ADTRAN Total Access Octal DS1 IMA User manual

The Total Access Octal DS1 IMA Access Module is designed to interface
with the Total Access DS3 Cell Switch Module(CSM). Each of the eight ports
provide DS1 interfaces. These can be used to connect the shelf to an
upstream ATM element or to a DS1 IMA unit of a subtended shelf.
The eight (8) ATM DS1s correspond to the eight port interfaces on the
line card. The Octal DS1 IMA automatically swaps from the online to the
offline multiplexer, if one fails or is physically removed. Each of the eight
ports have a single balanced twisted pair for each direction of transmission.
User access to the Octal DS1 IMA Module is through the SCU via the sys-
tem bus of the Total Access DSLAM backplane. The unit retains provision-
ing data in a nonvolatile memory device for recovery after a power loss and
supports optional autoprovisioning through the SCU.
The module detects CRC errors, Bipolar Violations, and frame bit errors
in the loop side receiver. These are used to calculate Errored Seconds,
Severely Errored Seconds and Unavailable Seconds in accordance with
ANSI T1.231-1997.
The Octal DS1 IMA card is capable of both short and long haul signals.
The interface can be configured for the standard DS1 signal (0 to 22.5 db)
or for DSX-1 measured from 0 to 655 feet.
PRODUCT FEATURES
■Software configurable via menu
access or SNMP
■Supports from one to eight DS1
line interfaces
■Supports standard T1 MIB 1406
for alarm states
■Supports extended NUB protocol
for NTU management
■Supports up to four IMA groups
■DS1 or DSX-1 signal
OCTAL DS1 IMA
TOTAL ACCESS®DSLAM
OCTAL DS1 IMA ACCESS MODULE

Product Specifications
FACEPLATE FEATURES
Indicators
■Power LED
■8 DSL T1 Port indicators
MECHANICAL
■Dimensions: 5.20 in. H x 1.320 in. W x
10 in. D
■Weight: Less than 1 lb.
■Mounting: Occupies two access module
slots in the Total Access 3000 or 3010
chassis
INTERFACES
■Network Interface: ATM upstream through
the Cell Switch Module
■Subscriber Interface: DSX-1, Robbed Bit
Signaling and DS1
ELECTRICAL
■Power Requirements: –42 VDC to –56 VDC
input range
CORPORATE OFFICE
ADTRAN, Inc.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
800 9ADTRAN
256 963-8000
fax: [phone]
fax back: 256 963-8200
e-mail: [email protected]
web site: www.adtran.com
REGIONAL OFFICES
Dallas, TX
800 471-8648
Denver, CO
800 471-8651
Irvine, CA
800 788-5408
Kansas City, KS
800 471-8649
Philadelphia, PA
800 471-8656
San Antonio, TX
888 223-7671
INTERNATIONAL
CONTACTS
Beijing, China
8610 8529-8895
Canada
877 923-8726
Germany
49 6007 930-203
Hong Kong
852 2824-8283
Latin America
954 474-4424
London, U.K.
44 1252 626-730
Melbourne, Australia
61 3 9658-0500
Mexico/Caribbean
954 577-0357
Zürich, Switzerland
41 1 880-2777
ADTRAN is an ISO 9001
registered company.
Printed in the U.S.A. on recycled paper.
61181409L1-8A July 2001
©2001 ADTRAN, Inc. All rights reserved.
REGULATORY STANDARDS
■NEBS Level 3
■GR-1089-CORE
■UL 1950
MANAGEMENT
■Craft interface, SNMP, TL1
ENVIRONMENTAL
■Operating: –40ºC to + 65ºC
■Storage: –40ºC to + 85ºC
■Relative Humidity: Up to 95 percent,
nocondensing
Ordering Information
EQUIPMENT PART #
Total Access 3000 Octal DS1 IMA.....1181409L1
Specifications subject to change without notice.
