AeroTow T3 User manual

AeroTow T3
User manual
Are you ready to go?
989-777-0910 AmigoAeroTow.com

T3 Weight
Unit weight is 500 lbs
Drive train
2,237 watt / 3 hp
drive

Battery & Charger
x2 12V, AGM batteries.
1 / 2 / 4 amp selectable
charger

Max tow capacity
20,000 lbs on level
ground
Controls
Electric, forward /
reverse. Power, on /
off. Lighting switch.
Hydraulic lift remote.
Tires
18” x 8” x 8.5”
|Specs
Always follow all warnings and labeling on the T3.
|Labeling

|Precautions
As the operator, you are fully responsible for the safe
operation of the tug and any damage done to the aircraft or
hangar due to operation errors.
1
Familiarize yourself with the throttle and speed response of
the tug before attaching your aircraft. The tug does not stop
immediately, this is intentional to protect your aircraft from
damage.
2
Aircraft should never be moved on any type of uneven,
sloping or hilly terrain.
3
Store the tug in a dry location when not in use.
4
Always turn the tug off while not in use. The tug will
automatically turn off after 10 minutes. Toggle the power
switch to turn on.
5
Leave the tug plugged in while not in use. The smart charge
feature will prevent damage to the battery.
6
Extreme cold can negatively impact the batteries, but climate
control is not necessary in most circumstances.
7

|Assembly
DD
AA
CC
BB
FF
EE
GG
Remove the handle (A) from the T3 frame by cutting
the zipties.
1
Unscrew the nut and remove bolt (B).
2
Secure the handle to the T3 using the nut and bolt (B).
4
Connect the hydraulic control cable (D) to (E).
5
Connect the battery cable (F) to (G).
6
Insert the handle into the handle connector on the T3
frame (C).
3

|Handle controls
AA
DD
EE
BBCC
A. T3 power on / off
B. Toggles light on / off
C. Fuse knob
D. Hydraulic lift up / down
E. Press in for forward / reverse

To connect the tug to the aircraft, move the tug close to the front
wheel. Use the lower lift button on the handle controls to drop the
hydraulic lift.
Using the winch controller, run the winch line out, so there is
enough slack to attach the wheel strap around the nose gear. Then
using the winch controller (gure B), press the line in button to pull
the plane on to the lift.
Once the plane is on the lift relax the winch line by running the line
back out a small mount to allow the lift to raise without binding.
Once the wheel is lifted to desired height, use the winch controller
to tighten the strap before moving. ***Only tighten the strap before
moving the aircraft.
|Connecting your aircraft
Winch controller. Button A tightens the strap, button B
loosens the strap.
1
Hydraulic lift.
2
Wheel strap.
3
11
22
33

Check the surrounding area, and remove any obstacles or
obstructions before moving your aircraft, remove chocks.
Make sure the wheel strap is tightened around the nose gear.
Return to the handle of the tug.
Turn power on and move your aircraft using the reverse / forward
switch located on the front of the handle control box.
Chock your aircraft and loosen the wheel strap that is wrapped
around the nose gear.
Lower the hydraulic lift and remove the wheel strap.
Reverse the tug away from the aircraft.
|Moving your aircraft
|Disconnecting your aircraft
You’re ready to go!

AeroTow by Amigo Mobility
6693 Dixie Hwy, Bridgeport, MI 48722
989-777-0910 AmigoAeroTow.com
