2: Cold Junction Sensor Selection....................................13
2.8 Termination Board Connection.....................................14
Chapter 3 Registers Format ...............................15
3.1 PCI PnP Registers.........................................................15
3.2 I/O Address Map............................................................17
3.3 A/D Data Registers........................................................18
3.4 A/D Channel Control Register.......................................18
3.5 A/D Input Signal Range Control Register......................20

ii • Contents
3.6 A/D Status Read-back Register......................................20
3.7 Trigger Mode Control and Read-back Register.............21
3.8 Interrupt Control and Read-back Register.....................21
3.9 Software Trigger Register.............................................22
3.10 Hardware Interrupt Clear Registers...............................22
3.11 Timer/Counter Register.................................................23
3.12 High Level Programming..............................................23
Chapter 4 Operation Theorem............................25
4.1 A/D Conversion .............................................................25
4.1.1 A/D Conversion Procedure.....................................................26
4.1.2 A/D Signal Source Control.......................................................26
4.1.3 A/D Trigger Source Control.....................................................28
4.1.4 A/D Data Transfer Modes........................................................29
4.1.5 A/D Data Format.........................................................................31
4.2 Interrupt Control............................................................32
4.2.1 System Architecture.................................................................32
4.2.2 IRQ Level Setting........................................................................32
4.2.3 Dual Interrupt System...............................................................32
4.2.4 Interrupt Source Control..........................................................33
4.3 Isolation Digital Input....................................................33
4.4 Isolation Digital Output .................................................35
4.5 Timer/Counter Operation..............................................37
4.5.1 Introduction..................................................................................37
4.5.2 Pacer Trigger Source................................................................37
Chapter 5 Software Library ................................39
5.1 Libraries Installation.....................................................39
5.2 Programming Guide .....................................................40
5.2.1 Naming Convention...................................................................40
5.2.2 Data Types...................................................................................40
5.3 _9114_Initial..................................................................41
5.4 _9114_Software_Reset..................................................42
5.5 _9114_DO ......................................................................42
5.6 _9114_DI........................................................................43
5.7 _9114_AD_Read_Data....................................................43
5.8 _9114_AD_Read_Data_Repeat.......................................45
5.9 _9114_AD_Read_Data_MUX...........................................46
5.10 _9114_AD_Read_Data_Repeat_MUX..............................46
5.11 _9114_AD_Set_Channel.................................................48

Contents • iii
5.12 _9114_AD_Set_Range....................................................50
5.13 _9114_AD_Get_Range ...................................................51
5.14 _9114_AD_Get_Status....................................................51
5.15 _9114_AD_Set_Mode .....................................................53
5.16 _9114_AD_Get_Mode.....................................................53
5.17 _9114_INT_Set_Reg.......................................................54
5.18 _9114_AD_Get_Reg.......................................................54
5.19 _9114_Reset_FIFO.........................................................55
5.20 _9114_AD_Soft_Trigger.................................................55
5.21 _9114_Set_8254.............................................................57
5.22 _9114_Get_8254.............................................................57
5.23 _9114_AD_Timer............................................................59
5.24 _9114_Counter_Start .....................................................59
5.25 _9114_Counter_Read.....................................................60
5.26_9114_Counter_Stop......................................................60
5.27 _9114_INT_Source_Control............................................61
5.28 _9114_CLR_IRQ1 ...........................................................62
5.29 _9114_CLR_IRQ2 ...........................................................62
5.30 _9114_Get_IRQ_Channel...............................................63
5.31 _9114_Get_IRQ_Status...................................................63
5.32 _9114_AD_FFHF_Polling................................................64
5.33 _9114_AD_FFHF_Polling_MUX.......................................64
5.34 _9114_AD_Aquire ..........................................................65
5.35 _9114_AD_Aquire_MUX .................................................66
5.36 _9114_AD_INT_Start ......................................................68
5.37 _9114_AD_FFHF_INT_Start ............................................69
5.38 _9114_AD_INT_Status....................................................71
5.39 _9114_AD_FFHF_INT_Status..........................................71
5.40 _9114_AD_FFHF_INT_Restart.........................................73
5.41 _9114_AD_INT_Stop.......................................................73
Chapter 6 Calibration & Utilities........................75
6.1 Calibration....................................................................75
6.1.1 What do you need......................................................................75
6.1.2 VR Assignment..........................................................................76
6.1.3 A/D Adjustment..........................................................................76
6.1.4 Software A/D Offset Calibration.............................................77
6.2 Utility ..........................................................................77
6.2.1 9114util.........................................................................................77
6.2.2 I_EEPROM ...................................................................................81

iv • Contents
Product Warranty/Service....................................83

How to Use This Guide • v
How to Use This Guide
Thismanualisdesigned to help you to use the PCI-9114/9114HR. It is
divided into six chapters:
•Chapter 1, "Introduction," gives an overview of product features,
applications, and specifications.
•Chapter 2, "Installation," describes how to install the PCI-9114.
The layout of PCI-9114 is shown, and the jumper settings for
analog input channel configuration are specified. The connectors
pin assignments and termination boards connection are
described.
•Chapter 3, "Registers Format," describes the details of registers
format and structure of the PCI-9114, this information is very
importantfortheprogrammerswhowanttocontrolthehardwareby
low-level programming language.
•Chapter 4, "Operation Theorem" describes how the PCI-9114
operates.TheA/Dandtimer/counterfunctionsareintroduced.Also,
some programming concepts are specified in this chapter.
•Chapter 5, "C/C++ Library" describes high-level programming
interface. It helps programmer to control PCI-9114 in high-level
language style.
•Chapter 6, "Calibration & Utilities," describes how to calibrate the
accuracyofPCI-9114, and how to use the utility programs included
in the software CD.

Introduction • 1
1
Introduction
ThePCI-9114 is an advanced data acquisition card based on the 32-bit
PCI Bus architecture. High performance designs and the
state-of-the-art technology make this card ideal for data logging and
signal analysis applications in medical, process control, and etc. The
following block diagram shows the brief functions of the PCI-9114.
32 bits PCI Bus
32 SE/
16DI
MUX
PGA
Gain=1,10
100,1000
16 bits
AD
PCI Controller
AD Controller
ASIC
8254
Timer
Cold Junction
Sensor
1K FIFO
16 Channels
Isolation DI
16 Channels
Isolation DO

2 • Introduction
1.1 Features
The PCI-9114 PCI-Bus Advanced Data Acquisition Card provides the
following advanced features:
•32-bit PCI-Bus, Plug and Play
•32 single-ended or 16 differential analog inputs channels
•16-bits high resolution AD conversion
•High amplification gain of 1, 10, 100, 1000 for PCI-9114 HG
•Normal gain of 1, 2, 4, 8 for PCI-9114 DG
•Single channel sampling rate up to 100 KHz
•Multi-AD trigger mode: software trigger, timer pacer trigger
•On-board A/D 1K WORDS FIFO memory
•Auto-scanning channel selection
•16 Isolated Digital Input Channels
•16 Isolated Digital Output Channels with high driving capability
•5000 V rms high voltage isolation for DIO channels
1.2 Applications
•Industrial process control
•Transducer, thermocouple, RTD
•Power monitor
•Medical instrument
•Biomedical measurement
1.3 Specifications
♦
Analog Input (A/D)
•Converter: B.B. ADS7805 or equivalent, successive
approximation type
•Resolution:16 bits
•Input channels:32single-endedor16differentialinputchannels
•Input Range:(Programmable)
Bipolar: ±10V, ±1V, ±100 mV, ±10 mV (PCI-9114-HG)
Bipolar: ±10V, ±5V, ±2.5, ±1.25V (PCI-9114-DG)
•Throughput: 100 KHz max for single channel

Introduction • 3
•Over Voltage Protection for Analog inputs: Continuous ±35V
maximum
•Input Impedance:10 MΩ
•A/D Trigger Modes:Software and Pacer timer trigger
•Data Transfer Mode: Pooling, EOC Interrupt, FIFO Half-full
Interrupt
•FIFO Buffer Size: 1024 samples
♦
Isolation Digital Input (IDI)
•Number of input channels: 16
•
Input voltage:0~ 24 VDC
Logic L: 0~1.5V
Logic H: 3~24V
•Input resistance: 4.7 KΩ@ 0.5W
•Isolation voltage:5000 V rms
•Throughput: 10 KHz
♦
Isolation Digital Output (IDO)
•Number of output channels: 16 channels current source
•Output type: open emitter 0.5 to 50 VDC
•Source Current:
Single channel sources 500 mA maximum
8 channels source 60mA maximum simultaneously
(One TD62083 chip contains 8 channels totally)
•Isolation voltage:5000 V rms
•Throughput: 10 KHz
♦
General Specifications
•Connector: 37-pin D-type connector
•Operating Temperature: 0°C ~ 60°C
•Storage Temperature: -20°C ~ 80°C
•Humidity: 5 ~ 95%, non-condensing
•Power Consumption:
+5 V @ 600 mA (typical)
+12 V @ 100 mA (typical)
•Dimension: 7.88” (200 mm)(L) x 4.18” (107 mm)(W)

4 • Introduction
1.4 Software Support
ADLinkprovidesversatile software drivers and packages for users’
different approach to built-up a system. We not only provide
programming library such as DLL for many Windows systems, but
alsoprovidedriversformanysoftwarepackagesuchasLabVIEW®,
HP VEETM, DASYLabTM, InTouchTM, InControlTM, ISaGRAFTM, and
so on.
All the software options are included in the ADLink CD. The
non-free software drivers are protected with serial licensed code.
Without the software serial number, you can still install them and
run the demo version for two hours for demonstration purpose.
Please contact with your dealer to purchase the formal license
serial code.
1.4.1 Programming Library
For customers who are writing their own programs, we provide
function libraries for many different operating systems, including:
uDOS Library: Borland C/C++ and Microsoft C++, the functions
descriptions are included in this user’s guide.
uWindows 95 DLL: For VB, VC++, Delphi, BC5, the functions
descriptions are included in this user’s guide.
uPCIS-DASK: Include device drivers and DLL for Windows 98,
Windows NT and Windows 2000. DLL is binary compatible
across Windows 98, Windows NT and Windows 2000. That
means all applications developed with PCIS-DASK are
compatible across Windows 98, Windows NT and Windows
2000. The developing environment can be VB, VC++, Delphi,
BC5, or any Windows programming language that allows calls
to a DLL. The user’s guide and function reference manual of
PCIS-DASK are in the CD. Please refer the PDF manual files
under \\Manual_PDF\Software\PCIS-DASK
The above software drivers are shipped with the board. Please
refer to the “Software Installation Guide” to install these drivers.
1.4.2 PCIS-LVIEW: LabVIEW®Driver
PCIS-LVIEW contains the VIs, which are used to interface with NI’s
LabVIEW®software package. The PCIS-LVIEW supports Windows
95/98/NT/2000. The LabVIEW®drivers are free shipped with the
board. You can install and use them without license. For detail

Introduction • 5
information about PCIS-LVIEW, please refer to the user’s guide in
the CD.
(\\Manual_PDF\Software\PCIS-LVIEW)
1.4.3 PCIS-VEE: HP-VEE Driver
The PCIS-VEE includes the user objects, which are used to
interface with HP VEE software package. PCIS-VEE supports
Windows 95/98/NT. The HP-VEE drivers are free shipped with the
board. You can install and use them without license. For detail
informationaboutPCIS-VEE, please refer to the user’s guide in the
CD.
(\\Manual_PDF\Software\PCIS-VEE)
1.4.4 DAQBenchTM: ActiveX Controls
We suggest the customers who are familiar with ActiveX controls
and VB/VC++ programming use the DAQBenchTM ActiveX Control
components library for developing applications. The DAQBenchTM
is designed under Windows NT/98. For more detailed information
about DAQBench, please refer to the user’s guide in the CD.
(\\Manual_PDF\Software\DAQBench\DAQBench Manual.PDF)
1.4.5 DASYLabTM PRO
DASYLab is an easy-to-use software package, which provides
easy-setup instrument functions such as FFT analysis. Please
contact us to get DASYLab PRO, which include DASYLab and
ADLink hardware drivers.
1.4.6 PCIS-DDE: DDE Server and InTouchTM
DDE stands for Dynamic Data Exchange specifications. The
PCIS-DDE includes the PCI cards’ DDE server. The PCIS-DDE
server is included in the ADLINK CD. It needs license. The DDE
servercanbeusedconjunctionwithanyDDEclientunderWindows
NT.
1.4.7 PCIS-ISG: ISaGRAFTM driver
The ISaGRAF WorkBench is an IEC1131-3 SoftPLC control
program development environment. The PCIS-ISG includes
ADLink products’ target drivers for ISaGRAF under Windows NT
environment. ThePCIS-ISGisincluded intheADLINK CD. Itneeds
license.
1.4.8 PCIS-ICL: InControlTM Driver
PCIS-ICL is the InControl driver which support the Windows NT.
The PCIS-ICL is included in the ADLINK CD. It needs license.

6 • Introduction
1.4.9 PCIS-OPC: OPC Server
PCIS-OPC is an OPC Server, which can link with the OPC clients.
There are many software packages on the market can provide the
OPC clients now. The PCIS-OPC supports the Windows NT. It
needs license.

Installation • 7
2
Installation
This chapter describes how to install the PCI-9114. Please follow the
following steps to install the cards.
♦Check what you have (section 2.1)
♦Unpacking (section 2.2)
♦Check the PCB and jumper location(section 2.3)
♦Install the hardware and setup and jumpers (section 2.4, 2.7)
♦Install the software drivers and run utility to test (section 2.5)
♦Cabling with external devices (section 2.6, 2.8)
2.1 What You Have
In addition to this User's Manual, the package includes the following
items:
•PCI-9114 Enhanced Multi-function Data Acquisition Card
•ADLINK CD
•Software Installation Guide
If any of these items is missing or damaged, contact the dealer from
whom you purchased the product. Save the shipping materials and
carton in case you want to ship or store the product in the future.

8 • Installation
2.2 Unpacking
Your PCI-9114 card contains sensitive electronic components that can be
easily damaged by static electricity.
The card should be put on a grounded anti-static mat. The operator
shouldbewearingananti-static wristband, grounded at the same point
as the anti-static mat.
Inspect the card module carton for obvious damage. Shipping and
handling may cause damage to your module. Be sure there are no
shipping and handing damages on the module before processing.
After opening the card module carton, extract the system module and
place it only on a grounded anti-static surface component side up.
Again inspect the module for possible damage.
Note: DO NOT APPLY POWER TO THE CARD IF IT HAS BEEN
DAMAGED.
You are now ready to install your PCI-9114.
