Advantech ASMB-975 Series User manual

User Manual
ASMB-975 Series
Dual LGA 3647-P0 Intel Xeon®
Server Board with 12 DDR4, 4
PCIe x16, 14 SATA3, 8 USB3.0,
Dual 10GbE, IPMI

ASMB-975 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2018
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel® Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft® Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2001097511 Edition 2
August 2018

iii ASMB-975 User Manual
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for the labo-
ratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name Advantech has come to be
known. Your satisfaction is our primary concern. Here is a guide to Advantech’s cus-
tomer services. To ensure you get the full benefit of our services, please follow the
instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are
normally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your Advantech products. In fact, most problems
reported are minor and are easily solved over the phone.
In addition, free technical support is available from Advantech engineers every
business day. We are always ready to give advice on application requirements or
specific information on the installation and operation of any of our products.
Declaration of Conformity
FCC
This device complies with the requirements in part 15 of the FCC rules:
Operation is subject to the following two conditions:
This device may not cause harmful interference
This device must accept any interference received, including interference that
may cause undesired operation.
Note! This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These lim-
its are designed to provide reasonable protection against harmful inter-
ference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harm-
ful interference in which case the user will be required to correct the
interference at his own expense.

ASMB-975 User Manual iv
Initial Inspection
Before installing motherboard, please make sure that the following materials have
been shipped:
1 x ASMB-975 Server Board
1 x ASMB-975 Startup Manual
1 x Driver CD
2 x Serial ATA HDD data cables
1 x I/O port bracket
2 x CPU power cable (8P)
2 x SATA power cable
1 x Warranty card
2 x Heatsink clip for CPU
If any of these items are missing or damaged, contact distributor or sales representa-
tive immediately. We have carefully inspected the ASMB-975 mechanically and elec-
trically before shipment. It should be free of marks and scratches and in perfect
working order upon receipt. When unpacking the ASMB-975, check it for signs of
shipping damage. (For example, damaged box, scratches, dents, etc.) If it is dam-
aged or it fails to meet the specifications, notify our service department or local sales
representative immediately. Also notify the carrier. Retain the shipping carton and
packing material for inspection by the carrier. After inspection, we will make arrange-
ments to repair or replace the unit.
Order Information
Part Number Chipset Memory GbE/10GbE LAN IPMI VGA Chip
ASMB-975-00A1 C621 DDR4 RDIMM 2/- - AST 2510
ASMB-975I-00A1 C621 DDR4 RDIMM 2/- Yes AST 2500
ASMB-975T2-00A1 C622 DDR4 RDIMM 2/2 Yes AST 2500

v ASMB-975 User Manual
Contents
Chapter 1 Overview...............................................1
1.1 Introduction ............................................................................................... 2
1.2 Features .................................................................................................... 2
1.3 Specifications ............................................................................................ 3
Table 1.1: Specifications ............................................................. 3
1.4 Board Layout, Jumpers and Connectors................................................... 5
Figure 1.1 Board Layout .............................................................. 5
Figure 1.2 Rear I/O of full SKU .................................................... 5
Table 1.2: Onboard LAN LED Color Definition ............................ 6
Table 1.3: Onboard LAN LED Color Definition ............................ 6
Table 1.4: Jumpers...................................................................... 6
Table 1.5: Connectors ................................................................. 7
Table 1.6: Onboard LED.............................................................. 8
1.5 Block Diagram........................................................................................... 9
Figure 1.3 Block Diagram ............................................................ 9
1.6 System Memory ........................................................................................ 9
1.7 Memory Installation Procedures.............................................................. 10
1.8 Processor Installation.............................................................................. 11
Chapter 2 Connections......................................13
2.1 Introduction ............................................................................................. 14
2.2 USB Ports (USB1~11)............................................................................. 14
2.3 LAN Ports (LAN1_2, LAN3_4) ................................................................ 15
2.4 VGA Connector (VGA1) .......................................................................... 15
2.5 Serial Ports (COM1~2)............................................................................ 16
2.6 PS2 Keyboard and Mouse Connectors (KBMS2) ................................... 16
2.7 CPU Fan Connector (CPUFAN0~1)........................................................ 17
Table 2.1: CPU FAN Pin Definition............................................ 17
2.8 System Fan Connector (SYSFAN0~7).................................................... 18
Table 2.2: SYS FAN Pin Definition ............................................ 18
2.9 Front Panel Connector (JFP1) ................................................................ 19
2.9.1 Power LED (JFP3) ...................................................................... 19
Table 2.3: ATX Power Supply LED Status ................................ 19
2.9.2 External Speaker (JFP2 pins 1, 4, 7, 10).................................... 19
2.9.3 HDD LED Connector (JFP1 Pins 2 & 5) ..................................... 20
2.9.4 Reset Connector (JFP1 Pins 9 & 12).......................................... 20
2.9.5 Case Open (JCASE1)................................................................. 20
2.10 SATA SGPIO (SGPIO1).......................................................................... 21
2.11 Front Panel LAN Indicator Connector (LANLED1).................................. 22
2.12 SATA and M.2 Connector (SATA0~7,SSATA0~3,SSATA4~5 as M2_2242)
22
2.13 PCIe Expansion Slots ............................................................................. 23
2.14 Auxiliary Power Connector (ATXPWR1/ATX12V1/ATX12V2) ................ 24
2.15 HD Audio Interface Connector (HDAUD1) .............................................. 25
2.16 LPC Connector (LPC1) for Optional TPM Module .................................. 26
2.17 Clear CMOS Connector (JCMOS1, JME1) ............................................. 27
2.18 PMBUS Connector (PMBUS1)................................................................ 27
2.19 Front Panel SMBUS Connector (SMBUS1) ............................................ 28
2.20 IPMI Module Connector (BMC_CN1 & BMC_CN2) ................................ 28
2.21 VOLT1 Connector (VOLT1) .................................................................... 29
2.22 GPIO Connector (GPIO1) ....................................................................... 29

ASMB-975 User Manual vi
Chapter 3 AMI BIOS............................................ 31
3.1 Introduction ............................................................................................. 32
3.2 BIOS Setup ............................................................................................. 33
3.2.1 Main Menu .................................................................................. 33
3.2.2 Advanced BIOS Features Setup................................................. 34
3.2.3 Platform Configuration ................................................................ 53
3.2.4 Socket Configuration .................................................................. 63
3.2.5 Server Management ................................................................... 82
3.2.6 Security....................................................................................... 85
3.2.7 Boot ............................................................................................ 87
3.2.8 Save & Exit ................................................................................. 88
Chapter 4 Chipset Software Installation Utility 91
4.1 Before Beginning .................................................................................... 92
4.2 Introduction ............................................................................................. 92
4.2.1 Main Menu .................................................................................. 92
4.3 Windows 10/ Windows server 2012 R2 & 2016...................................... 93
Chapter 5 Graphic Setup ................................... 95
5.1 Introduction ............................................................................................. 96
5.2 Windows Series Driver Setup ................................................................. 96
Chapter 6 LAN Configuration & USB 3.0.......... 97
6.1 LAN Configuration................................................................................... 98
6.1.1 Introduction ................................................................................. 98
6.1.2 Features...................................................................................... 98
6.1.3 Installation................................................................................... 98
6.1.4 Windows Series Driver Setup (LAN)........................................... 98
6.2 USB 3.0................................................................................................... 99
6.2.1 Introduction ................................................................................. 99
6.2.2 Windows Series Driver Setup ..................................................... 99
6.3 SATA & PCIe SSD RAID ...................................................................... 100
Appendix A Programming the Watchdog Timer101
A.1 Watchdog Timer Overview.................................................................... 102
A.2 Programming the Watchdog Timer ....................................................... 102
Appendix B I/O Pin Assignments ....................... 105
B.1 USB Header (USB9_10) ....................................................................... 106
Table B.1: USB Header ........................................................... 106
B.2 USB3.0 Header(USB5_6, USB7_8)...................................................... 106
Table B.2: USB Header ........................................................... 106
B.3 VGA Connector (VGA1)........................................................................ 107
Table B.3: VGA Connector ...................................................... 107
B.4 RS-232 Interface (COM2) ..................................................................... 107
Table B.4: RS-232 Interface .................................................... 107
B.5 External Keyboard Connector (KBMS1) ............................................... 108
Table B.5: External Keyboard Connector ................................ 108
B.6 CPU and System Fan Power Connector (CPUFAN0~1,

vii ASMB-975 User Manual
SYSFAN0~SYSFAN4) .......................................................................... 108
Table B.6: Fan Power Connector............................................. 108
B.7 Power LED (JFP3) ................................................................................ 108
Table B.7: Power LED ............................................................. 108
B.8 External Speaker Connector (JFP2) ..................................................... 109
Table B.8: External Speaker Connector .................................. 109
B.9 Reset Connector (JFP1) ....................................................................... 109
Table B.9: Reset Connector..................................................... 109
B.10 HDD LED Connector (JFP1) ................................................................. 109
Table B.10:HDD LED Connector .............................................. 109
B.11 ATX Soft Power Switch (JFP1) ............................................................. 110
Table B.11:ATX Soft Power Switch .......................................... 110
B.12 Front panel SMBus Connector (SMBUS1)............................................ 110
B.13 USB/LAN Ports (LAN1_USB1_2, LAN2_USB3_4) ............................... 110
Table B.12:USB Port................................................................. 110
Table B.13:Giga LAN 10/100/1000 Base-T RJ-45 Port ............ 110
B.14 Audio Connector (HDAUD1) ................................................................. 111
Table B.14:Front Panel Audio Connector ................................. 111
B.15 Alarm Board Connector (VOLT1).......................................................... 111
Table B.15:Alarm Board Connector .......................................... 111
B.16 Case Open Connector (JCASE1) ......................................................... 111
Table B.16:Case Open Connector............................................ 111
B.17 Front Panel LAN LED Connector (LANLED1)....................................... 112
Table B.17:LAN LED Connector ............................................... 112
B.18 SATA SGPIO (SGPIO1/SGPIO2) ......................................................... 112
B.19 LPC Connector (LPC1) ......................................................................... 112
B.20 Clear CMOS and Update ME Connector (JCMOS1, JME1) ................. 113
B.21 PMBUS Connector (PMBUS1).............................................................. 113
B.22 GPIO Connector (GPIO1) ..................................................................... 113

ASMB-975 User Manual viii

Chapter 1
1Overview

ASMB-975 User Manual 2
1.1 Introduction
The ASMB-975 serverboard is the most advanced Intel Xeon Processor Scalable
Family series board for server-grade IPC applications that require high-performance
computing power & multi-expansion slots. This serverboard supports Intel Xeon Pro-
cessor Scalable Family series processor and DDR4 2133/2400/2666 MHz memory
up to 384 GB. ASMB-975 provides four PCIe x16, one PCIe x8 and four PCIe x4
slots in Gen3.0 high speed. In addition, the ASMB-975T2 has dual Gigabit and dual
10GbE Ethernet LAN ports that eliminate network bottlenecks. One GbE RJ-45 LAN
and one 10GbE RJ-45 LAN jack are shared with IPMI function that allows remote
control management. High reliability and outstanding performance makes ASMB-975
the ideal platform for industrial server/networking applications.
By using the Intel C622/C621 chipset, the ASMB-975 offers a variety of features such
as 8 x USB3.0 and 3x USB 2.0 connectivity, 12 x onboard SATA III and 2 x M.2
(SATA only) interface. The 12 x SATA ports support software RAID 0, 1, 10 and 5
(Windows only*), and with the latest Intel RSTe (Rapid Storage Technology Enter-
prise) it provides compelling RAID solution for NVMe SSDs via Intel VROC (Virtual
RAID on Chip) HW key.
These powerful I/O capabilities ensure even more reliable data storage capabilities
and high-speed I/O peripheral connectivity.
1.2 Features
General
Intel Xeon Processor Scalable Family support: ASMB-975 supports two Intel
Xeon Platinum/Gold/Silver/Bronze series up to 28-core processors.
High performance I/O capability: 2 x 10GbE (T2 SKU Only) + 2 x GbE LAN, 4
x PCIe x16 slot (x16 link) + 1 x PCIe x8 slot (x8 link), 12 x SATA and 2 x M.2
connectors,8 x USB 3.0 and 3 x USB 2.0 (incl. 1 x Type-A) ports.
Outstanding industrial features: ASMB-975 provides industrial features like
long product lifecycle, reliable operation under wide temperature range, watch-
dog timer, etc.
IPMI 2.0 support: ASMB-975I/ASMB-975T2 equipped with ASPEED 2500
BMC chip supports IPMI 2.0 (Intelligent Platform Management Interface 2.0) via
sharing LAN port.
KVM over IP: KVM over IP function allows BIOS level remote control of ASMB-
975I/ASMB-975T2 sku system through your own computer.
Note! 1. IPMI module will be included in ASMB-975I and ASMB-975T2
SKUs.
2. Three USB 2.0 ports (1*Type- A) and eight USB 3.0 ports (4 ports
from on-board 20-pin header)
3. Please refer to the release note of each Linux OS for Intel's C622/
C621 chipset SATA RAID function support.

3 ASMB-975 User Manual
Chapter 1 Overview
1.3 Specifications
Table 1.1: Specifications
Processor
CPU
Dual Intel LGA3647-P0 Xeon processor sockets
Supports Intel Processor Scalable Family, up to 28 cores
Supports the TDP of processor up to 205 W
System Memory
Memory Capacity
Xeon processor supports DDR4 memory bus
Total 12 memory slots provided
Supports up to 384 GB memory
1 DIMM slot per channel, 6 channels per processor
Memory Type Supports DDR4 2133/2400/2666 MHz ECC-REG DIMM modules
DIMM Sizes Each memory slot supports 4GB, 8GB, 16GB and 32GB memory
modules
Memory Voltage 1.2 V
Error Detection Corrects single-bit errors (Using ECC memory)
Detects double-bit errors (Using ECC memory)
On-Board Devices
Chipsets Intel C622/C621 PCH provide 20 PCIe Gen3 lanes (8 GT/s)
Network controllers
2 x Intel I210-AT Gigabit Ethernet controller connected to
C621/C622 through PCIe x1 Gen1.
Intel X557-AT2 10 Gigabit Ethernet controller connected to
C622 through PCIe Gen3 lane.
VGA ASPEED AST2500/2510 controller with 64 MB VGA memory pro-
vides basic 2D VGA function.
EC ITE IT8528E chip provide motherboard keyboard mouse, RS-232,
parallel port and hardware monitor functions
BMC (975I/975T2
SKUs)
One of Intel I210 Gigabit Ethernet connected to AST2500 for shar-
ing IPMI / iKVM
Input / Output
Storage
Total 12 x SATA ports and 2 x M.2 (SATA only) provide 6 Gb/s
bandwidth
RAID 0, 1, 5, 10 support (Windows only. For Linux support
please refer to note item 3 of chapter 1.1)
LAN 4 x RJ-45 LAN ports (2 x 10GbE + 2 x 10/100/1000 Base-T
LAN)
USB
4 x USB 3.0 ports at rear window
2 x USB 3.0 internal header (4 ports)
1 x USB 2.0 internal headers (2 ports)
1 x internal Type-A USB port.
Graphics 1 x VGA port.
Serial Port / Header 1 x RS232 port at rear window, 1 x internal header (2 x 5P
pitch: 2.50 mm), both ports are RS-232 (5V)
Keyboard / Mouse PS/2 keyboard and mouse connector (onboard).

ASMB-975 User Manual 4
Power Connector
System Power 1 x 24-pin SSI EPS 12V power connector (Input 12V, 5V, 3.3V,
5Vsb)
CPU Power 2 x 8-pin SSI EPS 12V power connector for CPU & Memory power
(12V)
PCIe slot power 1 x 8-pin power connector for PCIe slot 12V input
Expansion Slots
PCI-express
4 x PCIe x16 slot (Gen3 x16 link)
–PCIEX16_SLOT2 (from CPU 0)
–PCIEX16_SLOT4 (from CPU 1)
–PCIEX16_SLOT6 (from CPU 1)
–PCIEX16_SLOT8 (from CPU 0)
1 x PCIe x8 slot (Gen3 x8 link)
–PCIEX8_SLOT9 (from CPU 1)
4 x PCIe x4 slot (Gen3 x4 link)
–PCIEX4_SLOT1 (from CPU1)
–PCIEX4_SLOT3 (from CPU1)
–PCIEX4_SLOT5 (from CPU0)
–PCIEX4_SLOT7 (from CPU0)
System BIOS
BIOS Type 128 Mb SPI Flash EEPROM with AMI BIOS
PC Health Monitoring
Voltage Monitors for CPU Cores, +3.3V, +5V, +12V, +5V Standby, VBAT
FAN
Two 4-pin headers for CPU cooler and eight 4-pin headers for
system fans
All fans with tachometer status monitoring (except SYSFAN6
and SYSFAN7)
Thermal control for all fan connectors
Temperature Monitoring for CPU (PECI)
Monitoring for System (EC)
Other Features
(Case Open)
Chassis intrusion detection
Chassis intrusion header
Operating Environment / Compliance
RoHS RoHS Compliant 6/6 Pb Free
Environmental Spec.
Operating Temperature: 0 to 40° C
Non-operating Temperature: -40 to 85° C
Operating Relative Humidity: 10% to 90% (non-condensing)
Non-operating Relative Humidity: 10% to 95% (non-condens-
ing)
Table 1.1: Specifications

5 ASMB-975 User Manual
Chapter 1 Overview
1.4 Board Layout, Jumpers and Connectors
Connectors on the ASMB-975 are linked to external devices such as hard disk
drives. In addition, ASMB-975 has a number of jumpers that are used to configure
the system for specific applications.
The tables below list the functions of each jumper and connector. Later sections in
this chapter give instructions for setting jumpers. Chapter 2 gives instructions for con-
necting external devices to ASMB-975.
Figure 1.1 Board Layout
Figure 1.2 Rear I/O of full SKU
SYSFAN6
VGA1_COM1
SYSFAN7
PCIEX4_SLOT1
PCIEX16_SLOT2
PCIEX4_SLOT3
KBMS1
GPIO1
SSATA0_1
SSATA2_3
SATA0_1
SATA2_3
SATA4_5
SATA6_7
SYS_LED1
JTHR_SEL1
SLOT12V1
SYSFAN0
SYSFAN2
ATX12V1 DIMMF_E_D
DIMMA1
DIMMB1
DIMMH1
ATXPWR1
ATX12V2
CPUFAN1
PMBUS1
DIMMJ1
DIMMK1
DIMML1
PCIEX16_Slot 8
DIMMI1
PCIEX8
_Slot9
PCIEX4
_Slot7
PCIEX4
_Slot5
PCIEX16
_Slot4
SYSFAN4
LAN1_USB1_2
LAN2_USB3_4
LAN3_4
SYSFAN5
JWDT1
USB5_6
USB7_8
SP1_CN1
SMBUS1
BH2
USB9_10
SSATA5
SSATA4
COM2
DIMMG1
DIMMC1
SYSFAN1
SYSFAN3 CPUFAN0 JFP1_JFP2
USB11
JFP3
PCIEX16
_Slot6
IPMI Module
EX_THR1
LPC1
SGPIO2
JME
VROC1
VOLT1
SPI_SKT1
JCOMS1
HDAUD1
SGPIO1
ASMB-975-00A1
ASMB-975I-00A1
ASMB-975T2-00A1

ASMB-975 User Manual 6
Table 1.2: Onboard LAN LED Color Definition
10/100/1000 Mbps LAN Mbps LAN Link/Activity LED Scheme
LAN1 & LAN2 (1G)
Left LED Right LED
10 Mbps Link
Active
Off
Off
Green
Blinking green
100 Mbps Link
Active
Amber
Amber
Green
Blinking green
1000 Mbps Link
Active
Green
Green
Green
Blinking green
No Link Off Off
Table 1.3: Onboard LAN LED Color Definition
100/1000 & 10G bps LAN Mbps LAN Link/Activity LED Scheme
LAN3 & LAN4 (10G)
Left LED Right LED
100M bps Link
Active
Off
Off
Green
Blinking green
1G bps Link
Active
Amber
Amber
Green
Blinking green
10G bps Link
Active
Green
Green
Green
Blinking green
No Link Off Off
Table 1.4: Jumpers
Label Function Default
JCMOS1 CMOS Clear 1-2
JME1 ME update 1-2
JWDT1 Watch Dog Reset 1-2
PSON1 AT(1-2) / ATX(2-3) 2-3
JCASE1 Chassis case open alarm 1-2
JTHR_SEL On board(1-2)/external thermistor(2-3) 1-2

7 ASMB-975 User Manual
Chapter 1 Overview
Keep CMOS data/
disable ME update/
Clear CMOS data/
Enable ME update/
Table 1.5: Connectors
Label Function
ATX12V1 SSI EPS 12V auxiliary power connector (for CPU0) and memory
ATX12V2 SSI EPS 12V auxiliary power connector (for CPU1) and memory
ATXPWR1 SSI EPS 24-pin main power connector (for system)
BH2 For optional battery kit
BIOS_SKT1 BIOS SPI ROM
BMC_CN1, BMC_CN2 IPMI connector
COM2 Serial port: RS-232
CPU0 Intel LGA3647 CPU0 socket
CPU1 Intel LGA3647 CPU1 socket
CPUFAN0 CPU0 fan connector (8-pin)
CPUFAN1 CPU1 fan connector (8-pin)
DIMMA1 Channel A1 DIMMA1 of CPU0
DIMMB1 Channel B1 DIMMB1 of CPU0
DIMMC1 Channel C1 DIMMC1 of CPU0
DIMMD1 Channel D1 DIMMD1 of CPU0
DIMME1 Channel E1 DIMME1 of CPU0
DIMMF1 Channel F1 DIMMF1 of CPU0
DIMMG1 Channel G1 DIMMG1 of CPU1
DIMMH1 Channel H1 DIMMH1 of CPU1
DIMMI1 Channel I1 DIMMI1 of CPU1
DIMMJ1 Channel J1 DIMMJ1 of CPU1
DIMMK1 Channel K1 DIMMK1 of CPU1
DIMML1 Channel L1 DIMML1 of CPU1
EC_SMBUS1 For EC debug
EX_THR1 Connector for external thermistor
GPIO1 GPIO function for customize usage
HDAUD1 Audio header
JFP1/JFP2/JFP3 Front panel pin header
KBMS1 For additional keyboard/mouse
LAN1_2, LAN3_4 RJ-45 LAN connector
LANLED1 LAN LED extension connector
LPC1 LPC port for debug & TPM module
SSATA4, SSATA5 SATA port 4/5 for M.2 2242 SATA SSD
PMBUS1 PMBUS connector to communicate with power supply
PEHP1 NVMe RAID LED control
SATA0~SATA7 Serial ATA0~7
SSATA0~SSATA3 sSATA port 0~3
SGPIO1 Supports Serial_Link interface for onboard SATA connections
123
123

ASMB-975 User Manual 8
SLOT1 PCIE x 4 slot of CPU1
SLOT2 PCIE x 16 slot of CPU0
SLOT3 PCIE x 4 slot of CPU1
SLOT4 PCIE x 16 slot of CPU1
SLOT5 PCIE x 4 slot of CPU0
SLOT6 PCIE x 16 slot of CPU1
SLOT7 PCIE x 4 slot of CPU0
SLOT8 PCIE x 16 slot of CPU0
SLOT9 PCIE x 8 slot of CPU1
SLOT12V1 For PCIe slot 12V input only
SMBUS1 Front panel SMBus header
SPI_CN1 Connector for BIOS update tool
SPI_SKT1 EC EEPROM
SYSFAN0-SYSFAN7 System FAN connector (4-pin)
SYS_LED1 System LED connector
USB5_6,USB7_8 USB 3.0 port 5,6,7,8 (20 pin header)
USB9_10 USB 2.0 pin header 9, 10
USB11 USB 2.0 port 11 (Type-A)
LAN1_USB1_2 RJ-45 LAN port 1 + USB 3.0 port 1/2 connector
LAN2_USB3_4 RJ-45 LAN port 2 + USB 3.0 port 3/4 connector
VOLT1 Voltage display
VROC1 Intel Virtual RAID (VROC) key
VGA1_COM1 VGA and COM connector
COM2 Serial port: RS-232
Table 1.6: Onboard LED
LED Description LED Definition
5V_LED1 Power on LED Off:
Power off
On (Green):
System is On
5VSB_LED1 Standby LED Off:
No input AC Power
On (Green):
System is ON, in sleep mode,
or in soft-off mode
LED3
BMC heartbeat LED
(ASMB-975I & ASMB-
975T2 SKU Only)
Blinking (Green):
controller is working normally
Table 1.5: Connectors

9 ASMB-975 User Manual
Chapter 1 Overview
1.5 Block Diagram
Figure 1.3 Block Diagram
1.6 System Memory
ASMB-975 has twelve 288-pin memory slots for DDR4 2133/2400/2666 MHz mem-
ory modules with maximum capacity of 384 GB (Maximum 32 GB for each DIMM).
ASMB-975 supports registered DIMMs memory module.
Intel LGA 3647-P0
Xeon® Scalable
Processors
(CPU1)
Intel LGA 3647-P0
Xeon® Scalable
Processors
(CPU0)
UPI PORT0 : 10.4GT/s
UPI PORT1 : 10.4GT/s
Channel 0
ECC DDR4 2133/2400
Channel 1
ECC DDR4 2133/2400
Channel 2
ECC DDR4 2133/2400
Channel 3
ECC DDR4 2133/2400
Channel 4
ECC DDR4 2133/2400
Channel 5
Channel 0
Channel 1
Channel 2
Channel 3
Channel 4
Channel 5
ECC DDR4 2133/2400
ECC DDR4 2133/2400
ECC DDR4 2133/2400
ECC DDR4 2133/2400
ECC DDR4 2133/2400
ECC DDR4 2133/2400
ECC DDR4 2133/2400
PCIe x4 Slot PCIe Gen3 x4
Slot 1
PCIe x4 Slot PCIe Gen3 x4
Slot 3
PCIe x16 Slot PCIe Gen3 x16
Slot 4
PCIe x16 Slot PCIe Gen3 x16
PCIe Gen3 x16
PCIe Gen3 x4
PCIe Gen3 x4
PCIe Gen3 x16
Slot 6
PCIe x16 Slot Slot 2
20160225: need check
PCIe x4 Slot Slot 5
PCIe x4 Slot Slot 7
PCIe x16 Slot Slot 8
PCIe x8 Slot PCIe Gen3 x8
Slot 9
DMI Gen3 x4
PCIEUP Gen3 x8
PORT0,1,2,3,4,5,6,7
SATA
6 Gb/s
Intel C622/C621 PCH
LAN3/LAN4
Intel X557-AT2
8 x SATA3
(RAID 0,1,5,10)
CPU Power
VR13
CPLD
Port1,2,3,4,5,6,7,8
USB 3.0
8 x USB3.0
(4 on board / 4 Rear)
Port0,1,2,3
sSATA
6 Gb/s
4 x SATA3
Port4,5
sSATA
6 Gb/s
2 x M.2
Port9,10,11
USB 2.0
3 x USB2.0
(1 type A)
(2 on board)
HD Audio
HD Conn.
LAN1 Intel I210
MDI RJ45
10/100/1G/10G
MDI RJ45
10/100/1G/10G
MDI RJ45
10/100/1G
NC-SI
NC-SI
USB 2.0
PCIe Gen3 x1 BMC
AST2500/AST2510 SPI SPI Flash 32MB
DDR4 DRAM
RGB VGA Conn.
SPI BUS
LPC Conn.
2 x RS-232 Header/Conn.
EC
ITE-8528
SPI BIOS
8 bit GPIO Pin Header
SPI SKT
PS/2 KB, MS
128Mbit
LPC BUS
LPC BUS
Port0,1
10 Gb/s
Port4
PCIe Gen1 x1
2.5 Gb/s
LAN2 Intel I210 MDI RJ45
10/100/1G
Port5
PCIe Gen1 x1
2.5 Gb/s
8 x FAN Conn.
PWM
SPI

ASMB-975 User Manual 10
1.7 Memory Installation Procedures
Single CPU Installed (CPU0)
Quantity of
memory installed 123456
DIMMA1 vvvvvv
DIMMB1 vvvvv
DIMMC1 vvvv
DIMMD1 v v v
DIMME1 v v
DIMMF1 v
DIMMG1
DIMMH1
DIMMI1
DIMMJ1
DIMMK1
DIMML1
Dual CPU Installed (CPU0 & CPU1)
Quantity of
memory installed 23456789101112
DIMMA1 vvvvvvvvvvv
DIMMB1 vvvvvvvvvv
DIMMC1 vvvvvvvv
DIMMD1 vvvvvv
DIMME1 vvvv
DIMMF1 v v
DIMMG1 vvvvvvvvvvv
DIMMH1 vvvvvvvvv
DIMMI1 vvvvvvv
DIMMJ1 vvvvv
DIMMK1 v v v
DIMML1 v

11 ASMB-975 User Manual
Chapter 1 Overview
1.8 Processor Installation
The ASMB-975 is designed for Intel Xeon processor scalable family.
Step 1
Remove dust cover.
Step 2
Install CPU on CPU clip and align pin 1 mark.

ASMB-975 User Manual 12
Step 3
Install the CPU clip assembly on the heatsink as a processor + heatsink module.
Step 4
Put the processor heatsink module into the motherboard bolster plate by using a T-30
screw driver (follow heatsink label direction 1-2-3-4).
