Ads Opc6012 User manual

Stand:31.10.2014

User Manual

Industrial PCs

OPC6012/6015

Version 2.0

Industrial PCs OPC6012/6015

Product Portfolio

ads-tec GmbH

Heinrich-Hertz-Str. 1

D-72622 Nürtingen

Germany

Industrial PCs OPC6012/6015

INDEX

About us.....................................................................................................................................5

1Remarks.....................................................................................................................6

1.1 Relevant documentation for the device ..................................................................................6

1.2 Explanation of used symbols...................................................................................................6

1.3 Data, figures and modification.................................................................................................7

1.4 Trade marks................................................................................................................................7

1.5 Copyrights..................................................................................................................................7

1.6 Environmental conditions.........................................................................................................8

1.7 Standards ...................................................................................................................................8

1.8 Equipment versions ..................................................................................................................9

1.9 Scope of delivery.......................................................................................................................9

2Operating instructions............................................................................................10

2.1 Operating location...................................................................................................................10

2.2 Damage due to improper use .................................................................................................10

2.3 Warranty / repair ......................................................................................................................10

2.4 Treatment and disposal of lithium batteries.........................................................................11

2.5 Notes on safety........................................................................................................................12

3Mounting..................................................................................................................13

3.1 External Device Dimensions for OPC6012............................................................................13

3.1 Installation Layout for OPC6012 ............................................................................................14

3.2 External Device Dimensions for OPC6015............................................................................15

3.3 Installation Layout for OPC6015 ............................................................................................16

4Commissioning .......................................................................................................17

4.1 Available interfaces.................................................................................................................17

4.2 Check for operational readiness............................................................................................17

5Operation.................................................................................................................18

5.1 Front control keys ...................................................................................................................18

5.2 Soft keyboard...........................................................................................................................18

5.3 Status indicators......................................................................................................................20

5.4 Touch screen............................................................................................................................20

Industrial PCs OPC6012/6015

6Interfaces.................................................................................................................21

6.1 Interface setup......................................................................................................................... 21

6.2 24V DC power supply ............................................................................................................. 21

6.1 Speakers .................................................................................................................................. 23

6.2 USB connections .................................................................................................................... 24

6.3 PS/2 connector........................................................................................................................ 25

6.4 Network connection (RJ45).................................................................................................... 26

6.5 Serial COM interface (RS232)................................................................................................. 27

7Drives.......................................................................................................................28

7.1 Hard drive / Flash SSD............................................................................................................ 28

7.2 External drives ........................................................................................................................ 28

8Software & driver installation.................................................................................29

8.1 Installing the operating system ............................................................................................. 29

8.2 Touch screen driver installation............................................................................................ 30

8.3 Configuration Center .............................................................................................................. 31

8.4 Automatic brightness adaptation.......................................................................................... 32

8.5 USB Lock function.................................................................................................................. 33

8.6 ON / OFF pushbutton configuration...................................................................................... 34

8.7 Exemplary RFID application................................................................................................... 35

8.8 Soft keyboard .......................................................................................................................... 36

8.9 Screen Mob.............................................................................................................................. 36

8.10 Soft keyboard installation ...................................................................................................... 37

9Technical details.....................................................................................................38

10 Service and support................................................................................................39

10.1 ads-tec support ....................................................................................................................... 39

10.2 Company address................................................................................................................... 39

11 CE conformity declaration......................................................................................40

Industrial PCs OPC6012/6015

Pos: 1/D atentechni k/Allgemeine Hin weise/Wir über uns/ Wir über uns @ 2 \mod_1254 923190378_6.d oc @ 6522 @

ABOUT US

ads-tec GmbH

Raiffeisenstr. 14

D-70771 Leinfelden-Echterdingen

Phone: +49 711 45894-0

Fax: +49 711 45894-990

www.ads-tec.com

As a supplier of high tech equipment, ads-tec supports large enterprises and globally

operating groups of companies with state-of-the-art technology, know how that is always

up to date and delivery of comprehensive services in the area of automation, data and

system technology.

ads-tec puts entire solutions for automation into practice - from the planning to the

commissioning - and has particularly specialised in manipulation and material manipulation

technology.

The Data Technology division develops and manufactures PC based solutions and holds a

wide range of industrial PCs, thin clients and embedded systems available.

ads-tec has specialised in the adaptation and optimisation of operational systems and

develops software tools to complement the offered hardware platforms.

Pos: 2/D atentechni k/Allgemeine Hinweis e/Relevante Dokum entationen zum Gerät/Rel evante Dokument ationen für OPC / CPC / OTC / V MT/ STC @ 2\mod_ 1268662117522_ 6.doc @ 7352 @

Industrial PCs OPC6012/6015

1REMARKS

1.1 RELEVANT DOCUMENTATION FOR THE DEVICE

The following documents are essential for setting up and operating this device:

USER MANUAL (THIS DOCUMENTATION):

Contains information for installation, commissioning and operating the device along with

technical data of the device hardware.

WEBSITE

By using the website www.ads-tec.de, you can download drivers, software, user manuals,

leaflets and flyers from the Download section on the website.

Note:

We would recommend to make use of our website contents (www.ads-tec.de) in

order to ensure an optimised data quality and to be quickly and comprehensively

informed of any technical modification.

SERVICE CD:

Contains drivers and user manuals.

Note:

The service CD menu automatically starts if the autostart option for removable

media is activated.

The service CD was created by using Adobe Flash. The service CD menu is even

available if the Flash Player is not installed.

Pos: 3/D atentechni k/Allgemeine Hinweis e/Erläuterung zu den verwendeten Symb olen/Erläuterung zu den verwendet enS ymbolen @ 0\mod _1158752779484 _6.doc @ 141 @

1.2 EXPLANATION OF USED SYMBOLS

Warning:

The "Warning" symbol refers to activities which could cause personal injury or

damage to the hardware and software!

Note:

The "Note" symbol describes conditions which unconditionally have to be observed

in order to ensure trouble-free operation. Additionally, hints and advice for the

efficient use of this device and for software optimisation are given using this

symbol.

Pos: 4/D atentechni k/Allgemeine Hinweis e/Daten, Abbildunge n,Ä nderungen/Date n,Abbildungen,Ä nderungen @ 1\m od_12354804987 75_6.doc @ 5162 @

Industrial PCs OPC6012/6015

1.3 DATA,FIGURES AND MODIFICATION

All texts, data and figures are non-binding. All these materials are subject to modification

due to technological progress. Our products comply with all provisions and requirements of

the legislation at that point in time when the products leave our company premises. The

operator/operating company bears sole responsibility for the compliance with any

consecutive new technological development or adherence to any consecutive new

legislatory provision, as well as for the observance of their obligation as the

operator/operating company.

Pos: 5/D atentechni k/Allgemeine Hinweis e/Warenzeichen/W arenzeichen @ 2\ mod_1263298182 965_6.doc @ 6972 @

1.4 TRADE MARKS

We would like to emphasise that all names of hardware and software products used in this

documentation, as well as all brand names of corresponding companies are subject to the

general copyrights of the intellectual property in terms of trademarks, brand names and

patents.

Windows®, Windows®CE are registered trademarks of Microsoft Corp.

Intel®, Pentium®, Atom™, Core™2, are registered trademarks of Intel Corp.

IBM®, PS/2®and VGA®are registered trademarks of IBM Corp.

CompactFlash®is a registered trademark of the Compact Flash Association.

RITTAL®is a registered trademark of Rittal Werk Rudolf Loh GmbH & Co. KG.

Any other national and international trademarks and product names shall hereby also be

recognised.

Pos: 6/D atentechnik/Allg emeine Hinweise/Urhe berrecht/Urheberrecht @ 0 \mod_115875695 4232_6.doc @ 153 @

1.5 COPYRIGHTS

This manual including all contained figures is protected by copyright law. Any use of this

manual by a third party in non-compliance with the international copyright law shall hereby

be prohibited. Any reproduction, translation and electronic or photographic archiving or

modification requires previous written agreement by ads-tec GmbH.

In the event of non-compliance, you shall be obliged to compensate for damages.

Pos: 7/D atentechni k/Allgemeine Hinweis e/Umweltbedingunge n/Umweltbedinu ngen für VMT 60xx- Serie @ 2\mod_1263 307758056_6.d oc @ 6981 @

Industrial PCs OPC6012/6015

1.6 ENVIRONMENTAL CONDITIONS

The device may be operated under the following conditions. Failure to observe these

specifications will terminate any warranty for this device. Ads-tec cannot be held liable for

any damages arising due to improper use and handling.

Temperature

in operation -20 ... 55°C

for storage -30 ... 60°C

Humidity:

In operation 10 … 85% without condensate

For storage 10 … 85% without condensate

Vibration resistance

Standard EN 60068-2-6 / 1 G, 10 … 150 Hz

Additionally applies MIL-STD 810F (01.2000), annex C., figure 514.5C

(US highway truck transportation)

Shock resistance

Standard EN 60068-2-27 / 5 G, with a half-wave of 11 ms duration

Pos: 8/D atentechni k/Allgemeine Hinweis e/Normen/Normen f ürVMT -Serie @ 2\ mod_1263309234 182_6.doc @ 6984 @

1.7 STANDARDS

This device complies with the requirements and protective aims of the following EC

regulations:

This device meets the test requirements for granting the CE sign according to the

European test standards EN 61000-6-4 and EN 61000-6-2.

This device complies with the test requirements in accordance with DIN EN 60950

(VDE0805, IEC950) "Safety of Information Technology Equipment"

The device meets the DIN EN 60068-2-6 test requirements (sinus excitation).

The device meets the DIN EN 60068-2-27 test requirements (shock resistance

test).

Note:

All connected components, as well as cable connections must also meet these

requirements for compliance with the EMC legislation. For this reason, screened

bus and LAN cables including screened connectors must be used and installed

according to the instructions in this user manual.

Note:

By using the CE conformity declaration in this document, you can find detailed

information about the standards applicable to this device.

Industrial PCs OPC6012/6015

Warning:

This is equipment of class A. This unit might cause radio interferences in living

areas; in this case the operator might be obliged to take suitable protective

measures at the operator’s expense."

Pos: 9/D atentechni k/Allgemeine Hinweis e/Ausstattungsvaria nten/Ausstattungs varianten für VMT 600 0erS erie @ 2\mod_ 1263211168928_ 6.doc @ 6933 @

1.8 EQUIPMENT VERSIONS

The system is available in two equipment versions:

Platform including a Flash SSD:

Platform without any rotating mass storage medium (hard disc, etc.) and with an embedded

operating system (Windows CE 6.0 / XP embedded) for stationary use with a standard

Ethernet.

Platform including a hard disc:

Equipped with a hard disc for stationary use, e.g. in the manufacturing department using a

standard operating system.

Pos: 10 /Datentech nik/Allgemeine Hinw eise/Lieferumfang/Li eferumfang für VMT 6 0xx-Serie @ 2\mod_ 1263299644184_ 6.doc @ 6976 @

1.9 SCOPE OF DELIVERY

Please check that all of the following components are contained in the packaging:

•1 x device

•4-pin Lead-through connector from Phoenix Contact

•Service CD

Optional delivery scope

•Operating system

Pos: 11 /Datentech nik/Betriebshinweise/ Betriebsort/Betri ebsort für VMT-Serie @ 2\mod_126 8841352905_6.doc @ 7 486 @

Industrial PCs OPC6012/6015

2OPERATING INSTRUCTIONS

This device contains electrical voltages and extremely sensitive components. The

manufacturer, or a service partner authorised by the manufacturer, should be consulted if

you plan to make any modifications. For this type of work, the device must be switched off

at the mains and the power lead must be disconnected. Suitable measures for avoiding

electrostatic discharge towards parts of the components when touching the equipment

must be taken. If the device is opened by an unauthorised person, hazards for the user

might arise and any warranty claim will cease.

General instructions:

All users must read this manual and have access to it at all times.

Installation, commissioning and operation may only be carried out by trained and

qualified staff.

The security instructions and the manual itself must be observed by all persons

who work with this device.

At the location of use the valid guidelines and regulations for accident prevention

must be observed.

The manual contains the most important instructions on how to use this device in a

safe way.

Appropriate storage, proper transport, installation and commissioning, as well as

careful operation are prerequisites for ensuring safe and proper operation of the

device.

The device can be cleaned by using a soft cloth and a commercially available

glass cleaning agent (e.g. Sidolin) with low alcohol content.

Warning:

Any leads (e.g. power leads, interface cables) may only be connected if the device

is switched off in order to avoid damaging the device.

2.1 OPERATING LOCATION

The control system is designed for use inside a switching cabinet. You must ensure

compliance with the specified environmental conditions. Using the device in non-specified

environments, for example on board ships, or in areas that might contain explosive gases,

or in extreme heights is prohibited.

Warning:

The device may only be switched on after acclimatising to the ambient temperature in

order to avoid condensate accumulation. The same applies if the device has previously

been exposed to extreme temperature variations.

To avoid overheating in operation: The device must not be exposed to direct

radiation by sunlight or any other light or heat source.

Pos: 12 /Datentech nik/Betriebshinweise/ Schäden durch uns achgemäßen Gebra uch/Schäden durch u nsachgemäßen Gebr auch @ 0\mod_115 8827867958_6. doc@ 221 @

2.2 DAMAGE DUE TO IMPROPER USE

If the control system shows any obvious damage, e.g. caused by improper operating or

storage conditions or by improper use or handling, you must immediately put the device out

of operation and protect it from being accidentally switched on.

Pos: 13 /Datentech nik/Betriebshin weise/Gewährleistung / R eparatur/Gewährleist ung /R eparatur @ 0\m od_115882805 4427_6.doc @ 223 @

2.3 WARRANTY /REPAIR

During the warranty period, any repair must be carried out by the manufacturer or by

persons duly authorised by the manufacturer only.

Pos: 14 /Datentech nik/Betriebshinweise/ Behandlung und Ents orgung von Lithium- Batterien/Behan dlung und Entsorgung vo n Lithium-Batterie n @ 1\mod_1247056 308470_6.doc @ 592 2@

Industrial PCs OPC6012/6015

2.4 TREATMENT AND DISPOSAL OF LITHIUM BATTERIES

This device contains a lithium battery for supplying the system clock with power as long as

the supply voltage is not connected. The battery has a life cycle of 3 - 5 years depending

on which load is applied.

Note:

The more the battery is exposed to higher temperatures, the faster it ages.

Warning:

There is an acute risk of explosion should the wrong type of battery be used.

Warning:

Do not put lithium batteries into a fire, do not solder on the cell body, do not

recharge them, open them, short-circuit them, do not reverse their polarity or heat

them up over 100°C; dispose of them properly and protect lithium batteries from

direct sun light, humidity and condensation.

Lithium batteries may only be replaced by the same type, or by a type recommended by

the manufacturer.

The lithium battery must be disposed of according to the local legislation at the end of its

life cycle.

Pos: 15 /Datentech nik/Betriebshinweise/ Sicherheitshin weise/Sicherheitshinw eise @ 0\mod_1 162458821197 _6.doc @ 1558 @

Industrial PCs OPC6012/6015

2.5 NOTES ON SAFETY

Warning:

Installation works at the device are only permitted if the device is disconnected from

the power supply and protected from accidental switch-on.

Note:

Always adhere to the safety measures applicable when handling components at

risk of being destructed by electrostatic discharges.

(EN 61340-5-1 / EN 61340-5-2)

Pos: 16 /Datentech nik/Montage/Montages kizzen/Außenab messungen des Ger äts/Montageskizze / Außenabmessung en für VMT 6012 @ 1\ mod_122656194 3192_6.doc @ 4171 @

Industrial PCs OPC6012/6015

3MOUNTING

3.1 EXTERNAL DEVICE DIMENSIONS FOR OPC6012

Industrial PCs OPC6012/6015

3.1 INSTALLATION LAYOUT FOR OPC6012

Pos: 17 /echnik/Inb etriebnahme/System merkmale/Inbetrie bnahme für VMT 60 xx-Serie @ 2\mod_126 3217785475_6. doc@ 6944 @

Industrial PCs OPC6012/6015

3.2 EXTERNAL DEVICE DIMENSIONS FOR OPC6015

Industrial PCs OPC6012/6015

3.3 INSTALLATION LAYOUT FOR OPC6015

Pos: 17 /echnik/Inb etriebnahme/System merkmale/Inbetrie bnahme für VMT 60 xx-Serie @ 2\mod_126 3217785475_6. doc@ 6944 @

Industrial PCs OPC6012/6015

4COMMISSIONING

The power supply connection and interfaces of this device are installed underneath a

protective cover. This cover has to be removed in order to connect the power supply lead

and the interface cables.

All supply leads and all required data leads have to be connected before commissioning.

Warning:

The device must be switched off before connecting or disconnecting any cables in

order to prevent damage to the electronics!

The device may only be switched on after acclimatising to the ambient temperature

in order to avoid condensate accumulation. Make sure to meet the permissible

voltage requirements for this device.

After switching off and before switching on you must wait for at least 5 seconds.

Note:

The screen of a data cable must always be connected with the connector housing

(EMC).

Under the embedded operating system, interfaces must explicitly be enabled and

required drivers must be installed in order to be able to use them.

4.1 AVAILABLE INTERFACES

Note:

If the case is connected with earth potential at the provided PE contact (e.g. by

connecting the PE contact with the device plug), the electrical insulation is no

longer given. This also applies if the device is installed by using a metal retainer

clip.

If you want to have the device electrically insulated from the power supply, you

have to use a method of installation that ensures appropriate insulation.

Pos: 18 /Datentech nik/Inbetriebnahme/R eihenfolge der Inbetrie bnahme/Reihenf olge der Inbetriebnah mef ürVMT 60xx- Serie @ 1\mod_1222 073159179_6.d oc @ 4100 @

Pos: 19 /Datentechni k/Inbetriebnahme/Betri ebsbereitschaft prüfen/ Betriebsbereitschaft prüf enf ürO PC/CPC/PLC/OTC /ITC/VMT-Serie(+ Monitore) / IPC 5100/550 0/2400/1100 @ 0\mod_1 158905578361_6.do c@ 38 1@

4.2 CHECK FOR OPERATIONAL READINESS

Check the device for any hidden damage potentially caused by improper transport,

operating or storage conditions or by improper use or handling (e.g. smoke development

from the device, etc.). If any damage is detected, the device must be put out of service

immediately and protected from accidental switch-on.

Pos: 20 /Datentech nik/Bedienung/Frontseitig e Tasten/Fronts eitige Bedientast en für VMT 60xx-Serie @ 2\ mod_126052665 2092_6.doc @ 6881 @

Industrial PCs OPC6012/6015

5OPERATION

Pos: 22 /Datentech nik/Bedienung/Touch Scr een/Touch Screen für VMT 60xx @ 1\ mod_1246361069 977_6.doc @ 5853 @

5.1 FRONT CONTROL KEYS

Depending on the device equipment version, an operating system (Windows CE.net,

Windows XP embedded or Windows XP Prof.) and a soft keyboard are already installed ex

factory. The keys on the front panel are occupied with the following functions by a specific

driver in the soft keyboard:

Level 1:

Activate and deactivate the soft keyboard for

letter/character input using the touch screen.

Level 2:

Decrease display brightness

Level 1:

Change task (Alt+ESC) in Windows.

Level 2:

Increase display brightness

Level 1:

Not connected

Level 2:

The volume can be decreased with devices equipped with an

audio output.

Level 1:

Right mouse-key function

Level 2:

The volume can be increased with devices equipped with an audio

output

Shift key (SHIFT) for activating the second keyboard level. This

key must be pressed simultaneously with the desired function key

Note:

If the software keyboard is not installed, only the functions for display settings and

volume control are active. The controller display will not be output on the display, in

this case.

The key functions can be modified in accordance with customer specific

requirements. Above described functions are pre-set ex works.

Pos: 25 /Datentechni k/Bedienung/Softke yboard/Softkeyboard für OPC / CPC / OTC / VMT / STC- Serie@ 1\ mod_120471408 2851_6.doc @ 3402 @

5.2 SOFT KEYBOARD

If an operating system is installed ex works, the soft keyboard is also preinstalled. If the

operating system is delivered separately with the device, the soft keyboard must also be

installed on site. By using the soft keyboard, data can be entered via the touch screen like

with an external keyboard.

Industrial PCs OPC6012/6015

HOW TO OPERATE THE SOFT KEYBOARD FROM VERSION 3.11:

Activate and deactivate the soft keyboard for letter/character input using

the touch screen

Switches numeric keys on and off

(only if numeric keys are visible)

Switching between different representations

(Alphanumeric keys Numeric keys Function key bar)

Soft keyboard representation, zoom in

Soft keyboard representation, zoom out

Note:

If a function is to be activated, which requires pressing two keys at the same time

(e.g. Alt + F4), these keys have to be pushed one after another at the soft

keyboard, and the special keys Shift, Alt and Ctrl must always be pushed first.

Due to differences in programming of a large variety of software, we cannot ensure

that the soft keyboard works properly with all software programmes. When

deactivating the soft keyboard, the previously active state (alphanumeric / numeric

keys or function keys) will be stored and will be displayed when re-activating the

keyboard.

Pos: 26 /Datentechni k/Bedienung/Status-A nzeigen/SYS-LED/ SYS-LED für OPC / CPC / PLC / OTC / ITC / VMT( +Monitore) - Serie / IPC 5100 / 5300 / 5500 / 1100 @ 1\mod_12 04714132162_6.d oc@ 3405 @

Industrial PCs OPC6012/6015

5.3 STATUS INDICATORS

SYS LED (BICOLOURED)

Depending on the colour and type of flashing, different device states are displayed by the

SYS LED.

The following signals are displayed:

LED lights green The device is ready for operation (Power ON).

LED is off The device is switched off. (POWER OFF)

5.4 TOUCH SCREEN

The control system is equipped with a touch screen monitor. The touch screen monitor is

internally connected with the USB interface. The driver software required for using the

touch screen is integrated in the corresponding operating system, or can alternatively be

installed from the enclosed service CD.

Pos: 23 /Datentech nik/Bedienung/Status -Anzeigen/S YS-LED/SYS-LED für VMT 60xx-Serie @ 2\ mod_1260525540 269_6.doc @ 6876 @
