6Gb/s Backplane Specification
P/N: 3RAMPD017600 (Version A0)
PCB DIMENSION : 400mm X 37 mm X 2.4mm
PCB LAYERS : 4
COMMUNICATION INTERFACE : SATA/SAS 6.0Gbit/s COMPATIBLE INTERFACE
DC POWER CONNECTOR : 4
SATA HDD 29 PIN CONNECTOR : 10
MINISAS CONNECTOR : 2
SATA Connector: 2
FAN CONNECTOR (4PIN) : 2 (PWM TYPE)
ON BOARD LED :
(A) HDD POWER LED (BLUE)
WHEN HDD INSERT -------- ACTIVE
(B) HDD ACCESS / FAIL LED (GREEN / RED)
WHEN HDD R/W -------- ACTIVE (GREEN)
WHEN HDD FAIL ------- ACTIVE (RED)
ACCESS SINNAL : Always from device
HDD FAIL SIGNAL INPUT CONNECTOR : 1
ON BOARD SENSOR : 1
Temperature setting:
25℃fan speed :70%
35℃fan speed:100%
Temperature Alarm : 47℃
(When the temperature is less than the temperature of 44 ° C, automatic discharge alarm)
FAN SPEED CONTROL : 2 TYPE
(A) AUTO ---- By Temperature
(B) MANUAL
(a) 60% : 60% of the max fan speed
(b) 80% : 80% of the max fan speed
ALARM BUZZER
(A) Fan fail(single beep)
(B) Temperature fail(double beep)
Accommodation Chassis
●RS110-02

10-port 6Gb/s SAS/SATA backplane User’s Manual
3RAMPD017600
The actual product is subject to change without prior notice.
In Win Development Inc. reserves the right to make final modifications. 6
Backplane Layout
(A) Power Connector x 3
Pin No.
Descriptions
1
12V
2
GND
3
GND
4
5V
(B) Fan Connector
Pin No.
Descriptions
1
GND
2
+12V
3
Fan Clock Input
4
Fan PWN
Output

10-port 6Gb/s SAS/SATA backplane User’s Manual
3RAMPD017600
The actual product is subject to change without prior notice.
In Win Development Inc. reserves the right to make final modifications. 7
(C)Fan Setting
Jumper Setting Description
1-2 Short
Alarm Reset
No Jumper on P3 ~P8
Default rpm from 70% /29
℃
to 100%/39
℃
3-4 Short
Fan speed max 60% by temperature control Fan speed
Minimize about 42% to Maximize 60%
5-6 Short
Fan speed max 60% by temperature control Fan speed
Minimize about 42% to Maximize 60%
7-8 Short
Temperature Fault set 55
℃
(D) HDD Fail signal input
Pin No.
Descriptions
1
HDD1
2
HDD2
3
HDD3
4
HDD4
5
HDD5
6
HDD6
7
HDD7
8
HDD8
9
HDD9
10
HDD 10

10-port 6Gb/s SAS/SATA backplane User’s Manual
3RAMPD017600
The actual product is subject to change without prior notice.
In Win Development Inc. reserves the right to make final modifications. 8
(E) SGPIO Setting x3
E1 for HDD 1~4 ; E2 for HDD 5~8 ; E3 for HDD 9~10
(F) SGPIO signal Connector for HDD 9/10
(G) Mini SAS connector x2
(H) SATA Connector x2
Led Indicator
Pin No. Descriptions
1-2 short
SGPIO Disable
2-3 short
SGPIO Enable
Pin No.
Descriptions
Pin No.
Descriptions
1
NC
5
SG_LD
2
SG_DI
6
GND
3
GND
7
SG_CK
4
SG_DO
8
GND
LED
Sta tus
Color
Power Led
Power On
Blue
HDD Led
Active
Green
HDD Led
Fail
Red

10-port 6Gb/s SAS/SATA backplane User’s Manual
3RAMPD017600
The actual product is subject to change without prior notice.
In Win Development Inc. reserves the right to make final modifications. 9
Backplane Layout
The In Win 10-Port 6Gb/s Backplane can be assembled on In Win Storage Server
Chassis RS110-02. Please refer to the chassis Quick Installation Guide.
