Advantech ASMB-920IR Installation and operation manual

ASMB-920IR Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 ASMB-920IR Startup Manual
• 1 Driver CD (user’s manual is included)
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
ASMB-920IR Intel® Xeon® E5-2600 series dual 2011 Sock-
et EATX Server Board with 2 PCIe x16 Expansion Slots
Startup Manual
Standard SBC Functions
• CPU: LGA2011 Intel ® Xeon® E5-2600 series
• BIOS: AMI 64 Mb SPI BIOS
• Chipset: Intel® C600
• System memory: 8* DDR3 REG/ECC/Non-ECC
1066/1333/1600 unbuffered DIMM, Max. 128 GB
Note: Due to the inherent limitations of PC architecture,
the system may not fully detect 128 GB RAM
when 128 GB RAM is installed.
• SATA Interface: 4 SATA2 3 Gb/s ports, 2 SATA3 6Gb/s,
supports Intel Matrix Storage (for Windows only) software
RAID 0, 1, 10 & 5.
• SAS Interface(ASMB-920IR sku only): 8 SAS2 6Gb/s
ports,supports RAID 0, 1, 1E.
• Serial ports: Two serial ports, only support RS-232
• Keyboard/mouse connector: Supports standard PS/2
keyboard and mouse
• Watchdog timer: 255 level timer intervals
• USB 2.0: Supports up to eleven USB 2.0 ports (1* Type-
A)
VGA Interface
• Chipset: Aspeed AST2300
• Display Memory: 64 MB
• Resolution: Supports VGA up to resolution 1920 x 1200
@ 60 Hz refresh rate
Ethernet interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1:Intel 82579LM; LAN2: Intel 82574L;
LAN3: Realtek 8201EL(10/100Mbps for IPMI,ASMB-
920IR sku only)
Mechanical and Environmental
• Dmensions (L x W): 330 x 304 mm (13” x 12”)
• Power supply voltage: +3.3 V, +5 V, ±12 V, +5 Vsb
• Power consumption(Main board only, excluded IO
device): Max. load: +3.3 V @ 13.69 A, +5 V@ 8.77 A, +12
V @ 11.48 A, +12 V(8P1) @ 22 A, +12 V(8P2) @ 22 A,
+5 Vsb@ 2 A
• Operating temperature: 0 ~ 40° C (depending on CPU)
• Weight: 1.1 kg (weight of board)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the ASMB-920I series Rev. A1
Part No. 2002920I10
Print in China
1st Edition,
Jan. 2012
All manuals and user guides at all-guides.com
all-guides.com

2 ASMB-920IR Startup Manual
Jumper list
Label Function
JCMOS1 CMOS clear
JME1 ME update
JWDT1 Watch dog selection
JCMOS1/JME1: CMOS clear/ME update function
Closed pins
Result
1-2 Keep CMOS data/Disable ME update*
2-3
Clear CMOS data/Enable ME update
*: Default
JWDT1: Watchdog timer function selection
Pins
Result
1-2 Enable*
2-3
Disable
*: Default
**Note: To enable WDT function must to be set as Enable
both in Jumper & BIOS setting.
Enable Disable
1 2 3
1 2 3
Installation Note
JFP1
Pin.1 #PWR_SW
Pin.3 GND
Pin.2 #RST_SW
Pin.4 GND
*Power button pin is located in Pin 1 & 3 of front panel
connector
The board has a number of jumpers that allow you to con-
figure your system to suit your application. The table below
lists the function of each jumper and connector.
Connector list
Label Function
ATX24P_P1 ATX 24 Pin main power con-
nector
ATX8P_P0 Processor power connector(for
CPU0)
ATX8P_P1 Processor power connector(for
CPU1)
SATA0~SATA5 Serial ATA0~5
USB45,USB67,
USB89 USB port 4,5,6,7,8,9 (Header)
USB01,USB23
USB10 USB port 0,1,2,3,10(type A)
PCIE_PME1 PCIE x16 slot (For PME)
PCIEX16_SLOT6,
PCIEX16_SLOT7 PCIE x16 slot
DIMMA1 ~ DIMMH1 DDR3 slot
CPUFAN0,CPUFAN1 CPU FAN connector
SYSFAN0,SYSFAN1,
SYSFAN2 System FAN connector
LAN1,LAN2 LAN connector
BMC LAN1 LAN connector for IPMI
VGA_COM1 VGA+COM connector
KBMS1 Keyboard and mouse connector
KBMS2 External keyboard and mouse
connector(6 pin)
BIOS_SKT1 BIOS SPI ROM
LANLED1 LAN LED extension connector
SMBUS1 Front panel SMBus header
IPMI1 IPMI header
SATA_SGPIO_1 SATA SGPIO header
SAS_SGPIO_1,
SAS_SGPIO_2 SAS SGPIO header
AUDIO1 Audio header
COM2 Serial port: RS-232
JFP1 Front panel header
Jumpers and Connectors
Keep CMOS data/Disable ME update Clear CMOS data/Enable ME update
1 2 3
1 2 3
Jumpers and Connectors
All manuals and user guides at all-guides.com

ASMB-920IR Startup Manual 3
The CD disc contains a driver installer program that will lead
you through the installation of various device drivers needed
to take full advantage of your motherboard.
The computer is supplied with a battery-powered realtime
clock circuit. There is a danger of explosion if battery is
incorrectly replaced. Replace only with same or equivalent
type recommended by the manufacturer. Discard used bat-
teries according to manufacturer’s instructions.
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion.
Software Installation Declaration of Conformity
Board Layout: Jumper and Connector Locations
Board Layout
PCIEx16_SLOT6
PCIEx16_SLOT7
DIMM E1
DIMM F1
CPU Fan1
IPMI LAN1
LAN1_USB01
LAN2_USB23
COM1 + VGA1
KBMS1
KBMS2
ATX8P_P1
DIMM H1
DIMM G1
CPU1
PMBUS1
ATX 24P_P1
CPU0
DIMM A1
DIMM B1
ATX 8P_P0
CPU Fan0
DIMM C1
DIMM D1
SYS FAN0
SYS FAN1
SMBUS1
SAS_SGPIO_2
SYS FAN2
8 SAS II
2 SATA III
4 SATA II
USB4_5
USB6_7
USB8_9
USB10
LAN LED1
JFP1
SATA _SGPIO1
PCIE_PME1
JCMOS1
LPC1
IPMI1
COM2
AUDIO 1
SAS_
SGPIO1
GPIO1
JME1
