ADTRAN XFP NG-PON2 ONU User manual

Q
uic
k
Start
Description
The Next-Generation Passive Optical Network 2 Optical Network
Unit (NG-PON2 ONU) Small Form-factor Pluggable (XFP) is a
single-mode fiber XFP. It plugs into an ADTRAN optical interface
that is designed to accept XFPs. The XFP provides a single
optical interface to a physical interface, and is intended for use
with a 10 Gigabit Passive Optical Network (PON) Optical Line
Termination (OLT) module. Installed into an appropriate module,
the XFP provides a 10 Gbps PON interface to the supporting
system.
The following features are supported on this XFP:
■Data rate: 10 Gbps
■Tuneable Wavelength
■Optical distance: 20 km maximum
■Hot Pluggable
Due to compliance certification requirements, use only XFPs
supplied by ADTRAN. ADTRAN cannot certify system integrity
with other XFPs.
Installation
Before installing the equipment, inspect the XFP. If damage has
occurred during shipping, file a claim with the carrier, and then
contact ADTRAN Customer Support. For more information, refer
to the warranty.
Installation Steps
To install the XFP into an appropriate device, complete the
following steps:
gNOTE
Do not remove the protective end cap from the XFP until the fiber
optic cable is ready to be connected.
1. Insert the XFP into the XFP cage on the module. Ensuring
that the latch on the XFP is facing upward, slide the XFP all
the way into the XFP cage until there is an audible “click”.
gNOTE
The latch on the XFP is for removal only. When removing the XFP,
rotate the latch away from the XFP. It should easily slide out of the
cage.
wNOTICE
Do not remove the protective end cap until the optical fiber
connection is made. Ensure that you keep the protective end cap
on whenever the transceiver optical fiber connector is not
inserted.
2. Continue the installation and turn-up of the host module
using the instructions in the Job Aid provided with the
module or other system-level documentation available
online at www.adtran.com.
Specifications
Specifications for this XFP are as follows:
■Optical
♦Optical transmit level: +4.0 dBm to +8.0 dBm
♦Optical receive level: –28 dBm to –8 dBm
♦Optical Connectors: Single SC receptacle
♦Compatible with XFP MSA
■Environmental
♦Operational Case Temperature Range: 0°C to +70°C
♦Storage Temperature Range: –40°C to +85°C
♦Relative Humidity - Storage: 0% to 95%, noncondensing
♦Relative Humidity - Operational:50% to 85%, noncon-
densing
ADTRAN Pluggable Optics
XFP
NG-PON2 ONU
October 2017
61200491F1C-19A
P/N: 1200491F1C

2 61200491F1C-19A
2. This device must accept any interference received, including
interference that may cause undesired operation.
■Changes or modifications not expressly approved by ADTRAN
could void the user's authority to operate this equipment.
■This product meets EU RoHS Directive 2011/65/EU and/or
applicable exemptions. Refer to www.adtran.com for further
information on RoHS/WEEE.
Français
fAVERTISSMENT!
Lisez tous les avertissements et mises en garde avant l’instal-
lation de cet équipement ou la réalisation de toute opération de
maintenance.
C
ATTENTION!
Ce produit contient ou utilise un module Laser de classe 1 qui est
conforme avec la FDA 21 CFR 1040.10, 1040.11 et IEC 60825-1.
Pour le maintien de la conformité avec les normes ci-dessus,
seulement approuvé classe 1 modules laser d'un ADTRAN
approuvés liste des fournisseurs (situé sur le site ADTRAN) doit
être installé dans ce produit. ADTRAN ne peut certifier l'intégrité
du système avec d'autres modules laser.
fATTENTION!
■L'ESD (décharge électrostatique) peut endommager les
modules électroniques. Lors de la manipulation des modules,
portez un bracelet de décharge antistatique pour éviter
d'endommager les composants électroniques. Placez les
modules dans un emballage antistatique lors du transport ou
du stockage. Lorsque vous travaillez sur les modules, placez-
les toujours sur un tapis antistatique certifié muni d'un
branchement de mise à la terre.
■La borne de terre de châssis doit être connecté à une prise de
terre pour assurer que le métal exposé (tels que les panneaux
avant, des modules SFP / XFP) sur le produit est correctement
mis à la terre via le connecteur de fond de panier.
Deutsch
f
WARNUNG!
Lesen Sie sich alle Warn- und Sicherheitshinweise durch, bevor
Sie dieses Gerät installieren oder warten.
C
VORSICHT!
DasProdukt enthält oder verwendet Klasse 1 Laser-Module, die
60825-1 mit FDA 21 CFR 1040.10, 1040.11 und IEC erfüllen.
Damit die obigen Richtlinien auch in Zukunft eingehalten werden
können, dürfen ausschließlich Klasse 1 Lasermodule von einem
von ADTRAN zugelassenen Anbieter in dem Produkt installiert
werden (siehe Website von ADTRAN). ADTRAN garantiert nicht
für die Systemintegrität bei anderen Lasermodulen
f
VORSICHT!
■Elektrostatische Entladung (ESD) können elektronische
Baugruppen beschädigt werden. Beim Umgang mit Modulen ,
SAFETY AND REGULATORY
English
fWARNING!
Read all warnings and cautions before installing or servicing this
equipment.
CCAUTION!
This product contains or uses a Class 1 Laser module that
complies with FDA 21 CFR 1040.10, 1040.11 and IEC 60825-1.
For continued compliance with the above standards, only
approved Class 1 laser modules from an ADTRAN approved
vendor list (located on the ADTRAN website) should be installed
in this product. ADTRAN cannot certify system integrity with other
laser modules.
fCAUTION!
■Electrostatic Discharge (ESD) can damage electronic
modules. When handling modules, wear an antistatic
discharge wrist strap to prevent damage to electronic
components. Place modules in antistatic packing material
when transporting or storing. When working on modules,
always place them on an approved antistatic mat that is
electrically grounded.
■This product and the host system are designed and intended
for installation as part of a Common Bonding Network (CBN).
This product and the host system are not designed nor
intended for installation as part of an Isolated Bonding Network
(IBN).
■This product is designed and intended only for deployment in
a DC-C (common) bonding and grounding configuration. This
product is not intended or designed for deployment in a DC-I
(isolated) bonding and grounding system.
■The chassis frame ground terminal must be connected to an
earth ground to ensure that the exposed metal (i.e., front
panels, SFP/XFP modules) on the product is properly
grounded via the backplane connector.
gNOTE
■This product is designed to be deployed in GR-3108-CORE
environmental Class 1 or 2.
■This product is NRTL Listed to the applicable UL Standards.
The product is designed to meet the applicable requirements
of Telcordia GR-3108-CORE and GR-1089-CORE.
■This product has also been evaluated to international safety
standards EN 60950-1, AS/NZS 60950.1, and IEC 60950-1.
Standards used to demonstrate Compliance are EN 60950-1.
■This product is intended for deployment in Central Office type
facilities, EEEs, EECs, and locations where the NEC applies
(for example, Customer Premises).
■This device complies with Part 15 of the FCC rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference.

tragen Sie eine Antistatikarmband, um Schäden an
elektronischen Bauteilen zu verhindern. Ort -Module in
antistatische Verpackung, beim Transport oder Lagerung. Bei
Arbeiten an Modulen immer legen Sie sie auf einer
zugelassenen antistatische Unterlage, die elektrisch geerdet
ist.
■Der Fahrgestellrahmen Erdanschluß muß zu einer Erde
verbunden werden, um sicherzustellen, dass das freiliegende
Metall (dh Frontplatten, SFP / XFP-Module) auf dem Produkt
richtig über den Backplane-Anschluss geerdet ist.
Warranty: ADTRAN will replace or repair this product within the warranty period if it does not
meet its published specifications or fails while in service. Warranty information can be
found online at www.adtran.com/warranty.
Trademarks: Brand names and product names included in this document are trademarks,
registered trademarks, or trade names of their respective holders.
©2017 ADTRAN, Inc. All Rights Reserved.
CAUTION!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY
HANDLING PRECAUTIONS REQUIRED
ADTRAN CUSTOMER CARE:
From within the U.S. 1.888.423.8726
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61200491F1C-19A*
Documentation for ADTRAN Network Solutions products is available for
viewing and download directly from the ADTRAN Support Community
website.
Go to: https://supportforums.adtran.com/welcome
Registration is required.
ADTRAN offers training courses on our products, including customized
training and courses taught at our facilities or at customer sites.
For inquiries, go to: http://adtran.com/training
The following online documents and resources provide additional information for this product:
ADTRAN Pluggable Optics Compatibility Matrix (online tool, go to: http://www.adtran.com/
pluggableoptics)
