Advent TOCMR-OE100 Manual

TOCMR-OE100
Install Manual

2
INSTALLATION PREPARATION
Before starting installation:
1. Familiarize yourself with the installation
instructions.
2. Inspect kit components (Refer to kit contents
and hardware bag contents parts list located
at the rear of this manual).
3. If you have any questions during this
installation, please contact Audiovox
Technical Support at 1-800-323-4815.
VEHICLE PREPARATION
4. Place protective coverings on vehicle.
5. Disconnect negative battery cable
6. Pull the side center console panels forward
as shown in the illustration.
Negative Battery
Cable
Socket (10 mm), Ratchet

3
7. Pull forward and side panels will come off.
8. Remove the screws from the center
console pocket assembly.
9. Using the trim panel removal tool gently
pry up the gear shift panel.

4
10. Unplug the heated seat switch if
equipped.
11. Grasp the top half panel of the center
console and lift upwards and remove.
12.Panel being lifted and removed.

5
13.Unplug the accessory port connector.
14.Remove the center console pocket and
unplug.
15.Using the trim panel removal tool pry
the AC vent assembly above the radio
outwards.

6
16.Unplug the hazard switch.
17.Using a ten millimeter socket remove
the mounting screws from the top of the
radio.
18.Using a ten millimeter socket remove the
mounting screws from the bottom of the
radio.

7
19.Unplug all wiring harnesses connected to the
radio.
20.Remove right side mounting bracket.
21.Remove left side mounting bracket.

8
22.Remove the climate control assembly from
the radio.
23.Connect the climate control assembly to
the new radio and install right side
mounting bracket.
24.Install left side mounting bracket.
.

9
25.Remove the driver’s side door weather
strip gasket along the A-pillar area.
26.Using the trim panel tool, pull the side
airbag slightly away from the A-pillar.
27.Run the handsfree microphone plug
between the side airbag and A-pillar.

10
28.Run the handsfree microphone plug
between the dashboard and the A-pillar.
Once the wire is positioned behind the
dashboard, continue routing the wire to
radio opening.
29.Mount the microphone and clip as
shown the illustration.
GPS Antenna Installation
30.Remove the GPS antenna from
packaging.

11
31.Mount the GPS antenna on the top of
the AC vent.
32.GPS antenna is mounted.
33.Release the glove box door and lower it.

12
34.Place USB/ AV2 Interface Module in the
glove box and route the wire harness to
the back of the radio.
35.Attach all wire harnesses to the rear of the
radio. Plug matching color connectors
together.
NOTE: Route the brown parking brake wire
down to the center console emergency
brake switch.
36. Reinstall the radio in the dashboard in the
reverse order of disassembly.
37. Reconnect the negative battery cable.

13
Non JBL Connection Diagram
Parking Brake (-)
Steering Wheel Controls
Illumination Control
Power Speaker
Connector
Speaker Connector
Not Used

14
JBL Connection Diagram
Steerin
g
Wheel Controls
JBL Module
Audio/Power Connector
Parking Brake (-)
Illumination Control
Reverse Lights (+)

15
SIRIUS
Satellite
Control
Harness Layout Diagram
USB/AV2 Interface
Module
Rear Camera
iPod Connector
External Handsfree
Microphone
GPS Antenna Accessory Cable
(Optional)
SIRIUS Module Optional. Cable
Should Be Connected if SIRIUS
Radio is to be Installed.
XM Module
(Optional)

16
Label Placement
After the installation of the radio is complete, the factory AUX/USB port will no
longer function. Place the black ahesive sticker to cover the lettering of the original
port. Refer to illustration above.
Label
USB/AV2 Interface Module
Label
Two labels are provided for the USB/AV2 Interface module to
accommodate various mounting positions.
BEFORE
AFTER
BEFORE
AFTER

17
Toyota Radio Parts List
Item QTY
Unit Part Number Title
1 1 136-4853
Remote Control 1 with Battery (Front Zone)
2 1 130-2844
Polybag For Remote Control
3 1 136-4855 External Microphone
4 1 130-5217 Polybag for External Microphone
5 1 118-1221 GPS Antenna
6 21 138-1456 Velcro Strip,1" x 1.5"for GPS Antenna
7 1 130-5218 Polybag for Antenna
8 1 130-5219 White Cardboard Box for Antenna
9 1 112-4031 PS
USB/Aux Interface Cable(for iPod or AV2 input)
10 1 150-1747 Hardware Kit for USB/AUX Interface Cable
11 1 112-4033 Main Power & Audio Cable
12 1 112-4034 Steering Wheel Control Cable
13 1 112-4035 SIRIUS Cable
14 1 112-4036 Reverse Extension Cable
15 1 136-4858 Microphone Connector Jumper Assembly (installed on
Radio)
16 1 100-2520
Cable Retention, Plastic
17 1 130-5222 Polybag for Cable Retention
18 1 130-5188 Cardboard Accessory Box
19 1 Label 2 170-0123 Label Part Number, 8 Digit (132B7001)
Apply to Items 1, 3, 5, 9, 10, 11, 12,13,14
20 2 102-4629 Screw Cap
21 2 100-2525 Screw, Mounting
22 2 132-7630 Label 1, AV2 with USB Symbol
23 2 132-7645 Label 2, USB Symbol with AV2
24 130-4077 Polybag for Cable Retention
© 2009 Audiovox Electronics Corp. 150 Marcus Blvd. Hauppauge, NY 11788
128-8561
12/14/09
