ADTRAN NetVanta 1638 Manual

NetVanta 1600 Series
Gigabit Ethernet Switch
Hardware Installation Guide
1700568F1 NetVanta 1638
1700569F1 NetVanta 1638P
1700460F1 NetVanta 120 W AC Power Supply
1700462F1 NetVanta 500 W PoE Power Supply
1700470F1 NetVanta Dual Stacking XIM
61700568F1-34A
May 2011

Trademarks NetVanta 1600 Series Hardware Installation Guide
2 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A
Trademarks
Any brand names and product names included in this manual are trademarks, registered trademarks, or
trade names of their respective holders.
To the Holder of the Manual
The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change
the contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential damages or for
commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
Software Licensing Agreement
Each ADTRAN product contains a single license for ADTRAN-supplied software. Pursuant to the
Licensing Agreement, you may: (a) use the software on the purchased ADTRAN device only and (b) keep
a copy of the software for backup purposes. This Agreement covers all software installed on the system, as
well as any software available on the ADTRAN website. In addition, certain ADTRAN systems may
contain additional conditions for obtaining software upgrades.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
Phone: [phone]
Copyright © 2011 ADTRAN, Inc.
All Rights Reserved.
Printed in U.S.A.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

NetVanta 1600 Series Hardware Installation Guide Conventions
61700568F1-34A Copyright © 2011 ADTRAN, Inc. 3
Conventions
Notes provide additional useful information.
Cautions signify information that could prevent service interruption or damage to the
equipment.
Warnings provide information that could prevent injury or endangerment to human
life.

Safety Instructions NetVanta 1600 Series Hardware Installation Guide
4 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A
Safety Instructions
When using your telephone equipment, please follow these basic safety precautions to reduce the risk of
fire, electrical shock, or personal injury:
1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There is a remote
risk of shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord, power supply, and batteries indicated in the manual. Do not dispose of
batteries in a fire. They may explode. Check with local codes for special disposal instructions.
5. The socket-outlet shall be installed near the equipment and shall be easily accessible.
If any of the following conditions occur, unplug the product from the electrical outlet and replace the part
or contact your qualified service personnel:
1. The power cable, extension cable, or plug is damaged.
2. An object has fallen into the product.
3. The product has been exposed to water.
4. The product has been dropped or damaged.
5. The product does not operate correctly when you follow the operating instructions.
Save These Important Safety Instructions
This equipment incorporates double pole/neutral fusing. If the neutral fuse opens and the
line fuse does not open, voltage could still be present in the unit.
These units contain no user-serviceable parts. They should only be serviced by qualified
service personnel.
Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE),
are given in the document NetVanta Safety and Regulatory Information (ADTRAN’s
Knowledge Base article 3444) available at http://kb.adtran.com.

NetVanta 1600 Series Hardware Installation Guide FCC Radio Frequency Interference Statement
61700568F1-34A Copyright © 2011 ADTRAN, Inc. 5
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio frequencies.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Electromagnetic Compatibility (EMC) Table
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio frequencies. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canadian Emissions Requirements
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus
as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the
Department of Communications.
Cet appareil numérique respecte les limites de bruits radioelectriques applicables aux appareils numériques
de Class A prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques,” NMB-003 edictee
par le ministre des Communications.
Service and Warranty
For information on the service and warranty of ADTRAN products, visit the Support section of the
ADTRAN website at http://www.adtran.com.
NetVanta Module P/N and Name NetVanta 1638 NetVanta 1638P
1700470F1 Dual Stacking XIM FCC Part 15 Class A
EN55022 Class A
EN 55024
FCC Part 15 Class A
EN55022 Class A
EN 55024
1700460F1 NetVanta 120 W AC Power Supply FCC Part 15 Class A
EN55022 Class A
EN 55024
EN 61000-3-2
EN 61000-3-3
ICES 003 Class A
AS/NZS CISPR22 Class A
N/A
1700562F1 NetVanta 500 W PoE Power Supply N/A FCC Part 15 Class A
ICES 003 Class A

Service and Warranty NetVanta 1600 Series Hardware Installation Guide
6 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A

61700568F1-34A Copyright © 2011 ADTRAN, Inc. 7
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Physical Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power over Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Redundant Power Supply (Future Release) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Extended Power Supply (Future Release) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
NetVanta 1600 Series Shipping Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
NetVanta 1638 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
NetVanta 1638P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Option Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
XAUI Interface Module Shipping Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
XAUI Interface Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Supplying Power to the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Replacing the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Installing XAUI Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Installing a SODIMM for Expandable Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Appendix A. Connector Pin Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Table of Contents NetVanta 1600 Series Hardware Installation Guide
8 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A

61700568F1-34A Copyright © 2011 ADTRAN, Inc. 9
List of Figures
Figure 1. NetVanta 1638 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 2. NetVanta 1638 Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 3. NetVanta 1638P Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 4. NetVanta 1638P Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 5. NetVanta Dual Stacking XIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Figure 6. Installing the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 7. XIM Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 8. SODIMM Installation – Keyed Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 9. SODIMM Installation – Applying Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 10. SODIMM Installation – Rotating the Module Downward . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

List of Figures NetVanta 1600 Series Hardware Installation Guide
10 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A

61700568F1-34A Copyright © 2011 ADTRAN, Inc. 11
List of Tables
Table 1. Front Panel LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table A-1. CONSOLE Port Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Table A-2. 1000Base-T Gigabit Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

List of Tables NetVanta 1600 Series Hardware Installation Guide
12 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A

61700568F1-34A Copyright © 2011 ADTRAN, Inc. 13
1. INTRODUCTION
The NetVanta 1600 Series Gigabit Switches include the NetVanta 1638 and the NetVanta 1638P (Power
over Ethernet (PoE)).
This hardware installation guide lists the NetVanta 1600 Series units’ specifications, describes the physical
characteristics of the units, introduces basic functionality, and provides installation instructions.
•Physical Descriptions on page 14
•Product Specifications on page 21
•Option Modules on page 24
•Unit Installation on page 26
For additional information on mounting options, powering the unit, and installing option modules, refer to the
following sections:
•Mounting Options on page 27
•Replacing the Power Supply on page 28
•Installing XAUI Interface Modules on page 29
•Installing a SODIMM for Expandable Memory on page 30
For information on switch configuration for a specific application, refer to the configuration guides provided on
ADTRAN’s Knowledge Base. For details on the command line interface (CLI), refer to the AOS Command
Reference Guide (ADTRAN’s Knowledge Base article 2219).
In this document, the term NetVanta 1600 means all of the units collectively. If a statement
only applies to one particular switch, the text refers to that switch individually.

Physical Descriptions NetVanta 1600 Series Hardware Installation Guide
14 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A
2. PHYSICAL DESCRIPTIONS
The NetVanta 1600 Series is a 48-port multi-layer Gigabit Ethernet switch. These high-capacity Ethernet
switches provides Layer 2 and Layer 3 switching capability. Two dual high-speed option module slots provide
optional 10 G interfaces. Applications for the NetVanta 1600 Series include edge switching with high-speed
stacking and network aggregation. Virtual chassis functionality is also supported.
The NetVanta 1600 Series units’ front panels contain 48 10/100/1000Base-T Ethernet interfaces that are
accessed via standard RJ-45 connectors. Also, on the front panel a Type A universal serial bus (USB) host
connector is integrated into the 10/100Base-T (RJ-45) management port.
The NetVanta 1600 Series is housed in a 1U-high rack-mountable metal enclosure that includes field replaceable
power supplies and fans. The NetVanta 1638 is shipped with the NetVanta 120 W AC power supply
(P/N 1700460F1) installed that provides +12 VDC and a redundant power supply (RPS) connector. The
NetVanta 1638P is shipped with the NetVanta 500 W PoE power supply (P/N 1700462F1) installed that
provides +12 VDC and +54 VDC and both an RPS and an extended power supply (EPS) connector.
NetVanta 1600 Series units run the ADTRAN Operating System (AOS), and are managed through an
EIA-232(DB-9) console port located on the front panel, a 10/100Base-T Ethernet management port, Telnet
session, or the Web-based graphical user interface (GUI). The NetVanta 1600 Series is RoHS compliant.
Power over Ethernet
The NetVanta 1638P PoE device provides the same basic functionality as the NetVanta 1638 product. By
default, the PoE switch discovers attached powered devices (PDs) and provides 48 VDC to the PD via Ethernet
cabling. The NetVanta 1638P is fully compliant with the IEEE 802.3af PoE and IEEE 802.3at PoE+ standards
and also supports legacy PDs.
Redundant Power Supply (Future Release)
All NetVanta 1600 Series units provide a connection for an optional RPS on the rear panel. The NetVanta 1162
RPS/EPS (P/N 1700530F1) is sold separately. When connected, the RPS will provide 120 W of backup power
should the internal power supply fail. The units will automatically switch to RPS when needed, providing
uninterrupted power to the unit.
Extended Power Supply (Future Release)
The NetVanta 1638P unit also provides a connection for an optional EPS on the rear panel. The NetVanta 1162
RPS/EPS (P/N 1700530F1) is sold separately. When an EPS is connected, the internal and external supplies will
use load sharing to provide up to 740 W of power for PoE applications. In the event that the internal power
supply fails, the EPS will provide up to 370 W of power for PoE applications.
NetVanta 1600 Series Shipping Contents
Each NetVanta 1600 Series unit is shipped in its own cardboard shipping carton. Open each carton carefully, and
avoid deep penetration into the carton with sharp objects.
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit,
immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Repair and
Return section of the Support page on the ADTRAN website).

NetVanta 1600 Series Hardware Installation Guide Physical Descriptions
61700568F1-34A Copyright © 2011 ADTRAN, Inc. 15
Domestic shipments of the NetVanta 1638 include the following items:
• NetVanta 1638 base unit
• NetVanta 120 W AC power supply
• A detachable power cable with a grounded, three-prong plug
• Quick start guide
• Two 19-inch rack mounting brackets and eight screws
International shipments of the NetVanta 1638 include the following items:
• NetVanta 1638 base unit
• NetVanta 120 W AC power supply
• All necessary power cords
• Quick start guide
• Two 19-inch rack mounting brackets and eight screws
Domestic shipments of the NetVanta 1638P include the following items:
• NetVanta 1638P base unit
• NetVanta 500 W PoE power supply
• A detachable power cable with a grounded, three-prong plug
• Quick start guide
• Two 19-inch rack mounting brackets and eight screws
International shipments of the NetVanta 1638P include the following items:
• NetVanta 1638P base unit
• NetVanta 500 W PoE power supply
• All necessary power cords
• Quick start guide
• Two 19-inch rack mounting brackets and eight screws
NetVanta 1638
Front Panel Design
The NetVanta 1638 front panel is shown below. Table 1 on page 20 describes all of the LEDs, and
Appendix A on page 33 shows the connector pinouts.
Figure 1. NetVanta 1638 Front Panel Layout
Front Panel Features
Status LED
The STAT LED is located on the upper left side of the unit and indicates the unit’s status.
Redundant Power Supply LED (Future Release)
The RPS LED is located on the upper left side of the unit and indicates RPS status.
®

Physical Descriptions NetVanta 1600 Series Hardware Installation Guide
16 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A
High-Speed Port LEDs
The high-speed port LEDs labeled X1/1, X1/2,X2/1, and X2/2 are located on the upper left portion of
the unit’s front panel and indicate when there is link/activity on the four 10 Gigabit Ethernet interfaces.
Port LEDs
The port LEDs labeled 1through 48 are located above the 10/100/1000Base-T Ethernet interfaces.
Using the LED mode switch (future release), these LEDs can display either link/activity or VCID
(future release) status.
LED Mode Switch
The LED mode switch is located on the left side of the unit and is used to toggle Ports 1through 48
between link/activity and VCID (future release) display modes.
Link/Activity LED
The LINK/ACT LED is located on the left side of the unit and indicates that the port LEDs are
displaying link/activity for the interface.
Virtual Chassis LED (Future Release)
The VCID LED is located on the left side of the unit and indicates that the port LEDs are displaying
VCID.
CONSOLE Interface
The CONSOLE interface is an EIA-232 serial port (DCE) that provides local management and
configuration (via a DB-9 female connector). See Table A-1 on page 33 for pinouts.
Management Interface
The 10/100Base-T management interface labeled MGMT is located above the USB interface. LEDs in
the RJ-45 connector provide link and activity indications for the management interface. The
management interface provides the following:
• 10Base-T or 100Base-T with a single connector
• Auto MDIX
• Autonegotiation
• Advanced cable diagnostics
• CSMA/CD
• IEEE 802.3 compatibility
USB Interface
The USB interface labeled USB is located below the management interface.
10/100/1000Base-T Ethernet Interfaces
The front panel contains 48 10/100/1000Base-T Ethernet interfaces (RJ-45). These interfaces are
arranged in stacked pairs, with the numbers 1through 48 screened from left to right directly above the
corresponding ports. Status LEDs for each stacked pair of interfaces are located directly over the
interfaces. See Table A-2 on page 33 for pinouts.
Connection directly to an external modem requires a cross-over cable.

NetVanta 1600 Series Hardware Installation Guide Physical Descriptions
61700568F1-34A Copyright © 2011 ADTRAN, Inc. 17
Rear Panel Design
The NetVanta 1638 rear panel is shown below.
Figure 2. NetVanta 1638 Rear Panel Layout
Rear Panel Interfaces
Option Module Slots
The rear panel contains two high-speed option module slots labeled X1 and X2 that accept a variety of
high-speed option modules.
NetVanta 120 W AC Power Supply
The rear panel houses the field replaceable NetVanta 120 W AC power supply. For information on
replacing the power supply, refer Replacing the Power Supply on page 28.
RPS (Future Release)
The NetVanta 120 W AC power supply has a power input to a +12 VDC RPS. The RPS LED, located
on the front panel of the unit, indicates RPS status.
Power Connection
The NetVanta 120 W AC power supply has a power input to the AC universal power supply. Refer to
Supplying Power to the Unit on page 28 for connection details.
NetVanta 1638P
Front Panel Design
The NetVanta 1638P front panel is shown below. Table 1 on page 20 describes all of the LEDs, and
Appendix A on page 33 shows the connector pinouts.
Figure 3. NetVanta 1638P Front Panel Layout
Front Panel Features
Status LED
The STAT LED is located on the upper left side of the unit and indicates the unit’s status.
Redundant Power Supply LED (Future Release)
The RPS LED is located on the upper left side of the unit and indicates RPS status.
Extended Power Supply LED (Future Release)
The EPS LED is located on the upper left side of the unit and indicates EPS status.
®120 WATT POWER SUPPLY
DISCONNECT ALL POWER CABLES PRIOR
TO REMOVALOF POWER SUPPLY
CAUTION
AC INPUT
X1
X2
RPS - 12VDC
1700460F1
®
PoE
P
EPS
Power over Ethernet

Physical Descriptions NetVanta 1600 Series Hardware Installation Guide
18 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A
High-Speed Port LEDs
The high-speed port LEDs labeled X1/1, X1/2,X2/1, and X2/2 are located on the upper left portion of
the unit’s front panel and indicate when there is link/activity on the four 10 Gigabit Ethernet interfaces.
Port LEDs
The port LEDs labeled 1through 48 are located above the 10/100/1000Base-T Ethernet interfaces.
Using the LED mode switch (future release), these LEDs can display either link/activity, PoE, or
VCID (future release) status.
LED Mode Switch (Future Release)
The LED mode switch is located on the left side of the unit and is used to toggle Ports 1through 48
between link/activity, PoE, and VCID (future release) display modes.
Link/Activity LED
The LINK/ACT LED is located on the left side of the unit and indicates that the port LEDs are
displaying link/activity for the interface.
Virtual Chassis LED (Future Release)
The VCID LED is located on the left side of the unit and indicates that the port LEDs are displaying
VCID.
PoE LED
The PoE LED is located on the left side of the unit and indicates that the port LEDs are displaying PoE
status.
CONSOLE Interface
The CONSOLE interface is an EIA-232 serial port (DCE) that provides local management and
configuration (via a DB-9 female connector). See Table A-1 on page 33 for pinouts.
Management Interface
The 10/100Base-T management interface labeled MGMT is located above the USB interface. LEDs in
the RJ-45 connector provide link and activity indications for the management interface. The
management interface provides the following:
• 10Base-T or 100Base-T with a single connector
• Auto MDIX
• Autonegotiation
• Advanced cable diagnostics
• CSMA/CD
• IEEE 802.3 compatibility
USB Interface
The USB interface labeled USB is located below the management interface.
Connection directly to an external modem requires a cross-over cable.

NetVanta 1600 Series Hardware Installation Guide Physical Descriptions
61700568F1-34A Copyright © 2011 ADTRAN, Inc. 19
10/100/1000Base-T Ethernet Interfaces
The front panel contains 48 10/100/1000Base-T Ethernet interfaces (RJ-45). These interfaces are
arranged in stacked pairs, with the numbers 1through 48 screened from left to right directly above the
corresponding ports. Status LEDs for each stacked pair of interfaces are located directly over the
interfaces. See Table A-2 on page 33 for pinouts.
Rear Panel Design
The NetVanta 1638P rear panel is shown below.
Figure 4. NetVanta 1638P Rear Panel Layout
Rear Panel Interfaces
Option Module Slots
The rear panel contains two high-speed option module slots labeled X1 and X2 that accept a variety of
high-speed option modules.
NetVanta 500 W PoE Power Supply
The rear panel houses the field replaceable NetVanta 500 W PoE power supply. For information on
replacing the power supply, refer to Replacing the Power Supply on page 28.
RPS (Future Release)
The NetVanta 500 W PoE power supply has a power input to a +12 VDC RPS. The RPS LED, located
on the front panel of the unit, indicates RPS status.
EPS (Future Release)
The NetVanta 500 W PoE power supply has a power input to a +50 VDC EPS. The EPS LED, located
on the front panel of the unit, indicates EPS status.
Power Connection
The NetVanta 500 W PoE power supply has a power input to the AC universal power supply. Refer to
Supplying Power to the Unit on page 28 for connection details.
®500 WATT POWER SUPPLY
DISCONNECT ALL POWER CABLES PRIOR
TO REMOVALOF POWER SUPPLY
CAUTION
AC INPUT
X1
X2
RPS - 12VDC EPS - 50VDC
1700462F1

Physical Descriptions NetVanta 1600 Series Hardware Installation Guide
20 Copyright © 2011 ADTRAN, Inc. 61700568F1-34A
LED Descriptions
The following table describes LED activity.
Table 1. Front Panel LED Descriptions
LED Color Indication
STAT Off Unit is not receiving power.
Green (flashing) On power up, the STAT LED flashes rapidly for five
seconds, during which time the user may escape to boot
mode from the CONSOLE port.
Green (solid) Power is on and self-test passed.
Red (solid) Power is on, but the self-test failed or the application code
could not be booted.
RPS Off RPS is not connected.
Green (solid) RPS is connected and the internal supply is functioning.
Red (solid) RPS is connected and the internal supply has failed.
EPS
(PoE units only) Off EPS is not connected.
Green (solid) EPS is connected and the internal supply is functioning.
Red (solid) EPS is connected and the internal supply has failed.
LINK/ACT
(PoE units only) Off Link status/activity is not being displayed on port LEDs
1 through 48.
Green (solid) Link status/activity is being displayed on port LEDs
1 through 48.
PoE
(PoE units only) Off PoE status is not being displayed on port LEDs 1 through
48.
Green (solid) PoE status is being displayed on port LEDs 1 through 48.
VCID Off VCID is not selected.
Green (solid) VCID is selected. The port LED (1 through 48) that
corresponds to the unit’s VCID will display green.
Port LED in
Link/Activity Mode
(1- 48 and X1/1, X1/2,
X2/1, X2/)
Off The port is not connected.
Green (solid) The link is up and the port is enabled.
Amber (flashing) There is activity on the port.
Port LED in PoE Mode
(1- 48 PoE units only) Off The port is not delivering power.
Green (solid) The port is delivering power.
Red (solid) The port has detected a PoE fault.
Port LED in VCID Mode
(1- 48)Future release Future release
Future release Future release
Future release Future release
