Advanced Elements ADVANCEDFRAME ELITE User manual

OWNER’S MANUAL
MODEL AE1012-E
IMPORTANT
ADVANCEDFRAME ELITE
INFLATABLE KAYAK
®
IMPORTANT! PLEASE READ THIS MANUAL CAREFULLY BEFORE PROCEEDING.
AFTER READING THIS MANUAL, SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ADVANCED ELEMENTS, INC 2022 REV 10-2022
1 PERSON KAYAK

AdvancedFrame® Inatable Kayak Owner’s Manual
3
TABLE OF CONTENT
1. Caution – Safety Warning........................................................4
1.1 Boating Safety...................................................................5
2. Specifications .............................................................................6
2.1 Capacity.............................................................................6
2.2 Features..............................................................................6
3. Assembly/Inflating/Deflation Instruction .............................7
3.1 Assembly...........................................................................7
3.2 Understanding Your Valves...........................................8
3.3 Inflation And Setup In 3 Simple Stages ......................10
3.4 Over Inflation And Temperature Regulation............11
3.5 Deflation..........................................................................12
3.6 Folding.............................................................................12
4. Guidelines For Usage .............................................................12
5. Proper Care And Storage.......................................................13
6. Repairs......................................................................................14
6.1 Repairing Small Punctures And Cuts Using The
Peel-And-Stick Patch .....................................................14
6.2 Repairing Pinholes.........................................................14
7. Troubleshooting ......................................................................14
Manufacturer’s Statement Of Origin (MSO)...........................17
Declaration Of Conformity........................................................18
Limited Warranty........................................................................19
Section 2 : Français

6
2. SPECIFICATIONS
Dimensions:
Length: 10’5” (317 cm)
Width: 32” (81 cm)
Weight: 36 lbs (16 kg)
Max. Person Capacity: 235 lbs (107 kg)
Max. Persons & Gear Capacity: 300 lbs (136 kg)
Recommended Pressure:
Main chambers: 2.0 psi (0.14 bar)
Floor chambers: 6.0 psi (0.41 bar)
2.1 CAPACITY
The person/load capacity is determined by the availability of proper seating on the kayak.
Acceptable seating determines the number of passengers, not the overall load capacity.
WARNING: Do not exceed the certied maximum capacities under any circumstances.
Overloading will reduce freeboard and increase the likelihood of swamping, especially in heavy
seas. Overloading causes handling to become sluggish, making it dicult to react quickly.
2.2 FEATURES
Hull Design: Built-in Aluminum ribs dene the bow and stern and improve tracking.
Durable: 3 Layers of material for extreme puncture resistance.
Easy to Set Up: Pre-assembled at the factory. Simply unfold, inate and aach the seat.
Comfortable: High support, adjustable padded seat provides comfort for hours of paddling.
Style : Looks and paddles similar to a rigid hard shell kayak with the portability of an inatable.

AdvancedFrame® Inatable Kayak Owner’s Manual
7
3. ASSEMBLY/INFLATING/DEFLATION INSTRUCTION
The AdvancedFrame Kayak has a rigid frame in the bow and stern that enhances its
performance.
3.1 ASSEMBLY
The illustration below shows the general assembly of the kayak. Your kayak comes from the
factory pre-assembled. The only assembly your should need to do is aach the adjustable seat.
1. Your AdvancedFrame kayak comes from the factory pre-assembled however should you take
it apart you will need to insert the aluminum Bow rib and the Stern Rib into the webbing slots
on the cover of the AdvancedFrame tube (while deated).
2. Place the AdvancedFrame (with Ribs installed), into the Outer Skin, making sure that the air
valve is upright and at the back of the boat, and lined up with the opening on the outer cover
Chamber 1 and 2 are separate chambers but equalize in pressure because they are inside a
Bungee Deck
Lacing
Adjustable High-
Back Seat
Storage
Compartment
Molded Rubber
Carry Handle
Welded
Seams
Reinforced
Bow Seam
Hard Edge
Bow & Stern Durable Double
Coated Fabric
Zipper Lips Inatable Coaming
for Spray Skirt
Aachment
Neoprene Paddle
Guard
Skeg/
Tracking Fin
D-ring
Tie-Downs
Advanced
Elements
Spring
Valve
®

3.3 INFLATION AND SETUP IN 3 SIMPLE STAGES
For the best setup experience, we recommend using the Advanced Elements Double Action
Hand Pump with Gauge (AE2011) which provides 4,000 cc’s per full cycle stroke.
two separate air chambers that encircle the entire kayak. This provides optimum safety when out
air into the two main chambers, not only for proper performance, but for safety as well.
STEP 1 :
1. Starting with Main Chamber 1, check to be sure that the valve plunger is UP or in the
INFLATE position (See Figure 1 on previous page).
down) strokes until the kayak begins to take shape. If using another pump, the key here is to
minimal amount of air pressure.
DO NOT PUT ALL OF THE AIR PRESSURE IN THIS CHAMBER.
alve and proceed to
Main Chamber 2.
10

STEP 2 :
1. Moving to Main Chamber 2 on the inside of kayak, check to be sure that the valve plunger is
(2.0 psi ONLY).
alve.
STEP 3 :
MAX)
4. Make sure all valves are closed tightly and properly.
5. Finally, insert plastic Bow and Stern Forms into the grey pockets on the bow and stern of the
kayak. (See Figure 3).
INFLATION TIPS
CO2, OR COMPRESSED AIR AS THEY MAY DAMAGE YOUR KAYAK. The main chambers use
high-end military style, plunger valves (Push in and twist to activate the spring-loaded check
3.4 OVER INFLATION AND TEMPERATURE REGULATION
weather and water your kayak will lose some pressure. If this occurs, you may want to add a
bit more air to the kayak to improve performance. In hot weather or prolonged sunlight, the air
inside the kayak will expand. You must let some air out of the appropriate chambers to prevent
the kayak from failing due to overpressure. You should avoid exposing your kayak to extreme
temperatures (hot or cold).
Figure 3. Plastic Bow and Stern Insert
11
®

3.5 DEFLATION
1. Remove the caps from chamber 1, 2 & 3.
3. Open twist valves on chambers 4 through 7.
3.6 FOLDING
NOTICE:
3. Fold in half, down the center (right to left)(A).
4. Fold into 4 equal sections.
4. GUIDELINES FOR USAGE
Paddlesports can be very dangerous and physically demanding. The user of this product should
understand that participation in paddlesports may involve serious injury or death. Observe the
following safety standards whenever using this product. The user of this product acknowledges
both an understanding and an assumption of the risk involved in paddlesports.
for obvious signs of wear or failure. Review local rules and regulations and read again the
“CAUTION” statement.
FOLDFOLD
FOLD
FOLD
