OWNER’S MANUAL
TRINITY 32” BAMBOO AND METAL KITCHEN CART
Model # TSCPWH-1413 / TSCPDG-1413
Important / Important / Importante
FOR 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D
PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D
Intelligent Instructions
Directives intelligentes
Instrucciones Inteligentes
DOWNLOAD THE FREEAPP | TÉLÉCHARGERL’APPLICATION GRATUITE| DESCARGUE LA APLICACIÓN GRATUITA

PARTS LIST
Your TRINITY 32” Bamboo and Metal Kitchen Cart should include the following parts. Please inspect box
contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [email protected]. Parts can also be requested online
via “Contact Us” section at www.trinityii.com.
You will NOT need additional tools for assembly.
A
SHELF (3)
B
LEG (4)
C
NON-LOCKING CASTER (2)
D
LOCKING CASTER (2)
E
WASHER (24)
F
BOLT (24)
G
HEX KEY (1)
H
WRENCH (1)
I
BAMBOO TOP (1)
1© 2023 TRINITY - 800.985.5506

ASSEMBLY INSTRUCTIONS
STEP 1
Two people are recommended for ease of
assembly.
Attach (3) SHELVES (A) to (2) LEGS (B) on
same side using (12) WASHERS (E) and (12)
BOLTS (F) as shown.
Note: The end with a steel plate welded is
the bottom end of leg.
Steel plate AB
Only hand tighten BOLTS (F). Do not
fully tighten until Step 2.
EF
STEP 2
Carefully turn over partially assembled unit
from step 1 onto other side. Repeat step 1 to
assemble remaining two legs.
Put assembled cart upside down as shown.
Fully tighten all (24) BOLTS (F) with provided
HEX KEY (G).
2
© 2023 TRINITY - 800.985.5506

ASSEMBLY INSTRUCTIONS
STEP 3
Screw each CASTER (C & D) into threaded nut at bottom of each leg.
Turn clockwise to screw in place. Make sure LOCKING CASTERS (D)
are on same side.
Note: Use provided WRENCH (H) to tighten all casters completely.
Failure to do as instructed could result in caster stem breaking.
Stand cart right side up. Place BAMBOO TOP (I) on top of cart.
DC
H
I
3© 2023 TRINITY - 800.985.5506

USAGE INSTRUCTIONS
SHELF HEIGHT ADJUSTMENT
Height of middle shelf can be adjusted. Before adjusting, remove bamboo top and ensure all
items have been removed from shelves.
Unscrew (8) BOLTS (F) and (8) WASHERS (E) unfastening middle shelf from legs. Tilt middle
shelf diagonally to move it up or down to your desired height. Attach middle shelf to LEGS (B)
with (8) BOLTS (F) and (8) WASHERS (E). Fully tighten BOLTS (F) with hex key.
4
© 2023 TRINITY - 800.985.5506

SERVICE PARTS LIST –TSCPWH-1413 / TSCPDG-1413
TRINITY Customer Service provides the following replacement parts:
Part Number Description Part Number Description
1) ONA-20-009-3220 Bamboo Top 6) ZSV-99-033-3010 Non-locking Caster
2) ZSV-01-007-0613 Washer 7) XXX-97-002-0008 Wrench
3) ZSV-01-002-0615 Bolt 8) XXX-97-001-0003 Hex Key
4) PWH-04-061-3200 Leg (white) 9) PWH-03-104-3018 Shelf (white)
4) PDG-04-061-3200 Leg (dark gray) 9) PDG-03-104-3018 Shelf (dark gray)
5) ZSV-99-032-3010 Locking Caster
9
8
7
65
4
3
2
1
5© 2023 TRINITY - 800.985.5506

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and / or damage.
2. Tighten all casters completely by using the wrench. Failure to do as instructed could result
in the caster stem breaking, thereby causing the product to collapse.
3. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of the
environment and ensure to use the product in a safe and responsible manner.
4. Do NOT modify the product in any way. Unauthorized modification may impair the
function and / or safety of the product, and may affect the life of the product.Any
modifications will void product warranty.
5. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
6. Do NOT overload the product.
7. Do NOT allow children to climb or play around the product. Tipping may occur causing
injury.
8. Do NOT stand or lean on the product or use any part of this product as a step ladder.
Tipping may occur causing injury.
9. Do NOT roll the product on an uneven surface. Only move the product on a smooth
surface. Rolling over rough or uneven surface may cause casters to break or items on the
product to fall, resulting in injury and / or damage.
10. Wood and laminate flooring can be scratched or dented. Ensure your flooring can bear the
weight of loaded product before rolling loaded product across your flooring.
11. Lock all locking casters when leaving the product in stationary position.
12. Make sure that the casters are LOCKED when using the bamboo top as a cutting or work
surface.
13. Load the product evenly and place the heaviest items on the lower shelves.
14. Do NOT leave knifes or sharp objects on the bamboo top unattended.
Weight capacity per Shelf (evenly distributed) 100 lb
Weight capacity of Bamboo Top (evenly distributed) 100 lb
Total weight capacity of Cart (evenly distributed) 300 lb
© 2023 TRINITY - 800.985.5506 6

CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Bamboo top can be cleaned with damp cloth and wiped dry immediately with dry cloth.
•Bamboo top should be hand washed only and periodically treated with food safe oil.
•Clean up any spills immediately to prevent stains from forming on bamboo top.
•Do not put hot items directly on bamboo top to prevent damaging and discoloring bamboo
surface.
•The product is designed for indoor use. outdoor use is not recommended.
© 2023 TRINITY - 800.985.5506
7

PRODUCT REGISTRATION
