Advantech PPC-MB-610 Installation and operation manual

PPC-MB-610 Startup Manual 1
Before installation, check to ensure that the following items
are included in the shipment:
1. 1 x PPC-MB-610 mini-ITX motherboard
2. 1 x COM cable (1-to-4 DB9)
3. 1 x SATA cable
4. 1 x PPC-MB-610 startup manual
5. 1 x Warranty card
6. 1 x Thermal grease
7. 14 x COM port screws
8. 2 x M.2 packet screws
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1:  FordetailedPPC-MB-610specications,refer
to the latest product information provided on the
Advantech website (PPC-61X1C model).
Note 2:  AcrobatReaderisrequiredtoviewPDFles.
This software can be downloaded from www.
adobe.com/Products/acrobat/readstep2.html
(Acrobat is a trademark of Adobe).
PPC-MB-610 Mini-ITX Motherboard with Intel® Core™ i7/
i5/i3/Pentium®/Celeron® Processor, DP/VGA, 5 x COM,
6 x USB, Dual LAN, PCIe x16, and M.2 (M Key and E Key)
Startup Manual
1. Insert the memory module into the memory slot at a 45
degree angle, as shown below. Ensure that the gold
ngersofthemodulearefullyinsertedintotheslot.
2. Once inserted, gently press the memory module into
the slot until the tabs snap into place, securing the
module in position.
45°
Installation GuidePacking List
For more information about this or other Advantech
products, visit our website at
http://www.advantech.com
For technical support and service, visit our support
website at
http://support.advantech.com
This manual is for PPC-MB-610, Rev. A2.
Part No. 2043776002
Printed in China
Edition 3
Jan 2021

2 PPC-MB-610 Startup Manual
PPC-MB-610
System
Proces-
sor
i7-8700/
i7-8700T
i5-8500/
i5-8500T
i3-8100/
i3-8100T
Pentium
G5400/
G5400T
Celeron
G4900/
G4900T
i7-9700E/
i7-9700TE
i5-9500E/
i5-9500TE
i3-9100E/
i3-9100TE
Number
of Cores 6/6 6/6 4/4 2/2 2/2 8/8 6/6 4/4
Max
Speed
3.2 GHz
(up to 4.6
GHz)/
2.4 GHz
(up to 4.0
GHz)
3.0 GHz
(up to 4.1
GHz)/
2.1 GHz
(up to 3.5
GHz)
3.6/3.1
GHz
3.7/3.1
GHz
3.1/2.9
GHz
2.6 GHz (up
to 4.4 GHz)/
1.8 GHz (up
to 3.8 GHz)
3.0 GHz
(up to 4.2
GHz)/
2.2 GHz
(up to 3.6
GHz)
3.1 GHz
(up to 3.7
GHz)/
2.2 GHz
(up to 3.2
GHz)
L3 Cache 12/12 MB 9/9 MB 6/6 MB 4/4 MB 2/2 MB 12/12 MB 9/9 MB 6/6 MB
TDP 65/35 W 65/35 W 65/35 W 54/35 W 54/35 W 65/35 W 65/35 W 65/35 W
Chipset Q370
Memory 2 x 260-pin SODIMM DDR4, 2666 MHz, up to 32 GB (non ECC)
Network
(LAN)
2 x 10/100/1000 Mbps Ethernet, 1 x Intel® L219LM (with AMT 12.0 support for i7 and i5 only), 1 x Intel i211
Rear I/O 1 x RS-232/422/485, 1 x RS-232, 1x DisplayPort 1.2, 1 x VGA, 6 x USB 3.1, 1 x Line-out, 1 x Mic-in
Internal
Connector
3 x RS-232, 1 x GPIO (8 x channels), 2 x speakerx, 1 x LED, 2 x USB 2.0, 1 x LVDS, 1 x touch control,
2 x SATA 3.0 ( supports RAID 0, 1), 1 x LPC (supports TPM 2.0)
Watchdog
Timer
255timerintervals,congurableusingsoftware
Expansion
1 x M.2 slot (2280 M key) for storage, 1 x M.2 slot (2230 E key) for wireless modules
1 x PCIe x16 slot for riser cards
Dimensions
(W x H)
170 x 170 mm/6.69 x 6.69 in
Operating
System
Microsoft® Windows 10 (64 bit), Linux
Specications

PPC-MB-610 Startup Manual 3
USB3COM12DP1
VGA1
LAN1_USB1
LAN2_USB1
CN2
AMP1
CN4
PCIEX16
CN9
CN12
DIMMA1
DIMMB1
SYS FAN2
SYS FAN1
CPU FAN1
CN20
JP3
JP4
JP5
CN17
JP2
CN16
JP1JP7
CN21
ATX12V1
CN22
SATA1
SATA2
SPI1
CN6
CN5BAT1JP6
JCMOS1
CPU1
M.2EKey2230
NGFF1
(
M.2 M key2280)
Board Layout: Jumper and Connector Locations

4 PPC-MB-610 Startup Manual
COM12: COM 2 Connector
Pin Denition
(RS-232)
Denition
(RS-422)
Denition
(RS-485)
1DCD TX- TX RX-
2RXD TX+ TX RX+
3TXD RX+
4DTR RX-
5 GND
6 DSR
7RTS
8 CTS
9 RI
CN6: COM 3/4/5 and GPIO Connector
1 COM3_DCD# 2 COM3_DSR#
3 COM3_RXD 4 COM3_RTS#
5 COM3_TXD 6 COM3_CTS#
7 COM3_DTR# 8 COM3_RI#
9 GND 10 GND
11 COM4_DCD# 12 COM4_DSR#
13 COM4_RXD 14 COM4_RTS#
15 COM4_TXD 16 COM4_CTS#
17 COM4_DTR# 18 COM4_RI#
19 GND 20 GND
21 COM5_DCD# 22 COM5_DSR#
23 COM5_RXD 24 COM5_RTS#
25 COM5_TXD 26 COM5_CTS#
27 COM5_DTR# 28 COM5_RI#
29 GND 30 GND
31 GND 32 SIO_GPIO6
33 SIO_GPIO4 34 SIO_GPIO2
35 SIO_GPIO0 36 SIO_GPIO7
37 SIO_GPIO5 38 SIO_GPIO3
39 SIO_GPIO1 40 +V5_DUAL
The PPC-MB-610 motherboard features a number of
jumpersthatallowuserstocongurethesystemaccording
tospecicapplications.Thefunctionsofeachjumperand
connector are listed in the table below.
Connector and Headers
Connectors and Headers List
Label Function
CN2 Mic-In/Line-Out connector
LAN2_USB1 RJ45 + USB 3.1 stack connector
LAN1_USB1 RJ45 + USB 3.1 stack connector
VGA1 VGA display connector
DP1 DisplayPort connector
COM12 COM 1/2 connector
USB3 2 x USB 3.1 connector
ATX12v1 ATX 12V power supply connector
CN21 ATX power supply connector
CN5 Power button connector
CN6 COM 3/4/5 and GPIO connector
BAT1 Battery connector
SPI1 SPIBIOSashsocket
CN16 Touchscreen connector
CN17 LVDS panel connector
CN20 LVDS backlight inverter power connector
Sysfan1 ~ 2 System fan power connector
CPUFAN1 CPU fan power connector
SATA1 ~ 2 SATA signal connector
CN4 Power LED connector
CN9/CN12 2 x USB 2.0 pin header
PCIEX16_1 PCIe x16 slot connector
AMP1 Audioamplieroutputconnector
DIMMA1/
DIMMB1 DDR4 SODIMM socket
CPU1 CPU socket
M.2_2 M.2 E key
NGFF1 M.2 M key
Jumpers and Connectors Jumpers and Connectors (Cont.)

PPC-MB-610 Startup Manual 5
CN16: Touch Connector
Pin Denition
1 Y+
2 X+
3 SENSE
4Y-
5 X-
Sysfan 1 ~ 2: System Fan Power Connector
Pin Denition
1 GND
2 POWER
3 SPEED
4 PWM
CPUFAN1: CPU Fan Power Connector
Pin Denition
1 GND
2 POWER
3 SPEED
4 PWM
CN4: Power LED Connector
Pin Denition
1 +V5_DUAL
2 +V5
3 GND
4 GND
AMP1: Audio Amplier Output Connector
Pin Denition
1 SPK L-
2 SPK L+
3 SPK R+
4 SPK R-
Jumpers and Connectors (Cont.) Jumpers and Connectors (Cont.)
Jumper Settings
Jumper List
Jumper Function
JP1 ATX/AT select
JCMOS1 RTC select
JP2 Touch power select
JP3 LCD power select
JP4 Enable power select
JP5 LVDS PWM power select
JP6 COM pin 9 power select (COM 1 and 2)
JP7 LVDS resolution select
ATX/AT Select (JP1)
(1-2) P1 AT
(2-3) P2 ATX (default)
P1 P2
RTC Select (Jcmos1)
(1-2) P3 Normal (default)
(2-3) P4 Clear CMOS
P3 P4

6 PPC-MB-610 Startup Manual
Jumpers and Connectors (Cont.)
DI/O Pin Denition (DB9)
Pin Denition
1 GND
2 GPIO4
3 GPIO0
4 GPIO5
5 GPIO1
6 GPIO6
7 GPIO2
8 GPIO7
9 GPIO3
Touch Power Select (JP2)
(1-2) P5 Connect resistive touchscreen (default)
NC P6 Disconnect resistive touchscreen
P5 P6
LCD Power Select (JP3)
(1-2) P7 +V5
(2-3) P8 +V3.3 (default)
P7 P8
Enable Power Select (JP4)
(1-2) P9 +V5
(2-3) P10 +V3.3 (default)
P9 P10
LVDS PWM Power Select (JP5)
(1-2) P11 +V5
(2-3) P12 +V3.3 (default)
P11 P12
COM Ring Select (JP6)
(1-3)/(2-4)
P13/P14
COM 2/1 ring (default)
(3-5)/(4-6)
P15/P16
COM 2/1 5V
(7-9)/(8-10)
P17/P18
COM 2/1 12V
P13 P14
P15 P16
P17 P18
LVDS Resolution Select (JP7)
(1-2)/(5-6)/(7-8)
P19
1024 x 768 (24 bit)
(for PPC-6151C chassis)
(1-2)/(7-8)P20 1280 x 1024 (24 bit)
(for PPC-6171C chassis)
(3-4)/(7-8) P21 1280 x 1024 (24 bit)
(for PPC-6191C chassis)
P19 P20 P21
Jumpers and Connectors (Cont.)
