Aeotec Smart Switch 6 User manual

Smart Switch 6 user guide.
Modified on: Thu, 5 Oct, 2017 at 1:17 AM
Aeotec by Aeon Labs Smart Switch 6.
Aeotec Smart Switch 6 has been crafted to power connected lighting using Z-Wave Plus. It is
powered by Aeotec’s Gen5 technology.
To see whether Smart Switch 6 is known to be compatible with your Z-Wave system or not,
please reference our Z-Wave gateway comparison listing. The technical specifications of Smart
Switch 6 can be viewed at that link.
Get to Know your Smart Switch.

Note: this figure is a sample of USA version. For other versions, the product
appearance would be different.
Quick start.
Getting your Smart Switch up and running is as simple as plugging it into a wall socket
and adding it to your Z-Wave network. The following instructions will tell you how to add
your Smart Switch to your Z-Wave network via Aeotec by Aeon Labs’ Z-Stick or
Minimote controller, and general instructions if using an existing gateway/controller. If
you are using other products as your main Z-Wave controller, such as a Z-Wave
gateway, please refer to the part of their respective manual that tells you how to add
new devices to your network.

If you're using an existing gateway:
1. Place your gateway or controller into Z-Wave pair or inclusion mode. (Please refer to your
controller/gateway manual on how to do this)
2. Press the Action Button on your Switch once and the LED will flash a green LED.
3. If your switch has been successfully linked to your network, its LED will become solid
green for 2 seconds. If linking was unsuccessful, the LED will return to a rainbow gradient.
If you’re using a Z-Stick:

1. Decide on where you want your Smart Switch to be placed and plug it into a wall
outlet.
2. If your Z-Stick is plugged into a gateway or a computer, unplug it.
3. Take your Z-Stick to your Smart Switch.
4. Press the Action Button on your Z-Stick.
5. Press the Action Button on your Smart Switch
6. If Smart Switch has been successfully added to your Z-Wave network, its RGB LED
will be solid. If the adding was unsuccessful, the red LED will be on for 2 seconds and then
remain colorful gradient status, repeat the instructions from step 4.
7. Press the Action Button on the Z-Stick to take it out of inclusion mode and then
return it to your gateway or computer.
If you’re using a Minimote:
1. Decide on where you want your Smart Switch to be placed and plug it into a wall
socket.
2. Take your Minimote to your Smart Switch.
3. Press the Include button on your Minimote.
4. Press the Action Button on your Smart Switch.

5. If Smart Switch has been successfully added to your Z-Wave network, its RGB
LED will be solid. If the adding was unsuccessful, the red LED will be on for 2 seconds
and then remain colorful gradient status, repeat the instructions from step 4.
6.Press any button on your Minimote to take it out of inclusion mode.
With your Smart Switch now working as a part of your smart home, you’ll be able to
configure it from your home control software. Please refer to your software’s user guide
for precise instructions on configuring Smart Switch to your needs.
Default LED color (Energy Mode).
The color of RGB LED will change according to the output load power level when it is in
Energy mode (default use [Parameter 81 [1 byte] = 0]):
While the Switch is in an ON state:
The colors of the LED will change based on the power being used by the load plugged
into Smart Switch 6.
Version
LED
indication
Output
(W)
US
Green
[0W,
900W]
Yellow
[900W,
1600]
Red
[1600W,
2000W]
AU
Green
[0W,
1000W]
Yellow
[1000W,
2000W]
Red
[2000W,
2500W]
EU
Green
[0W,
2000W]

Yellow
[1500W,
2500W]
Red
[2500W,
3000W]
While the Switch is in an OFF state:
The LED will appear as a light purple.
You can also configure the brightness and color of RGB LED when the Smart Switch is
in Night Light mode by setting Parameter 81 [1 byte] = 2, or set it into Momentary mode
by setting Parameter 81 [1 byte] = 1 to have the LED turn off after 5 seconds during a
state change.
Removing your Smart Switch from a Z-Wave network.
Your Smart Switch can be removed from your Z-Wave network at any time. You’ll need
to use your Z-Wave network’s main controller to do this and the following instructions
will tell you how to do this using a Aeotec by Aeon Labs’ Z-Stick or Minimote controller.
If you are using other products as your main Z-Wave controller, please refer to the part
of their respective manuals that tells you how to remove devices from your network.
If you're using an existing gateway:
1. Place your gateway or controller into Z-Wave unpair or exclusion mode. (Please refer to
your controller/gateway manual on how to do this)
2. Press the Action Button on your Switch.
3. If your switch has been successfully unlinked from your network, its LED will become a
rainbow gradient. If linking was unsuccessful, the LED will become green or purple
depending on how your LED mode is set.

If you’re using a Z-Stick:
1. If your Z-Stick is plugged into a gateway or a computer, unplug it.
2. Take your Z-Stick to your Smart Switch.
3. Press the Action Button on your Z-Stick.
4. Press the Action Button on your Smart Switch.
5. If your Smart Switch has been successfully removed from your network, its RGB
LED will remain colourful gradient status. If the removal was unsuccessful, the RGB
LED will still be solid (Energy mode state when the output is on or Night light mode
state when the output load is off), repeat the instructions from step 3.
6. Press the Action Button on the Z-Stick to take it out of removal mode.
If you’re using a Minimote:

1. Take your Minimote to your Smart Switch.
2. Press the Remove Button on your Minimote.
3. Press the Action Button on your Smart Switch.
4. If your Smart Switch has been successfully removed from your network, its RGB
LED will remain the colourful gradient status. If the removal was unsuccessful, the
RGB LED will still be solid (Energy mode state when the output is on or Night
light mode state when the output load is off), repeat the instructions from step 2.
5. Press any button on your Minimote to take it out of removal mode.
Advanced functions.
Changing LED mode.
You can change the mode of how the LED acts through configuring Smart Switch.
There are 3 different modes: Energy mode, Momentary indicate mode, and Night
Light mode.

Energy mode will allow the LED to follow the state of Smart Switch, when the switch is
on, the LED will be on, and while the switch is off, the current colour LED will be off and
then remain the purple colour of 10% brightness. Momentary indicate mode will
momentarily turn the LED on for 5 seconds then turn off after every state change in the
switch. Night light mode will allow the LED to be turned on and off during your selected
time of day you have configured for it.
Parameter 81 [1 byte dec] can be set to:
(0) Energy Mode
(1) Momentary Indicate Mode
(2) Night Light Mode
Advanced Security or Basic Security feature of your Smart Dimmer in Z-wave
network:
If you want your Smart Switch as a non-security device in Z-wave network, you just need to
press the Action Button once on Smart Switch when you use a controller/gateway to add/include
your Smart Switch.
In order to take full advantage of the Smart Switch functionality, you may want your Smart
Switch as a security device that uses secure/encrypted message to communicate in your Z-wave
network, so a security enabled controller/gateway is needed.
Pair in Advanced Security Mode:
Put your existing secure gateway into pair mode
During the pairing process, tap the Action button of the Smart Switch 6 twice within 1
second.

Blinks blue to indicate advanced secure pairing.
Pair in Basic Security Mode:
Put your existing gateway into pair mode
During pairing process, tap the Action button of the Smart Switch 6 once.
Blinks green to indicate basic secure pairing.
Testing Health Connectivity.
You can determine the health of your Smart Switch 6s direct connectivity to your gateway (no
routing nodes) using a manual button press, hold, and release function which is indicated by the
LED color.
1. Press and hold Smart Switch 6 Action button
2. Wait until the RGB LED turns into a Purple Color
3. Release Smart Switch 6 Action Button
The RGB LED will blink its Purple color while sending ping messages to your gateway, when it
has finished, it will blink 1 of 3 colors:
Red = Bad Health
Yellow = Moderate Health
Green = Great Health

Be sure to watch for the blink, as it will only blink once very quickly.
Reset your Smart Switch.
If at some stage, your primary controller is missing or inoperable, you may wish to reset all of
your Smart Switch 6 settings to their factory defaults and allow you to pair it to a new
gateway. To do this:
1. Press and hold the Action Button for 20 seconds
2. The LED will change between these colors:
oYellow
oPurple
oRed (blinks faster and faster)
oGreen (Successful indication of factory reset)
oRainbow LED (waiting to pair to new network)
3. When the LED changes to Green state, you may let go of the action button.
4. When the LED changes to a rainbow LED state, it will indicate that it is ready to pair to a
new network.
Firmware Update Smart Switch 6
In the case that you need to firmware update your Smart Switch 6, please refer to this article
here: https://aeotec.freshdesk.com/solution/articles/6000134294-smart-switch-6-firmware-v1-03-
update
It is currently required to have:
1. Z-Wave USB Adapter that conforms to Z-Wave Standards
2. Windows Operating System (XP, 7, 8, 10)
Additional information on other Gateways uses.

Smartthings Hub.
Smartthings hub has basic compatibility to the Smart Switch 6, it does not allow you to access
its advanced configuration functions readily. In order to make full use of your Smart Switch 6
to its fullest, you must install a custom device handler in order to access other functions of the
switch.
You can find the article for the custom device handler here:
https://aeotec.freshdesk.com/solution/articles/6000086383-using-smart-switch-6-with-
smartthings-hub-s-custom-device-type
The article contains the github code, and information used to create the article. If you need
help installing the custom device handler, please contact support about this.
More Advanced Configurations
The Smart Switch 6 has a longer list of device configurations that you can do with Smart Switch
6. These are not exposed well in most gateways, but at the least you can manually set
configurations through most Z-Wave gateways available. These configuration options may not
be available in a few gateways.
