FORM NO.56041560 / AquaPro™H - 1
06/03 revised 11/03 Form Number 56041560
Instructions for use and parts list
Advance MODEL 56102801
AquaPro™H

2 - FORM NO. 56041560 / AquaPro™H
INTRODUCTION
This manual will help you get the most from your Advance AquaProTM H. Read thoroughly before
operating the machine.
NOTE: Bold numbers in parenthesis indicate an item illustrated on page 7.
This product is intended for commercial use only.
PARTS AND SERVICE
Repairs, when required, should be performed by your authorized Advance Service Center, who
employs factory-trained service personnel, and maintains an inventory of Advance original
replacement parts and accessories.
Call the Advance DEALER named below for parts or service. Please specify the Model and Serial
Number when discussing your machine.
NAME PLATE
The Model and Serial Number of your machine are shown on the nameplate in the machine. This
information is needed when ordering repair parts for the machine. Use the space below to note the
Model and Serial Number of your machine for future reference.
MODEL : ________________________________________
SERIAL NUMBER : _____________________________________
UNCRATING
When the machine is delivered, carefully inspect the shipping carton and the machine for damage. If
damage is evident, save the shipping carton so that it can be inspected. Contact Advance Customer
Service Department immediately to file a freight damage claim.
DO NOT OPERATE THE MACHINE UNTIL YOU HAVE READ THIS SECTION.
IMPROPER USE WILL VOID THE WARRANTY.
•Always use a defoamer when foaming occurs to prevent vacuum motor damage.
•Never use water above 140°F (60°C).
•Do not store outdoors. Avoid extremes in temperature.
•Do not let the pump run dry. Turn the pump off and refill that tank when cleaning solution
gets low.
•Use approved chemicals only. All chemicals should be mixed thoroughly. Liquid chemicals
are recommended to prevent powder buildups. A pH between 6 and 9 is recommended.
The use of high alkaline detergents or strong acids will accelerate the wear of the pump
and seals, and will void the warranty.
•All extension cords must have a rating of at least 12/3 (#12 cord). Extension cords should
be no longer than 50 feet. Replace the plug immediately if the ground prong becomes
damaged or is broken off.
(Dealer, affix service sticker here)

FORM NO.56041560 / AquaPro™H - 3
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories,
shops and offices other than normal residential housekeeping purposes.
When using an electrical appliance, basic precautions should always be followed, including the
following:
Read all instructions before using this appliance.
WARNING!
To reduce the risk of fire, electric shock, or injury:
•Do not leave the appliance when it is plugged in. Unplug the unit from the outlet when not in
use and before servicing.
•To avoid electric shock, do not expose to rain. Store indoors.
•Do not allow to be used as a toy. Close attention is necessary when used near children.
•Use only as described in this manual. Use only the manufacturer’s recommended attachments.
•Do not use with damaged cord or plug. If the appliance is not working as it should be, has
been dropped, damaged, left outdoors or dropped into water, return it to a service center.
•Do not pull or carry by the cord, use the cord as a handle, close a door on the cord, or pull the
cord around sharp edges or corners. Do not run the appliance over the cord. Keep the cord
away from heated surfaces.
•Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord.
•Do not handle the plug, cord or appliance with wet hands.
•Do not put any object into openings. Do not use with any opening blocked; keep free of dust,
lint, hair, and anything that may reduce air flow.
•Keep loose clothing, hair, fingers, and all parts of body away from openings and moving parts.
•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes,
or any health endangering dusts.
•Turn off all controls before unplugging.
•Use extra care when cleaning on stairs.
•Do not use to pick up flammable or combustible liquids such as gasoline or use in areas
where they may be present.
•Connect to a properly grounded outlet only. See Grounding Instructions.
•Liquid ejected at the spray nozzle could be dangerous as a result of its temperature, pressure
or chemical content.

4 - FORM NO. 56041560 / AquaPro™H
CONSIGNES DE SECURITE IMPORTANTES
Cette machine ne convient qu´à un usage industriel, par exemple dans des hôtels, écoles, hôpitaux,
usines, boutiques et bureaux et autres à l´exclusion de tout usage de maintenance résidentielle
normale.
L’utilisation d’un appareil électrique demande certaines précautions:
LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CET APPAREIL)
AVERTISSEMENT!
Pour réduire les risques d’incendie, de choc électrique ou de blessure:
• Ne pas laisser l’appareil sans surveillance lorsqu’il est branché. Débrancher lorsque l’appareil
n’est pas utilisé et avant l’entretien.
• Pour réduire les risques de choc électrique, utiliser à l’intérieur seulement.
• Ne pas permettre aux enfants de jouer avec l’appareil. Une attention particulière est
nécessaire lorsque l’appareil est utilisé par des enfants ou à proximité de ces derniers.
• N’utiliser que conformément à cette notice avec les accessoires recommandés par le fabricant.
• Ne pas utiliser si le cordon ou la fiche est endommagé. Retourner l’appareil à un atelier de
réparation s’il ne fonctionne pas bien, s’il est tombé ou s’il a été endommagé, oublié à l’extérieur
ou immergé.
• Ne pas tirer soulever ou traîner l’appareil par le cordon. Ne pas utiliser le cordon comme une
poignée, le coincer dans l’embrasure d’une porte ou l’appuyer contre des arêtes vives ou des
coins. Ne pas faire rouler l’appareil sur le cordon. Garder le cordon à l’écart des surfaces
chaudes.
• Ne pas débrancher en tirant sur le cordon. Tirer plutôt la fiche.
• Ne pas toucher la fiche ou l’appareil lorsque vos mains sont humides.
• N’insérer aucun objet dans les ouvertures. Ne pas utiliser l’appareil lorsqu’une ouverture est
bloquée. S’assurer que de la poussière, de la peluche, des cheveux ou d’autres matières ne
réduisent pas le débit d’air.
• Maintenir les cheveux, les vêtements amples, les doigts et toutes les parties du corps à l’écart des
ouvertures et des pièces mobiles.
• Ne pas aspirer de matières en combustion ou qui dégagent de la fumée, comme des cigarettes,
des allumettes ou des cendres chaudes.
• Mettre toutes les commandes à la position ARRÊT avant de débrancher l’appareil.
• User de prudence lors du nettoyage des escaliers.
• Ne pas aspirer des liquides inflammables or combustibles, comme de l’essence, et ne pas faire
fonctionner dans des endroits ou peuvent se trouver de tels liquides.
• Ne brancher qu’à une prise de courant avec mise à la terre. Voir les instructions visant la mise à
la terre.
• Le liquide qui sort de l’embout de vaporisation peut s’avérer dangereux en raison de sa
température, de sa pression ou du produit chimique qu’il contient.
CONSERVER CES INSTRUCTIONS

FORM NO.56041560 / AquaPro™H - 5
120VAC GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should electrically malfunction, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock. This appliance is equipped
with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged
into an appropriate outlet that is properly installed and grounded in accordance with all local codes
and ordinances.
DANGER!
Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service person if you are in doubt as to whether the outlet is
properly grounded. Do not modify the plug provided with the appliance. If it will not fit the outlet, have
a proper outlet installed by a qualified electrician.
This appliance is for use on a nominal 120-volt circuit, and has a grounding plug that looks like the
plug illustrated in Figure 1 below. A temporary adapter illustrated in Figures 2 and 3 may be used to
connect this plug to a 2-pole receptacle as shown in Figure 2 if a properly grounded outlet is not
available. The temporary adapter should be used only until a properly grounded outlet (Figure 1) can
be installed by a qualified electrician. The green-colored rigid ear, tab, or the like extending from the
adapter must be connected to a permanent ground such as a properly grounded outlet box cover.
Whenever the adapter is used, it must be held in place by a metal screw. Grounding adapters are not
approved for use in Canada.
Replace the plug if the grounding pin is damaged or broken.
The Green (or Green/Yellow) wire in the cord is the grounding wire. When replacing a plug, this wire
must be attached to the grounding pin only.
Extension cords connected to this machine should be 12 gauge, three-wire cords with three-prong
plugs and outlets. DO NOT use extension cords more than 50 feet (15 m) long.
PLEASE NOTE: FOR NORTH AMERICA ONLY

6 - FORM NO. 56041560 / AquaPro™H
INSTRUCTIONS VISANT LA MISE À LA TERRE (120VAC)
Cet appareil doit être mis à la terre. En cas de défaillance ou de panne éventuelles, la mise a la terre
fournit au courant un chemin de moindre résistance qui réduit le risque de choc électrique. Cet
appareil est pourvu d’un cordon muni d’un conducteur de terre et d’une fiche avec broche de terre.
La fiche doit être branchée dans une prise appropriee correctement installée et mise à la terre
conformément aux règlements et ordonnances municipaux.
AVERTISSEMENT !
Un conducteur de terre mal raccordé peut entraîner un risque de choc électrique. Consulter un
électricien ou un technicien d’entretien qualifié si vous n’êtes pas certain que la prise est correctement
mise à la terre. Ne pas modifier la fiche fournie avec l’appareil - si elle ne peut être insérée dans la
prise, faire installer une prise adéquate par un électricien qualifié.
Cet appareil est destiné à un circuit de 120 V et est muni d’une fiche de terre semblable à celle
illustrée par le croquis 1. Un adaptateur temporaire semblable à celui illustré par le croquis 2 et C
peut être utilisé pour brancher cette fiche à une prise bipolaire comme l’illustre le croquis 2 si une
prise avec mise à la terre n’est pas disponible. L’adaptateur temporaire devrait etre utilisé seulement
jusqu’à ce qu’une prise avec mise à la terre soit installée par un électricien qualifié. L’oreille rigide ou
le crochet ou autre dispositif semblable, de couleur verte, prolongeant l’adaptateur doit Iêtre raccordé
à un élément correctement mis à la terre comme le couvercle d’une boîte de sortie mise à la terre.
L’adaptateur doit être fixé par une vis métallique. Note: Au Canada, I’utilisation d’un adaptateur
temporaire n’est pas autorisée par le Code canadien de l’électricité.
Remplacez la prise si la prise de terre est abîmée ou cassée.
Le fil Vert (ou Vert/Jaune) dans la ganse est le fil de terre. Lors du remplacement d´une prise, ce fil
doit être raccordé à la prise de terre uniquement.
Les ralonges connectées à cette machine doivent avoir 12 mesures, trois ganses de fil ayant trois
fiches masculines féminines tree-prong plugs and outlets. N´UTILISEZ PAS de ralonge de plus de
15 m (50 pieds) de long.
VEUILLEZ NOTER: CES INSTRUCTIONS CONCERNENT UNIQUEMENT L’AMÉRIQUE DU
NORD

FORM NO.56041560 / AquaPro™H - 7
KNOW YOUR MACHINE
KNOW YOUR MACHINE DESCRIPTIONS
Operator Handle (1) - Operator holds this to move the machine from one location to another.
Lift Handle (2) - Operator grasps this handle when lifting the machine.
Solution Tank Lid (3) - Fill Solution Tank here with warm water and chemicals.
Recovery Tank Lid (4) -The Recovery Tank can be flushed out by running clean water into this
opening with the Recovery Tank Drain Hose open. The vacuum float Shut-OFF can also be
accessed through this opening for maintenance.
Switch Plate (5) - The switches that operate the motors and the heater are located here, as well as
indicator lights for the heater.
Vacuum Hose Connector (6) - This is where the vacuum hose attaches to the machine.
Solution Hose Connector (7) - This is where the solution hose attaches to the machine.
Latches (8) - These latches can be opened if the base compartment needs to be accessed.
The latches are normally closed to keep the machine sections held together tightly.
Drain Hose (9) - This hose is used to empty the recovery tank of dirty water.
2
3
4
5
8
9
6
1
7

8 - FORM NO. 56041560 / AquaPro™H
I
OO
I
O
II
O
212° F
SWITCH PLATE DESCRIPTIONS
Locator Light (1) - This green light will turn on when the two power cords are plugged into separate
circuits. Separate circuits are defined as outlets fed by circuit breakers on opposite sides of the
circuit breaker panel. This feature helps to prevent blown breakers. When the locator light (1) turns
on, the heat exchanger will automatically turn on. If you can not get the locator light to turn on, use
the Heat Switch (2) to turn the heat exchanger on.
Heat Switch (2) - This rocker switch turns the heat exchanger on and off, when the locator light (1)
is not on. The switch will light when ON.
Mode Light (3) - This indicator light will turn on while the heat exchanger is actively heating. It will
turn off when the heater has reached operating temperature. Normally, this light will be on most of
the time as you do your job, but it may go out if you stop cleaning to move furniture or to empty or fill
the tanks.
Vacuum 1 Switch (4) - This switch turns one vacuum on and off. The switch will light when ON.
When operating with only one vacuum -- as when cleaning delicate fabric -- use Vacuum 1. When
cleaning carpet, use both Vacuum 1 and Vacuum 2 (5).
Vacuum 2 Switch (5) - This switch turns the second vacuum on and off. The switch will light when
ON. Use this switch when you want maximum vacuum lift. The CFM of both motors is the same as
it is for one motor alone, since the vacuums are operated in parallel; however the vacuum lift
doubles when both vacuums are running.
Pump Switch (6) - This switch turns the pump on and off. The switch will light when ON.
The pump in this machine is a “demand” style pump. This means the pump only runs when you are
actually spraying. Once spraying stops, the pump stops running.
➃➃
➃➃
➃➅➅
➅➅
➅
➀➀
➀➀
➀➁➁
➁➁
➁
➂➂
➂➂
➂
➄➄
➄➄
➄

FORM NO.56041560 / AquaPro™H - 9
Power
Cord #1
∼
115V
Green
SW VAC 1
VAC 2
Line
FAN
PUMP
Neutral
SW
White
Black
Black
White
White
Dual Cord
Sensor Board
SW
Black
P3 P4
Black
P1 P2 P5
“LOCATOR”
LIGHT
P6 P7
White
Black
HEAT
EXCHANGER
Green
Black
∼
Power
Cord #2
115V
•
•
White
“MODE”
LIGHT
Black
∼
Thermostat
Thermal
Fuse
White
Black
MACHINE WIRING

10 - FORM NO. 56041560 / AquaPro™H
OPERATION
1Inspect the machine, hoses, and cleaning tools for cleanliness and completeness.
2Fill the solution tank with warm water. Using warm water may be a benefit in cleaning
effectiveness, but do not use hot water (above 140°F / 60°C) in the tank. Add liquid cleaning
solution with a pH of between 6 and 9.
3Plug in the power cords. Do not connect both cords to the same outlet; the circuit locator
light on the switch plate should light up. If the locator light does not come on, try different
outlets until it does. If you are certain the cords are on separate circuits, turn the heat
switch on. CAUTION: using the heat switch when the cords are on the same circuit may
cause the breaker to trip. NOTE: the cord with the red sleeve powers the heat exchanger.
4Attach the spray hose to the solution quick disconnect and the vacuum hose to the hose
barb on the recovery tank. Attach the other ends of the hoses to the cleaning tool.
5Turn the pump on, and spray through the tool to make sure everything is working, and to fill
the heat exchanger with water. NOTE: the pump has a built in pressure switch; the pump
only runs when you are spraying.
6Allow the heat exchanger two minutes to reach operating temperature.
7Turn the vacuums on.
8Begin cleaning using the correct hoses and tool.
9Use defoamer in the recovery tank any time foaming occurs.
10 Monitor water level in the solution tank. Do not let the pump run dry.
11 When the solution tank gets low, turn off the pump, fill the solution tank, empty and clean the
recovery tank.
12 When finished with the job, remove any unused solution from the solution tank, and run a
few gallons of clean water through the system.
BALL FLOAT VACUUM SHUT-OFF
Prior to using the machine, always check that the float filter is clean and the ball can travel freely.
When the recovery tank is full, the ball float will rise and will shut off the vacuum flow to prevent
any more water from entering the tank. Turn off the vacuum, and empty the recovery tank.
NOTE: if foam is present or if the ball float is prevented from rising, the float will not be able to
stop the air flow, and the tank may over fill.
CAUTION!
To avoid vacuum motor damage, always make sure the float filter is clean and the ball can travel
freely prior to using the machine. And always use a defoamer when foaming occurs.
ELECTRIC CIRCUIT LOCATOR
This unique, patented system is operated by a solid state circuit. It will inform the operator when
the two cords are plugged into separate circuits by turning the circuit locator light (see 1 on switch
plate)on. This helps to prevent tripping circuit breakers.
NOTE: if the circuit locator light does not illuminate when the cords are plugged in, then both
cords are on the same circuit. Try other outlets with one of the cords until you get the locator light
to come on. NOTE: if the heat switch (2 on switch plate)is turned on when both cords are on
the same circuit, the breaker will trip.

FORM NO.56041560 / AquaPro™H - 11
USE AND MAINTENANCE
1Use only liquid chemicals with a pH between 6 and 9 at the recommended mix ratios. Improper
chemicals, or improperly mixed chemcials, can cause possible damage to the pump, seals, and
other components.
2Turn the pump “off” when the solution tank is low on fluid. Do not let the pump run dry.
3Regularly clean any mineral or chemical deposits in the heat exchanger, lines and pump with a
mild acid descaler. Rinse the descaler out of the machine with a few gallons of clear water.
4Prior to each job, inspect, and clean if needed, the solution filter, the recovery tank float filter,
and the drain hose.
5Make sure the airways are not blocked before each use.
6Inspect the carbon brushes on the vacuum motors once a year. Replace if worn down.
7Clean the Recovery Tank daily. Clean the body and wheels as needed.
8Keep the machine from extremes in temperatures.
MAINTENANCE SCHEDULE
Daily Monthly Yearly
PMUP&SENILHSULF
X
RETLIFTAOLFMUUCAVNAELC
X
RETLIFNOITULOSNAELC
X
SYAWRIATELNIKCEHC
X
ENIHCAMELACSED
X
SEHSURBROTOMMUUCAVKCEHC
X

12 - FORM NO. 56041560 / AquaPro™H

FORM NO.56041560 / AquaPro™H - 13
PART LIST AquaProTM H
Item Ref. No. Qty Description
1 56102815 1 Bracket, Mating (Bracket Kit)(Bracket Kit)
(Bracket Kit)(Bracket Kit)
(Bracket Kit)
1A 56102815 1 Bracket, Mating W/Hole (Bracket Kit)(Bracket Kit)
(Bracket Kit)(Bracket Kit)
(Bracket Kit)
2 56102816 4 Screw, 8-32 x .50 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
3 56108074 2 Latch, Rubber W/Strike
5 56102808 1 Recovery Tank, Light Gray
6 56108061 1 Vac Inlet Hose Barb
7 56102816 1 Gasket (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
8 56108055 1 Lid, 6”, Clear Center, W/Ring
8A 56108054 2 Chain, 8” (also included in Solution Lid Kit 56102812)(also included in Solution Lid Kit 56102812)
(also included in Solution Lid Kit 56102812)(also included in Solution Lid Kit 56102812)
(also included in Solution Lid Kit 56102812)
8B 56102812 1 Screw, 10-32 x .38, Brass (Solution Lid Kit)(Solution Lid Kit)
(Solution Lid Kit)(Solution Lid Kit)
(Solution Lid Kit)
8C 56102816 1 Screw, 10-32 x .62 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
9 56102816 6 Screw, 8-32 x .88 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
9A 56102816 6 Lock Nut, 8-32 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
10 56108052 1 Float, Ball & Cage on Manifold
13 56102815 1 Bracket, Vacuum Motor (Bracket Kit)(Bracket Kit)
(Bracket Kit)(Bracket Kit)
(Bracket Kit)
14 56102817 4 Hose Clamp (Hose Clamp Kit)(Hose Clamp Kit)
(Hose Clamp Kit)(Hose Clamp Kit)
(Hose Clamp Kit)
15 56102841 1 Hose, Vacuum 2” x 41”
16 56102825 1 Heat Exchanger, Complete (Heat Exchanger(Heat Exchanger
(Heat Exchanger(Heat Exchanger
(Heat Exchanger, Complete), Complete)
, Complete), Complete)
, Complete)
17 56102817 1 Hose Clamp (Hose Clamp Kit)(Hose Clamp Kit)
(Hose Clamp Kit)(Hose Clamp Kit)
(Hose Clamp Kit)
18 56102869 1 Mount Bracket, Heat Exchanger
19 56102825 1 Hose, Braided SS (Heat Exchanger(Heat Exchanger
(Heat Exchanger(Heat Exchanger
(Heat Exchanger, Complete), Complete)
, Complete), Complete)
, Complete)
20 56102825 4 Washer, Brass (Heat Exchanger(Heat Exchanger
(Heat Exchanger(Heat Exchanger
(Heat Exchanger, Complete), Complete)
, Complete), Complete)
, Complete)
20A 56102813 3 Washer, Fiber (Quick Disconnect Kit)(Quick Disconnect Kit)
(Quick Disconnect Kit)(Quick Disconnect Kit)
(Quick Disconnect Kit)
(also included in Heat Exchanger(also included in Heat Exchanger
(also included in Heat Exchanger(also included in Heat Exchanger
(also included in Heat Exchanger, Complete 56102825), Complete 56102825)
, Complete 56102825), Complete 56102825)
, Complete 56102825)
21 56102825 1 Nipple, SS 1/4 NPT (Heat Exchanger(Heat Exchanger
(Heat Exchanger(Heat Exchanger
(Heat Exchanger, Complete), Complete)
, Complete), Complete)
, Complete)
22 56102825 1 Bushing, Fiber (Heat Exchanger(Heat Exchanger
(Heat Exchanger(Heat Exchanger
(Heat Exchanger, Complete), Complete)
, Complete), Complete)
, Complete)
23 56102825 1 Heat Control Switch (Heat Exchanger(Heat Exchanger
(Heat Exchanger(Heat Exchanger
(Heat Exchanger, Complete, Complete
, Complete, Complete
, Complete
(also included in Heat Repair Kit 56102819)(also included in Heat Repair Kit 56102819)
(also included in Heat Repair Kit 56102819)(also included in Heat Repair Kit 56102819)
(also included in Heat Repair Kit 56102819)
24 56102825 1 Elbow, Brass (Heat Exchanger(Heat Exchanger
(Heat Exchanger(Heat Exchanger
(Heat Exchanger, Complete), Complete)
, Complete), Complete)
, Complete)
(also included in Hose Barb Kit 56102829)(also included in Hose Barb Kit 56102829)
(also included in Hose Barb Kit 56102829)(also included in Hose Barb Kit 56102829)
(also included in Hose Barb Kit 56102829)
24A 56102825 1 Coupling, Brass (Heat Exchanger(Heat Exchanger
(Heat Exchanger(Heat Exchanger
(Heat Exchanger, Complete), Complete)
, Complete), Complete)
, Complete)
25 56102816 20 Washer, Flt 3/16 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
26 56102816 18 Lock Nut, 1/4 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
26A 56102816 4 Bolt, 1/4-20 x 1-1/4 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
27 56102818 2 Vacuum Motor (V(V
(V(V
(Vacuum Motor Kit)acuum Motor Kit)
acuum Motor Kit)acuum Motor Kit)
acuum Motor Kit)
28 56102818 2 Gasket, Vacuum Motor (V(V
(V(V
(Vacuum Motor Kit)acuum Motor Kit)
acuum Motor Kit)acuum Motor Kit)
acuum Motor Kit)
29 56102842 2 Manifold
30 56102816 6 Bolt, 1/4-20 x 5.00 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
31 56102816 6 Washer, 1/4 Split Lock (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
32 56102816 6 Nut, Finish 1/4 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
33 56102829 1 Hose Barb, Nylon, Straight (Hose Barb Kit)(Hose Barb Kit)
(Hose Barb Kit)(Hose Barb Kit)
(Hose Barb Kit)
38 56102843 1 Handle, Chrome
39 56102816 4 Bolt, 1/4-20 x .75 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
40 56102813 1 Quick Disconnect, Male 1/4 NPT (Quick Disconnect Kit)(Quick Disconnect Kit)
(Quick Disconnect Kit)(Quick Disconnect Kit)
(Quick Disconnect Kit)
(also included in Heat Exchanger(also included in Heat Exchanger
(also included in Heat Exchanger(also included in Heat Exchanger
(also included in Heat Exchanger, Complete 56102825), Complete 56102825)
, Complete 56102825), Complete 56102825)
, Complete 56102825)
41 56102844 1 Flange, Exhaust
42 56102845 2 Louver, W/Screws
45 56102820 2 PVC Reducer (Cord Outlet Kit)(Cord Outlet Kit)
(Cord Outlet Kit)(Cord Outlet Kit)
(Cord Outlet Kit)
46 56102820 2 Cord Retainer (Cord Outlet Kit)(Cord Outlet Kit)
(Cord Outlet Kit)(Cord Outlet Kit)
(Cord Outlet Kit)
47 56102866 1 Dual Cord Sensor PCB
48 56102867 1 Snap Track, PCB Mount, 4” LG
49 56102847 1 Axle Rod Plated 18.25”
Item Ref. No. Qty Description
50 56102811 2 Wheel, 10” (Wheel Kit)(Wheel Kit)
(Wheel Kit)(Wheel Kit)
(Wheel Kit)
51 56102811 2 Axle Cap (Wheel Kit)(Wheel Kit)
(Wheel Kit)(Wheel Kit)
(Wheel Kit)
52 56102846 2 Cord, 25ft, 12/3
52A 56102820 2 Cord, Pigtail, 24”, 12/3 (Cord Outlet Kit)(Cord Outlet Kit)
(Cord Outlet Kit)(Cord Outlet Kit)
(Cord Outlet Kit)
53 56102850 2 Hinge Pin
55 56102810 1 Base Compartment, Gray
57 56102809 1 Solution Tank, Light Gray
58 56102853 1 Filter, Pump Inlet
59 56102854 1 Nipple, PVC, 1/2 NPT
60 56102812 1 Lid, Solution Tank (Solution Lid Kit)(Solution Lid Kit)
(Solution Lid Kit)(Solution Lid Kit)
(Solution Lid Kit)
61 56102817 4 Hose Clamp (Hose Clamp Kit)(Hose Clamp Kit)
(Hose Clamp Kit)(Hose Clamp Kit)
(Hose Clamp Kit)
62 56102851 1 Pump, 150PSI, 120V
63 56102829 2 Hose Barb, Elbow (Hose Barb Kit)(Hose Barb Kit)
(Hose Barb Kit)(Hose Barb Kit)
(Hose Barb Kit)
67 56102839 1 Hose, 3/8”ID x 76”LG
69 56102858 1 Switch Plate
70 56102816 5 Screw, #4 x .38 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
71 56102863 2 Light, Green, 120V
73 56102827 3 Switch, SPST, W/Cover
74 56102828 1 Switch, DPDT, W/Cover
75 56102816 3 Screw, 10-32 x .62 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
76 56102816 3 Lock Nut, 10-32 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
77 56102816 4 Screw, 6-32 x 2.00 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
78 56102816 4 Lock Nut, 6-32 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
79 56108096 1 Fan, 120V (Fan Kit)(Fan Kit)
(Fan Kit)(Fan Kit)
(Fan Kit)
80 56108096 1 Fan Guard (Fan Kit)(Fan Kit)
(Fan Kit)(Fan Kit)
(Fan Kit)
82 56102860 1 Gasket, 7ft
83 56102856 2 Cord Wrap, Black
84 56102816 4 Screw, 1/4-20 x 1.00 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
85 56102815 2 Bracket, Bag Hanger (Bracket Kit)(Bracket Kit)
(Bracket Kit)(Bracket Kit)
(Bracket Kit)
86 56102848 2 Castor, 4” No Brake
87 56102840 2 Label, Advance AquaPro
89 56102816 8 Bolt, 1/4-20 x .75 (Hardware Kit)(Hardware Kit)
(Hardware Kit)(Hardware Kit)
(Hardware Kit)
90 56108084 1 Hose, Barb / Elbow 1/2”
(Solution Hose Kit)(Solution Hose Kit)
(Solution Hose Kit)(Solution Hose Kit)
(Solution Hose Kit)
91 56108084 1 Hose, Site, 1/2” (Solution Hose Kit)(Solution Hose Kit)
(Solution Hose Kit)(Solution Hose Kit)
(Solution Hose Kit)
92 56108084 1 Hose Barb, Nylon, 1/2”
(Solution Hose Kit)(Solution Hose Kit)
(Solution Hose Kit)(Solution Hose Kit)
(Solution Hose Kit)
93 56108071 1 Hose, Drain 1-1/2” x 24”
(Dump Hose Kit)(Dump Hose Kit)
(Dump Hose Kit)(Dump Hose Kit)
(Dump Hose Kit)
93A 56108071 1 Plug, Drain Hose (Dump Hose Kit)(Dump Hose Kit)
(Dump Hose Kit)(Dump Hose Kit)
(Dump Hose Kit)
* 56108093 1 Label, Warning
* = Not Shown
revised 11/03

14 - FORM NO. 56041560 / AquaPro™H
TECHNICAL SPECIFICATIONS
Vacuum Motor:
Water lift:
Air Flow:
Amp Draw:
Tank Construction:
Solution Tank Capacity:
Recovery Tank Capacity:
Application Flow:
Solution Hose Length:
Recovery Hose Length:
Power Cord:
Rear Wheels:
Front Castors:
Heat Exchanger:
Height:
Length:
Width:
Machine weight:
Two 2-Stage
150”
100 cfm
16 amps, each cord
Rotationally molded polyethylene
14 Gal. (53.2 L)
13 Gal.(49.4 L)
150 psi
15 ft. (4.5 m)
15 ft. (4.5 m)
Two 25 ft. (7.6 m), High visability yellow, removable
10 in. (25 cm)
4 in. (10.2 cm)
2000 Watt
38 in (96.5 cm)
36 in (91.4 cm)
17.6 in (44.7 cm)
84 lb (38 kg)
KITS
56108096 1 Fan Kit (#79, 80)
56102811 1 Wheel Kit (1 each of #50, 51)
56102812 1 Solution Lid Kit (#8B, 60 / also includes #8A)
56102816 1 Hardware Kit (#2, 7, 8C-9A, 25-26A, 30-32, 39, 70, 75-78, 84, 89)
56102817 1 Hose Clamp Kit (#14, 17, 61)
56102818 1 Vacuum Motor Kit (1 each of #27, 28)
56102813 1 Quick Disconnect Kit (#20A, 40)
56102815 1 Bracket Kit (#1, 1A, 13, 85)
56102825 1 Heat Exchanger, Complete (#16, 19, 20, 21-24A / also includes #20A, 40)
56102819 1 Heat Repair Kit (#23)
56108071 1 Dump Hose Kit (#93, 93A)
56108084 1 Solution Hose Kit (#90-92)
56102820 1 Cord Outlet Kit (1 of each #45, 46, 52A)
56102829 1 Hose Barb Kit (#33, 63 / also includes #24)
ACCESSORIES
56102804 1 Single Bend Wand Assembly
56102805 1 Double Bend Wand Assembly
56102807 1 Extractor Hand Tool
56102861 1 Vac Hose / Pressure Line 25ft.
56102871 1 Vac Hose / Pressure Line 15ft.

FORM NO.56041560 / AquaPro™H - 15

.
NOTE: There should be
no voltage reading when
switch is “OFF” (Step 3).
FIGURE 1
VACUUM BALL-FLOAT SYSTEM
TROUBLESHOOTING
(120V)
NOTE: The motors on these extractor models are controlled by AC voltage passing through the ON/OFF
switch.
VACUUM MOTOR NOT RUNNING:
1. Always unplug the machine before working on the wiring system.
2. Open the machine to look for damaged or disconnected wires leading to the vac motor.
3. Remove the screws from the switch plate. Gently turn the switch plate over and check
the back of the switches to make sure no wires have pulled loose.
MEASURING THE AC VOLTAGE THROUGH THE SWITCH:
1. Connect a voltmeter to the terminals (with wires) on the vacuum switch being tested. Set
the AC voltage in the range of 120 volts, or more. (See Figure 1 to the right).
2. Turn the vacuum switch “OFF”.
3. With the switch in the “OFF”
position, plug the #1 Cord (red
sleeve) into an outlet and
measure for NO AC voltage.
4. Turn the switch “ON” and look
for an AC voltage reading. (See
Figure 1 to the right).
5. If the switch is not
working, replace it.
Refer to the
schematic and parts list for the
particular machine you are
working on.
6. If the switch is working correctly,
test the motor itself by connecting
it directly to AC voltage.
Switch ON
Opposite sides
of the switch

TESTING THE MOTOR DIRECTLY TO AC VOLTAGE:
1. Unplug the power cords.
2. Cut both the power wires leading from the vacuum motor, several inches from the motor
itself. Leave enough length for reconnecting the wires.See Figure 2 below.
3. Connect the motor wires (leading from the motor) to an AC jumper wire. See Figure 2.
4. Plug the jumper into an outlet. Does the vacuum motor run? If the vacuum motor runs,
unplug the jumper, visually inspect and/or use the “continuity tester” or “ohm meter” to
find the opening between the switch and motor wires. Refer to the wiring schematic for
your machine model.Repair.
5. If the motor does not run, replace it.Refer to the parts list and schematic for your machine
for the correct part number. Refer to Vacuum Motor Replacement Instructions for steps
on removal and installation.
FIGURE 2 NOTE: Do not remove the mo-
tor to test.
Step 2 & 3: Cut both power wires sev-
eral inches from the motor and con-
nect to an AC jumper wire.
Step 5: Plug the jumper
into an outlet.
NOTE: Do not remove the
motor to test it.

.
NOTE: There should be
no voltage reading when
switch is “OFF” (Step 3).
FIGURE 1
VACUUM BALL-FLOAT SYSTEM
TROUBLESHOOTING
AquaPro
TM
300
(120V)
NOTE: The motors on these extractor models are controlled by AC voltage passing through the ON/OFF
switch.
VACUUM MOTOR NOT RUNNING:
1. Always unplug the machine before working on the wiring system.
2. Open the machine to look for damaged or disconnected wires leading to the vac motor.
3. Remove the screws from the switch plate. Gently turn the switch plate over and check
the back of the switches to make sure no wires have pulled loose.
MEASURING THE AC VOLTAGE THROUGH THE SWITCH:
1. Connect a voltmeter to the terminals (with wires) on the vacuum switch being tested. Set
the AC voltage in the range of
120 volts, or more. (See Figure
1 to the right).
2. Turn the vacuum switch “OFF”.
3. With the switch in the “OFF”
position, plug the #1 Cord (red
sleeve) into an outlet and
measure for NO AC voltage.
4. Turn the switch “ON” and
look for an AC voltage
reading. (See Figure
1 to the right).
5. If the switch is not working,
replace it. Refer to the
schematic and parts list for the
particular machine you are
working on.
6. If the switch is working correctly,
test the motor itself by connecting
it directly to AC voltage.
Switch ON
Opposite sides
of the switch
