ADTRAN jobAid 1442351G1 User manual

jobAid
DESCRIPTION
TheSmallForm‐FactorPluggableGigabitEthernet1510nm
CWDM(SFP)isasingle‐modefiberSFPthatplugsintoADTRAN
GigabitEthernetmodulesdesignedtoacceptSFPs.TheSFP
providesadualopticalinterfacetoaGigabitEthernetphysical
interface.
Installedintoanappropriatemodule,theSFPprovidesaGigabit
Ethernetinterfacetothesupportingsystem.
ThisSFPisdesignedforuseinCoarseWavelengthDivision
Multiplexing(CWDM)applications.
ThefollowingfeaturesaresupportedontheSFP:
♦LCopticalconnectors
♦TransmitWavelength:1511nm(1504.5nm‐1517.5nm)
♦ReceiveWavelength:1200nm‐1625nm
♦Opticaldistance:50kmmaximum
Small Form-Factor Pluggable Gigabit
Ethernet 1510 nm CWDM
SPECIFICATIONS
SpecificationsfortheSFPareasfollows:
♦OpticalSpecifications:
◊Opticaltransmitlevel:0dBmto–5dBm
◊Opticalreceivelevel:–3dBmto–24dBm
♦ExtendedEnvironmentalSupport:
◊Operationaltemperaturerange:–40°Cto+85°C
◊Storagetemperaturerange:–40°Cto+85°C
◊Relativehumidityto95%,noncondensing
INSTALLATION
ToinstalltheSFPintoanappropriatemodule,completethe
followingsteps:
1. InspecttheSFP.Ifdamaged,fileaclaimwiththecarrierand
thencontactADTRANCustomerSupport.
CAUTION
!
DonotremovetheprotectiveendcapfromtheSFPuntilthefiber
opticcableisreadytobeconnected.
2. InserttheSFPintotheSFPcageonthemodule.Ensurethe
manufacturer’slabelontheSFPisfacingupwardforcorrect
installation.
3. SlidetheSFPallthewayintothereceptacleuntilthereisan
audible“click”.
NOTE
ThelatchontheSFPisusedtoremovetheSFPfromthecageon
thecircuitcard.
CLEI: BVL3AEKD_ _
Product P/N: 1442351G1
Issue Date: July 2010
Document P/N: 61442351G1-22B
C A U T I O N
C A U T I O N
!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
Warranty: ADTRAN will replace or repair this product within the warranty period if it does not
meet its published specifications or fails while in service. Warranty information can
be found online at www.adtran.com/warranty.
©2010 ADTRAN, Inc. All Rights Reserved.
ADTRAN CUSTOMER CARE:
From within the U.S. 1.800.726.8663
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61442351G1-22B*
SAFETY AND REGULATORY COMPLIANCE
CAUTION
!
♦ ElectrostaticDischarge(ESD)candamageelectronicmodules.
Whenhandlingmodules,wearanantistaticdischargewrist
straptopreventdamagetoelectroniccomponents.Place
modulesinantistaticpackingmaterialwhentransportingor
storing.Whenworkingonmodules,alwaysplacethemonan
approvedantistaticmatthatiselectricallygrounded.
♦ TheSFPmeetsorexceedsalltheapplicablerequirementsof
NEBS,TelcordiaGR‐63‐CORE,andGR‐1089‐CORE.TheSFPis
intendedfordeploymentinCentralOfficetypefacilities,EEEs,
EECs,andlocationswheretheNECapplies(forexample,
CustomerPremises).TheSFPistobeinstalledinADTRAN
productsinRestrictedAccessLocationsonly,andinstalledby
trainedservicepersonnel.
ThisdevicecomplieswithPart15oftheFCCrules.Operationis
subjecttothefollowingtwoconditions:
1. Thisdevicemaynotcauseharmfulinterference
2. Thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
ChangesormodificationsnotexpresslyapprovedbyADTRAN
couldvoidtheuserʹsauthoritytooperatethisequipment.
CAUTION
!
♦ PerGR‐1089‐COREtheADTRANsystemthattheSFPisbeing
deployedinisdesignedandintendedforinstallationaspartof
aCommonBondingNetwork(CBN).TheADTRANsystem
thattheSFPisbeingdeployedinisnotdesignednorintended
forinstallationaspartofanIsolatedBondingNetwork(IBN).
♦ PerGR‐1089‐CORESection9,theSFPdoesnothaveaninternal
DCconnectionbetweenbatteryreturnandframeground.The
SFPcanbeinstalledinaDC‐I(isolated)orDC‐C(common)
installation.Forinstallationswhereothercardsorthehost
systemhaveinternalconnectionsbetweenbatteryreturnand
frameground,thesystemwouldbeintendedfordeployment
onlyinaDC‐Cinstallation.
♦ TheADTRANsystemchassisframegroundterminalmustbe
connectedtoareliableearthgroundtoensurethatthemetal
enclosureoftheSFPisproperlygroundedviathebackplane
connector.
CAUTION
C
TheSmallForm‐FactorPluggableGigabitEthernet1510nm
CWDMisaClass1LaserProductandcomplieswiththeLaser
SafetyrequirementsofFDA21CFR1040.11,andEN60825‐1and
EN60825‐2.TheSFPisNRTLListedandCBCertifiedtoall
applicableAmericanandEuropeansafetystandards.
NOTE
TheGigabitEthernetport(s)areopticalandthereforearenot
classifiedasanytypeofportasdefinedinAppendixBofGR‐
1089‐COREIssue4.
TheSFPisdesignedtomeetthefollowingenvironmentalclasses:
♦ETSIEN300019‐1‐1“Classificationofenvironmental
conditions;Storage,”Class1.2
♦ETSIEN300019‐1‐2“Classificationofenvironmental
conditions;Transportation,”Class2.3
♦ETSIEN300019‐1‐3“Classificationofenvironmental
conditions;Stationaryuseatweather‐protectedlocations,”
Class3.3
Theequipmentisdesignedtofunctionwithoutdegradation
duringexposuretoalltestseveritiesperClass3.3.
TheSmallForm‐FactorPluggableGigabitEthernet1510nm
CWDMmeetsEURoHSDirective2002/95/ECand/orapplicable
exemptions.Refertowww.adtran.comforfurtherinformationon
RoHS/WEEE.
NOTE
♦ ThisSFPiscompliantwithSFF‐8472“DigitalDiagnostics
MonitoringInterfaceforOpticalTransceivers,”Revision9.3.
♦ ThisSFPiscompliantwiththeSmallForm‐FactorPluggable
(SFP)Multi‐SourceAgreement(MSA).
♦ ThisSFPisdesignedtobedeployedinGR‐3108‐CORE
environmentalclass1or2asdefinedinGR‐3108‐COREIssue
2.
