Aercus WeatherSpy User manual

WN2810 WeatherSpy Multi-Channel Desktop
Weather Station

Aercus Instruments™ - WeatherSpy 2 | P a g e
WeatherSpy Multi-Channel Weather
Station User Manual
Contents
1 Introduction .......................................................... 4
1.1 Mode d'emploi en français...................... 4
1.2 Manuale Operativo in italiano ................. 4
1.3 This instruction manual ........................... 4
2 roduct Features .................................................. 5
3 Getting started ...................................................... 6
3.1 arts list ................................................... 6
3.1.1 Console ........................................... 7
3.1.2 Remote sensor................................ 8
3.2 Thermo-Hygrometer Sensor Set Up ........ 8
3.3 Sensor Operation Verification ............... 12
3.4 Radio-Controlled Clock .......................... 12
3.5 Remote Sensor Installation ................... 13
3.6 Display Console Set Up .......................... 14
3.7 Display Console Layout.......................... 16
4 Console Operation .............................................. 18
4.1 Setup Mode ........................................... 18
4.1.2 Setup Mode Operation ................. 21
4.2 Changing Remote Sensor Channels ....... 24
4.3 Barometric ressure .............................. 24

Aercus Instruments™ - WeatherSpy 3 | P a g e
4.3.1 Barometric ressure History .... 24
4.3.2 Relative ressure Calibration ... 24
4.3.3 Relative vs. Absolute ressure . 25
4.4 Dew point .............................................. 26
4.5 Alarm Mode .......................................... 26
4.5.1 Time Alarm ............................... 26
4.5.2 Low Temperature Alarm ........... 27
4.5.3 Cancelling an alarm .................. 28
4.6 Calibration Mode .................................. 28
4.7 MAX/MIN Mode .................................... 31
4.8 Other Console Features......................... 32
4.8.1 Colour Weather Forecasting .... 32
4.8.2 Moon phase ............................. 34
4.8.3 Temperature/Humidity Trends . 35
4.8.4 ressure Tendency Arrows ....... 36
4.8.5 Restoring Lost Connections ...... 36
5. Glossary of Terms ............................................... 37
6. Specifications ...................................................... 39
7. Contact Information ........................................... 41

Aercus Instruments™ - WeatherSpy | P a g e
1 Introduction
1.1 Mode d'emploi en français
Téléchargez ce manuel d'instructions en français sur
aercusinstruments.com/manuals/
1.2 Manuale Operativo in italiano
Scarica questo manuale di istruzioni in italiano da
aercusinstruments.com/manuals/
1.3 This instruction manual
Thanks for purchasing this WN2810 WeatherSpy
multi-channel weather. This device measures
temperature, humidity, barometric pressure and
displays moon phase and a weather tendency
forecast. This device can receive signals up to
three temperature/humidity sensors.
lease read this manual and retain it for future
reference.

Aercus Instruments™ - WeatherSpy 5 | P a g e
2 Product Features
Figure 1
1) erpetual calendar
2) Time alarm with snooze
3) Moon phase
4) Weather forecast
5) Barometric pressure (inHg, mmHg or h a)

Aercus Instruments™ - WeatherSpy 6 | P a g e
6) Wireless outdoor temperature (°C or °F) and humidity
(%RH)
7) Support up to three outdoor sensors measuring
temperature and humidity in different locations
8) Records minimum and maximum temperature and
humidity
9) Indoor temperature (°C or °F) and humidity (%RH)
10) Time and date set from DCF atomic clock (European
868MHz version only)
11) LED backlight
12) Wall hanging or free standing
13) Included transmitter (Outdoor sensor)
14) Synchronized instant reception
3 Getting started
lease set apply power to the devices in the order
described here – transmitters followed by
console/receiver.
3.1 Parts list
One Display Console
One Thermo/Hygro Sensor Unit

Aercus Instruments™ - WeatherSpy 7 | P a g e
One ower Adaptor
One Manual
3.1.1 Console
Figure 2
LIGHT/SNOOZE Key
Hanging hole
Power jack
Folding bracket

Aercus Instruments™ - WeatherSpy 8 | P a g e
3.1.2 Remote sensor
Figure 3
3.2 Thermo-Hygrometer Sensor Set Up
Note: To avoid operating problems, please take note of
battery polarity before/when inserting any batteries
(the unit could be permanently damaged incorrect
insertion). Do not use rechargeable batteries. We
recommend fresh alkaline batteries for miler outdoor
temperature ranges and fresh lithium batteries for
colder outdoor temperatures.

Aercus Instruments™ - WeatherSpy 9 | P a g e
1. lace the transmitter about 2 to 3m away from the
console. With multiple transmitters, make sure all
transmitters are powered up.
2. Remove the battery door on the back of the
thermo-hygrometer sensor by sliding down the
battery door.
Figure 4

Aercus Instruments™ - WeatherSpy 10 | P a g e
3. BEFORE inserting the batteries, locate the
switches on the inside cover of the lid of the
transmitter (see figure 4).
4. Channel Number: the WeatherSpy supports up to
three sensors. Choose a channel number for each
transmitter by, sliding the button.
5. Temperature units of measure: To change the
sensor display units of measure between °C and °F,
press the round button marked C/F.
6. Insert two AA batteries
7. Wait for a few seconds until temperature and
humidity displayed on the LCD screen of sensors.
8. Verify the correct channel number (CH) and
temperature units of measure are on the display,
as shown in Figure 5.

Aercus Instruments™ - WeatherSpy 11 | P a g e
Figure 5
(1) Temperature
(2) Temperature units (°C and °F)
(3) Channel number
(4) Relative humidity
9. Close the battery door.
10. Repeat for each additional remote sensor, verifying
each remote is on a different channel.

Aercus Instruments™ - WeatherSpy 12 | P a g e
3.3 Sensor Operation Verification
Each temperature and humidity sensor will read similar
but not necessarily identical values.
Temperature readings should be within 2°C of each
other (the accuracy is ± 1°C). Allow about 30 minutes
for all sensors to stabilise.
The humidity readings should be 10% of each other (the
accuracy is ± 5%). Allow about 30 minutes for all sensors
to stabilise.
3. Radio-Controlled Clock
Note: Only supported in the 868MHz version, within
range of the DCC signal.
After the remote sensor is powered up, the sensor will
transmit weather data for 30 seconds, and then the
sensor will begin waiting for radio-controlled clock (RCC)
reception. During this period, lasting up to five minutes,
no weather data will be transmitted to avoid
interference. Once received successfully, the RCC
reception icon will show on the outdoor sensor
LCD display.

Aercus Instruments™ - WeatherSpy 13 | P a g e
The outdoor sensor then sends the RCC signal to display
console, Once the radio controlled time is received, RCC
reception icon will show on the display console.
If the signal reception linking is not successful within five
minutes, the signal search will stop and will
automatically resume every six hours until the signal is
successfully captured. The regular data link will resume
once the RCC reception routine is finished. In some
locations, RCC signal may take a couple of days to be
acquired.
3.5 Remote Sensor Installation
Before mount the units, ensuring that the receiver can
still pick up the signal from transmitters. lease mount
the sensors in a sheltered position, out of direct
sunlight. Direct sunlight and radiant heat sources will
result in inaccurate temperature readings. Although the
sensors are water resistant, it is best to mount in a
covered area, such as under the eaves or an awning.
Use a screw or nail to affix the remote sensor to the wall,
as shown in Figure 6 or hang the remote sensor up on
string, as shown in Figure 7.

Aercus Instruments™ - WeatherSpy 1 | P a g e
Figure 6 Figure 7
3.6 Display Console Set Up
lace the remote thermo-hygrometer about 2 to 3
meters away from the display console (if the sensor is
too close, it may not be received by the display console).
1. Insert the power adapter into the power jack of the
console and plug in the adapter. The LCD display will
beep once and then light up. The brightness
selection is set to high when plugged into the
adapter. ress the LIGHT/SNOOZE key can adjust

Aercus Instruments™ - WeatherSpy 15 | P a g e
among HIGH/MIDDLE/OFF level according to your
preference.
2. Remove the battery door on the back of the display.
Insert three AAA (alkaline or lithium, avoid
rechargeable) batteries in the back of the display
console.
Note: To avoid permanent damage, please take
note of the battery polarity before inserting the
batteries.
3. Replace the battery door and fold out the desk
stand and place the console in the upright position.
Note: The batteries are intended for back-up power
only. The backlight will remain on for 5 seconds
when on battery power only. For continuous
backlight you need to use the power adapter.
4. The console will instantly display indoor
temperature, humidity, barometer, moon phase,
date, and time. The remote search icon will turn on:

Aercus Instruments™ - WeatherSpy 16 | P a g e
3.7 Display Console Layout
Note: The following illustration shows the full segments
of the LCD for description purposes only and will not
appear like this during normal operation.
Figure 8

Aercus Instruments™ - WeatherSpy 17 | P a g e
1. Time
12. Channel number
2. Moon phase
13. Outdoor humidity
3. Weather forecast icon
14. Min Outdoor humidity
4.
Day of week
15.
Max outdoor humidity
5. Date 16. Indoor temperature
6. Absolute/relative
barometric pressure
selection
17. Max indoor temperature
7. Barometric pressure 18. Min indoor temperature
8. Outdoor sensor signal
19. Indoor humidity
9. Outdoor temperature
20. Min indoor humidity
10. Max outdoor
temperature
21. Max indoor humidity
11. Min outdoor
temperature
22. MAX/MIN DAILY icon

Aercus Instruments™ - WeatherSpy 18 | P a g e
Console Operation
The console has four keys for easy operation: TEMP./+
key, ALARM key, BARO./- key and SET/CH key. There
are four program modes: Setup Mode, Alarm Mode,
Calibration Mode and Min/Max Mode.
Any program mode can be exited at any time by either
pressing the SNOOZE/LIGHT key (on the top of the
display console) or waiting for the 30-second time-out
to take effect.
.1 Setup Mode
To enter Setup Mode, hold the SET/CH key for 2
seconds. You can then cycle through the setup options
by pressing the SET/CH button multiple times, in the
following order:

Aercus Instruments™ - WeatherSpy 19 | P a g e
SET/CH Mode Settings
0 Beep On/Off ress TEMP./+ or
BARO./- to toggle
OFF and ON
1 RST- Reset max/min at
0:00
ress TEMP./+ or
BARO./- to toggle
OFF and ON
2 Time Zone (TZ) ress TEMP./+ to
increase. BARO./- to
decrease
3 12/24 Hour Format ress TEMP./+ or
BARO./- to toggle
between 12-hour
(12h) and 24-hour
(24h) format
4 Hour of Day ress TEMP./+ to
increase. BARO./- to
decrease
5 Minutes ress TEMP./+ to
increase. BARO./- to
decrease

Aercus Instruments™ - WeatherSpy 20 | P a g e
6 D-M/M-D Format ress TEMP./+ or
BARO./- to toggle
between D-M and M-
D format
7 Year ress TEMP./+ to
increase. BARO./- to
decrease
8 Month of Year ress TEMP./+ to
increase. BARO./- to
decrease
9 Day of Month ress TEMP./+ to
increase. BARO./- to
decrease
10 Temperature Units of
Measure
ress TEMP./+ to
toggle between °C
and °F
11 Barometric ressure
Units of Measure
ress TEMP./+ to
toggle between inHg,
mmHg and h a
