Advanced Axis AX-PSU-6 User manual

www.advancedco.com
AX-PSU-6
Figure 1 - AX-PSU-6 Power Supply Charger Module Mounting
COM NO NC OV +VO -BAT +BAT
COM NO NC OV +VO -BAT +BAT

www.advancedco.com2
These instructions cover the installation and replacement of the AX-PSU-6, Power Supply Charger Module.
Refer to separate wiring diagrams and manuals for additional system module installation wiring, operation and
programming functions.
AX-CTL-1:
Wiring Diagram: 670-1342 Product Manual: 682-010 Program Manual: 682-002
AX-CTL-1L, AX-CTL-2 and AX-CTL-4:
Wiring Diagram: 670-1233 Product Manual: 682-001 Program Manual: 682-002
AX-CTL-1V, AX-CTL-2V and AX-CTL-4V:
Wiring Diagram: 670-1233 Product Manual: 682-001V Program Manual: 682-002
AX-CC1-16, AX-CC2-16, AX-CC4-16 and Command Centers CCM-01/CCM-02:
Wiring Diagram: 670-1233 Product Manual: 682-001CC Program Manual: 682-002
Caution: Before installing or removing any printed circuit boards remove all sources of power (AC and
battery).
This equipment is constructed with static sensitive components. Observe anti-static precautions
at all times when handling printed circuit boards. Wear an anti-static ground strap connected to
panel enclosure earth ground.
Installation (see figure 1):
[1] Place the AX-PSU-6, Power Supply Charger Module, over the four (4) standoffs located on the right side of the
back box below the AX-CTL base card or below a previously installed AX-PSU, AX-PSU-6 and secure with the four (4)
provided screws.
[2] Connect the provided Molex connector cable into the available Molex connector on the AX-ACB, AC Board, and
wire the Hot, Neutral and Ground wires to the AC terminal block located on the AX-PSU-6 module.
[3] Wire AX-PSU-6 as indicated in figure 1, and in the product manuals.
Note: If there are no available Molex connectors on the AX-ACB, AC Board, remove the Molex connector on
the cable and wire directly to the AC input terminals of the AX-ACB, AC Board, or previous AX-PSU-6, Power
Supply Charger Module.
Replacement (see figure 1):
[1] Remove the AC, battery, 24 VDC output and relay trouble contact wiring from the AX-PSU-6, Power Supply
Charger, terminal block.
[2] Remove the four (4) screws securing the AX-PSU-6, Power Supply Charger Module, to the back box and remove
the AX-PSU-6 module.
Doc Number: 682-028 AFS
Revision: 1
First Issued: 2013-mm-dd
100 South Street, Hopkinton, Massachusetts 01748
Tel: [phone] Fax: [phone]
Email: [e-mail] Web: www.advancedco.com
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE DEVICES
