Afag Electric Slide Series Operational manual

Electric Slide
ES8 I ES12
Installation declaration
Module Data
Installation manual
Maintenance manual
Translation of the original operating manual
© Copyright by Afag Automation AG

2 ES8-ES12-BA vers. 1.3 en. 20190311
This operating manual is valid for:
Type Order number
ES8-15 50433800
ES8-40
50433801
ES12-20
ES12-60
ES12-100
50433802
50433803
50433804
Installation and commissioning only by qualified personnel in accordance with the instal-
lation manual.
Version of this
documentation:
ES8-ES12-BA vers. 1.3 en. 20190311
Explanation of symbols and signs:
DANGER
Designates a directly threatening danger. If the information is
not observed, death or most severe injury (invalidity) will be the
consequence!
WARNING
Designates a possible dangerous situation.
If the information is not observed, death or most severe injury
(invalidity) will be the consequence.
CAUTION
Designates a potentially dangerous situation.
If the information is not observed, property damage or light to
moderate injury will be the consequence.
NOTE
Draws attention to general notes, useful tips for the operator and
working recommendations, but which have no influence on the
health and safety of the personnel.
The current serial number is attached here
on delivery of the machine

ES8-ES12-BA vers. 1.3 en. 20190311 3
Table of Contents
1 Declaration of Incorporation for Partly Completed Machinery ................. 5
1.1 Machinery Directive: EC Directive 2006/42/EC .............................................. 5
2 Module Data .................................................................................................. 6
2.1 Safety instructions .......................................................................................... 6
2.2 Transport, handling, storage ........................................................................... 6
2.3 Description of the electric slide ....................................................................... 7
2.4 User instructions ............................................................................................. 7
2.5 Observe the notes in the operating manual! ................................................... 8
2.6 Protection against dangerous movements ..................................................... 9
2.7 Installation, connection ................................................................................... 9
2.8 Mounting Instructions ................................................................................... 11
2.9 Centring Sleeves .......................................................................................... 12
2.10 Tightening Torques for Bolts ........................................................................ 13
2.11 Operating Conditions .................................................................................... 13
2.12 Installation of the ES Electric Slides in a System ......................................... 14
2.13 Electric Slide ES8 ......................................................................................... 15
2.14 Preferred combinations for ES8 ................................................................... 16
2.15 Preferred combinations for ES12 ................................................................. 17
2.16 Programming the ES Electric Slides ............................................................. 18
3 Installation manual ..................................................................................... 19
3.1 Manufacturer's address: ............................................................................... 19
3.2 Scope of delivery .......................................................................................... 20
3.3 Intended use ................................................................................................. 20
3.4 Warranty and liability .................................................................................... 21
3.5 Safety instructions ........................................................................................ 21
3.6 Dimensional drawing ES8 ............................................................................ 22
3.7 Technical data ES8 ...................................................................................... 23
3.8 Module loads ES8 ........................................................................................ 24
3.9 Dimensional drawing ES12 .......................................................................... 25
3.10 Technical data ES12 .................................................................................... 26
3.11 Module loads ES12 ...................................................................................... 27
3.12 Safety fence at the installation site ............................................................... 28

4 ES8-ES12-BA vers. 1.3 en. 20190311
3.13 Commissioning, operation, training .............................................................. 28
3.14 Preparations prior to commissioning ............................................................ 29
3.15 Commissioning ............................................................................................. 30
3.16 Setup, Retrofitting ......................................................................................... 31
3.17 Normal operation .......................................................................................... 32
3.18 Setting speeds at the electric axes ............................................................... 33
4 Maintenance ................................................................................................ 34
4.1 After commissioning ..................................................................................... 34
4.2 Every 3 months ............................................................................................ 34
4.3 Repairs ......................................................................................................... 35
5 Accessories ................................................................................................. 36
5.1 Servo controller Overview ............................................................................ 36
5.2 Servo controller Technical Data ................................................................... 37
5.3 Overview, controller, cable, plug .................................................................. 40
5.4 Dimensional drawings for cable types .......................................................... 42
6 Disposal ....................................................................................................... 44

ES8-ES12-BA vers. 1.3 en. 20190311 5
1 Declaration of Incorporation for Partly Completed Machinery
1.1 Machinery Directive: EC Directive 2006/42/EC
Standard: EN ISO 12100:2010 (German version)
The manufacturer:
Afag Automation AG, Fiechtenstrasse 32, CH-4950 Huttwil, Switzerland
hereby declares that the following products:
ES8-15
ES8-40
ES12-20
ES12-60
ES12-100
comply with the applicable EC Directives:
EC Low-Voltage Directive: 2014/35/EU
EMC Directive 2014/30/EU
Applied harmonised standards: EN 349; EN 60204-1:2006
- Safety of machinery - General principles for design - Risk assessment and
risk reduction
- In response to a duly substantiated request, these special technical documents will
be submitted to the competent national authorities as printed documents or in elec-
tronic form (pdf).
Directive: Applied and satisfied fundamental requirements:
1.1; 1.1.1; 1.1.2; 1.1.3, 1.1.5, 1.3.2, 1.3.4 and 1.5.1
The person or company installing this partly completed machinery or combining it with
other machinery must carry out a risk assessment for the resulting machinery that satis-
fies the requirements of the EC Directive: 2006/42/EC.
Standard: EN ISO 12100:2010 (German version)
Authorised representative:
Responsibility for the compilation of the technically relevant documents lies with:
Niklaus Röthlisberger, Product Manager, Afag Automation AG, CH-4950 Huttwil
Place/date: Huttwil, 11.03.2019
Siegfried Egli
Managing Director
Afag Automation AG
Niklaus Röthlisberger
Product Manager
Afag Automation AG

6 ES8-ES12-BA vers. 1.3 en. 20190311
2 Module Data
2.1 Safety instructions
DANGER
The strong magnetic fields (even when the module is switched
off) can interfere with electronic devices, e.g. heart pacemakers,
or impair their function.
Persons with a heart pacemakers must keep a safety distance
of at least 50 cm.
No modifications may be made to the ES Electric Slide that are not described in this in-
stallation manual or have been approved in writing by Afag Automation AG. Afag Auto-
mation AG will assume no liability for any unauthorised modifications or for improper
erection, installation, operation, maintenance or repair.
2.2 Transport, handling, storage
The following values must be observed during transport and storage:
Storage temperature: 0-50°C
Humidity: < 90%, non-condensing
CAUTION
Take care when packing and unpacking the ES Electric Slides!
Careless handling of the electric slide can result in fingers be-
ing crushed as the electric slide can move back and forth when
loose!
The slide is transported in the transport packaging from Afag Automation AG.
If the packaging from Afag Automation AG is not used, the electric slide must be packed
so that it is protected against impact and dust.
The electric slides must be stored dry in the transport packaging.
The electric slides weigh from 0.1 to 0.4 kg (depending on stroke length).
NOTE
Please note!
A safety information sheet is included with each module. This infor-
mation sheet must be read by every person involved with the mod-
ule.

ES8-ES12-BA vers. 1.3 en. 20190311 7
2.3 Description of the electric slide
The ES Electric Slides are used in automation systems and are intended exclusively for
the movement of workpieces.
The ES Electric Slides are intended exclusively for operation with original LinMot compo-
nents (controllers, cables, etc.). Use for any other purpose does not constitute an intend-
ed use.
The intended use also includes compliance with the prescribed installation and removal
instructions, the service and maintenance conditions and observance of the specifica-
tions in the data sheets.
Pay attention to magnetic fields!
DANGER
The strong magnetic fields (even when the module is switched
off) can interfere with electronic devices, e.g. heart pacemakers,
or impair their function.
Persons with a heart pacemaker must keep a safety distance of
at least 50 cm.
2.4 User instructions
The ES Electric Slides are built to the state-of-the-art and the generally accepted safety
regulations and may only be used
For the intended purpose
In an operationally safe condition

8 ES8-ES12-BA vers. 1.3 en. 20190311
Description of the electric slide
ES Electric Slides are available in the following versions:
Type
Stroke
Order number
ES8-15 15 mm 50433800
ES8-40 40 mm 50433801
ES12-20 20 mm 50433802
ES12-60 60 mm 50433803
ES12-100 100 mm 50433804
Installation and commissioning only by qualified personnel in accordance with the instal-
lation manual.
2.5 Observe the notes in the operating manual!
A precondition for the safe handling and problem-free operation of the ES Electric Slides
is the knowledge of the fundamental safety regulations.
All persons involved in the installation, commissioning, maintenance and operation of the
ES machines must have read and understood the complete operating manual, in particu-
lar the chapter "Safety instructions".
Furthermore, the rules and regulations on accident prevention applicable at the place of
installation/operation must also be observed. Improper use may result in dangers to the
life and limb of the operator or third parties and in impairments to the machine or other
assets.
In the event of faults that could impair safety, the machine must be switched off immedi-
ately and secured to prevent restarting. The fault must then be remedied.
All work on the machines must be carried out with the machines depressurised and dis-
connected from the electrical power supply.
For the operation of the machines, the user must provide safety hoods, safety doors or
other safety precautions conforming to the normal safety guidelines and safety standards
which prevent people from entering or remaining in the working area of the machines
during operation. The machines may only be put into operation when the guards are se-
curely closed.

ES8-ES12-BA vers. 1.3 en. 20190311 9
2.6 Protection against dangerous movements
Dangerous movements can occur if drives are actuated incorrectly. The drive compo-
nents are monitored so that a malfunction can be effectively ruled out. For reasons of
personal safety, the risk of injury and the risk of material damage, however, this must not
be relied on completely. Faulty drive movements must be expected until installed moni-
toring devices become active.
2.7 Installation, connection
WARNING
The ES Electric Slides are set in motion by the electric control
system. If the Electric Slides cannot move freely, there is a risk
of injury and crushing in conjunction with attachments.
If attachments on the Electric Slides can pose a hazard in con-
junction with the moving slides or the superstructures, a corre-
spondingly safe operation must be ensured.
WARNING
Due to the decentralised control unit, the operator of the Elec-
tric Slide is not necessarily alongside the product and can
therefore endanger other persons in other areas.
For work at the Electric Slides, turn off the control unit of the
module and secure it against unintentional restarts. Signals
from the control unit can lead to unintentional movements of
the module, which can cause injuries.

10 ES8-ES12-BA vers. 1.3 en. 20190311
CAUTION
The ES Electric Slide is a partially completed machine.
For safe operation, the ES Electric Slide must be integrated into
the safety concept of the plant in which it is installed.
Measures must be taken to ensure that the operating personnel
cannot enter the working area of the ES Electric Slides during
operation.
Depending on the version and the installation, there is an addi-
tional safety risk, e.g. of pinching fingers!
The ES Electric Slide may only be used for its intended pur-
pose.
Measures must be taken to ensure that the operator cannot en-
ter the working area of the ES Electric Slide during normal op-
eration. This can be achieved by suitable protective measures
such as enclosures, light barriers or de-energisation of the
drive.

ES8-ES12-BA vers. 1.3 en. 20190311 11
2.8 Mounting Instructions
The ES8 and ES12 Electric Slides can be installed in a horizontal position as no load
compensation for vertical installation is intended. A vertical installation position may be
possible upon consultation. The mounting holes (M3 for ES8) and (M4 for ES12) are po-
sitioned on the base element. The slide contains mounting holes with the sizes M2.5 and
M3 (for ES8) and M4 (for ES12). Use the centring sleeves included in the scope of sup-
ply.
Mounting holes
ES8 (M2.5, M3)
Hole pitch 16 x 16 mm
On the slide and 20 x 20 mm
ES12 (M4) Hole pitch 30 x 30 mm
Mounting holes ES8 (M 3) Hole pitch 20 x 20 mm
On the base element ES12 (M4) Hole pitch 30 x 30 mm

12 ES8-ES12-BA vers. 1.3 en. 20190311
2.9 Centring Sleeves
ES8 Base element
Slide
Hole pitch 20 x 20 mm 16 x 16 mm and 20 x 20 mm
Bore and mounting thread M3 M2.5 and M3
Centring sleeves (H7) 50035831
50332257
Ø 5 mm Ø 4 mm and Ø 5 mm
ES12 Base element
Slide
Hole pitch 30 x 30 mm 30 x
30 mm
Bore and mounting thread M4 M4
Centring sleeves (H7) 11016850 Ø 7 mm Ø 7 mm
Use the centring sleeves supplied for positioning. Insert these into two diagonally op-
posed bores of the installation grid.

ES8-ES12-BA vers. 1.3 en. 20190311 13
2.10 Tightening Torques for Bolts
Bolts meeting at least the following specification must be used for installation:
Standard: VDI 2230
Strength: Class 8.8
Surface: Blue galvanised, oiled or greased
Thread Tightening torques
M3 1.1 … 1.4 Nm
M4 2.6 … 3.3 Nm
M5 5.2 … 6.5 Nm
M6 9.0 ... 11.3 Nm
M8 21.6 … 27.3 Nm
2.11 Operating Conditions
The series of the ES Electric Slides is intended for jerk-free linear movement of firmly
installed loads in non-explosive atmospheres and under the ambient and operating
conditions defined for these modules. We generally recommend that ES8 and ES12
Electric Slides are installed in a horizontal position. A vertical installation should only by
considered upon consultation with AFAG Automation AG and when using a weight com-
pensation via a spring (not included as standard).
NOTE
This installation manual must be read carefully before any work on or
with the ES Electric Slide. The ES Electric Slide may only be used
for its intended purpose.

14 ES8-ES12-BA vers. 1.3 en. 20190311
2.12 Installation of the ES Electric Slides in a System
CAUTION
The ES Electric Slides may only be installed in a system when
the control system is switched off and secured. The ES Electric
Slides may only be installed by qualified technical personnel.
Connect and disconnect cables only when the control system is
switched off!
NOTE
The plant installer bears sole responsibility for the installation of the
ES Electric Slides!

ES8-ES12-BA vers. 1.3 en. 20190311 15
2.13 Electric Slide ES8
The ES Electric Slides are electric modules with a contact-free, wear-free direct drive
(linear motor).
Cable incl. motor plug
Mounting of the periphery:
- 2x M3 with centring Ø 5 H7 hole pitch 20 mm
Mounting of the module (base element):
-
4x M3 with Ø 5 H7 centring Hole pitch 20 x 20 mm
Mounting of the module (slide):
- M2.5 with centring Ø 4 H7
- M3 with centring Ø 5 H7
- Hole pitch 16 x 16 mm and 20 x 20 mm
Bores can be screwed through
Bores can be screwed through

16 ES8-ES12-BA vers. 1.3 en. 20190311
2.14 Preferred combinations for ES8

ES8-ES12-BA vers. 1.3 en. 20190311 17
2.15 Preferred combinations for ES12

18 ES8-ES12-BA vers. 1.3 en. 20190311
2.16 Programming the ES Electric Slides
CAUTION
Commissioning of ES Electric Slides should be done in setup or
step mode. Incorrect programming can trigger an uncontrolled
movement of the ES Electric Slides. Quick or unintended
movements of the module can lead to injuries and property
damage.
Programming varies depending on the control unit used. Observe the respective manuals
of the provider of the control unit.
WARNING
When the key data is entered incorrectly in the PLC, it is possi-
ble that the ES Electric Slide will slam into the stop at full
speed. This could lead to injuries caused by flying parts.
The ES Electric Slide can perform unexpected movements when
the path measuring system fails or an end switch cable is de-
fective.
This could lead to injuries of personnel working nearby.
WARNING
The plant installer is responsible for securing the plant with a
safety fence to ensure that persons will not be harmed when the
plant is being operated.

ES8-ES12-BA vers. 1.3 en. 20190311 19
3 Installation manual
3.1 Manufacturer's address:
Afag Automation AG
Fiechtenstrasse 32
CH-4950 Huttwil
Sales Handling:
Tel. +41 62 959 87 02
www.afag.com
This installation manual is intended for:
Electric Slide ES Types ES8-15
ES8-40
ES12-20
ES12-60
ES12-100
This is partly completed machinery
The person or company installing this partly completed machinery or combining it with
other machinery must carry out a risk assessment for the resulting machinery that satis-
fies the requirements of the EC Directive: 2006/42/EC.
Standard: EN ISO 12100:2010 (German version)
For the installation of the partly completed machinery
the following conditions must be satisfied so that it can be assembled together with other
parts to form a complete machine correctly and without endangering the health and safe-
ty of persons:
Please observe the safety information in the risk assessment
Read, understand and observe the whole operating manual
Installation may only be carried out by qualified specialist personnel
Authorised representative:
Responsibility for the compilation of the technically relevant documents lies with:
Niklaus Röthlisberger, Product Manager HT, Afag Automation, CH-4950 Huttwil.

20 ES8-ES12-BA vers. 1.3 en. 20190311
3.2 Scope of delivery
Number Description
1
Module ES8
2
Centring sleeves Ø 5 x 2.5 mm
2
Mounting screws M3 x 16
1
Operating manual
Number
Description
1
Module ES12
2
Centring sleeves Ø 7 x 3 mm
2
Mounting screws M4 x 22
1
Operating manual
3.3 Intended use
ES Electric Slides are intended for intended for jerk-free linear movement of loads in non-
explosive atmospheres and under the ambient and operating conditions defined for these
modules.
NOTE
This operating manual must be read carefully before any work on
or with the ES Electric Slides.
ES Electric Slides may only be used for their intended purpose.
No modifications may be made to the ES Electric Slides that are not described in this in-
stallation manual or have been approved in writing by Afag Automation AG. Afag Auto-
mation AG will assume no liability for any unauthorised modifications or for improper
erection, installation, operation, maintenance or repair.
NOTE
When an ES Electric Slide is installed in a plant or system, it must
be completely surrounded by a safety fence.
The intended use also includes following the installation manual as well as observing the
maintenance and repair instructions prescribed by the manufacturer.
This manual suits for next models
2
Table of contents
Other Afag Controllers manuals
