Advantech POC-W242 Instruction manual

POC-W242 Quick User Guide
POC-W242 Quick User Guide
POC-W242 Quick User GuidePOC-W242 Quick User Guide
ENGLISH
Power1.
Volume up/down2.
Touchscreen status control3.
Read light control4.
Brightness increase/decrease5.
2 x USB 2.0 port*6.
Speaker out7.
Mic-in8.
PCIe x4 card slot9.
Equipotential terminal pin10.
1 x RS-232/422/485 serial port11.
(isolated)
2 x USB 3.0 port*12.
VGA port13.
2 x RS-232 serial port (isolated)14.
2 x Gigabit ethernet interface15.
(isolated)
DC-in16.
HDMI-out port17.
NOTE: *USB ports or other
removable media drives may
present a security risk.
CAUTION: Before you set up and
use the POC, view the support
documentation on our website –
search by name, i.e., POC-W242.
Cleaning instructions can also be
found in the documentation.
http://support.advantech.com.tw/
support/new_default.aspx
DEUTSCH
Ein/Aus1.
Lauter/Leiser2.
Touchscreen Statussteuerung3.
Leselichtsteuerung4.
Helligkeit erhöhen/verringern5.
2 x USB 2.0 Port*6.
Lautsprecherausgang7.
Mikrofon-Eingang8.
PCIe x4 Kartensteckplatz9.
Potentialausgleichsstecker10.
1 x RS-232/422/485 serieller11.
Port (isoliert)
2 x USB 3.0 Port*12.
VGA-Port13.
2 x RS-232 serieller Port14.
(isoliert)
2 x Gigabit Ethernet15.
Schnittstelle (isoliert)
DC-Eingang16.
HDMI-Ausgang17.
HINWEIS: *USB-Ports oder andere
entfernbare Medienlaufwerke
könnten ein Sicherheitsrisiko
darstellen.
ACHTUNG: Lesen Sie die Support-
Dokumentation auf unserer
Webseite, bevor Sie den POC
einrichten und benutzen – suchen
Sie nach dem Produkt z.B.: POC-
W242. In der Dokumentation stehen
auch Hinweise zur Reinigung.
http://support.advantech.com.tw/
support/new_default.aspx
NEDERLANDS
Voeding1.
Volume omhoog/omlaag2.
Aanraakscherm standregeling3.
Licht lezen regeling4.
Helderheid verhogen/5.
verminderen
2x USB 2.0 poort*6.
Luidspreker uit7.
Mic in8.
PCIe x4 kaart gleuf9.
Equipotentiele terminale pin10.
1x RS 232/422/485 seriepoort11.
(geisoleerd)
2x USB 3.0 poort*12.
VGA poort13.
2 x RS-232 seriepoort14.
(geisoleerd)
2x Gigabit Ethernet interface15.
(geisoleerd)
DC-in16.
HDMI- uit poort17.
OPMERKING: *USB poorten of
andere verwijderbare mediaschijven
kunnen een beveiligingsrisico
presenteren.
WAARSCHUWING: Neem eerst
op onze website de begeleidende
documentatie door voordat u
de POC instelt en gebruikt-
zoek op naam,bijv. POC- W242.
Schoonmaak instructies zijn ook in
de documentatie te vinden.
http://support.advantech.com.tw/
support/new_default.aspx
FRANCAISE
Marche/Arrêt1.
Volume plus/moins2.
Contrôle de l'écran tactile3.
Contrôle de la lumière de4.
lecture
Luminosité plus/moins5.
Ports USB 2.0 x 2*6.
Sortie haut-parleur7.
Entrée micro8.
Emplacements carte PCIe x49.
Broche de connexion10.
équipotentielle
Port série RS-232/422/48511.
(isolé) x 1
Ports USB 3.0 x 2*12.
Port VGA13.
Ports série RS-232 (isolé) x 214.
Interface Ethernet Gigabit (isolé)15.
x 2
entrée DC16.
Port sortie HDMI17.
NOTE : * les ports USB ou les
autres média amovibles peuvent
présenter des risques de sécurité.
ATTENTION : avant d'installer
et d'utiliser cet écran, veuillez
consulter le manuel d'utilisation
sur notre site internet – faites
une rechercher par nom, i.e.,
POC-W242. Les instructions de
nettoyage et d'entretien se trouvent
aussi dans le manuel d'utilisation.
http://support.advantech.com.tw/
support/new_default.aspx
ITALIANO
Alimentazione1.
Regolazione volume2.
Gestione stato Touchscreen3.
Gestione luce di lettura4.
Regolazione luminosità5.
2 porte USB 2.0*6.
Uscita casse7.
Ingresso microfono8.
Slot 4 schede PCIe9.
Pin terminale equipotenziale10.
Porta seriale 1 x RS-11.
232/422/485 (isolata)
2 porte USB 3.0*12.
Porta VGA13.
Porta seriale 2 x RS-23214.
(isolata)
Interfaccia Ethernet 2x Gigabit15.
(isolata)
Ingresso DC16.
Porta uscita HDMI17.
NOTA:*Porte USB o altri dispositive
rimovibili possono presentare rischi
per la sicurezza.
ATTENZIONE: Prima di impostare
e usare il POC, vedere la
documentazione di supporto sul
nostro sito – cercare per nome,
es: POC-W242, istruzioni per la
pulizia possono essere usate nella
documentazione.
http://support.advantech.com.tw/
support/new_default.aspx
ESPAÑOL
Encendido1.
Subir / bajar el volumen2.
Control del estado de la pantalla3.
táctil
Control de la iluminación de4.
lectura
Aumentar / disminuir el brillo5.
2 puertos USB 2.0*6.
Salida para altavoces7.
Entrada para micrófono8.
Ranura de la tarjeta PCIe x49.
Pin del terminal equipotencial10.
1 puerto de serie RS-11.
232/422/485 (aislado)
2 puertos USB 3.0*12.
Puerto VGA13.
2 puertos de serie RS-23214.
(aislado)
2 interfaces Ethernet Gigabit15.
(aislado)
Entrada CC16.
Puerto de salida HDMI17.
NOTA: *Los puertos USB u otros
discos multimedia extraíbles
pueden producir un riesgo de
seguridad.
PRECAUCIÓN: Antes de congurar
y usar el POC, lea detenidamente
la documentación de soporte en
nuestra página web – búsqueda por
nombre, por ejemplo: POC-W242.
Las instrucciones de limpieza
también se pueden encontrar en la
documentación.
http://support.advantech.com.tw/
support/new_default.aspx
PORTUGUÊS
Energia1.
Aumentar/Diminuir Volume2.
Controlo do Ecrã Táctil3.
Controlo da luz de leitura4.
Aumentar/Diminuir Brilho5.
2 x Portas* USB 2.06.
Saída para Altifalante7.
Entrada de mic8.
PCIe x4 slot de cartão9.
Pino do terminal equipotencial10.
1 x porta serial RS-232/422/48511.
(isolada)
2 x Porta* USB 3.012.
Porta VGA13.
2 x Portas seriais RS-23214.
(isoladas)
2 x interfaces Gigabit ethernet15.
(isoladas)
Entrada DC16.
Porta de saída HDMI17.
Nota: Portas* USB ou outras
unidades de armazenamento
removíveis podem apresentar um
risco a segurança
ATENÇÃO: Antes de congurar
e utilizar o POC, veja a
documentação de suporte no
nosso site – pesquise por nome,
ou seja, POC-W242. As Instruções
de Limpeza também poderão ser
encontradas nesta documentação.
http://support.advantech.com.tw/
support/new_default.aspx
SVENSKA
Ström1.
Volym upp/ner2.
Pekskärmens statuskontroll3.
ljusstyrning4.
Ljusstyrka öka/minska5.
2 x USB 2.0-port *6.
Högtalare ut7.
Mic-in8.
PCIe x4 kortplats9.
Anslutningsstift till potentiell10.
utrustning
1 x RS-232/422/485 seriell port11.
(isolerad)
2 x USB 3.0-port *12.
VGA-port13.
2 x RS-232 seriell port (isoloitu)14.
2 x Gigabit Ethernet-gränssnitt15.
(isoloitu)
Virta sisään16.
HDMI-ut-port17.
OBS: *USB-minnen eller andra
yttbara media enheter kan utgöra
en säkerhetsrisk.
VARNING: Innan du ställer in
och använder POC, läs igenom
användare dokumentationen
(Manual) på vår webbplats -
sök på namn, dvs. POC-W242.
Rengöringsanvisningar nns också
i dokumentationen.
http://support.advantech.com.tw/
support/new_default.aspx
SUOMI
Virta1.
Ääni ylös/alas2.
Kosketusnäytön tilanhallinta3.
Punavalon hallinta4.
Kirkkauden lisäys/vähennys5.
2 x USB 2.0 Portti*6.
Kaiutin ulos7.
Mikrofonin sisääntulo8.
PCIe x4 korttipaikka9.
Potentiaalintasausterminaalin10.
nasta
1 x RS-232/422/485 sarjaportti (11.
eristetty)
2 x USB 3.0 Portti*12.
VGA portti13.
2x RS-232 sarjaportti (eristetty)14.
2xGigabitin ethernet-liittymä15.
(eristetty)
Virranlataus-portti16.
HDMI-ulostuloportti17.
HUOMIO: *USB-portit tai muut
poistettavat tiedontallentimet voivat
aiheuttaa turvariskin.
VAROITUS: Ennen kuin asennat ja
käytät POC:tä, katso tukitiedostot
nettisivuiltamme -etsi nimellä esim.
POC-W242. Puhdistusohjeet
löytyvät myös samasta tiedostosta.
http://support.advantech.com.tw/
support/new_default.aspx
NORSK
Strøm1.
Volum opp/ ned2.
Kontroll av berøringsskjermen3.
Les lyskontroll4.
Økning/reduksjon av lysstyrke5.
2 x USB 2.0-port*6.
Høyttaler7.
Mik-in8.
PCIe x4 kortspor9.
Ekvipotensial terminalpin10.
1 x RS-232/422/485 serieport11.
(isolert)
2 x USB 3.0-port*12.
VGA-port13.
2 x RS-232 serieport (isolert)14.
2 x Gigabit ethernet -grensesnitt15.
(isolert)
DC-inn16.
HDMI-out-port17.
MERK: *USB-porter eller andre
stasjoner med utskiftbare medier
kan innebære en sikkerhetsrisiko.
FORSIKTIG: Før du setter
opp og bruker POC, se
støttedokumentasjonen på
vår hjemmeside - søk etter
navn, det vil si, POC-W242.
Rengjøringsinstruksjonene kan
også nnes i dokumentasjonen
http://support.advantech.com.tw/
support/new_default.aspx
DANSK
Tænd/sluk1.
Lydstyrke op/ned2.
Statuskontrol for touch screen3.
Kontrol til læselys4.
Øg/sænk lysstyrke5.
2 x USB 2.0-port*6.
Højtalerudgang7.
Mikrofonindgang8.
PCIe x4-kortport9.
Ækvipotential terminalpind10.
1 x RS-232/422/485-serieport11.
(isoleret)
2 x USB 3.0-port*12.
VGA-port13.
2 x RS-232 serial port (isoleret)14.
2 x Gigabit Ethernet-interface15.
(isoleret)
Jævnstrømsindgang16.
HDMI-out-port17.
BEMÆRK: *USB-porte eller andre
udskiftelige mediedrev kan udgøre
en sikkerhedsrisiko.
ADVARSEL: Før du opsætter
og bruger denne POC, så læs
supportdokumentationen på vores
hjemmeside - søg efter navnet
fx POC-W242. Instruktioner for
rengøring kan også ndes i samme
dokumentation.
http://support.advantech.com.tw/
support/new_default.aspx
General Views of the POC-W242

POC-W242 Quick User Guide
POC-W242 Quick User Guide
POC-W242 Quick User GuidePOC-W242 Quick User Guide
CLASSIFICATION:
Supply Class I adapter
No applied parts
IP54
Continuous operation
Not AP or APG category
WARNING! This device is not suitable for use in the presence of flam-
mable anesthetic mixtures with air, oxygen, nitrous oxide,
or as a life support system.
Maintenance: To properly maintain and clean the surfaces, use only the approved products or clean
with a dry applicator.
CAUTION! When servicing the device, always use replacement parts
that meet Advantech standards. Advantech Medical can-
not warrant or endorse the safe performance of third-party
replacement parts for use with our medical device.
Make sure users do not come in contact with SIP/SOPs and the patient at the same time.
When connecting electrical devices, the operator is responsible for ensuring that the resulting system
meets the requirements set forth by the following standards:
EN 60601-1 (IEC 60601-1)
Medical electrical equipment
Part 1: General requirements for safety
EN 60601-1-1 (IEC 60601-1-1)
Medical electrical equipment
Part 1-1: General requirements for safety
Collateral standard: Safety requirements for Medical electrical systems
EN 60601-1-2 (IEC 60601-1-2)
Medical electrical equipment
Part 1-2: General requirements for safety
Collateral standard: Electromagnetic compatibility; Requirements and tests
Accessory equipment connected to the analog and digital interfaces must be in compliance with the
respective nationally harmonized IEC standards (i.e. IEC 60950 for data processing equipment, IEC
60065 for video equipment, IEC 61010-1 for laboratory equipment, and IEC 60601-1 for medical equip-
ment). Furthermore all configuration should comply with the system standard IEC 60601-1-1. Anyone
who connects additional equipment to the signal input or signal output is configuring a medical system,
and is therefore responsible that the system complies with the requirements set forth in standard IEC
60601-1-1. The unit is for exclusive interconnection with IEC 60601-1 certified equipment in the patient
environment and IEC 60XXX certified equipment outside of the patient environment. If in doubt, consult
the technical services department or your local representative.
FCC Class B
This equipment has been tested and found to comply with the limits for a Class B digital device, pursu-
ant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a residential environment. This equipment generates, uses, and can radiate
radio frequency energy. If not installed and used in accordance with this user’s manual, it may cause
harmful interference to radio communications.
Note that even when this equipment is installed and used in accordance with this user’s manual, there
is still no guarantee that interference will not occur. If this equipment is believed to be causing harmful
interference to radio or television reception, this can be determined by turning the equipment on and
off. If interference is occurring, the user is encouraged to try to correct the interference by one or more
of the following measures:
■
■
■
■
■
SAFETY INSTRUCTIONS
Strictly follow these Instructions for Use, please read these safety instructions carefully.
Y
ou are reminded to keep this User’s Manual for later reference, and any use of the product requires
full understanding and strict observation of all portions of these instructions. Observe all WARNINGS
and CAUTIONS as rendered throughout this manual and on labels on the equipment.
Repair of the device may only be carried out by trained service personnel. Advantech recommends that
a service contract be obtained with Advantech Service and that all repairs also be carried out by them.
Otherwise the correct functioning of the device may be compromised.
WARNING!Because of the danger of electric shock, never remove the
cover of a device while it is in operation or connected to a
power outlet.
If one of the following situations arises, have the equipment checked by service personnel:
The power cord or plug is damaged.
Liquid has penetrated the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to the user’s
manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or
spray detergents for cleaning and keep this equipment away from humidity.
CAUTION!To avoid short-circuits and otherwise damaging the device,
do not allow fluids to come in contact with the device. If
fluids are accidentally spilled on the equipment, remove the
affected unit from service as soon as possible and contact
service personnel to verify that patient safety is not com-
promised.
Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause dam-
age. For plug-in equipment, the power outlet socket must be located near the equipment and must be
easily accessible.
CAUTION!To prevent overheating, it is recommended to install the unit
in an upright position. Do not lie it flat on a table and do not
cover the openings or place the device in direct sunlight or
near radiant heaters.
Make sure the voltage of the power source is correct before connecting the equipment to the power
outlet. Position the power cord so that people cannot step on it. Do not place anything over the power
cord. If the equipment is not used for a long time, disconnect it from the power source to avoid damage
by transient over voltage.
CAUTION!Do not leave this equipment in an uncontrolled environ-
ment where the storage temperature is below -20°C (-4°F)
or above 60°C (140°F). This may damage the equipment.
If your computer clock is unable to keep accurate time or the BIOS configuration resets to default,
please check the battery.
CAUTION!Do not replace the battery yourself. Please contact a qualified
technician or your retailer.
The computer is provided with a battery-powered real-time
clock circuit. There is a danger of explosion if battery is incor-
rectly replaced. Replace only with same or equivalent type
recommended by the manufacturer. Discard used batteries
according to the manufacturer’s instructions.
Improper installation of VESA mounting can result in serious personal injury! VESA mount installation
should be completed by a professional technician, please contact the service technician or your retailer
if you need this service. The detailed installation procedure is specified in Appendix A.
■
■
■
■
■
■
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment to a power outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution! Any changes or modifications made to the equipment which
are not expressly approved by the relevant standards author-
ity could void your authority to operate the equipment.
List of Accessories
Before installing your Point-of-Care Terminal, ensure that the following materials have been received:
Caution! No user serviceable parts inside, refer servicing to qualified
personnel. Only the accessories indicated on the list of ac-
cessories above have been tested and approved to be used
with the device. It is strongly recommended that only these
accessories be used in conjunction with the specific device.
Otherwise the correct functioning of the device may be com-
promised.
Additional Information and Assistance
Contact your distributor, sales representative, or Advantech’s customer service center for technical
support if you need additional assistance. Please have the following information ready before you call:
Product name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
This equipment is a source of electromagnetic waves. Before use please make sure that there are not
EMI sensitive devices in its surrounding which may otherwise malfunction.
Manufacturer
Advantech Co., Ltd.
No.1, Alley 20, Lane 26, Rueiguang Road Neihu District, Taipei,
Taiwan 11481, R.O.C.
TEL: [phone]
Distributed in Europe by:
Advantech Europe Service Center
Ekkersrijt 5708 Science Park, Eindhoven 5692 EP Son, The Netherlands
Phone: [phone]
Visit the Advantech websites at www.advantech.com or www.advantech.com.tw if you need more
information.
■
■
■
■
■
■
Medical Equipment
With respect to electrical shock,
fire, and mechanical hazards only.
In accordance with UL 60601-1,
CAN/CSA C22.2 No. 601.1 and,
IEC 60601-1
POC-W242 series Point-of-Care Terminal
Accessories for POC-W242
- CD-ROM disc-”Drivers, User’s manual and Utilities”
- Mounting kits and packet of screws
- VESA mounting note x1
- China RoHs note x1
Printed in Netherland April 2014
