AGI M42 Installation instructions

Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: 10230018 R10
Revised: January 26, 2024
Original Instructions
M42 Bucket Elevators
Assembly, Operation, and Maintenance Manual
This manual applies to:
Bucket elevator capacities: 8000–20,000 BPH (283–708 m3/h)

New in this Manual
The following changes have been made in this revision of the manual:
Description Section
Part number changes were made. Complete the Work Platform
Distributor Platform
Updates were made. Back cover
Reformatted to standard AGI manual format. All sections

This product has been designed and manufactured to meet general engineering standards. Other local
regulations may apply and must be followed by the operator. All personnel must be trained in the correct
operational and safety procedures for this product. Use the sign-off sheet below to record initial and periodic
reviews of this manual with all personnel.
Date Employee Name and Signature Employer Name and Signature

4 10230018 R10
M42 BUCKET ELEVATORS –

M42 BUCKET ELEVATORS –
10230018 R10 5
CONTENTS
1. Introduction ............................................................................................................................................ 8
1.1 Intended Use ............................................................................................................................. 8
2. Safety....................................................................................................................................................... 9
2.1 Safety Alert Symbol and Signal Words...................................................................................... 9
2.2 General Safety Information....................................................................................................... 9
2.3 Belt and Bucket Safety .............................................................................................................. 9
2.4 Torque Arm Safety .................................................................................................................. 10
2.5 Explosion Vent Safety.............................................................................................................. 10
2.6 Rotating Parts Safety............................................................................................................... 10
2.7 Strong Magnetic Fields............................................................................................................ 11
2.8 Lifting the Head Section .......................................................................................................... 11
2.9 Combustible Dust .................................................................................................................... 12
2.10 Ladder Safety......................................................................................................................... 12
2.11 Fall Protection System Safety................................................................................................ 13
2.12 Platform Safety...................................................................................................................... 13
2.13 Drives and Lockout Safety..................................................................................................... 13
2.13.1 Electric Motor Safety.............................................................................................. 14
2.14 Personal Protective Equipment............................................................................................. 14
2.15 Safety Equipment .................................................................................................................. 15
2.16 Safety Decals ......................................................................................................................... 15
2.16.1 Decal Installation/Replacement............................................................................. 15
2.16.2 Safety Decal Locations and Details ........................................................................ 15
3. Features................................................................................................................................................. 18
3.1 Main Elevator Parts ................................................................................................................. 18
3.2 Leg Cross Section Profiles........................................................................................................ 20
3.3 Drive Side Identification .......................................................................................................... 21
3.4 Stacking Drawing ..................................................................................................................... 22
4. Site Preparation .................................................................................................................................... 23
4.1 Site Layout ............................................................................................................................... 23
4.2 Foundation and Anchoring...................................................................................................... 24
4.3 Boot Footing and Pit Design Information ............................................................................... 24
4.4 Structural Capacity .................................................................................................................. 25
4.5 Locating Spouting .................................................................................................................... 25
4.6 Lateral Support of Bucket Elevator ......................................................................................... 26
4.6.1 Guy Cables Horizontal and Vertical Loads ............................................................... 27
4.7 Electrical Requirements, Controls, and Devices ..................................................................... 30
5. Pre-Installation ..................................................................................................................................... 32
5.1 Approval Drawing.................................................................................................................... 32
5.2 Before Unloading the Shipment ............................................................................................. 32
5.3 Unload the Shipment .............................................................................................................. 32
5.4 Product Storage....................................................................................................................... 33
5.5 Before You Begin..................................................................................................................... 33
6. Assembly ............................................................................................................................................... 34
6.1 Installation Safety.................................................................................................................... 34
6.2 General Assembly Instructions................................................................................................ 34

M42 BUCKET ELEVATORS –
6 10230018 R10
6.2.1 Trunking, Platforms, and Ladders General Assembly.............................................. 35
6.3 Lifting and Moving................................................................................................................... 36
6.4 General Platform Installation Requirements .......................................................................... 37
6.4.1 Platforms Hardware ................................................................................................. 37
6.4.2 Installing Floor Planks............................................................................................... 38
6.5 Installing the Work Platform ................................................................................................... 39
6.5.1 Platform Top View, Basic Dimensions...................................................................... 39
6.5.2 Raising the Head onto Supports .............................................................................. 43
6.5.3 Installing the Platform Brackets and Support Channels.......................................... 44
6.5.4 Mounting the Work Platform Base.......................................................................... 47
6.5.5 Assembling the Work Platform Base ....................................................................... 48
6.5.6 Assembling the Work Platform Basic Components................................................. 49
6.5.7 Completing the Work Platform Assembly ............................................................... 50
6.6 Installing the Distributor Platform .......................................................................................... 51
6.6.1 Platform Top View With Dimensions....................................................................... 51
6.6.2 Assembling the Distributor Platform Basic Components ........................................ 52
6.6.3 Completing the Distributor Platform Assembly....................................................... 53
6.7 Installing the Rest Platform..................................................................................................... 55
6.7.1 Platform Top View, Basic Dimensions...................................................................... 55
6.7.2 Positioning the Platform Walk Surface at the Necessary End ................................ 56
6.7.3 Assembling The Rest Platform Basic Components .................................................. 57
6.7.4 Installing the Rest Platform to the Elevator at Base to Leg Flanges
Locations...................................................................................................................... 58
6.7.5 Installing the Rest Platform at an Intermediate Location ....................................... 62
6.8 Installing the Boot ................................................................................................................... 68
6.9 Installing the Inlet Hoppers..................................................................................................... 69
6.10 Installing the Discharge Hopper............................................................................................ 70
6.11 Installing the Drive ................................................................................................................ 71
6.11.1 Drive Parts .............................................................................................................. 71
6.11.2 Torque Arm Mounting Bracket Positions .............................................................. 72
6.11.3 Mounting the Reducer to the Head Shaft and Torque Arm.................................. 72
6.11.4 Installing the Motor ............................................................................................... 74
6.11.5 Installing the Belt Guard Back and Sheaves .......................................................... 75
6.11.6 Installing and Tensioning the V-belts..................................................................... 76
6.11.7 Installing the Belt Guard Cover .............................................................................. 79
6.12 Installing Spacer Angles and Ladder Brackets ...................................................................... 79
6.13 Installing Ladders and Cages ................................................................................................. 82
6.13.1 Installing Ladder Splices ......................................................................................... 82
6.13.2 Installing Ladder Clip and Bolt Assemblies ............................................................ 83
6.13.3 Installing Ladders to Ladder Brackets and Legs..................................................... 84
6.13.4 Installing Cages, General Assembly ....................................................................... 85
6.13.5 Correct Ladder Placement at the Platform Location............................................. 87
6.13.6 Example Ladders and Platforms Installed to Leg Sections .................................... 88
6.14 Stacking the Elevator............................................................................................................. 89
6.14.1 Preparing Stackable Leg Sections for Lifting.......................................................... 89
6.14.2 Installing Guy Wire Brackets .................................................................................. 90
6.14.3 Lifting And Installing Stackable Leg Sections ......................................................... 91
6.14.4 Setting Elevator Legs .............................................................................................. 94
6.14.5 Elevator Legs Final Check and Adjustment............................................................ 94
6.15 Installing the Buckets ............................................................................................................ 95

M42 BUCKET ELEVATORS –
10230018 R10 7
6.16 Installing the Bucket Elevator Belt ........................................................................................ 97
6.16.1 Installing The Belt Into the Elevator ...................................................................... 97
6.16.2 Splicing The Belt ..................................................................................................... 99
6.16.3 Belt Splice Methods ............................................................................................. 100
6.17 Tensioning and Aligning the Bucket Elevator Belt.............................................................. 104
6.18 Adjusting the Baffle............................................................................................................. 105
7. Operation ............................................................................................................................................ 106
7.1 Operation Safety ................................................................................................................... 106
7.2 Ladders Safety ....................................................................................................................... 106
7.3 Pre-Start Inspection Checklist ............................................................................................... 107
7.4 Start-Up and Break-In............................................................................................................ 108
7.5 Emergency Shutdown ........................................................................................................... 109
7.6 Re-starting a Plugged Bucket Elevator.................................................................................. 109
7.7 Extended Shutdown .............................................................................................................. 109
8. Maintenance ....................................................................................................................................... 110
8.1 Maintenance Safety .............................................................................................................. 110
8.2 Replacement Parts ................................................................................................................ 110
8.3 Routine Maintenance............................................................................................................ 111
9. Troubleshooting.................................................................................................................................. 114
10. Appendix ........................................................................................................................................... 124
10.1 Bucket Elevator Dimensions................................................................................................ 124
10.2 Model Specifications ........................................................................................................... 126
10.3 Parts Identification .............................................................................................................. 127
10.3.1 Inspection Section Parts Identification ................................................................ 127
10.3.2 Explosion Vent Parts Identification...................................................................... 130
10.4 Spouting Accessories Types and Dimensions ..................................................................... 131
10.5 Bolt Torque Values .............................................................................................................. 133
11. Warranty ........................................................................................................................................... 134

8 10230018 R10
1. Introduction
Follow the instructions in this manual for safe use of this bucket elevator. Following proper operation
and maintenance will help to keep the bucket elevator running in optimal condition.
Keep this manual handy for frequent reference and to review with new personnel. A sign-off form is
provided on the inside front cover for your convenience. If any information in this manual is not
understood or if you need additional information, please contact AGI or your representative for
assistance.
This manual should be regarded as part of the equipment.
1.1. Intended Use
The bucket elevator is intended for use described throughout this manual and as specified on the approval
drawing. Use in any other way is considered contrary to the intended use and is not covered by the warranty.
Important
This bucket elevator is designed to handle whole grains only.
1. INTRODUCTION M42 BUCKET ELEVATORS –

10230018 R10 9
2. Safety
2.1. Safety Alert Symbol and Signal Words
This safety alert symbol indicates important safety messages in this manual. When you see
this symbol, be alert to the possibility of injury or death, carefully read the message that
follows, and inform others.
Signal Words: Note the use of the signal words DANGER,WARNING,CAUTION, and NOTICE with the safety
messages. The appropriate signal word for each message has been selected using the definitions below as a
guideline.
Indicates an imminently hazardous situation that, if not avoided, will result in serious injury or
death.
Indicates a hazardous situation that, if not avoided, could result in serious injury or death.
Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation that, if not avoided, may result in property damage.
2.2. General Safety Information
Read and understand all safety instructions, safety decals, and manuals and follow them when assembling,
operating, or maintaining the equipment.
• Only experienced personnel who are familiar with this type of assembly and
installation should perform this work. Untrained assemblers/installers expose
themselves and bystanders to possible serious injury or death.
• Do not modify the bucket elevator in any way or deviate from the instructions in this manual without
written permission from the manufacturer. Unauthorized modification or methods may impair the function
and/or safety. Any unauthorized modification will void the warranty.
• Use for intended purposes only.
• Follow a health and safety program for your worksite. Contact your local occupational health and safety
organization for information.
• Contact your local representative or AGI if you need assistance or additional information.
• Always follow applicable local codes and regulations.
2.3. Belt and Bucket Safety
• Keep body, hair, and clothing away from moving belts and
buckets.
• Lock out power before removing cover or inspection door.
M42 BUCKET ELEVATORS – 2. SAFETY

10 10230018 R10
2.4. Torque Arm Safety
Bucket Elevator gear reducers may be equipped with backstops
and torque arms / swing base. Never remove the torque arm /
swing base when the bucket elevator is loaded. Removal of the
torque arm / swing base may cause the reducer to suddenly
rotate resulting in serious injury or death.
2.5. Explosion Vent Safety
• Keep away from explosion vents during operation.
• Be aware of the location of all explosion vents for this
equipment.
2.6. Rotating Parts Safety
• Keep body, hair, and clothing away from rotating parts.
• Do not operate with any guard removed or modified. Keep
guards in good working order.
• Shut off and lock out power source before inspecting or
servicing machine.
2. SAFETY M42 BUCKET ELEVATORS –

10230018 R10 11
2.7. Strong Magnetic Fields
The bucket elevator could be equipped with strong magnets on the boot inlet.
To prevent serious injury or death.
• Stay clear! Can be harmful to pacemaker wearers and other
medical implants.
• Keep tools and other metal objects away.
2.8. Lifting the Head Section
Crush Hazard
To prevent death or serious injury when assembling head
section, do not lift the bonnet with any other component
connected to it. Lifting with other components connected will
cause the bonnet to fail and head assembly to fall.
M42 BUCKET ELEVATORS – 2. SAFETY

12 10230018 R10
2.9. Combustible Dust
The bucket elevator has been designed for safe use in areas where hazards due to combustible
dust may potentially occur. Help reduce the risk of a dust explosion by following the preventive
measures below.
Control the dust:
• Clean grain to reduce fines.
• Use equipment to minimize breakage.
• Use a filtering system to capture dust.
• Use an air system to reduce dust.
• Spray edible mineral oil on the grain to reduce air-born dust when handling.
• Paint equipment that is in the interior of a facility with a coating that is slick, not allowing dust to accumulate.
• Clean up dust deposits after equipment operation.
• Enclose all equipment to keep dust from escaping.
Control the ignition source:
• Where applicable, use an electric motor rated for the dust classification area.
• Do not smoke in any potentially hazardous area.
• Use only explosion-proof lights and electric tools.
• Do not use anything around or inside the equipment that may produce a flame or sparks unless the air and
equipment are free of dust. For example: Do not use a match/lighter, grinder, or power saw. Use brush-less
electrical tools and explosion proof flash lights.
• Where possible, keep the work area wet such that dust cannot be dispersed in the air and smoldering
processes from sparks cannot develop.
• Follow the maintenance schedule to keep equipment operating properly at low temperatures.
• Purchase replacement parts from the manufacturer or authorized dealer/distributor. Original manufacturers
parts are designed with explosion proof features where applicable.
2.10. Ladder Safety
• Do not climb ladder if damaged, wet, icy, greasy, or slippery.
• Remove slippery materials on platforms, rungs and gripping
surfaces.
• Maintain good balance by having at least three points of
contact at all times.
• Use a fall restraint and arrest system when required. Consult
your local health and safety organization.
2. SAFETY M42 BUCKET ELEVATORS –

10230018 R10 13
2.11. Fall Protection System Safety
• Ensure that the personal fall protection equipment meets the requirements of the
applicable national and local codes.
• Follow all safety and user instructions provided by the personal fall protection equipment
manufacturer during installation and use of this system.
• All users must be trained thoroughly in the safe use and limitations of the personal fall
protection equipment. Misuse of this system could result in serious injury or death.
• Ensure that the fall protection system is inspected, tested and maintained in accordance
with the manufacturer’s recommendations.
• Inspect components before each use for wear, damage and other deterioration.
• If the fall protection system has been subjected to a fall arrest or impact force, all
equipment used to arrest fall must be inspected and approved by the manufacturer or by
a competent and/or qualified person prior to being used again. If any damage is detected,
replace the equipment before resuming use.
• If a fall event should occur, immediately call emergency responders.
2.12. Platform Safety
• Check the platform working load. Do not overload. Contact AGI before adding any equipment to a platform.
• Close platform access door before and after working on the platform.
2.13. Drives and Lockout Safety
Inspect the power source(s) before using and know how to shut down in an emergency.
Whenever you service or adjust your equipment, make sure you shut down the power
source and follow lockout and tagout procedures to prevent inadvertent start-up and
hazardous energy release. Know the procedure(s) that applies to your equipment from the
following power source(s). Ensure that only 1 key exists for each assigned lock, and that
you are the only one that holds that key. Ensure that all personnel are clear before turning
on power to equipment.
WARNING
M42 BUCKET ELEVATORS – 2. SAFETY

14 10230018 R10
2.13.1 Electric Motor Safety
Power Source
• Electric motors and controls shall be installed and serviced by a qualified electrician and
must meet all local codes and standards.
• Ensure electrical wiring and cords remain in good condition; replace if necessary.
Lockout
• The main power disconnect switch should be in the locked
position during shutdown or whenever maintenance is
performed.
• If reset is required, disconnect all power before resetting
motor.
SERVICE DISCONNECT
ON
OFF
2.14. Personal Protective Equipment
The following Personal Protective Equipment (PPE) should be worn when assembling, operating or maintaining
the equipment.
•Safety Glasses
Wear safety glasses at all times to
protect eyes from debris.
•Steel-Toe Boots
Wear steel-toe boots to protect feet from
falling debris.
•Coveralls
Wear coveralls to protect skin.
•Work Gloves
Wear work gloves to protect your hands
from sharp and rough edges.
•Hard Hat
Wear a hard hat to help protect your
head.
•Fall Protection
Use a fall arrester or fall restraint when
climbing or working at heights.
•Hearing Protection
Wear ear protection to prevent hearing
damage.
2. SAFETY M42 BUCKET ELEVATORS –

10230018 R10 15
2.15. Safety Equipment
The following safety equipment should be kept on site.
•Fire Extinguisher
Provide a fire extinguisher for use in case
of an accident. Store in a highly visible
and accessible place.
•First-Aid Kit
Have a properly-stocked first-aid kit
available for use should the need arise,
and know how to use it.
2.16. Safety Decals
• Keep safety decals clean and legible at all times.
• Replace safety decals that are missing or have become illegible. See decal location figures that follow.
• Replaced parts must display the same decal(s) as the original part.
• Replacement safety decals are available free of charge from your distributor, dealer, or factory as applicable.
2.16.1 Decal Installation/Replacement
1. Decal area must be clean and dry, with a temperature above 50°F (10°C).
2. Decide on the exact position before you remove the backing paper.
3. Align the decal over the specified area and carefully press the small portion with the exposed sticky backing
in place.
4. Slowly peel back the remaining paper and carefully smooth the remaining portion of the decal in place.
5. Small air pockets can be pierced with a pin and smoothed out using the decal backing paper.
2.16.2 Safety Decal Locations and Details
Replicas of the safety decals that are attached to the bucket elevator and their messages are shown in the
figure(s) that follow. Safe operation and use of the bucket elevator requires that you familiarize yourself with
the various safety decals and the areas or particular functions that the decals apply to, as well as the safety
precautions that must be taken to avoid serious injury, death, or damage.
M42 BUCKET ELEVATORS – 2. SAFETY

16 10230018 R10
Figure 1. Safety Decal Locations
HNGI-0103b
To prevent serious injury or death, keep
away from explosion release vents during
operation.
This explosion panel and its fasteners are
specifically designed for this bucket
elevator to relieve pressure in the unlikely
event of an explosion.
This is NOT an inspection or service panel.
DO NOT remove or alter the panel or
fasteners in any way. Contact AGI for
replacement panel and fasteners.
EXPLOSION RELEASE HAZARD
WARNING
PN 90204034
(if unit has explosion vents)
ref 8110-00030
PN 90204033
ref 8110-00267
PN 90204014
ref 8110-00267
WARNING
STRUCTURAL FAILURE HAZARD
Do not remove this panel. Removal will
cause the bucket elevator to collapse.
PN 90204034
(if unit has explosion vents)
ref 8110-00030
To prevent serious injury or death, keep
away from explosion release vents during
operation.
This explosion panel and its fasteners are
specifically designed for this bucket
elevator to relieve pressure in the unlikely
event of an explosion.
This is NOT an inspection or service panel.
DO NOT remove or alter the panel or
fasteners in any way. Contact AGI for
replacement panel and fasteners.
EXPLOSION RELEASE HAZARD
WARNING
PN 90204014
ref 8110-00267
WARNING
STRUCTURAL FAILURE HAZARD
Do not remove this panel. Removal will
cause the bucket elevator to collapse.
Exposed buckets and moving parts can cause severe
injury.
Lock out power before servicing.
AMPUTATION HAZARD
WARNING
90204033
To prevent serious injury or death:
 5HDGDQGXQGHUVWDQGWKHPDQXDOEHIRUH
DVVHPEOLQJRSHUDWLQJRUPDLQWDLQLQJWKH
HTXLSPHQW
 2QO\WUDLQHGSHUVRQQHOPD\DVVHPEOHRSHUDWH
RUPDLQWDLQWKHHTXLSPHQW
 &KLOGUHQDQGXQWUDLQHGSHUVRQQHOPXVWEHNHSW
RXWVLGHRIWKHZRUNDUHD
 'RQRWPRGLI\WKHHTXLSPHQW.HHSLQJRRG
ZRUNLQJRUGHU
 /RFNRXWSRZHUEHIRUHSHUIRUPLQJPDLQWHQDQFH
 ,IWKHPDQXDOJXDUGVRUGHFDOVDUHPLVVLQJRU
GDPDJHGFRQWDFWIDFWRU\RUUHSUHVHQWDWLYHIRU
IUHHUHSODFHPHQWV
WARNING
90204031
PN 90204031
ref 8110-00008
PN 90204032
ref 8110-00023
Exposed buckets and moving parts can cause severe
injury.
Lock out power before servicing.
AMPUTATION HAZARD
WARNING
90204033
(placed behind the
guard in the
belt drive area)
PN 90204011
ref 8110-00016
PN 90204011
To prevent serious injury or
death, shut off power and
reattach guard before operating
machine.
MISSING GUARD HAZARD
WARNING
90204011 (b)
To prevent serious injury or death:
• Keep body, hair, and clothing away from rotating
pulleys, belts, chains, and sprockets.
• Do not operate with any guard removed or
modified. Keep guards in good working order.
• Shut off and lock out power source before
inspecting or servicing machine.
ENTANGLEMENT HAZARD
WARNING
90204011 (a)
PN 90204010
ref 8110-00015
(placed on
AGI M16–M48
drive guards)
PN 90204012
(placed on inspection openings)
WARNING
Exposed moving
parts can cause
severe injury
LOCK OUT POWER
before servicing
90204012 Rev 01
2. SAFETY M42 BUCKET ELEVATORS –

10230018 R10 17
Figure 2. Safety Decal Details
BEARING INSPECTION SCHEDULE
SAFE OPERATION OF THIS EQUIPMENT REQUIRES PROPER MAINTENANCE
BEARING LOCATION: _________________________________________________
DATE GREASE NAME DATE GREASE NAME
AGI , Grand Island, NE
MARK WITH BALL POINT PEN
1____________________________ 7___________________________
2____________________________ 8___________________________
3____________________________ 9___________________________
4____________________________ 10 __________________________
5____________________________ 11 __________________________
6____________________________ 12 __________________________
90204018 Rev 4
90204018
To prevent serious injury or death:
 5HDGDQGXQGHUVWDQGWKHPDQXDOEHIRUH
DVVHPEOLQJRSHUDWLQJRUPDLQWDLQLQJWKH
HTXLSPHQW
 2QO\WUDLQHGSHUVRQQHOPD\DVVHPEOHRSHUDWH
RUPDLQWDLQWKHHTXLSPHQW
 &KLOGUHQDQGXQWUDLQHGSHUVRQQHOPXVWEHNHSW
RXWVLGHRIWKHZRUNDUHD
 'RQRWPRGLI\WKHHTXLSPHQW.HHSLQJRRG
ZRUNLQJRUGHU
 /RFNRXWSRZHUEHIRUHSHUIRUPLQJPDLQWHQDQFH
 ,IWKHPDQXDOJXDUGVRUGHFDOVDUHPLVVLQJRU
GDPDJHGFRQWDFWIDFWRU\RUUHSUHVHQWDWLYHIRU
IUHHUHSODFHPHQWV
WARNING
90204031
90204031 / 8110-00008
HNGI-0437
90204011 / 8110-00016
PN 90204011
To prevent serious injury or
death, shut off power and
reattach guard before operating
machine.
MISSING GUARD HAZARD
WARNING
To prevent serious
injury or death:
 'RQRWFOLPEODGGHULI
GDPDJHGZHWLF\
JUHDV\RUVOLSSHU\
 0DLQWDLQJRRG
EDODQFHE\KDYLQJDW
OHDVWWKUHHSRLQWVRI
FRQWDFWDWDOOWLPHV
FALLING HAZARD
WARNING
6$)
SAF-136 (when equipped with a ladder)
(Place at a
visible location
near the base
of the ladder)
90204032 / 8110-00023
(placed on the boot)
Exposed buckets and moving parts can
cause severe injury.
Lock out power before removing cover or
servicing.
AMPUTATION HAZARD
WARNING
90204032
90204034 / 8110-00030
(If unit has explosion vents)
To prevent serious injury or death, keep
away from explosion release vents during
operation.
This explosion panel and its fasteners are
specifically designed for this bucket
elevator to relieve pressure in the unlikely
event of an explosion.
This is NOT an inspection or service panel.
DO NOT remove or alter the panel or
fasteners in any way. Contact AGI for
replacement panel and fasteners.
EXPLOSION RELEASE HAZARD
WARNING
90204014 / 8110-00267
WARNING
STRUCTURAL FAILURE HAZARD
Do not remove this panel. Removal will
cause the bucket elevator to collapse.
To prevent serious injury or death:
• Keep body, hair, and clothing away from rotating
pulleys, belts, chains, and sprockets.
• Do not operate with any guard removed or
modified. Keep guards in good working order.
• Shut off and lock out power source before
inspecting or servicing machine.
ENTANGLEMENT HAZARD
WARNING
90204011 (a)
90204010 / 8110-00015
Exposed buckets and moving parts can cause severe
injury.
Lock out power before servicing.
AMPUTATION HAZARD
WARNING
90204033
90204033 / 8110-00267
90204012
(placed on inspection openings)
WARNING
Exposed moving
parts can cause
severe injury
LOCK OUT POWER
before servicing
90204012 Rev 01
UP LEG
INSTALL THE INLET
HOPPER IN REPLACEMENT
OF THIS PANEL
019017 Rev 01
019017
DOWN LEG
INSTALL THE INLET
HOPPER IN REPLACEMENT
OF THIS PANEL
Rev 01
/ 90204000
90204001
(placed on the boot up-leg side)
(placed on the boot down-leg side)
M42 BUCKET ELEVATORS – 2. SAFETY

18 10230018 R10
3. Features
3.1. Main Elevator Parts
Note
The figure below is a representation of a typical AGI bucket elevator. All features may not be an exact
visual representation.
For clarity the belt guard is not shown. Do not operate the bucket elevator without the guard
installed.
Figure 3.
1
2
3
4
5
6
7
8
10
12
11
13
15
16 17
HNGI-0513
A
9
18
14
Table 1. Typical M42 Bucket Elevators Components
Item Description
1head assembly
2head pulley
3discharge hopper
4guy wire bracket
5guy cable
6spacer angle
7belt
8bucket
9up leg section
10 leg flange
11 inspection section
12 down leg section
13 inspection door
14 boot take-up
15 inlet hopper
16 boot
17 boot pulley
18 clean out door
3. FEATURES M42 BUCKET ELEVATORS –

10230018 R10 19
Figure 4.
1
2
3
4
5
HNGI-0514
A
Table 2. Select Head Components
Item Description
1speed reducer
2belt drive
3motor mount
4motor
5discharge
M42 BUCKET ELEVATORS – 3. FEATURES

20 10230018 R10
3.2. Leg Cross Section Profiles
Figure 5. 16” x 14” Leg Profile
14"
(356 mm)
(DW) Design Width “A”
16"
(406 mm)
HNGI-0515
Figure 6. 26” x 14” Leg Profile
HNGI-0516
14"
(356 mm)
(DW) Design Width “A”
26"
(660 mm)
Figure 7. 20” x 14” Leg Profile
14"
(356 mm)
(DW) Design Width “A”
20"
(508 mm)
HNGI-0517
Figure 8. 30” x 14” Leg Profile
14"
(356 mm)
(DW) Design Width “A”
30"
(762 mm)
HNGI-0518
3. FEATURES M42 BUCKET ELEVATORS –
