ADTRAN Total Access 850 Instruction Manual

64200376L1-5A
Issue 14, April 2003
CLEI Code: SILCHL0DAA
Total Access 850 System Installation and Maintenance
64200376L1-5A 1
Trademarks: Any brand names and product names included in this document are
trademarks, registered trademarks, or trade names of their respective holdres.
Contents
1. General........................................................................... 1
2. Product Overview........................................................ 1
3. Installation..................................................................... 3
4. Specifications................................................................. 7
5. Maintenance.................................................................. 7
6. Warranty and Customer Service................................ 7
7. Regulatory Requirements............................................ 7
Figures
Figure 1. Total Access 850 ............................................... 1
Figure 2. Total Access 850 Backplane............................ 2
Figure 3. Total Access 850 Component Layout and
Cable Connections ........................................... 3
Figure 4. Connector Pinout............................................. 5
Figure 5. T1 Connections................................................. 5
Figure 6. Alternate Power Connection.......................... 6
Figure 7. Office Alarm Connections .............................. 6
Tables
Table 1. Total Access 850 Backplane Connections....... 4
Table 2. Wire Wrap Identification.................................. 6
Table 3. Alarm Notification............................................. 6
Table 4. Specifications and Part Numbers.................. 10
1. GENERAL
This practice provides installation and maintenance
procedures for the ADTRAN Total Access 850 System.
The Specifications and Part Numbers Table (Table 4 on
page 10) shows part numbers for equipment and docu-
ments referenced in this practice. Referenced practices
should be on-hand during system installation.
Revision History
Update document to reflect PSU hardware changes.
Updated Figures 1, 2, and 4. Removed IPX routing. Cor-
rected CAPS address. Updated Backup Battery Pack
Part Number List. Corrected connector reference.
2. PRODUCT OVERVIEW
The Total Access 850 system (see Figure 1) is an
integrated access device designed for cost-effective
deploymentofvoice and dataservices atthe customer’s
premises. The Total Access 850 system benefits
integrated communications providers, such as CLECs,
ILECs, and ISPs, who require a customer premises
device that integrates voice and data functions, and
provides a viable migration path from TDM to packet-
based technology. The Total Access 850 features remote
management, an integrated IP router, and special
services slots.
Figure 1. Total Access 850
The Total Access 850 is a modular device, with two
common slots and eight access slots. Common cards
required for operation are a power supply unit (PSU)
and a system controller. System controllers include a
bank controller unit (BCU) (L1 and L2) and a router
control unit (RCU). The RCU includes a wide area
network interface (T1 or SDSL), DSX-1 PBX interface,
Nx56/64 V.35 interface, and built-in IP router. Six
access slots allow the user to combine a variety of voice
and data services. Up to six Quad FXS or Quad FXO
access modules can be installed to support up to 24
analog voice lines. Other access modules for data
applications include the OCU DP (only supported in
the BCU) and ISDN U-BR1TE. The other access slots are
used for Nx56/64 module with the BCU, the Echo
Cancellation card for use with the T1 ATM RCU, and
the DSX-1 card used with the T1 TDM RCU.
Using local or remote inband management, carriers can
turn features, functions, and access ports on and off.
Easy access to modules, common cards, power
supplies, and the battery back-up system simplify
maintenanceprocedures.Hot-swappablemodulesmay
be replaced without disrupting other units. The four-
circuit-per-module design ensures that only four
analog circuits are affected when replacing a module.
NOTE
This is not an operational manual. To obtain an
operational manual, contact ADTRAN Technical
Support at (888) 4ADTRAN.

2 Issue 14, April 2003 64200376L1-5A
A compact, NEBS-compliant cabinet suitable for the
customer premises or the central office provides added
safety and reliability. The 2U design uses little rack
space. When wall mounted, the 8.5-inch by 11-inch
chassis occupies a space the size of a piece of notebook
paper. Two Total Access 850 systems can be mounted
side-by-side in either 19-inch or 23-inch relay racks.
Preconfigured packages are available.
Features
The Total Access 850 includes the following features:
• T1/FT1 integrated access
• TDM to ATM migration (RCU)
• Modular network interface (RCU)
• Integrated IP router (RCU)
• V.35 Nx56/64 DTE interface
• DSX-1 card for Dual T1 support (RCU)
• TR-08 signaling support
• Analog FXS and FXO voice expansion (four per card)
• SNMP management (RCU)
• NEBS and UL 1950 compliance
• Industry leading 10-year warranty
Functional Description
The Total Access 850 System comprises the chassis,
common cards, and access modules. Associated with
the system are additional elements including an AC to
DC power supply and battery charging unit and a bat-
tery pack for backup power.
External AC and DC Power. The ADTRAN AC/DC
Power Supply/Battery Charging unit receives its
power from a standard 115 VAC outlet. The PSU
supplies a constant -48 VDC to the voice cards. The
power supply battery charging circuit maintains the
battery pack at peak charge. In the event of an AC
power failure, the battery backup circuit automatically
provides battery power to the PSU for up to 8 hours.
WhenACpower is restored, input power automatically
returns to the AC supply and the battery charging
circuit will recharge the battery to peak.
On the Total Access 850 chassis, the incoming power
termination point is on either of two backplane
connections: P7 or P6. (See Figure 2.) Both sources
connect
directly to the PSU. Connector P6 is used when the
chassis is powered by the ADTRAN AC/DC Power
Supply unit (P/N 1175043L2) which mounts externally
to the chassis. Connector P7 is used when -48 VDC is
available on site and screw-type terminal connections
are required.
Figure 2. Total Access 850 Backplane
PSU. The Power Supply Unit supplies -48 VDC and
20 Hz ringing voltage to the RCU, BCUs, and access
modules. The PSU converts -48 VDC input to the
required voltages needed to operate all common units
andaccessmodules.Theringgeneratorcircuitprovides
20 Hz ring voltage to the analog access modules.
The PSU faceplate (see Figure 1 on page 1) shows the
following: a ring enable button, a power LED, a ring
LED, a bank alarm LED, and an alarm cutoff (ACO)
pushbutton switch. The separately fused ringgenerator
supplies up to 20 REN to the access modules.
BCU. The Bank Controller Unit is a common module
plug-in unit with a built-in CSU. The BCU provides all
controlfunctionsfortheTotalAccess850commonunits
and all individual access modules. A faceplate ADMIN
DB-9 provides access for a VT 100 terminal for screen
menu provisioning, and bantam test jacks provide
transmit and receive monitoring. An additional TEST
DB-9providestimingforDS0testequipment.Faceplate
LEDs show status information for the network and
Fractional (DSX-1) T1 (L2 only). The unit consists of a
main circuit board and daughter card and inserts
directly in the controller slot on the Total Access 850
shelf. An 8-position DIP switch is mounted on the
daughter card and is used for T1 provisioning and
clocking.
RCU. The Router Control Unit is a dual board assembly
that provides the network interface. The RCU can
provision, test, and provide status for any card in the
channel bank. A faceplate CRAFT DB-9 provides access
foraVT 100 terminalfor screenmenuprovisioning,and
bantam test jacks provide transmit and receive
monitoring. Faceplate LEDs show status information
for the network, V.35, and Ethernet ports.
WARNING
On Total Access 850 installations that do not use
all chassis slots, UL 1950/NEBS requires that the
empty slots must have a Total Access 850 blank unit
(part number 1175099L1) installed in the opening.

64200376L1-5A Issue 14, April 2003 3
Access Modules. The Total Access 850 is designed to
support Quad FXS, Quad FXO, OCU DP (only
supported with the BCU), DSX-1 (p/n 1200385L1) and
UBR1TE access modules.
3. INSTALLATION
Before installing the TA 850, carefully inspect the Total
Access 850 Base Unit for shipping damage. If you
suspect damage, file a claim immediately with the car-
rier and then contact ADTRAN Customer and Product
Service. (See “Warranty and Customer Service” on
page 7.) If possible, keep the original shipping contain-
er for returning the Total Access 850 for repair or for
verification of damage during shipment.
Your ADTRAN shipment includes the following items
(if the unit is not purchased directly from ADTRAN, it
may be packaged differently):
• Total Access 850 chassis, PSU, RCU, and blanks
• Total Access 850 System Installation and Mainte-
nance Practice
Grounding Instructions
This section provides grounding instruction informa-
tion from the Underwriters' Laboratory UL 1950 Stan-
dard for Safety: Information Technology Equipment.
An equipment grounding conductor that is not smaller
in size than the ungrounded branch-circuit supply
conductors is to be installed as part of the circuit that
supplies the product or system. Bare, covered, or
insulated grounding conductors are acceptable.
Individually covered or insulated equipment
grounding conductors shall have a continuous outer
finish that is either green, or green with one or more
yellow stripes. The equipment grounding conductor is
to be connected to ground at the service equipment.
The attachment-plug receptacles in the vicinity of the
product or system are all to be of a grounding type, and
the equipment grounding conductors serving these
receptacles are to be connected to earth ground at the
service equipment.
A supplementary equipment grounding conductor
shall be installed between the product or system and
ground that is in addition to the equipment grounding
conductor in the power supply cord.
The supplementary equipment grounding conductor
shall not be smaller in size than the ungrounded
branch-circuit supply conductors. The supplementary
equipment grounding conductor shall be connected to
the product at the terminal provided, and shall be
connected to ground in a manner that will retain the
ground connection when the product is unplugged
from the receptacle. The connection to ground of the
supplementary equipment grounding conductor shall
beincompliancewiththerulesfor terminatingbonding
jumpers at Part K or Article 250 of the National
Electrical Code, ANSI/NFPA 70. Termination of the
supplementary equipment grounding conductor is
permitted to be made to building steel, to a metal
electrical raceway system, or to any grounded item that
is permanently and reliably connected to the electrical
service equipment ground.
Install the Chassis
Standard installation is a single unit wall mount. Posi-
tion the chassis with the access modules facing up.
Mount on heavy plywood (3/4 inch minimum). Refer
to Figure 3 for component layout.
Required Clearances. A minimum 10-inch clearance
is required on the front end for access module insertion
and withdrawal. On the backplane end, a five-inch
clearance is required for wiring access to the V.35
connector. For those units installed in a
communications bay, standard bay clearances are
satisfactory.
Figure 3. Total Access 850 Component Layout and
Cable Connections
Mounting Brackets. The Total Access 850 chassis
includes wall mount brackets. If rack mount brackets
are needed, use part number 1175045L1 or 1175046L1
for 19-inch or 23-inch, respectively.
Tools Needed (Wall-Mount). The Total Access 850
chassis mounts and connects with standard fasteners
and hand tools:
• Four #8 x 3/4 inch pan-head wood screws
• Drill and drill bit set
• Flat head screwdriver (medium)
• Two Phillips head screwdrivers (small /medium)
• Wire-wrap gun (optional)
• 25-pair male amphenol cable (customer connection)
• Selected punch-down block and tool
Mount the Chassis. Install the chassis as follows:
1.Position the chassis at the desired location; observe
required clearances and ensure cable plugs reach
their designated sockets.
2.Ensure the chassis is plumb; then mark through the

4 Issue 14, April 2003 64200376L1-5A
flange mounting holes to identify where the pilot
holes will be drilled.
3.Using a 1/16 inch bit, drill pilot holes at the marked
locations.
4.Mount the chassis using the four #8 by 3/4 inch pan-
head wood screws.
Connections. All connections are made through
terminals, jacks, and wire-wraps on the backplane.
Refer to Figure 2 on page 2 for backplane connections.
Refer to Table 1 on page 4 for backplane reference
designator descriptions and functions supported.
A removable rear cover provides access to the
backplane, and an access panel that mounts to the rear
cover allows access to wire-wrap strips P1, P3, and P5,
power terminal strip P7, and clock termination switch
SW1 without removing the main rear cover. Most CPE
applications will not require removal of the rear cover.
Table 1. Total Access 850 Backplane Connections
UL 1950 Deployment Guidelines. One of the
following two powering schemes shall be used when
powering this equipment:
1. Use the ADTRAN power supply (part number
1175043L2).
2. Do the following:
a.Connect the unit to a reliably grounded -48 Vdc
source which is electrically isolated from the AC
source.
b.A readily accessible disconnect device, suitably
approved and rated, shall be incorporated in the
input source wiring.
c. The branch circuit overcurrent protection shall be a
fuse or circuit breaker rated minimum 48 V, maxi-
mum 20 A.
d.This unit shall be installed in accordance with the
requirements of NEC NFPA 70.
The installation configurations codes are given below:
Alternate Connections. For wire-wrap or screw
terminal connections, the rear cover does not need to be
removed; only the terminal access cover needs to be
removed. Make wire-wrap or screw terminal
connections as follows:
1.Unscrew the access cover hold-down screw.
2.Slide the access cover down slightly to disengage the
lock-tabs from their slots.
3.Identify the wire-wrap pins designated for use, and
make the connections starting with the pins closest to
the exit port to avoid wiring interference as work
progresses.
4.If alternate power connection to P7 is to be used,
make those terminal connections last.
5. Carefully route wiring through the exit port.
6.Position and align the access cover tabs to the slots;
insert the tabs and slide the cover up slightly until
the screw holes are aligned. Ensure that exit wiring is
not pinched or damaged.
7.Reinsert the hold-down screw.
Customer Connection. One 50-pin female
amphenol connector (P2) provides the interconnect
wiring for the access modules located in slots 1 through
6 of the chassis. This connector is usually terminated
with a punch-down block for premises wiring or
connected directly to a cross-connect or main
distribution frame. Figure 4 on page 5 details the
connector pinout.
T1 Connection. Therearetwoterminationpointsfor
connecting the network T1 to the chassis: the primary
RJ-48 connector (JP2) and the alternate wire-wrap pins
on terminal strip P3 (as shown in Figure 2 on page 2).
Only one connector type is used (not both).
Ref Des Device/Label Technology
P1 wire-wrap strip clock/tests
P2 50 pin amphenol FXO, FXS, etc.
P3 wire-wrap strip alternate T1 interface
P5 wire-wrap strip alarms
P6 4 pin jack primary -48 V in
P7 3-lug terminal alternate -48 V in
JP1 RJ-48/E-NET 10BaseT Ethernet
JP2 RJ-48/T1 primary T1 interface
JP3 RJ-48/FT1 DSX1 interface
JP4 RJ-48/MAINT RS 232 craft interface
J1 V.35 Nx56K/64K
In Out
PC FC
IC E-
TC XX
CAUTION
Both Power and T1 services have two connection
points. In all cases, only one of the connection
points is used. Adhere to the instructions in the
following subsections to ensure correct installation.
CAUTION
Use wire gauge suitable for the application.

64200376L1-5A Issue 14, April 2003 5
TheT1 primary connection is via theRJ-48connector labeled
T1 (JP2). This arrangement provides a convenient T1
connection for those installations where a T1 Smart Jack is
used.
The RCU and BCU L2 common module provides
termination for DSX-1 and DS1 signals. For wire-wrap
connections,shieldisprovidedbythegroundpinadjacent
to the DSX-1/DS1 pin set (see Figure 5 on page 5). Line
build-outand equalization settingsareprovisionedon the
RCU.
Power Connection. There are two power
connections on the backplane: a modular DC plug (P6),
and a three lug terminal strip (P7). (Refer to Figure 2 on
page 2.)
The primary connection is the modular plug, which
receives -48 VDC from the ADTRAN power supply/
battery charging unit (P/N 1175043L2). The alternate
connection is screw terminal P7, which can be used if
-48 Vdc is available as in central office applications. The
screw terminal connection is shown in Figure 6 on page 6.
Figure 4. Connector Pinout
Figure 5. T1 Connections
CAUTION
During installation, power should be the last
connection made after all other wire-wrap
connections are completed.

6 Issue 14, April 2003 64200376L1-5A
Figure 6. Alternate Power Connection
Office Alarms. Backplane alarm connections(P5)are
labeled as shown in Table 2 on page 6 and illustrated in
Figure 7 on page 6. Alarm relay contacts are open
duringnormaloperation.Thealarmrelaycontactsclose
in the event of a local alarm condition or the receipt of
an alarm from the T1 carrier. In a carrier alarm
condition such as a Red, Yellow, or Blue (unframed all
1s), various alarm contacts in the PSU close. Carrier
alarm conditions cause the Total Access 850 to initiate
trunk processing. The following chain of events then
occur:
1.MJ will be directly shorted to MJR.
2.MJV will be directly shorted to MJVR.
Contacts MJ and MJR can be overridden manually
during an alarm condition by pressing the ACO
pushbutton on the PSU faceplate. If the 3-Amp power
fuse on the PSU trips, the -48ALM relay will close,
providing a -48 VDC signal on that pin. This alarm
cannot be overridden by the ACO pushbutton. Refer to
Table 3 on page 6 for alarm notifications.
Table 2. Wire Wrap Identification
Figure 7. Office Alarm Connections
Table 3. Alarm Notification
NOTE
The following section is for information only, and
the features described are not necessary for typical
applications.
P3 Wire-Wrap Connections
T1 Connections
1 R1 DS1 Ring input from network
2 T1 DS1 Tip input from network
3 R DS1 Ring output from network
4 T DS1 Tip output from network
5 Gnd Ground
P5 Wire-Wrap Connections
Alarm Connections
1 -48 ALM DC Alarm output
2 MJVR Major Alarm Visual Common
3 MJV Major Alarm Visual
4 MJR Major Alarm Audible Common
5 MJ Major Alarm Audible
Alarm Condition Relays Activated
MJR MJVR -48 ALM
Red Alarm X X
Yellow Alarm X X
AIS Alarm X X
PSU Power Fuse Fails X X X
Alarms ACO Deactivates X X
Note: ACO will not deactivate MJR after a power fuse
failure.

64200376L1-5A Issue 14, April 2003 7
Install any Option Modules
After installing the Total Access 850 Base Unit and con-
necting the required cables, you can install your choice
of option modules.
Individual access modules insert from the front. A
locking bar holds the modules in place for added
security. Disengaging the captured screw allows
removal of the locking bar. All wiring connections
terminate on the backplane. Refer to Table 2 on page 6
for wire-wrap connections, and refer to Figure 2 on
page 2 for backplane layout. Refer to Table 1 on page 4
for backplane reference designator descriptions and
functions supported.
Power-Up
Asshipped, theTotalAccess 850 is set to factory default
conditions. After installing the Total Access 850 Base
Unit and any option modules, the Total Access 850 is
ready for power-up.
4. SPECIFICATIONS
Table4onpage10givesspecificationsand relevantpart
numbers.
5. MAINTENANCE
The Total Access 850 System does not require pro-
grammed maintenance for design operation.
ADTRAN does not recommend that repairs be
attempted in the field. Repair services are obtained by
returning the defective unit to ADTRAN Customer
Service.
6. WARRANTY AND CUSTOMER SERVICE
ADTRAN will replace or repair this product within the
warranty period if it does not meet its published
specifications or fails while in service. Warranty
information can be found at www.adtran.com/
warranty.
ADTRAN will replace or repair this product within the
warranty period if it does not meet its published
specifications or fails while in service. Warranty
information can be found at www.adtran.com/
warranty.
A return material authorization (RMA) is required
prior to returning equipment to ADTRAN. For service,
RMA requests, training, or more information, use the
contact information given below.
Product Support Information
Pre-Sales Inquiries and Applications Support.
Please contact your local distributor, ADTRAN Appli-
cations Engineering, or ADTRAN Sales:
Post-Sale Support. Please contact your local
distributor first. If your local distributor cannot help,
please contact ADTRAN Technical Support and have
the unit serial number available.
Repair and Return. If ADTRAN Technical Support
determines that a repair is needed, Technical Support
will coordinate with the Customer and Product Service
(CAPS) department to issue an RMA number. For
information regarding equipment currently in house or
possible fees associated with repair, contact CAPS
directly at the following number:
Identify the RMA number clearly on the package
(below address), and return to the following address:
ADTRAN, Inc.
901 Explorer Blvd.
Huntsville, Alabama 35806
RMA # _____________
7. REGULATORY REQUIREMENTS
Affidavit Requirements for Connection to Digital
Services
• An affidavit is required to be given to the telephone
company whenever digital terminal equipment with-
out encoded analog content and billing protection is
used to transmit digital signals containing encoded
analog content which are intended for eventual con-
version into voiceband analog signals and transmit-
ted on the network.
• The affidavit shall affirm that either no encoded ana-
logcontentorbilling information isbeingtransmitted
or that the output of the device meets Part 68 encoded
analog content or billing protection specifications.
• End user/customer will be responsible for filing an
affidavit with the local exchange carrier when con-
necting unprotected customer premise equipment
WARNING
Remove the 20 Hz fuse before exposing backplane or
accessing channel units.
Applications Engineering (800) 615-1176
Sales (800) 827-0807
Technical Support (888) 4ADTRAN
CAPS Department (256) 963-8722

8 Issue 14, April 2003 64200376L1-5A
(CPE) to 1.544 Mbps or subrate digital services.
• Until such time as subrate digital terminal equipment
is registered for voice applications, the affidavit re-
quirement for subrate services is waived.
Affidavit for Connection of Customer Premises
Equipment to 1.544 Mbps and/or Subrate Digital
Services
Forthe worktobeperformed in thecertifiedterritory of
________________________(telco name)
State of ________________
County of ________________
I, _____________________________ (name),
__________________________________(business
address),
____________________ (telephone number) being duly
sworn, state:
I have responsibility for the operation and maintenance
of the terminal equipment to be connected to 1.544
Mbps and/or ________ subrate digital services. The
terminal equipment to be connected complies with Part
68 of the FCC rules except for the encoded analog
content and billing protection specifications. With
respect to encoded analog content and billing
protection:
( ) I attest that all operations associated with the
establishment, maintenance, and adjustment of the
digital CPE with respect to analog content and
encoded billing protection information continu-
ously complies with Part 68 of the FCC Rules and
Regulations.
( ) The digital CPE does not transmit digital signals
containing encoded analog content or billing infor-
mation which is intended to be decoded within the
telecommunications network.
( ) The encoded analog content and billing protection is
factory set and is not under the control of the customer.
I attest that the operator(s)/maintainer(s) of the digital
CPE responsible for the establishment, maintenance,
and adjustment of the encoded analog content and
billing information has (have) been trained to perform
these functions by successfully having completed one
of the following (check appropriate blocks):
( ) A. A training course provided by the manufac-
turer/grantee of the equipment used to encode
analog signals; or
( ) B. A training course provided by the customer or
authorized representative, using training
materials and instructions provided by the
manufacturer/grantee of the equipment used
to encode analog signals; or
( ) C. An independent training course (e.g., trade
school or technical institution) recognized by
the manufacturer/grantee of the equipment
used to encode analog signals; or
( ) D. In lieu of the preceding training requirements,
the operator(s)/maintainer(s) is (are) under the
control of a supervisor trained in accordance
with _________ (circle one) above.
I agree to provide ______________________ (telco’s
name) with proper documentation to demonstrate
compliance with the information as provided in the
preceding paragraph, if so requested.
_________________________________Signature
_________________________________Title
_________________________________ Date
Transcribed and sworn to before me
This ________ day of ________, ________
_________________________________
Notary Public
My commission expires:
_________________________________
FCC regulations require that the following
information be provided in this manual to the
customer:
1.This equipment complies with Part 68 of the FCC
rules. The required label is affixed to the bottom of
the chassis.
2.An FCC-compliant telephone cord and modular plug
is provided with this equipment. This equipment is
designed to be connected to the telephone network
or premises wiring using a compatible modular jack
which is Part 68-compliant. See Chapter 2, Installa-
tion, for details.
3.If your telephone equipment (Total Access 850)
causes harm to the telephone network, the telephone
company may discontinue your service temporarily.
If possible, they will notify you in advance. But if
advance notice isn’t practical, you will be notified as
soon as possible. You will be advised of your right to
file a complaint with the FCC.
4.Your telephone company may make changes in its
facilities, equipment, operations, or procedures that
could affect the proper operation of your equipment.
If they do, you will be given advance notice to give
you an opportunity to maintain uninterrupted service.
5. If you experience trouble with this equipment (Total

64200376L1-5A Issue 14, April 2003 9
Access 850), please contact ADTRAN at (256) 963-8000
for repair/warranty information. The telephone com-
pany may ask you to disconnect this equipment from
the network until the problem has been corrected or
until you are sure the equipment is not malfunctioning.
6.This unit contains no user-serviceable parts.
7.The following information may be required when
applying to your local telephone company for leased
line facilities.
For a T1/FT1 Port:
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
frequencies. Operation of this equipment in a
residentialarea is likelytocauseharmful interferencein
which case the user will be required to correct the
interference at his own expense.
Shielded cables must be used with this unit to ensure
compliance with Class A FCC limits.
Industry Canada Compliance Information
Notice: The Industry Canada label applied to the prod-
uct (identified by the IndustryCanada logo or the “IC:”
in front of the certification/registration number) signi-
fies that the Industry Canada technical specifications
were met.
Notice: The Ringer Equivalence Number (REN) for this
terminal equipment is supplied in the documentation
or on the product labeling/markings. The REN
assigned to each terminal device indicates the
maximumnumberofterminalsthatcanbe connected to
a telephone interface. The termination on an interface
may consist of any combination of devices subject only
to the requirement that the sum of the RENs of all the
devices should not exceed five (5).
Canada Emissions Requirements
This digital apparatus does not exceed the Class A lim-
its for radio noise emissions from digital apparatus as
set out in the interference-causing equipment standard
entitled “Digital Apparatus,” ICES-003 of the Depart-
ment of Communications.
Cet appareil numérique respecte les limites de bruits
radioelectriques applicables aux appareils numériques
de Class A prescrites dans la norme sur le materiel
brouilleur: “Appareils Numériques,” NMB-003 edictee
par le ministre des Communications.
Canadian Class A Products
This Class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme á la
norme NMB-003 du Canada.
Service Type REN/
SOC FIC USOC
1.544 Mbps - SF 6.0N 04DU9-BN RJ-48C
1.544 Mbps - SF and
B8ZS 6.0N 04DU9-DN RJ-48C
1.544 Mbps - ESF 6.0N 04DU9-1KN RJ-48C
1.544 Mbps - ESF
and B8ZS 6.0N 04DU9-1SN RJ-48C
NOTE
When connecting FT1 port towards the network, a
suitable crossover cable is required.
WARNING
Change or modifications to this unit not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.

10 Issue 14, April 2003 64200376L1-5A
Table 4. Specifications and Part Numbers
Environmental
Operating Temperature 0 to 50 oC (32 to 113 oF)
Storage Temperature -20 to 70 oC (-22 to 158 oF)
Relative Humidity 95% maximum, noncondensing
Physical
Dimensions 11” deep x 3 7/16” high x 8 11/16” wide
Weight (fully loaded) 8 pounds
Weight (empty) 5 pounds
Total Access 850 Relevant Part Numbers
Total Access 850 Chassis 1200375L1
RCU, T1 TDM 4200376L1#TDM
RCU, T1 ATM 4200376L1#ATM
RCU, SDSL 1200377L1
BCU 1200373L1
BCU with Fractional T1 1200373L2
PSU 1175006L2
Quad FXS 1175408L2, User Manual 61175408L1-1A
Quad FXO 1175407L2, User Manual 61175407L1-1A
AC Power Supply/Battery Charger 1175043L2
Backup Battery Pack 1175044L1/L2/L4
Single Unit 19” Rack Mount Brackets 1175045L1
Single Unit 23” Rack Mount Brackets 1175046L1
Sample System Configuration Part Numbers
Total Access 850 DC RCU Chassis Bundle 4200376L1
Total Access 850 AC RCU Chassis Bundle 4200376L1#AC
Total Access 850 DC RCU Chassis Bundle + 12 FXS 4200376L2
Total Access 850 AC RCU Chassis Bundle + 12 FXS 4200376L2#AC
Total Access 850 DC RCU Chassis Bundle + 16 FXS 4200376L3
Total Access 850 AC RCU Chassis Bundle + 16 FXS 4200376L3#AC
Other manuals for Total Access 850
7
This manual suits for next models
1
Table of contents
Other ADTRAN Chassis manuals
