AEG LB4650WT User manual

USER
MANUAL
EN User Manual
Washer Dryer
LB4650WT

CONTENTS
1. SAFETY INFORMATION.............................................................................................3
2. SAFETY INSTRUCTIONS.............................................................................................6
3. INSTALLATION............................................................................................................7
4. PRODUCT DESCRIPTION.........................................................................................11
5. CONTROL PANEL..................................................................................................... 12
6. DIAL AND BUTTONS................................................................................................14
7. PROGRAMMES..........................................................................................................16
8. SETTINGS...................................................................................................................23
9. BEFORE FIRST USE................................................................................................... 23
10. DAILY USE - WASHING ONLY...............................................................................23
11. DAILY USE - WASHING & DRYING....................................................................... 28
12. DAILY USE - DRYING ONLY...................................................................................29
13. FLUFF IN THE FABRICS..........................................................................................30
14. HINTS AND TIPS..................................................................................................... 31
15. CARE AND CLEANING.......................................................................................... 33
16. TROUBLESHOOTING.............................................................................................37
17. CONSUMPTION VALUES.......................................................................................41
18. TECHNICAL DATA..................................................................................................42
19. ACCESSORIES.........................................................................................................43
20. GUARANTEE .......................................................................................................... 43
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
www.aeg.com
2

Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
ENGLISH 3

1.2 General Safety
•Do not change the specification of this appliance.
•This appliance is intended to be used in household
and similar applications such as:
–staff kitchen areas in shops, offices and other
working environments;
–by clients in hotels, motels, bed & breakfast and
other residential type environments;
–areas for communal use in blocks of flats or in
launderettes.
•The appliance shall be installed as a freestanding
product or below the kitchen worktop if space
margins permit.
•Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite
side, that would prevent the appliance door from
being fully open.
•Connect the mains plug to the mains socket only at
the end of the installation process. Make sure that the
mains plug is accessible after installation.
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
•WARNING: The appliance must not be supplied
through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on
and off by a utility.
•Ensure good air ventilation in the room where the
appliance is installed to avoid the backflow of
unwanted gases into the room from appliances
burning gas or other fuels, including open fires.
•Exhaust air must not be discharged into a flue which is
used for exhausting fumes from any appliances
burning gas or other fuels.
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
www.aeg.com
4

•Do not exceed the maximum load of 8 kg (refer to the
"Programme chart" chapter).
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Wipe away lint or packaging debris that has
accumulated around the appliance.
•Items that have been soiled with substances such as
vegetable or mineral oil, acetone, alcohol, petrol,
kerosene, spot removers, turpentine, waxes and wax
removers should be washed separately with an extra
amount of detergent before being dried in the washer
dryer.
•Do not use the appliance if items have been soiled
with industrial chemicals.
•Do not dry unwashed items in the wash dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, and rubber backed articles and
clothes, or pillows fitted with foam rubber pads should
not be dried in the washer dryer.
•Fabric softeners, or similar products, should only be
used as specified by the product manufacturer’s
instructions.
•Remove all objects from items that could be a source
of fire ignition such as lighters or matches.
•Never stop the washer dryer before the end of the
drying cycle unless all items are quickly removed and
separated so that residual heat can dissipate.
•The final part of the washer dryer cycle takes place
without heat (cool down cycle) to ensure that items
reach a temperature that will not cause damage to
them.
ENGLISH 5

•Do not use high pressure water sprays and/or steam
to clean the appliance.
•Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Follow the installation instructions
supplied with the appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• Always keep the appliance vertical
when it is being moved.
• Make sure that there is air circulation
between the appliance and the floor.
• Remove all the packaging and the
transit bolts.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
future they must be reattached to lock
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use a damaged
appliance.
• Do not install the appliance where the
appliance door cannot be fully
opened.
• Adjust the feet to have the necessary
space between the appliance and the
flooring.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
2.2 Electrical Connection
WARNING!
Risk of fire and electric
shock.
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• This appliance complies with the
E.E.C. Directives.
2.3 Water Connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes,
pipes not used for a long time, where
repair work has been carried out or
new devices fitted (water meters,
etc.), let the water flow until it is clean
and clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
www.aeg.com
6

2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the glass door while a
programme is in operation. The glass
can get hot.
• Do not dry damaged (torn, frayed)
items that contain padding or fillings.
• If laundry has been washed with a
stain remover, carry out an additional
rinse cycle before starting a drying
cycle.
• Make sure that all metal objects are
removed from the laundry.
• Only dry fabrics that are suitable to
dry in the washer dryer. Follow the
cleaning instruction on the item label.
• Plastic items are not heat resistant.
– If a detergent ball is used, remove
it before starting a drying
programme.
– Do not use a detergent ball if
setting a non-stop programme.
WARNING!
Risk of injury or damage to
the appliance.
• Do not sit or stand on the open door.
• Do not dry dripping wet clothes in the
appliance.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Unpacking
1. Remove the external film. If
necessary, use a cutter.
2. Remove the cardboard top and the
polystyrene packaging materials.
3. Open the door. Remove all the items
from the drum .
ENGLISH 7

4. Put the front polystyrene packaging
element on the floor under the
appliance. Carefully put down the
appliance onto its rear side.
5. Remove the polystyrene protection
from the bottom. Put the appliance
back into an upright position.
1
2
6. . Remove the power supply cable
and the drain hose from the hose
holders.
It is possible to see
water flowing from the
drain hose. This is
because the washing
machine has been tested
at the factory.
7. Remove the three transit bolts and
pull out the plastic spacers.
8. Put the plastic caps, that you find in
the user manual bag, in the holes.
We recommend that you
keep the packaging and the
transit bolts for any transport
of the appliance.
3.2 Information for installation
Positioning and levelling
Adjust the appliance correctly to prevent
vibration, noise and movement of the
appliance when it operates.
1. Install the appliance on a flat hard
floor. The appliance must be levelled
and stable. Make sure that the appliance
does not touch the wall or other units
and there is air circulation below the
appliance.
2. Loosen or tighten the feet to adjust
the level. All feet must rest firmly on the
floor.
www.aeg.com
8

WARNING!
Do not put cardboard, wood
or equivalent materials
below the appliance feet to
adjust the level.
The inlet hose
CAUTION!
Make sure there is no
damage to hoses and there
are no leaks from the
couplings. Do not use an
extension hose if the inlet
hose is too short. Contact
the service centre for a
replacement inlet hose.
1. Connect the water inlet hose to the
back of the appliance.
20º20º
45º45º
2. Position it toward left or right
depending on the positon of the water
tap. Make sure that the inlet hose is not
in vertical position.
3. If necessary, loosen the ring nut to set
it in the correct position.
4. Connect the water inlet hose to the
cold water tap with 3/4'' thread.
Water drainage
The drain hose should stay at a height of
no less than 60 cm and not more than
100 cm.
You can extend the drain
hose to maximum 400 cm.
Contact the authorised
service centre for the other
drain hose and the
extension.
It is possible to connect the drain hose in
different ways:
1. Make a U shape with the drain hose
and put it around the plastic hose guide.
2. On the edge of a sink - Fasten the
guide to the water tap or to the wall.
Make sure that the plastic
guide cannot move when
the appliance drains and the
drain hose end is not
immersed in the water.
There may be a return of
dirty water into the
appliance.
3. If the end of the drain hose looks like
this (see the picture), you can push it
directly into the stand pipe.
ENGLISH 9

4. To a stand pipe with vent hole - Insert
the drain hose directly into a drain pipe.
Refer to the illustration.
The end of the drain hose
must always be ventilated ,
i.e. the inner diameter of the
drain pipe (min. 38 mm -
min. 1.5") must be larger
than the external diameter
of the drain hose.
5. Without the plastic hose guide, to a
sink spigot- Put the drain hose in the
spigot and tighten it with a clamp. Refer
to the illustration.
Make sure that the drain hose makes a
loop to prevent particles going into the
appliance from the sink.
ø16
1
W011
2
Connect the drain hose to the spigot and
tighten it with a clamp. Make sure that
the drain hose makes a loop to prevent
particles going into the appliance from
the sink.
6. Position the hose directly to a built-in
drain pipe in the room wall and tighten it
with a clamp.
www.aeg.com
10

4. PRODUCT DESCRIPTION
4.1 Appliance overview
9
5
7
4
10
8
11 12
6
1 2 3
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
8Drain hose
9Inlet hose connection
10 Mains cable
11 Transit bolts
12 Hose support
ENGLISH 11

5. CONTROL PANEL
5.1 Control panel description
Denim
NonStop gk1/h1
Spülen
Baumwolle
Pflegeleicht
Feinwäsche
Baumwolle Eco
elloW
f
p
m
a
D
nep
m
u
pbA/nre
du
elhcS
-nen
i
h
csaM gnugin
ie
r
eigre
l
l
A-itnA
Sportwäsche
r
ood
tuO
Mode
90°
60°
40°
30°
20°
23 4 5
12 11 8
1
7 6
910
The permanent options are
set by holding pressed the
relative button for at least 3
seconds.
1Programme dial
2Display
3Auto Dry touch button
4Time Dry touch button
5Start/Pause touch button
6Delay Start touch button
7Time Manager touch button and
permanent Child Lock option
8Prewash touch button and
permanent Extra Rinse option
9Spin touch button
10 Temperature touch button
11 Mode touch button:
• Mode - Wash
• Mode - Dry
12 On/Off push button
5.2 Display
www.aeg.com12

Door locked indicator.
The digital indicator can show:
• Programme duration (e. g. , washing and/or drying phase).
• Delay time (e. g. ).
• Cycle end ( ).
• Warning code (e.g. ).
• Error indicator ( ).
Time Manager indicator.
Extra Rinse indicator.
The spin area:
Spin speed indicator
No Spin indicator. Spin phase is off.
Rinse Hold indicator.
After the ProSense System detection, it flashes when the laundry
load exceeds the maximum declared load of the selected pro-
gramme. Refer to "The ProSense System load detection " para-
graph.
Auto Dry indicator:
Iron dry
Cupboard dry
Extra dry
Child safety lock indicator.
Time Dry and Non-Stop programme indicator.
5.3 Multilingual badges
Adhesive badges in different languages
are supplied with the appliance.
The desired badge can be glued next to
the programme dial.
Outdoor
Puuvilla
Puuvilla
Koneenpuhdistus
Silkki
Villa
Tyhjennys/Linkous
Huuhtelu
Pika 14 min.
Hienopesu
Synteettiset
Denim
UltraWash
Anti-Allergy
ENGLISH 13

6. DIAL AND BUTTONS
6.1 Introduction
The options/functions are
not available with all
washing programmes. Check
the compatibility between
options/functions and
washing programmes in the
"Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set incompatible options/
functions.
6.2 On/Off
Press this button for a few seconds to
activate or deactivate the appliance. Two
different tunes sound while switching the
appliance on or off.
As the Stand-by function automatically
deactivates the appliance after several
minutes to reduce the energy
consumption, you may need to activate
the appliance again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
6.3 Mode
Thanks to this button, a cycle can
perform:
•Only washing: indicator is on
(default mode).
•Washing and drying: and
indicators are on.
•Only drying: indicator is on.
6.4 Temperature
When you select a washing programme,
the appliance automatically proposes a
default temperature.
Tap on this button to change the water
temperature.
The indicator of the set temperature
comes on.
The indicator corresponds to cold
water.
6.5 Spin
When you set a programme, the
appliance automatically sets the
maximum spin speed allowed, except for
programme Denim. With this option you
can decrease the default spin speed.
Touch repeatedly this button to:
•Decrease the spin speed. The
display shows only the spin speeds
available for the set programme.
• Additional spin options No Spin
.
Set this option to deactivate all spin
phases. The appliance performs the
only draining phase of the selected
washing programme. Set this option
for very delicate fabrics. The rinses
phase uses more water for some
washing programmes
• Activate the Rinse Hold option.
The final spin is not performed. The
water of the last rinse is not drained
out to prevent the fabrics from
creasing. The washing programme
ends with water in the drum.
The indicator is on display. The
door stays locked and the drum turns
regularly to reduce creasing. You
must drain the water to unlock the
door.
If you touch the Start/Pause
button, the appliance performs the
spinning phase and drains the water.
The appliance empties
the water out
automatically after 18
hours approximately.
6.6 Prewash
With this option you can add a prewash
phase to a washing programme.
The corresponding indicator above the
touch button illuminates.
• Use this option to add a pre-wash
phase at 30 °C before the washing
phase.
This option is recommended for
heavily soiled laundry, especially if
www.aeg.com
14

containing sand, dust, mud and other
solid particles.
The options can increase the
programme duration.
6.7 Permanent Extra Rinse
With this option you can permanently
have an extra rinse when you set a new
programme.
To activate/deactivate this option, hold
the Prewash button pressed for 3
seconds until the indicator comes on/
goes off on the display.
When it is activated, the appliance will
default to this option after you switch it
off or change/reset the programme.
This option increases the
programme duration.
6.8 Time Manager
With this option you can reduce the
programme duration depending on the
load size and the degree of soiling.
When you set a washing programme, the
display shows the default duration and
dashes.
Touch Time Manager button to
reduce the programme duration
according to your needs. The display
shows the new programme duration and
a number of dashes will decrease
accordingly:
suitable for a full load of normally
soiled garments.
a quick cycle for a full load of lightly
soiled garments.
very quick cycle for a smaller lightly
soiled load (max. half load
recommended).
the shortest cycle to freshen up a
small amount of laundry.
The Time Manager is available only with
the programmes in the table.
indicator
Cottons
Cottons Eco
Synthetics
1) ■■■
■ ■ ■
■■■
■ ■ ■
■ ■ ■
1) Default duration for all programmes.
Time Manager with steam
programmes
When setting a steam programme, this
button allows to chose three steam levels
and the programme duration is reduced
accordingly:
• : maximum.
• : medium.
•: minimum.
6.9 Child Lock
With this option you can prevent children
from playing with the control panel.
To activate/deactivate this option, hold
the Time Manager button pressed
until the indicator comes on/goes off
on the display.
When it is activated, the appliance will
default to this option after you switch it
off or change/reset the programme. If
you press any button, the indicator
blinks to indicate that the buttons are
disabled.
6.10 Time Dry
Touch this button to set the time that
suits the fabrics you have to dry (refer to
"Timed drying" table). The display shows
the set value.
ENGLISH 15

Each time you touch this button the time
value increases by 5 minutes.
You cannot set all time
values for different types of
fabrics.
6.11 Auto Dry
Touch this button to set one the
automatic dryness levels proposed by
the appliance.
On the display the relevant dryness
indicator goes on:
• Iron dry: laundry to be ironed.
• Cupboard dry: laundry to be put
in store.
• Extra dry: laundry to be fully
dried.
You can not set all
automatic levels for each
type of fabrics.
6.12 Delay Start
With this option you can delay the start
of a programme to a more convenient
time.
Touch the button repeatedly to set the
required delay. The time increases in
steps of 1 hour up to 20 hours.
The corresponding indicator above the
touch button illuminates.
The display shows the selected delay
time. After touching the Start/Pause
button, the appliance begins the
countdown and the door is locked.
6.13 Start/Pause
Touch the Start/Pause button to
start, pause the appliance or interrupt a
running programme.
7. PROGRAMMES
7.1 Programme Chart
Programme
Default tempera-
ture
Temperature
range
Reference
spin
speed
Spin
speed
range
Maxi-
mum
load
Programme description
(Type of load and soil level)
Cottons
40 °C
90 °C - Cold
1600 rpm
(1600- 400
rpm)
8 kg White cotton and coloured cotton. Normal,
heavy and light soil.
Cottons Eco1)
40 °C
60 °C - 40 °C
1600 rpm
(1600- 400
rpm)
8 kg White cotton and fast-coloured cotton. Nor-
mal soil. The energy consumption decreases
and the time of the washing programme is ex-
tended, ensuring good washing results.
Synthetics
40 °C
60 °C - Cold
1200 rpm
(1200 - 400
rpm)
3 kg Synthetic items or mixed fabric items. Nor-
mal soil.
www.aeg.com16

Programme
Default tempera-
ture
Temperature
range
Reference
spin
speed
Spin
speed
range
Maxi-
mum
load
Programme description
(Type of load and soil level)
Delicates
40 °C
40 °C - Cold
1200 rpm
(1200- 400
rpm)
3 kg Delicate fabrics such as acrylics, viscose and
mixed fabrics requiring gentler washing.
Normal soil.
Wool
40 °C
40 °C - Cold
1200 rpm
(1200 - 400
rpm)
1.5 kg Machine washable wool, hand washable
wool and other fabrics with «hand washing»
care symbol2).
Steam
-
1 kg Steam programme for cotton and synthetic
items. Steam can be used for dried3), washed
or worn once laundry. This programme reduce
creases and odours4) and relaxes the fibres.
When the programme is completed, quickly
remove the laundry from the drum. After a
steam programme, ironing becomes effort-
less. Do not use any detergent. If necessary,
remove stains by washing or using localized
stain removal. Steam programmes do not per-
form any hygienic cycle. Do not set a Steam
programme with these types of items:
• Items that are not suitable for tumble dry-
ing.
• All items with plastic, metal, wooden parts
or alike.
Spin/Drain
1600 rpm
(1600 - 400
rpm)
8 kg All fabrics, except woollens and delicate
fabrics. To spin the laundry and to drain the
water in the drum.
Spülen
1600 rpm
(1600- 400
rpm)
8 kg All fabrics, except woollens and very deli-
cate fabrics. Programme for rinsing and spin-
ning the laundry. The default spin speed is the
one used for cotton programmes. Reduce the
spin speed accordingly to the type of laundry.
If necessary, set the Extra Rinse option to add
rinses. With a low spin speed, the appliance
performs delicate rinses and a short spin.
ENGLISH 17

Programme
Default tempera-
ture
Temperature
range
Reference
spin
speed
Spin
speed
range
Maxi-
mum
load
Programme description
(Type of load and soil level)
Machine Clean
60 °C
1200 rpm
(1200 - 400
rpm)
-
Maintenance cycle with hot water to clean and
freshen the drum and to remove residue that
may cause odour. For the best result use this
cycle once a month. Before running this cycle,
remove all items from the drum. In the wash-
ing phase compartment of the detergent dis-
penser, put the flap of the compartment in up-
ward position. Pour a cup of chlorine bleach or
a washing machine cleaner in the washing
phase compartment. DO NOT use both to-
gether.
After the drum cleaning, run a
further rinse cycle with empty
drum and no detergent to re-
move any residue of bleach.
If you set this programme with the Mode - Dry,
the appliance performs the anti-fluff action.
Refer to chapter 'Fluff in the fabrics'.
Anti-allergy
60 °C
1600 rpm
(1600 - 400
rpm)
8 kg White cotton items. This programme re-
moves micro-organisms thanks to a washing
phase with the temperature maintained above
60°C for several minutes. This helps remove
germs, bacteria, micro-organism and particles.
An additional rinsing phase ensures a proper
removal of detergent residues and pollens/
allergenic items. In this way the wash is more
effective.
Sportswear
30 °C
40 °C - Cold
1200 rpm
(1200- 400
rpm)
3 kg Synthetic sport items. This programme is de-
signed to gently wash modern outdoor sports-
wear and is also suitable for gym, cycling or
jogging clothes or similar.
www.aeg.com18

Programme
Default tempera-
ture
Temperature
range
Reference
spin
speed
Spin
speed
range
Maxi-
mum
load
Programme description
(Type of load and soil level)
Outdoor
30 °C
40 °C - Cold
1200 rpm
(1200- 400
rpm)
2 kg Do not use fabric softener and
make sure that there is no soft-
ener residue in the detergent
dispenser.
Outdoor clothing, technical, sport fabrics,
waterproof and breathable jackets, shell
jackets with a removable fleece or inner in-
sulation.
By performing a combined
wash and dry programme, the
drying phase also acts as water-
repellent restorer. Make sure
that the garment care label
permits tumble drying.
Denim
30 °C
40 °C - Cold
1200 rpm
(1200 - 400
rpm)
3 kg Special programme for Denim clothing with
delicate washing phase to minimize colour
fading and marks. For better care a reduced
load size is recommended.
One GO 1h 1kg
30 °C
40 °C - 30 °C
1200 rpm
(1200 - 400
rpm)
1 kg Mixed fabrics (cotton and synthetic items).
Complete short programme to wash and dry
laundry loads up to 1 kg in one go. It only lasts
1 hour.
Reset position. The display shows dashes only.
1) Cottons energy saving programme. This programme at 60ºC with a load of 8 kg is the reference pro-
gramme for data entered in the energy label, in compliance with 96/60/EC Directive. Set this programme
to have a good washing results and decrease the energy consumption. The time of the washing pro-
gramme is extended.
2) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
3) If you set a Steam programme with dried laundry, at the end of the cycle the laundry can be humid.
Line dry the items for about 10 minutes.
4) Steam programme doesn't remove particularly intense odour.
ENGLISH 19

Programme options compatibility
Programme
Spin
No Spin
Prewash
Time Manager
Delay Start
Cottons ■ ■ ■ ■ ■ ■ ■
Cottons Eco ■ ■ ■ ■ ■ ■ ■
Synthetics ■ ■ ■ ■ ■ ■ ■
Delicates ■ ■ ■ ■ ■ ■
Wool ■ ■ ■ ■
Freshscent ■ ■
Spin/Drain ■■1) ■
Spülen ■ ■ ■ ■■
Machine Clean ■ ■ ■
Anti-allergy ■ ■ ■ ■ ■ ■
Sportswear ■ ■ ■ ■ ■ ■
Outdoor ■ ■ ■ ■■
Denim ■ ■ ■ ■■
One GO 1h 1kg ■
1) If you set the No Spin option, the appliance performs draining only.
www.aeg.com20
