NovoCon® S CO6, Energy, I/O - High Accuracy Actuator
Operating Guide
❶
IP40
IP54
IP54
IP54
❷ ❸ ❹
❺
①
②❻Calibration:
Press button ①until two
LED’s are turned on
DIP switch: ②
Manual override:
Adjust wheel ③
❼
NovoCon®analog cable
*VIHUI302*
③
②
①
Common ground shall be
used for all devices on the
same network.
Digital port
Port for CO6 actuator or Energy cable, I/O cable,
analog cable or voltage booster.
Digital port
Actuator NovoCon® ChangeOver6Flexible
NovoCon® Energy cable
- PT1000 surface sensors
NovoCon® Energy cable
- PT1000 immersed sensors
NovoCon® I/O cable
Red Power 24V
Black GND
Grey Analog input
Blue Analog input ground
NovoCon®digital cable
Red Power
Black
Green ´+´ non-inverting signal wire
White/green ´−´ inverting signal wire
Common ground for power
and bus signal wire
Purple O-ring
Actuator NovoCon®
ChangeOver6Red Power 24V
Black GND
White CO6 Control signal
Grey CO6 Feedback signal
Blue O-ring
Actuator NovoCon®
ChangeOver6Energy
Red Power 24V
Black Power ground. T1, T2 and V output signal ground.
Blue V/mA input signal ground
Grey V/mA input signal
White V output signal
Yellow T1 or resistance input
Orange T2 or resistance input

73690660/VI.HU.I3.02
2 | © Danfoss | DHS-SRMT/SI | 2017.05
Danf
oss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products
already on order pro
vided that such alterations can be made without subsequential changes being necessary eady agreed.
All trademarks in this material are property of the respec
tive companies. Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
NovoCon® S CO6, Energy, I/O - High Accuracy Actuator
E100 VXX
281624
0030471
E100 VXX
281624
0030471
MADE IN SLOVENIA
NovoCon S CO6, Energy, I/O
003Z8503
Actuator for AB-QM DN10-32
Control signal: BACnet MS/TP, Modbus RTU, 0-10V, 0-20mA
®
6430 Nordborg, Denmark
Power: 24VAC/DC, 50/60 HZ
Force: 90N. Stroke: 7 mm. Speed: 3-24s/mm
Consumption: 3.9VA running. Standby 0.9W
IP54/40, -10T55
III
01
E100 VXX
281624
0030471
E100 VXX
281624
0030471
MADE IN SLOVENIA
NovoCon S CO6, Energy, I/O
003Z8503
Actuator for AB-QM DN10-32
Control signal: BACnet MS/TP, Modbus RTU, 0-10V, 0-20mA
®
6430 Nordborg, Denmark
Power: 24VAC/DC, 50/60 HZ
Force: 90N. Stroke: 7 mm. Speed: 3-24s/mm
Consumption: 3.9VA running. Standby 0.9W
IP54/40, -10T55
III
01
01
Serial number can be removed from the
NovoCon® S and added to installation drawing.
Device Object
Instance Number
❽
❾ ❿
⓫
NovoCon® S
CO6, Energy, I/O
Application mode:
MSV:9 / 32810
Digital control (default),
Analog control,
CO6 mode,
Inverted CO6 mode
Select Valve Type
MSV:3 / 32802
(default AB-QM DN 15)
Design Flow Rate
in Digital / Analog mode
AV:0 / 32768
in CO6 mode
AV:30 / 32796 Heating
AV:31 / 32798 Cooling
 
Presettings
DIP Switch
DIP Switches 1 to 7 are used to assign the MAC address manually. Default MAC address assignment
method is Auto MAC addressing for BACnet MS/TP and DIP Switches for Modbus RTU.
For termination of last unit on the field bus, turn DIP Switch 8 ON.
Dip switch 9 is not used.
Dip switch 10 is used to select between BACnet MS/TP (OFF=Default) and Modbus RTU (ON).
When the protocol is changed on DIP Switch 10, a power cycle is required.
12345678910
ON
OFF
To avoid injury and damage to persons and
devices, it is absolutely necessary these
instructions are carefully read and observed
prior to assembly and commissioning.
Necessary assembly, start-up, and maintenance work
must be performed only by qualified, trained and
authorised personnel.
Switch off the power line before wiring the actuator.
Connect via safety isolating transformer.
Galvanic separations shall be provided for
segments crossing buildings.
Always follow the local disposal regulations.
Safety NoteSafety Note
Safety Note
⓬
If the NovoCon® S network is supplied with
two or more ACpowerboosters,cautionmust
be observed when disconnecting one of the
transformers from the high voltage power
line. As the NovoCons are connected in a daisy chain,
there may be high voltage on the primary side of the
disconnected power supply. Disconnect always both
the primary and secondary side of the transformer.
Safety Note
