Advantech POD-6704 Series User manual

POD-6704 series
Socket 370 Pentium®III/Celeron™
CPU Card with VGA, Ethernet x 4 and
CompactFlash Type II card

POD-6704 User's Manual i i
Copyright Notice
This document is copyrighted, 2002. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, nor for any
infringements upon the rights of third parties which may result from its
use.
Acknowledgements
Award is a trademark of Award Software International, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business
Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
UMC is a trademark of United Microelectronics Corporation.
All other product names or trademarks are properties of their
respective owners.
For more information on this and other Advantech products please
visit our website at: http://www.advantech.com
http://www.advantech.com/epc
For technical support and service for please visit our support website
at: http://www.advantech.com/support
This manual is for the POD-6704 Series Rev. A1
Part No. 200K670411 3rd. Edition
May, 2004

iii Preface and Table of Contents
Packing List
Before installing your board, ensure that the following materials have
been received:
• 1 ea. POD-6704 SBC
• 1 ea. Keyboard/Mouse cable (1700000190)
• 1 ea. COM port cable (1700100250)
• 1 ea. EIDE HDD cable (1701400452)
• 1 ea. Power cable (1703080101)
• 1 ea. Startup Manual
• 1 ea. CD-ROM or disks for utilities, drivers and manual (PDF format)
• 1 ea. VGA cable (1701160101)
• 1 ea. Printer cable (1700260250)
• 1 ea. FDD cable (1701340603)
Note 1: For detailed contents of the POD-6704 series, please refer to the
enclosed CD-ROM or disk (in PDF format).
If any of these items are missing or damaged, contact your distributor
or sales representative immediately.
Optional Devices
• 1759209100 Fan/Heatsink module
• 9689000042 IrDA adapter
• 1700100170 USB cable adapter
• 1703200100 ATX power cable
Model comparison
• POD-6704F-00A1 Socket370 815E SBC with Fast Ethernet (8139C
plus) supports VGA/CFC
• POD-6704F-01A1 Socket370 815E SBC with 4 x Fast Ethernet
(82559) supports VGA/CFC
• POD-6704F-02A1 Socket370 815E SBC with 4 x Fast Ethernet
(82559ER) supports VGA/CFC

POD-6704 User's Manual i v
Contents
Chapter 1 General Information ........................................ 1
1.1 Introduction ................................................................................. 2
1.2 Specifications .............................................................................. 3
1.3 Features ....................................................................................... 5
1.4 Board layout: Dimensions ........................................................... 6
Chapter 2 Installation ......................................................... 7
2.1 Safety Precautions ....................................................................... 8
2.2 Jumpers ....................................................................................... 9
2.3 Connectors ................................................................................. 10
2.3.1 Locating Jumpers ............................................................... 11
2.3.2 Locating Connectors .......................................................... 12
2.4 Setting jumpers ......................................................................... 13
2.4.1 COM1 RIN Function select (J1) ......................................... 14
2.4.2 COM1 External power select (J2) ........................................ 14
2.4.3 COM2 RIN Function select (J3) ......................................... 15
2.4.4 COM2 External power select (J4) ........................................ 15
2.4.5 PCI VIO power select (J5) ................................................... 16
2.4.6 Hardware Reset (J7) ........................................................... 16
2.4.7 CMOS clear function (J8) ................................................... 16
2.4.8 System LED connector (J10) .............................................. 17
2.4.9 CF master/slave select (J11) ............................................... 17
2.4.10 HDD LED connector (J12) ................................................17
2.5.1 RS-232 connector (CN1, CN10) ......................................... 18
2.5.2 Ethernet Configuration .......................................................18
2.5 Installation Caution ................................................................... 19
2.5.3 USB Connector (CN11) ..................................................... 19
2.5.4 Keyboard & PS/2 Mouse Connector (CN13) ....................20
2.5.5 Extra keyboard connector (CN14) ......................................20
2.5.6 Parallel Port Connector (CN15) ...........................................20
2.5.7 Floppy Drive Connector (CN16) ......................................... 20
2.5.8 IrDA Connector (CN17) ..................................................... 21
2.5.9 CPU Fan Power Supply Connector (CN18) ........................21
2.5.10 VGA Display Connector (CN19) ....................................... 21
2.5.11 Digital I/O (CN20) .............................................................21
2.5.12 Primary EIDE Connector (CN21) ....................................... 21
2.5.13 IDE2 connector (CN22) ..................................................... 22
2.5.14 CompactFlash Disk (CN25) ............................................... 23

v Preface and Table of Contents
Contents continued, next page.
2.5.15 ATX power button (CN26) ............................................... 23
2.5.16 ATX Feature Connector (CN27) ....................................... 23
2.5.17 EBX Power Connector (CN28) .......................................... 24
2.5.18 Mini PCI (CN29) ................................................................ 24
2.5.19 System fan (CN30) ............................................................24
2.6 Adding System Memory (DIMM) .............................................. 25
2.6.1 Installing DIMMs ............................................................... 25
2.7 CPU installation and upgrading ............................................... 26
Chapter 3 Award BIOS Setup .......................................... 27
3.1 AWARD BIOS Setup ................................................................ 28
3.1.1 Entering setup ................................................................... 28
3.1.2 Standard CMOS setup ......................................................29
3.1.3 Advanced BIOS Features ..................................................30
3.1.4 Advanced Chipset Features .............................................. 34
3.1.5 Integrated Peripherals ....................................................... 35
3.1.6 Power management setup .................................................. 36
3.1.7 PnP PCI configuration setup ............................................. 37
3.1.8 PC Health Status ................................................................ 38
3.1.9 Frequency/Voltage Control ................................................39
3.1.10 Load Optimized Defaults ................................................. 40
3.1.11 Set Password ................................................................... 40
3.1.12 Save & Exit Setup ............................................................41
3.1.13 Exit Without Saving ......................................................... 41
Chapter 4 AGP SVGA Setup ............................................ 43
4.1 Introduction ............................................................................... 44
4.1.1 Chipset ............................................................................... 44
4.1.2 Display memory .................................................................. 44
4.1.3 Display types ..................................................................... 44
4.1.4 Dual/simultaneous display ................................................. 44
4.2 Installation of SVGA driver ....................................................... 46
4.2.1 Installation for Windows 98 and 2000 ................................ 47
4.2.2 Installation for Windows NT .............................................. 52
4.3 Further information ................................................................... 56
Chapter 5 PCI Bus Ethernet Interface ........................... 57
5.1 Introduction ............................................................................... 58
5.2 Installation of Ethernet driver ................................................... 58
5.2.1 Installation for Windows 98 and 2000 ................................ 59
5.2.2 Installation for Windows NT .............................................. 71
5.3 Further information ................................................................... 86

POD-6704 User's Manual v i
Appendix A Programming the Watchdog Timer ............. 87
Appendix B Filler .............................................................. 91
Appendix C Pin Assignments .......................................... 93
C.1 COM1 RS-232 Serial Port (CN1) ............................................ 94
C.2 Serial port2 (CN10) .................................................................. 95
C.3 LAN LED connectors (CN2,CN3,CN4,CN5) ............................ 96
C.4 LAN RJ45 connectors (CN6, CN7, CN8, CN9) ....................... 97
C.5 USB1/USB2 Connector (CN11) ................................................ 98
C.6 LAN1 box connector (CN12) .................................................... 99
C.7 Keyboard and Mouse Connnector (CN13) .............................. 100
C.8 Extra keyboard (CN14) ........................................................... 100
C.9 Printer Port Connector (CN15) ............................................. 100
C.10 Floppy Drive Connector (CN16) ........................................... 102
C.11 IR Connector (CN17) ............................................................ 102
C.12 CPU Fan Power Connector (CN18) ...................................... 103
C.13 VGA Display Connector (CN19) .......................................... 104
C.14 IDE connector (CN21) ........................................................... 105
C.15 IDE Hard Drive Connector (CN22) ....................................... 106
C.16 CompactFlash Card Connector (CN25) ................................ 107
C.17 ATX Power On/Off button connector (CN26) ...................... 109
C.18 ATX Power Connector (CN27) ............................................. 109
C.19 EBX Power Connector (CN28) ............................................ 109
C.20 System fan power connector (CN30) .................................... 109
Appendix D System Assignments ................................. 111
D.1 System I/O Ports ..................................................................... 112
D.2 DMA Channel Assignments ................................................... 113
D.3 Interrupt Assignments ........................................................... 113
D.4 1st MB Memory Map ............................................................... 114

General Information
This chapter gives background information
on the POD-6704.
Sections include:
• Introduction
• Features
• Specifications
• Board layout and dimensions
CHAPTER
1

2POD-6704 User's Manual
1.1 Introduction
The POD-6704 all-in-one industrial grade package FC-PGA CPU
card uses Intel’s highly acclaimed Celeron® processor or Pentium®
III processor, together with the Intel 815E PCI chipset.
The CPU provides 128/256 KB (or 256/512 KB for Pentium III) on-
CPU L2 cache, eliminating the need for external SRAM chips. It
has two PCI EIDE interfaces for up to four devices, a miniPCI
socket on solder side, and a floppy disk drive interface for up to
two devices. Other features include two RS-232 serial ports
(16C550 UARTs with 16-byte FIFO or compatible), one enhanced
parallel port (supports SPP/EPP/ECP) and two USB (Universal
Serial Bus) ports. The PCI enhanced IDE controller supports Ultra
DMA100, Ultra DMA33 and PIO Mode 3 or 4 operation. This
provides data transfer rates of over 33 MB/sec. System BIOS
supports boot-up from an IDE, CD-ROM, USB devices, and LS-
120.
A backup of CMOS data is stored in the Flash memory, which
protects data even after a battery failure. Also included a 62-level
Watchdog timer which resets the CPU if a program cannot be
executed normally. This enables reliable operation in unattended
environments.
The POD-6704 offers several impressive industrial features such as
VGA (AGP) controller, one DIMM slot for up to 512 MB RAM
memory and four 10/100Base-T Ethernet controllers. In addition,
the POD-6704 series supports a solid state disk (SSD) using a
CompactFlash™ Type II disk that is not as vulnerable to the
hazards of an industrial computing environment. These features
make it an ideal choice for applications that require both high
performance and full functionality.

Chapter 1 General Information
3
1.2 Specifications
Standard SBC functions
•CPU: Socket 370 supports FCPGA for Intel® Pentium III
processors up to 1.26 GHz, and Celeron™ processor up
to 1.2 GHz
•BIOS: Award 256 KB Flash memory,
Supports Plug & Play, APM 1.2
Supports Ethernet Boot ROM
Supports boot from USB device
Supports boot from CD-ROM
Supports boot from LS-120 ZIP™ Drive
Optional Customer icon
•Chipset: Intel® 815E chipset support, FSB 133 MHz
•2nd level cache: 512/256 KB on Pentium III or 256/128 KB on
Celeron™ Processor
•System memory: One 168-pin DIMM socket, supports 64 MB to
512 MB
•PCI IDE interface: Two Enhanced IDE interfaces, support 4 IDE
devices. Channel One supports up to UltraDMA 100. Channel
Two supports PIO mode 3,4 with bus mastering up to 33MB/sec.
•Floppy disk drive interface: Supports up to two FDDs (360 KB/
1.2 MB/720 KB/1.44 MB/2.88 MB)
•Parallel port: One parallel port, supports SPP/EPP/ECP
•Buzzer: One onboard buzzer
•IR port: One 115 kbps IrDA compliant serial infrared port
•Serial ports: 2 serial ports
COM1& COM2: RS-232
•Watchdog timer: 1~255S or 1~255min., which is selective

4POD-6704 User's Manual
VGA Interface
•Chipset: Intel 815E embedded
•Frame buffer: Supports 8/16/32 MB frame buffer with system
memory
•Display type: CRT
•Interface: Direct AGP, Accelerator Graphics Ports 1.0 compliant
•Display mode: CRT display supports up to 1280 x 1024 @ 16 bpp,
1024 x 768 @ 16 bpp
Ethernet controller functions
• Intel 815E Chipset MAC embedded + 82562ET PHY
PCI +3 x 8139C Plus/82559/82559ER Ethernet controller, IEEE
802.3 protocol compatible. Supports 10/100 Mbps Base-T. Fast
Ethernet compatible.
Solid state disk
• Supports CompactFlash™ Type I/II disks
Mechanical and environmental specifications
• Standard Mode Power Consumption
Typical 5.23 A @ 5 V with Pentium III 1.26GHz and 256MB DRAM
Max 6.23A @ +5V, 0.5A @ +12V
•Operating temperature:
0 ~ 60° C (32 ~ 140° F)
•Size: 208 mm x 189.62 mm (8.2” x 7.5”)
•Weight: 0.35kg (weight of total package)

Chapter 1 General Information
5
1.3 Features
• Supports Socket 370 Package: FC-PGA for Intel® Pentium®III/
Celeron™ processor
• CPU supports up to 1.26GHz Pentium III with 512K
• Intel 815E quality chipset supports 133MHz FSB
• Supports CompactFlash Type I/II
• Ideal for network security applicances, firewalls, intrusion
detection systems
• Supports 4x 10/100 Base-T Ethernet connections with onboard
RJ-45 connectors
• Scalable LAN performance with selection of Ethernet controllers:
Intel 82559, 82559ER, or RealTek 8139C Plus.

6POD-6704 User's Manual
B
Figure 1-1: POD-6704 (dimensions)
1.4 Board layout: Dimensions

CHAPTER
2
Installation
This chapter tells how to set up the
POD-6704 hardware. It includes instructions
on setting jumpers, and connecting
peripherals, switches and indicators. Be
sure to read all the safety precautions
before you begin the installation procedure.

2.1 Safety Precautions
Follow these simple precautions to protect yourself from harm and
your PC from damage.
1. To avoid electric shock, always disconnect the power from your
PC chassis before you work on it. Don't touch any components on
the CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card
may damage sensitive electronic components.
3. Always ground yourself to remove any static charge before you touch
your CPU card. Be particularly careful not to touch the chip
connectors. Modern integrated electronic devices, especially CPUs
and memory chips, are extremely sensitive to static electric discharges
and fields. Keep the card in its antistatic packaging when it is not
installed in the PC, and place it on a static dissipative mat when you are
working with it. Wear a grounding wrist strap for continuous
protection.
8POD-6704 User's Manual

Chapter 2 Installation 9
2.2 Jumpers
The POD-6704 has a number of jumpers that allow you to
configure your system to suit your application. The table below
lists the function of each of the board’s jumpers.
Table 2-1: Jumpers
Label Function
J1 COM1 RIN Function select
J2 COM1 Extra power select
J3 COM2 RIN Function select
J4 COM2 Extra power select
J5 PCI VIO select
J7 reset button connector
J8 COMS clear jumper
J10 System LED connector
J11 CF master/slave select
J12 HDD LED connector

2.3 Connectors
On-board connectors link the POD-6704 to external devices such
as hard disk drives, a keyboard, or floppy drives. The table below
lists the function of each of the board’s connectors.
Table 2-2: Connectors
Label Function
CN1 Serial port 1
CN2 LAN1 LED
CN3 LAN4 LED
CN4 LAN3 LED
CN5 LAN2 LED
CN6 LAN1 RJ45
CN7 LAN4 RJ45
CN8 LAN3 RJ45
CN9 LAN2 RJ45
CN10 Serial port 2
CN11 USB
CN12 LAN1 box
CN13 Keyboard and PS2 mouse
CN14 Extra keyboard
CN15 Printer port
CN16 FDD
CN17 IR
CN18 CPU fan
CN19 VGA
CN20 Digital I/O
CN21 IDE1
CN22 IDE2
CN25 CF
CN26 ATX power on/off button
CN27 ATX power suspend 5V & PS_ON signal
CN28 EBX power
CN29 Mini PCI
CN30 System fan

Chapter 2 Installation 11
Figure 2-1: Locating jumpers (component side)
BIOSBIOS
BIOSBIOS
BIOS
2.3.1 Locating Jumpers

12 POD-6704 User's Manual
2.3.2 Locating Connectors
Figure 2-1: Locating connectors

Chapter 2 Installation 13
Open
1
Closed Closed 2-3
1
3
2
Open Closed Closed 2-3
2.4 Setting jumpers
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal clip (often protected
by a plastic cover) that slides over the pins to connect them. To
“close” a jumper, connect the pins with the clip. To “open” a
jumper, remove the clip. Sometimes a jumper will have three pins,
labeled 1, 2, and 3. In this case, you would connect either pins 1
and 2 or 2 and 3.
The jumper settings are schematically depicted in this manual as
follows:
A pair of needle-nose pliers may be helpful when working with
jumpers. Setting switches is slightly different but more simple.
Simply slide the desired switch to the on or off position. In the
example below, the 6 element switch would be. 1:off, 2:on, 3:off,
4:off, 5:off, 6:off.
If you have any doubts about the best hardware configuration for
your application, contact your local distributor or sales
representative.
On
123456
Off

14 POD-6704 User's Manual
2.4.2 COM1 External power select (J2)
The J2 jumper can be set for either of two kinds of power supply,
+12V, and +5V. Set this jumper with pins 1-2 closed for +12V, and
with pins 2-3 closed for +5V.
Table 2-4: COM1 extra powerselect (J2)
+12V +5V
1
1
2.4.1 COM1 RIN Function select (J1)
Short pins 1-2 for RIN; short pins 2-3 for external power.
Table 2-3: COM1 RIN Function select (J1)
RIN external power
1
1
