Advantech PCIE-1730H-AE User manual

User Manual
PCIE-1730/1730H
32-Ch Isolated Digital I/O with
Digital Filter PCI Express Card

PCIE-1730/1730H User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to improve the products described in this manual at any time without notice. No part
of this manual may be reproduced, copied, translated, or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd. The infor-
mation provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
of the rights of third parties that may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers are billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you believe that your product is defective, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any messages displayed onscreen when the prob-
lem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandize authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package. Then ship the
package prepaid to your dealer.
Part No. 2001173012 Edition 3
Printed in Taiwan August 2020

iii PCIE-1730/1730H User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
type of cable is available from Advantech. Test conditions for passing include the
equipment being operated within an industrial enclosure. In order to protect the prod-
uct from damage caused by electrostatic discharge (ESD) and electromagnetic inter-
ference (EMI) leakage, we strongly recommend the use of CE-compliant industrial
enclosure products. Please contact your local supplier for ordering information.
FCC Class B
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, users are encouraged to try to correct the interference by
implementing one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult your dealer or an experienced radio/TV technician for help.
Technical Support and Assistance
1. Visit the Advantech website at www.advantech.com/support to obtain the latest
product information.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before calling:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

PCIE-1730/1730H User Manual iv
Warnings, Cautions, and Notes
Document Feedback
To assist us with improving this manual, we welcome all comments and constructive
criticism. Please send all feedback in writing to [email protected]
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from the PC chassis
before manual handling. Do not touch any components on the system board,
CPU, or adapter cards while the PC is powered on.
Disconnect all power before making any configuration changes. The sudden
rush of power after connecting a jumper or installing a card may damage sensi-
tive electronic components.
Prevent electrostatic discharge by wearing a grounding strap at all times and
storing the equipment in an anti-static bag until installation.
Warning! Warnings indicate conditions that if not observed can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. For example,
“Batteries are at risk of exploding if incorrectly installed. Do not attempt
to recharge, force open, or heat the battery. Replace the battery only
with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.”

v PCIE-1730/1730H User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Retain the user manual for future reference.
3. Disconnect the equipment from all power outlets before cleaning. Use only a
damp cloth for cleaning. Do not use liquid or spray detergents.
4. For pluggable equipment, the power outlet socket must be located near the
equipment and easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
8. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet.
9. Position the power cord away from high-traffic areas. Do not place anything over
the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient over voltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following occurs, have the equipment checked by service person-
nel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment is malfunctioning or does not operate according to the user
manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. Do not leave the equipment in an environment with a storage temperature of
below -20 °C (-4 °F) or above 60 °C (140 °F) as this can damage the compo-
nents. The equipment should be kept in a controlled environment.
16. CAUTION: Batteries are at risk of exploding if incorrectly replaced. Replace only
with the same or equivalent type as recommended by the manufacturer. Discard
used batteries according to the manufacturer's instructions.
17. In accordance with IEC 704-1:1982 specifications, the sound pressure level at
the operator's position does not exceed 70 dB (A).
DISCLAIMER: These instructions are provided in accordance with the IEC 704-1
specifications. Advantech disclaims all responsibility for the accuracy of any state-
ments contained herein.

PCIE-1730/1730H User Manual vi

vii PCIE-1730/1730H User Manual
Contents
Chapter 1 Overview...............................................1
1.1 Introduction ............................................................................................... 2
1.2 Features .................................................................................................... 2
1.3 Software Overview .................................................................................... 3
1.4 Accessories............................................................................................... 3
1.5 Installation Guide ...................................................................................... 4
1.6 Product Applications ................................................................................. 4
Chapter 2 Hardware Installation ..........................5
2.1 Unpacking Instructions.............................................................................. 6
2.2 Driver Installation ...................................................................................... 7
2.3 Hardware Installation ................................................................................ 7
Figure 2.1 Device Manager ......................................................... 8
Chapter 3 Signal Connections .............................9
3.1 Overview ................................................................................................. 10
3.2 Switch and Jumper Settings.................................................................... 10
Figure 3.1 Card Connectors, Jumpers, and Switches ............... 10
Table 3.1: Jumper Function Descriptions .................................. 10
Table 3.2: Board ID Settings (SW1) .......................................... 10
3.3 Signal Connections ................................................................................. 11
Figure 3.2 TTL-Level DI/O Connection...................................... 12
Figure 3.3 Open/Short Connection ............................................ 12
Figure 3.4 Isolated DI Connection ............................................. 13
Figure 3.5 Isolated Digital Output Connection ........................... 13
Appendix A Specifications ....................................15
A.1 Specifications.......................................................................................... 16
A.1.1 Isolated Digital Input ................................................................... 16
A.1.2 Isolated Digital Output................................................................. 16
A.1.3 Non-Isolated Digital Input/Output................................................ 16
A.1.4 General ....................................................................................... 17
A.1.5 Digital Filter Time ........................................................................ 17
Appendix B Block Diagram ...................................19
B.1 PCIE-1730 Series Diagram..................................................................... 20

PCIE-1730/1730H User Manual viii

Chapter 1
1Overview

PCIE-1730/1730H User Manual 2
1.1 Introduction
Advantech’s PCIE-1730 series are 32-channel isolated digital I/O cards that support
PCI Express bus. The provision of isolated digital input channels make these cards
ideal for environments with noise or floating potentials.
The following sections of this chapter provide information regarding the features,
installation process, and relevant software and accessories for the PCIE-1730 series
cards.
1.2 Features
PCIE-1730/1730H
32 isolated DI/O channels
32 TTL DI/O channels
High output driving capacity with 500 mA per channel (maximum)
High-voltage isolation on isolated I/O channels (2,500 VDC)
Interrupt handling capability for all DI and IDI channels (PCIE-1730 only sup-
ports interrupt signals on 4 channels)
Two 20-pin connectors for isolated DI/O channels and two 20-pin connectors for
TTL DI/O channels
D-type connector for isolated input and output channels
High ESD protection (2,000 VDC)
High over-voltage protection (70 VDC)
Wide input range (10 ~ 30 VDC)
Board ID to identify specific cards when multiple devices are installed
16 isolated and TTL digital input channels with digital filter (PCIE-1750H only)
Robust Protection
The PCIE-1730 series cards’ digital input channels feature robust isolation protection
for industrial, laboratory, and automation applications. The channels can withstand
voltages of up to 2,500 VDC, thereby minimizing the risk of accidental damage to the
system components. If connected to an external input source with surge protection,
PCIE-1730 cards can offer up to a maximum of 2,000 VDC ESD protection. Even with
an input voltage of 70 VDC, the PCIE-1730 series cards can still function, albeit only
for a short period of time.
Wide Input Range
The PCIE-1730 series cards support a wide input voltage range of 10 ~ 30 VDC, mak-
ing them suitable for most industrial applications that require a 12 VDC or 24 VDC
input voltage.
Plug-and-Play Functionality
PCIE-1730 cards feature plug-and-play functionality and comply with PCI Express
Specifications, Revision 1.0. The benefit of this is that there is no need to set jumpers
or DIP switches during card installation. Instead, all bus-related settings, such as the
base I/O address and interrupt signaling, are automatically configured because of the
plug-and-play functionality, greatly streamlining installation.

3 PCIE-1730/1730H User Manual
Chapter 1 Overview
Board ID
The PCIE-1730 series card are equipped with a built-in DIP switch for setting a Board
ID for each card when multiple cards are installed on the same PC chassis. This
allows users to easily identify and access each card during hardware configuration
and software programming.
Reset Protection
After a hot reset (i.e., when the system is restarted with interrupting the power), the
PCIE-1730 series card can either retain the output values of each channel, or return
to the default configuration of open status depending on the on-board jumper set-
tings. This function protects the system from incorrect operations during unexpected
system resets.
1.3 Software Overview
Advantech offers device drivers, software development kits, third-party driver sup-
port, and application software that enable customers to fully exploit the functions of
the PCIE-1730 series card. These software packages are provided on the accompa-
nying CD-ROM and available for download from the Advantech website (http://
www.advantech.com).
1.4 Accessories
The PCIE-1730 series cards can be combined with a range of optional accessories
for enhanced operation.
Wiring Cable
Advantech’s PCL-10137 shielded cable is specially designed for PCIE-1730 series
cards and provides high noise resistance. For enhanced signal quality, the signal
wires are twisted into twisted-pair cables, reducing cross-talk and noise from other
signal sources. Furthermore, the digital lines are separately sheathed and shielded to
neutralize EMI/EMC problems.
Wiring Boards
Advantech’s ADAM-3937 is a 37-pin D-type wiring terminal module for DIN-rail
mounting. This terminal module can be connected to Advantech DAQ cards and pro-
vides easy access to individual pin connections for the PCIE-1730 series.
The PCLD-880 is a universal screw terminal board that can be integrated with any
Advantech DAQ card that features a 37-pin D-type connector.
Note! For detailed specifications of the PCIE-1730 series, refer to Appendix A,
Specifications.

PCIE-1730/1730H User Manual 4
1.5 Installation Guide
Before installing the PCIE-1730 series card, please ensure you have the following
necessary components:
1 x PCIE-1730 series card
1 x PCIE-1730 series user manual
1 x Advantech DAQNavi driver (included in the CD-ROM)
1 x Personal computer or workstation with a PCI-Express slot
Additional optional components are available for enhanced operation.
1 x Wiring cable PCL-10137 (optional)
1 x Wiring board PCLD-880, ADAM-3937 (optional)
Advantech Navigator Utility via DAQNavi software
After obtaining all necessary components and additional accessories for enhanced
operation, users can begin installing the PCIE-1730 series card.
1.6 Product Applications
Industrial ON/OFF control
Switch status sensing
BCD interfacing
Digital I/O control
Industrial and laboratory automation
Research and education

Chapter 2
2Hardware Installation

PCIE-1730/1730H User Manual 6
This chapter provides unpacking instructions, an item checklist, and step-by-step
procedures for driver and card installation.
2.1 Unpacking Instructions
Upon receiving your product, please check the contents to ensure that the following
items have been included:
1 x PCIE-1730 series card
1 x Accompanying CD-ROM
1 x PCIE-1730 series user manual
The PCIE-1730 series cards contain electronic components and integrated circuits
that are vulnerable to ESD. Before removing the card from the anti-static bag, take
the following precautions to prevent potential ESD damage:
Touch any metal part of the computer chassis with your hand to discharge any
static electricity accumulated in your body. Alternatively wear a grounding strap
at all times.
Touch the anti-static bag to a metal part of the computer chassis before opening
and removing components.
When removing the card from the anti-static bag, hold the card by the metal
bracket only.
After retrieving the card, first inspect the card for any external signs of damage (loose
or damaged components etc.). If the card is visibly damaged, please notify the
Advantech service department or your local sales representative immediately. Do not
install a damaged card in your system.
Users should also pay extra attention to the following advice to ensure proper instal-
lation:
Avoid physical contact with materials that may hold static electricity, such as
plastic, vinyl, and styrofoam.
When handling the card, hold it only by its edges. Do not touch the exposed
metal pins of the connector or the electronic components.
Note! Retain the anti-static bag for future use. The bag may be needed to
store the card during hardware upgrades or when moving the PC to
another location.

7 PCIE-1730/1730H User Manual
Chapter 2 Hardware Installation
2.2 Driver Installation
To ensure problem-free installation, all relevant drivers should be installed before
installing the PCIE-1730 series card. The Advantech device drivers for the PCIE-
1730 series card are provided on the accompanying CD-ROM shipped with your
product.
2.3 Hardware Installation
After driver installation, the PCIE-1730 series card can be installed via a PCI Express
slot. Follow the steps below for card installation.
1. Power off the computer and unplug the power cord and any connected cables.
(Note: Always verify that the computer is turned off and no power is flowing into
the system before installing or removing any components.)
2. Remove the computer cover.
3. Remove the slot cover on the back panel of the computer.
4. Touch any metal surface of the computer to neutralize any static electricity that
might be in your body.
5. Hold the PCIE-1730 series card by its edges and carefully align it with a PCI
Express slot. Insert and press firmly to install the card. Do not use excessive
force to avoid damaging the card.
6. Fasten the bracket of the PCI Express card on the back panel of the computer.
7. Connect any accessories to the PCI Express card.
8. Replace the cover of the computer chassis. Reconnect any cables that were
removed in Step 1.
9. Plug in the power cord and turn on the computer.
Note! Ensure that relevant drivers have been installed before attempting card
installation.
Note! After the card is installed, users can configure the device using the
Advantech Navigator Utility program automatically installed during driver
setup. Comprehensive device installation procedures should include
device setup, configuration, and testing. The following sections provide
instructions for setting up, configuring, and testing your device.

PCIE-1730/1730H User Manual 8
After completing the card installation procedures, users can verify whether the PCIE-
1730 series card is correctly installed using the Device Manager, as explained below.
1. Access the Device Manager via the Control Panel/System/Device Manager.
2. The PCIE-1730 series card should be included in the list of installed devices, as
show in Figure 2.1.
Figure 2.1 Device Manager
After the Advantech DAQNavi driver and PCIE-1730 series card are properly
installed, users can configure the system using the Advantech Navigator Utility.
Note! If your card is correctly installed, the card name should be included in
the list of installed devices on the Device Manager tab. If the device is
listed but marked with an exclamation mark “!”, this means the card was
not correctly installed. In this event, remove the card from the Device
Manager list by clicking on the device and selecting the Remove option.
Then perform the device installation process again.

Chapter 3
3Signal Connections

PCIE-1730/1730H User Manual 10
3.1 Overview
Maintaining signal connections is crucial for ensuring applications are sending and
receiving data correctly. Good signal connections can prevent unnecessary and
costly data losses and hardware damage. This chapter provides information that
explains how to connect input and output signals to the PCIE-1730 series card via
the I/O connector.
3.2 Switch and Jumper Settings
Figure 3.1 Card Connectors, Jumpers, and Switches
Note: 1 = On; 0 = Off. The default setting is 0.
Table 3.1: Jumper Function Descriptions
Name Function Description
JP2 (1, 2 short) Output channels will keep last status after system reset.
JP2 (2,3 short) Output channels will set their values to Low after system reset (default).
Table 3.2: Board ID Settings (SW1)
ID3 ID2 ID1 ID0 Board ID
1 1 1 1 0
1 1 1 0 1
1 1 0 1 2
1 1 0 0 3
1 0 1 1 4
1 0 1 0 5
1 0 0 1 6
1 0 0 0 7
0 1 1 1 8
0 1 1 0 9
0 1 0 1 10
0 1 0 0 11
0 0 1 1 12
0 0 1 0 13
0 0 0 1 14
0 0 0 0 15

11 PCIE-1730/1730H User Manual
Chapter 3 Signal Connections
3.3 Signal Connections
PCIE-1730 Series Pin Assignments
CN1 CN2
CN3 CN4
CN5
CN6
IDO 0 1 2 IDO 1 IDI 0 1 2 IDI 1
IDO 2 3 4 IDO 3 IDI 2 3 4 IDI 3
IDO 4 5 6 IDO 5 IDI 4 5 6 IDI 5
IDO 6 7 8 IDO 7 IDI 6 7 8 IDI 7
IDO 8 9 10 IDO 9 IDI 8 9 10 IDI 9
IDO 10 11 12 IDO 11 IDI 10 11 12 IDI 11
IDO 12 13 14 IDO 13 IDI 12 13 14 IDI 13
IDO 14 15 16 IDO 15 IDI 14 15 16 IDI 15
EGND 17 18 EGND ECOM0 17 18 ECOM1
NC 19 20 NC ECOM0 19 20 ECOM1
DO 0 1 2 DO 1 DI 0 1 2 DI 1
DO 2 3 4 DO 3 DI 2 3 4 DI 3
DO 4 5 6 DO 5 DI 4 5 6 DI 5
DO 6 7 8 DO 7 DI 6 7 8 DI 7
DO 8 9 10 DO 9 DI 8 9 10 DI 9
DO 10 11 12 DO 11 DI 10 11 12 DI 11
DO 12 13 14 DO 13 DI 12 13 14 DI 13
DO 14 15 16 DO 15 DI 14 15 16 DI 15
GND 17 18 GND GND 17 18 GND
NC 19 20 NC NC 19 20 NC
EGND 1 2 EGND
Pin Description
IDI 0 1 20 IDI 1
IDIn (n = 0 ~ 15): IDI 2 2 21 IDI 3
Isolated digital input IDI 4 3 22 IDI 5
IDOn (n = 0 ~ 15): IDI 6 4 23 IDI 7
Isolated digital output IDI 8 5 24 IDI 9
ECOMn (n = 0 ~ 1): IDI 10 6 25 IDI 11
External common VCC/GND of IDI IDI 12 7 26 IDI 13
PCOM (n = 0 ~ 1): IDI 14 8 27 IDI 15
Free wheeling common diode for IDO ECOM0 9 28 ECOM1
EGND: PCOM0 10 29 EGND
External ground for IDO IDO 0 11 30 IDO 1
NC: IDO 2 12 31 IDO 3
Not connected IDO 4 13 32 IDO 5
IDO 6 14 33 IDO 7
DIn (n = 0 ~ 15): IDO 8 15 34 IDO 9
TTL digital input IDO 10 16 35 IDO 11
DOn (n = 0 ~ 15): IDO 12 17 36 IDO 13
TTL digital output IDO 14 18 37 IDO 15
GND: PCOM1 19
TTL digital ground

PCIE-1730/1730H User Manual 12
TTL-Level Digital Input/Output
The PCIE-1730 series cards have 16 TTL-level digital inputs and 16 TTL-level digital
outputs. The connection configuration for exchange digital signals with other TTL
devices is shown in Figure 3.2.
Figure 3.2 TTL-Level DI/O Connection
The connection configuration for receiving an OPEN/SHORT signal from a switch or
relay is shown in Figure 3.3.
Figure 3.3 Open/Short Connection
