ADTRAN TRACER 1280050L1 User manual

TRACER ETHERNET SWITCH MODULE P/N 1280050L1
For more detailed documentation, visit us online at www.adtran.com
Quick Start Guide
Quick Start Guide, 61280050L1-13A, January 2005 Technical Support 1-888-4ADTRAN (1-888-423-8726) Copyright ©2005 ADTRAN, All Rights Reserved
SPECIFICATIONS
Interface Type: (4) 10BaseT/100BaseTX interfaces with auto MDI/MDIX
crossover on all interfaces
Flow Control: Back-pressure flow control on all half-duplex interfaces
Pause-frame flow control on full-duplex interfaces
Environmental
Specifications: Operating Temperature: -25°C to 65°C Storage Temperature: -20°C to 70°C
Relative Humidity: Up to 95% non-condensing
Compliance: FCC Part 15, Class A
NETWORK CONNECTION PINOUT
Pin Name Source Description
1 RX1 Attached Equipment Receive Positive
2 RX2 Attached Equipment Receive Negative
3 TX1 Module Transmit Positive
4, 5 UNUSED N/A —
6 TX2 Module Transmit Negative
7, 8 UNUSED N/A —
INSTALLATION INSTRUCTIONS
1. Remove the cover plate from the appropriate option slot in the TRACER
rear panel.
2. Slide the TRACER Ethernet Switch Module into the option slot until the
module is firmly positioned in the chassis.
3. Secure the thumbscrews at both edges of the module. Tighten with a
screwdriver.
4. Connect the cables to the associated device(s).
5. Complete installation of remaining modules and system as specified in
the TRACER 6000 Series System Manual.
The TRACER Ethernet Switch Module is not
hot-swappable. Remove power from the TRACER
system before installing or removing the module.
