AEG LWR734P16U User manual

USER
MANUAL
EN User Manual
Washer Dryer
LWR734P16U

CONTENTS
1. SAFETY INFORMATION......................................................................................3
2. SAFETY INSTRUCTIONS.................................................................................... 6
3. PRODUCT DESCRIPTION...................................................................................8
4. TECHNICAL DATA............................................................................................... 9
5. INSTALLATION...................................................................................................10
6. CONTROL PANEL..............................................................................................15
7. DIAL AND BUTTONS......................................................................................... 18
8. SETTINGS.......................................................................................................... 22
9. BEFORE FIRST USE..........................................................................................23
10. PROGRAMMES................................................................................................23
11. WI-FI - CONNECTIVITY SETUP................................................................. 30
12. DAILY USE....................................................................................................... 33
13. DAILY USE - WASHING & DRYING.................................................................38
14. DAILY USE - DRYING ONLY........................................................................... 40
15. FLUFF IN THE FABRICS..................................................................................41
16. HINTS AND TIPS..............................................................................................42
17. CARE AND CLEANING.................................................................................... 44
18. TROUBLESHOOTING......................................................................................50
19. CONSUMPTION VALUES................................................................................55
20. QUICK GUIDE.................................................................................................. 58
21. ENVIRONMENTAL CONCERNS......................................................................60
My AEG Care app
www.aeg.com2

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before beginning the installation and use of this
appliance, carefully read the supplied instructions.
The manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
ENGLISH 3

and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Children should be supervised to ensure that they do
not play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•This appliance is for washing and drying domestic-
type machine-washable and dryable laundry only.
•Do not use the dryer function if laundry has been
soiled with industrial chemicals.
•This appliance is designed for single household
domestic use in an indoor environment.
•This appliance may be used in, offices, hotel guest
rooms, bed & breakfast guest rooms, farm guest
houses and other similar accommodation where such
use does not exceed (average) domestic usage levels.
•Do not change the specification of this appliance.
•The appliance shall be installed as a freestanding
product or below the kitchen worktop if space margins
permit.
www.aeg.com4

•Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite
side, that would prevent the appliance door from being
fully open.
•Connect the mains plug to the mains socket only at
the end of the installation process. Make sure that the
mains plug is accessible after installation.
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
•WARNING: The appliance must not be supplied
through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on
and off by a utility.
•Ensure good air ventilation in the room where the
appliance is installed to avoid the backflow of
unwanted gases into the room from appliances
burning gas or other fuels, including open fires.
•Exhaust air must not be discharged into a flue which is
used for exhausting fumes from any appliances
burning gas or other fuels.
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 10 bar (1.0 MPa).
•The appliance maximum load is 10.0 kg. Do not
exceed the maximum load of each programme (refer
to the "Programmes" chapter).
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Wipe away lint or packaging debris that has
accumulated around the appliance.
•Items that have been soiled with substances such as
vegetable or mineral oil, acetone, alcohol, petrol,
ENGLISH 5

kerosene, spot removers, turpentine, waxes and wax
removers should be washed separately with an extra
amount of detergent before being dried in the washer
dryer.
•Do not use the appliance if items have been soiled
with industrial chemicals.
•Do not dry unwashed items in the wash dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, and rubber backed articles and
clothes, or pillows fitted with foam rubber pads should
not be dried in the washer dryer.
•Fabric softeners, or similar products, should only be
used as specified by the product manufacturer’s
instructions.
•Remove all objects from items that could be a source
of fire ignition such as lighters or matches.
•WARNING: Never stop the washer dryer before the
end of the drying cycle unless all items are quickly
removed and separated so that residual heat can
dissipate.
•The final part of the washer dryer cycle takes place
without heat (cool down cycle) to ensure that items
reach a temperature that will not cause damage to
them.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Follow the installation instructions
supplied with the appliance.
• Do not install or use the appliance
where the temperature can be less
www.aeg.com6

than 0°C or where it is exposed to the
weather.
• Always keep the appliance vertical
when it is being moved.
• Make sure that there is air circulation
between the appliance and the floor.
• Remove all the packaging and the
transit bolts.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
future they must be reattached to lock
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use a damaged
appliance.
• Do not install the appliance where the
appliance door cannot be fully
opened.
• Adjust the feet to have the necessary
space between the appliance and the
flooring.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
2.2 Electrical Connection
WARNING!
Risk of fire and electric
shock.
• WARNING: This appliance is
designed to be installed / connected
to a grounding connection in the
building.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
2.3 Water Connection
• The inlet water shall not exceed 25
°C.
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• Do not use an extension hose if the
inlet hose is too short. Contact the
Authorised Service Centre for the
replacement of the inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing
of the appliance with the use of water
in the factory.
• You can extend the drain hose to
maximum 400 cm. Contact the
Authorised Service Centre for the
other drain hose and the extension.
• Make sure that there is access to the
tap after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the glass door while a
programme operates. The glass can
get hot.
• Do not dry damaged (torn, frayed)
items that contain padding or fillings.
• If laundry has been washed with a
stain remover, carry out an additional
rinse cycle before starting a drying
cycle.
• Make sure that all metal objects are
removed from the laundry.
• Dry only fabrics that are suitable to
dry in the appliance. Follow the
cleaning instruction on the item label.
• Do not sit or stand on the open door
of the appliance.
• Do not dry dripping wet clothes in the
appliance.
ENGLISH 7

• Do not let hot items to touch the
plastic parts of the appliance.
• Remove a detergent ball (if used)
before starting a drying programme.
• Do not use a detergent ball if setting a
non-stop programme.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 10 years after the model
has been discontinued: motor and
motor brushes, transmission between
motor and drum, pumps, shock
absorbers and springs, washing drum,
drum spider and related ball bearings,
heaters and heating elements,
including heat pumps, piping and
related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware
including reset software, door, door
hinge and seals, other seals, door
locking assembly, plastic peripherals
such as detergent dispensers. Please
note that some of these spare parts
are only available to professional
repairers, and that not all spare parts
are relevant for all models.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
2.6 Disposal
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
3. PRODUCT DESCRIPTION
3.1 Special features
Your new washer-dryer meets all modern
requirements for effective treatment of
laundry with low water, energy and
detergent consumption and proper care
of fabric.
• The Wi-Fi connection and Remote
Start enable you to start a cycle, to
interact with your washing machine
and to check the washing cycle status
in remote control.
• The UniversalDose drawer with a
compartment dedicated to each type
of detergent, including a compartment
for PODS®, equipped with a system
able to spread and mixing the
detergent in an optimal way, and to
dissolve the detergent residues after
each cycle.
• The ProSense technology detects
the laundry load size defining the
programme duration in 30 seconds.
The washing programme is tailored to
the laundry load and the type of fabric
without consuming more time, energy
and water than necessary.
• The STEAM mode is a quick and
easy way to refresh the clothes. The
gentle steam phase removes odours
and reduces creases in dry fabrics so
they need little ironing.
The steam relaxes the fibres and
reduces fabric creasing. Ironing will
be easier!
• The AEG Steam Fragrance - thanks
to the steam mode - offers the perfect
solution for refreshing even the most
delicate garments without washing.
Use the delicate fragrance exclusively
www.aeg.com8

developed by AEG to add a pleasant
feeling of "just-washed" garment to
the removing odours and wrinkles
action.
3.2 Appliance overview
1 2 3 9
5
6
7
4
10
8
11 12
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
8Drain hose
9Inlet hose connection
10 Mains cable
11 Transit bolts
12 Hose support
00000000
00A
Mod. xxxxxxxxx
000V ~ 00Hz 0000 W
910000000 00
Prod.No.
B C D EA
The rating plate reports:
A. QR code
B. model name
C. product number
D. electrical ratings
E. serial number
4. TECHNICAL DATA
Dimension Width/ Height/ Total
depth
59.7 cm /84.7 cm /66.0 cm
ENGLISH 9

Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2100 W
10 A
50 Hz
Level of protection against ingress of solid particles
and moisture ensured by the protective cover, ex‐
cept where the low voltage equipment has no pro‐
tection against moisture
IPX4
Water supply 1) Cold water
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
10 bar (1.0 MPa)
Maximum wash load Cotton 10.0 kg
Maximum dry load Cotton
Synthetics
6.0 kg
4.0 kg
Spin Speed Maximum spin speed 1551 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
WARNING!
Remove all the packaging
and the transit bolts before
installing the appliance.
WARNING!
Use the gloves.
1. Remove the external film. If
necessary, use a cutter.
2. Remove the cardboard top and the
polystyrene packaging materials.
3. Remove the internal film.
4. Open the door and remove the
polystyrene piece from the door seal
and all the items from the drum.
www.aeg.com10

5. Carefully put the appliance down on
its rear side.
6. Put the front polystyrene packaging
element on the floor under the
appliance.
Make sure not to
damage the hoses.
7. Remove the polystyrene protection
from the bottom.
1
2
8. Pull up the appliance in vertical
position.
9. Remove the power supply cable and
the drain hose from the hose holders.
It is possible to see
water flowing from the
drain hose. This is due
to the testing with water
of the appliance in
factory.
10. Remove the three bolts by using the
spanner supplied with the appliance.
11. Pull out the plastic spacers.
12. Put the plastic caps, that you find in
the user manual bag, in the holes.
ENGLISH 11

We recommend that you
keep the packaging and the
transit bolts for any
movement of the appliance.
5.2 Positioning and levelling
1. Install the appliance on a flat hard
floor.
Make sure that carpets do
not stop the air circulation
below the appliance.
Make sure that the appliance
does not touch the wall or
other units.
2. Loosen or tighten the feet to adjust
the level.
WARNING!
Do not put cardboard, wood
or equivalent materials
below the appliance feet to
adjust the level.
x4
The appliance must be level and stable.
A correct adjustment of the
appliance level prevents the
vibration, noise and the
movement of the appliance
when in operation.
When the appliance is
installed on a plinth, use the
accessory described in
chapter 'Accessories'. Read
carefully the instructions
supplied with the appliance
and with the accessory.
5.3 Fixing plate kit
If you install the appliance on a plinth
that is not an accessory supplied by
AEG, secure the appliance with the fixing
plates. This spare part is available in web
shop or from authorised dealer.
Read carefully the instructions supplied
with the accessory.
5.4 The inlet hose
1. Connect the water inlet hose to the
back of the appliance.
2. Position it toward left or right
depending on the position of the
water tap.
www.aeg.com12

20º20º
45º45º
Make sure that the inlet hose
is not in vertical position.
3. If necessary, loose the ring nut to set
it in the correct position.
4. Connect the water inlet hose to the
cold water tap with 3/4" thread.
WARNING!
The inlet water shall not
exceed 25 °C.
CAUTION!
Make sure that there are no
leaks from the couplings.
Do not use an extension
hose if the inlet hose is too
short. Contact the service
centre for the replacement of
the inlet hose.
5.5 Water-stop device
The inlet hose has a water stop device.
This device prevents water leaks in the
hose because of its natural ageing.
The red sector in the window «A» shows
this fault.
A
If this occurs, close the water tap and
contact the authorized service centre to
replace the hose.
5.6 Water drainage
The drain hose should be positioned at a
height of not less than 60 cm and not
more than 100 cm from the floor.
You can extend the drain
hose to maximum 400 cm.
Contact the authorized
service centre for the other
drain hose and the
extension.
It is possible to connect the drain hose in
different ways:
1. Make a U shape with the drain hose
and put it around the plastic hose
guide.
2. On the edge of a sink - Fasten the
guide to the water tap or to the wall.
Make sure that the plastic
guide cannot move when the
appliance drains.
ENGLISH 13

Make sure that the drain
hose end is not immersed in
the water. There may be a
return of dirty water into the
appliance.
3. To a stand pipe with vent-hole -
Insert the drain hose directly into a
drain pipe. Refer to the illustration.
The end of the drain hose
must always be ventilated ,
i.e. the inner diameter of the
drain pipe (min. 38 mm -
min. 1.5") must be larger
than the external diameter of
the drain hose.
4. If the end of the drain hose looks like
this (see the picture), you can push it
directly into the stand pipe.
5. Without the plastic hose guide, to
a sink spigot - Put the drain hose in
the spigot and tighten it with a clamp.
Refer to the illustration.
Make sure that the drain
hose makes a loop to
prevent particles going into
the appliance from the sink.
6. Position the hose directly to a built-
in drain pipe in the room wall and
tighten it with a clamp.
5.7 Electrical connection
At the end of installation you can connect
the mains plug to the mains socket.
The rating plate and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are
compatible with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any
other appliances in use.
Connect the appliance to an earthed
socket.
www.aeg.com14

The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install
this appliance, contact our Authorised
Service Centre.
The manufacturer does not accept any
responsibility for damage or injury
through failure to comply with the above
safety precaution.
6. CONTROL PANEL
6.1 Control panel description
4 532 6 78
14 13 11 10 9
12
1
The options are not selectable with all washing programmes. Check the
compatibility between options and washing programmes in the "Options
compatibility with programmes" paragraph in the "Programmes" chapter.
An option can exclude another one, in this case the appliance doesn't
allow you to set the incompatible options together.
Make sure the screen and touch buttons are always clean and dry.
1On/Off push button
2Programme dial
3Favourite programmes
4Display
5PODS® touch button
6Finish In touch button and Remote
Start touch button
7Start/Pause touch button
8Time Save touch button
9STEAM mode touch button
10 DRY mode , Time Dry and Auto Dry
touch buttons
11 WASH mode touch button
12 Stains/Prewash touch button and
permanent Extra Rinse option
13 Spin touch button and permanent
Child Lock option
14 Temperature touch button
ENGLISH 15

6.2 Display
Washing phase indicator. It flashes during pre-wash and wash phase.
Rinsing phase indicator. It flashes during rinse phase.
Spinning and draining phase indicator. It flashes during spin and drain
phase.
Drying phase indicator.
Steam phase indicator.
Anti-crease phase indicator (available via APP only).
Door locked indicator.
Add garments indicator: it lights on when the programme starts and the
user can still pause the appliance and add more laundry.
Eco programme indicator: it lights on when the selected programme
and options have an eco profile.
Finish In indicator.
ProSense indicator.
APP notification to check.
Remote connection indicator.
Wi-Fi connection indicator.
www.aeg.com16

The digital indicator can show:
• Programme duration (e. g. , washing and/or drying phase).
The time shown when the programme is set could
not correspond to effective duration and change af‐
ter ProSense phase.
• Maximum load.
• Finish in time (e. g. or ).
• Cycle end ( ).
• Warning code (e.g. ).
• The led beside the digit area is on when the PODS® is ac‐
tive( ).
• When working with the APP: , (access point), (up‐
date). Please refer to the chapter 'Wi-FI - Connectivity setup'.
Maximum load indicator. The value is shown for three seconds after
programme selection, alternated with cycle duration.
Maximum laundry indicator. It blinks if the laundry amount exceeds the
declared load.
Drying time indicator.
Iron drying indicator.
Cupboard drying indicator.
Extra drying indicator.
The Temperature area:
Temperature indicator
Cold water indicator
The spin area:
Spin speed indicator
No Spin indicator. Spin phase is off.
Extra Silent indicator.
Rinse hold indicator.
Child safety lock indicator.
Pre-wash indicator.
Stain indicator.
ENGLISH 17

Extra Rinse indicator.
6.3 Multilingual badges
Adhesive badges in different languages
are supplied with the appliance.
The desired badge can be glued next to
the programme dial.
Progra m
Antial lergi
20 min. - 3 kg
Motion støj
Koge-/ Kulørt
Synteti sk
Finvask
Uld/Silke
Damp
Vattæpper
Jeans
7. DIAL AND BUTTONS
7.1 On/Off
Pressing this button for a few seconds
allows to activate or deactivate the
appliance. Two different tunes sound
while switching the appliance on or off.
As the Stand-by function automatically
deactivates the appliance to decrease
the energy consumption in a few cases,
you may need to activate the appliance
again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
7.2 Programme dial
By rotating the programme dial it is
possible to select the desired
programme.
7.3 Favourite programmes
These selector positions are available
after the appliance have been connected
to Wi-Fi.
The favourite programmes can be set
and saved via App only choosing from
the available ones which are divided into
the three categories indicated on the
control panel.
Once the favourite programmes have
been set, you can select one of them via
App or by turning the programme dial to
relevant position: the relevant led comes
on and the information on the display are
updated accordingly.
The favourite programmes
can be cancelled through the
related App command or
pressing the Factory Default
key combination.
7.4 Introduction
The options/functions are
not selectable with all
washing programmes.
Check the compatibility
between options/functions
and washing programmes in
the "Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set the incompatible
options/functions together.
Make sure the screen and
touch buttons are always
clean and dry.
7.5 PODS®
Touch this button to activate or
deactivate the PODS® option .
When activated the relevant indicator is
on.
Follow the Pods manufacturer's dosage
and storage recommendations.
Put maximum two tablets or single-dose
detergents in the PODS® compartment
in the detergent dispenser drawer.
www.aeg.com18

The option remains active also for next
cycles until it is deactivated and if it is
selectable with the set programme.
7.6 Finish In
Set this option as last after
programme and other
options selection, otherwise
it can be cancelled if you
change some setting.
This option allows choosing the time
within which a programme should
terminate. The programme end can be
postponed by one 1 hour every button
touch until 24 hours maximum.
The display shows the normal
programme duration alternatively with
the set programme end time (expressed
in hours 0h). The minimum selectable
time corresponds to rounded up hour of
the maximum duration of a programme
(e.g. if the cycle duration lasts 3:15
hours, the minimum selectable time will
be 4h).
After programme start, the door is locked
and the appliance starts the ProSense
phase. When load estimation ends, on
the display the icon of running phase
blinks and the time digit counts down in
steps of one hour and in steps of 1
minute during the last hour.
Remote start
To activate it:
1. Touch the Finish In button. The
remote indicator starts blinking.
2. Touch the Start/Pause button
within 3 seconds to confirm it. The
related icon appears steadily on
display and the door is locked.
If you set a programme via
App and it does not match
with the knob position,
text appears alternating with
programme duration.
The remote start can be deactivated in
different ways:
•before the cycle has started: touch
this button and then press the Start/
Pause button within 3 seconds:
the door unlocks;
•after the cycle has started: press the
Start/Pause button - the door
unlocks - and then touch this button;
• switch the appliance on and off;
• at the end of the cycle, when the door
unlocks.
7.7 Remote start
A quick touch of this button activates the
Remote Start function that allows you to
start, pause and stop the appliance
remotely.
The related led comes on and the related
icon appears on display.
If you set a programme via
App and it does not match
with the knob position,
text appears alternating with
programme duration.
Press and hold this button for longer time
to provide two other functions:
• hold it down for 3 seconds as long as
a click sounds: the Wi-Fi is turned on
and off.
• hold it down for 10 seconds as long
as a double beep sounds and
appears on the display: to reset the
Network Credentials.
7.8 Start/Pause
Touch the Start/Pause button to
start, pause the appliance or interrupt a
running programme.
7.9 Time Save
With this option you can decrease the
programme duration.
• If your laundry is normally or lightly
soiled, it may be advisable to shorten
the washing programme. Touch this
button once to decrease the duration.
• In case of smaller load, touch this
button twice to set an extra quick
programme.
In this case, the temperature 95°C is
not selectable.
ENGLISH 19

The led of the button is on and the
display shows the set programme
duration.
This option can also be used
to shorten the steam mode
duration.
7.10 Temperature
When you select a washing programme,
the appliance automatically proposes a
default temperature.
Touch this button repeatedly until the
desired temperature value appears on
the display.
When the display shows the indicators
and , the appliance does not heat
the water.
7.11 Spin
When you set a programme, the
appliance automatically selects the
default spin speed.
Touch this button repeatedly to:
•Change the spin speed.
The display shows only
the spin speeds available
for the set programme.
•Activate the Rinse Hold option .
The water of the last rinse is not
drained out to prevent the fabrics from
creasing. The washing programme
ends with water in the drum and the
final spin phase is not performed.
The display shows the indicator .
The drum turns regularly to reduce
creasing.
The door stays locked. The drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
Touch Start/Pause button : the
appliance performs the spinning
phase and drains the water.
•Activate the Extra silent option.
All spinning phases (intermediate spin
and final spin) are suppressed and
the programme ends with water in the
drum. This helps to reduce creasing.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are
available. In some programmes the
rinses are performed with more water.
The display shows the indicator .
The door stays locked. The drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
Touch the Start/Pause button: the
appliance performs only the draining
phase.
•No Spin .
Set this option to deactivate all spin
phases. The display shows the
indicator . The appliance
performs the only draining phase of
the selected washing programme. Set
this option for very delicate fabrics.
The rinses phase uses more water for
some washing programmes
The appliance empties the
water out automatically after
approximately 18 hours.
7.12 Stains/Prewash
Press this button repeatedly to activate
one of the two options.
The relevant indicator goes on in the
display.
•Stains
Select this option to add an anti-stain
phase to a programme in order to
treat heavily soiled or stained laundry
with stain remover.
Pour the stain remover into
compartment . The stain remover
will be added in the appropriate phase
of the washing programme.
This option is not
available with a
temperature lower than
40 °C.
•Prewash
Use this option to add a pre-wash
phase at 30 °C before the washing
phase.
This option is recommended for
heavily soiled laundry, especially if
containing sand, dust , mud and other
solid particles.
www.aeg.com20
