AEI COMMUNICATIONS SAX-8206-P User manual

VoIP Phone
SAX-8206-P / SAX-8106-P
QIG v1.0

1
1 O Ov ve er r v vi ie ew w
This Phone is a full-feature telephone that provides voice communication. Read this QIG carefully to learn how to
operate this product and take advantage of its features.
P
Pa ac ck ka ag ge e C Co on nt te en nt ts s
When unpacking the phone, ensure all the following items are present and undamaged. If anything appears to be
missing or broken, contact your dealer for a replacement.
1. Base Unit
2. RJ-45 Cable
3. Quick Installation Guide(This document)
2
2 P Pr ro od du uc ct t D De es sc cr ri ip pt ti io on n
The following contains important information to help you familiarize with the functions of the phone.
F
Fr ro on nt t V Vi ie ew w
Name
Description
1
Ring Indicator
A red light indicator means that you have incoming
calls.
2
Dialing Pad
Press the buttons to dial a phone number or enter
alphabetical characters.
3
LINE 1 / LINE 2
There are two LINEs bottom in this handset.
4
End key
Press to finish the call
5
Function keys
Hold
Press to put an active call on hold.
Mute
Press to mute a call.
Volume
Press to increase or decrease the volume of the ringer
tone.

B
Ba ac ck k V Vi ie ew w
NO.
Name
Description
1
LAN port
Connects to HUB, ADSL, or Switch(PSE)
3
3. . I In ns st ta al ll la at ti io on n
The following illustration shows how to install the phone on the wall.
4
4 O Op pe er ra at ti io on n
P
Pa ai ir ri in ng g w wi it th h m ma as st te er r u un ni it t
Please follow the step below to pair the SAX phone set with the master unit.
Please enter “* 112 *811” on master unit to standby.


Press the star key to enter the SAX menu; close the item 2 to start the pairing.


Press the line key to submit the pair.
A
An ns sw we er ri in ng g a a C Ca al ll l

An incoming call is indicated by a ringing tone and a flashing indicator at the top of both handset and base units. You
can answer the call by doing one of the followings:
Pick up the handset to answer the call.
M
Ma ak ki in ng g a a C Ca al ll l
Dialing with the Keypad
Enter the telephone number with the alphanumerical keypad.
After entering the number you want to call, press the #key to force dialing or wait for 3 seconds before the number
is dialed automatically.
C
Ca al ll l O Op pt ti io on ns s
While a call is in progress, a number of additional options are available.
P
Pu ut tt ti in ng g a a C Ca al ll l o on n H Ho ol ld d
You may want to put a call on hold temporarily while doing some work or attending to a second incoming or outgoing
call. To put a call on hold, do one of the following:
Press the HOLD key on the phone to put the call on hold.
When you receive a second call, press the next available LINE key to attend to the new call, and the first call will be
put on hold automatically.
C
Ch he ec ck ki in ng g V Vo oi ic ce e M Me es ss sa ag ge es s
If the message waiting indicator at top of handset or base unit lights up in red, it indicates that there are one or more
new messages in voicemail box.
Press the MESSAGE key on the phone to retrieve voice messages.
(An external ITSP or PBX must support voice message feature. And you need to set a voice message code before using
the voice mail feature.)
5
5 S Su up pp po or rt t
To configure through the web browser, do the following:
Ensure the phone is powered up and connected to a DCHP network.
Pick up the handset and then press *112*113#, the IP address is announced by the phone.
Open your browser (such as Chrome, Firefox, etc.) and type in the web address of the phone. For example, http://
IP.address.of.thePhone:8000
When the Web login front page is displayed. Enter the user name and the password and click Login.
The administrator’s user name and password are “admin”and “1234”respectively.
For technical support, please email to [email protected]
Model:
SAX-8206-P / SAX-8106-P
