Liko Viking M Manual

Product Descripon
In this document, the person being lied is referred to as the paent, and the person helping them is referred to as the caregiver.
Viking M mobile li is a general-purpose li with the intended
use in; health care, intensive care and rehabilitaon.
Viking M mobile li is an excellent aid in daily transfers of both
adults and children. With 3 various liing height posions
Viking M mobile li gives a exibility for most liing situaons
such as liing to and from wheel chair, bed, toilet and oor.
Horizontal liing can also be performed in combinaon with
the Liko™ OctoStretch™ accessory.
With the Viking™ Armrest accessory, Viking M mobile li can
be used for gait training.
The control box together with the handcontrol contains
a series of features which meet the needs for a safe and
comfortable li. Data is collected in the control box (work
counter & intelligent cycle counter) and can be read out
from the informaon display.
Individual ng of Liko slings and other Liko liing
accessories to t the paent is of the utmost
importance for opmal performance and safety when
using the li.
Viking™ M
mobile li
Instrucon Guide
Viking M Prod. No. 2040045
7EN137107 Rev. 1
ENGLISH
Important informaon before use!
Liing and transferring a person always involves a level certain risk. Read the instrucon guide for both the paent li and
liing accessories before use. It is important to completely understand and adhere to the contents of the instrucon guides.
Keep the instrucon guides available to those using the product. The equipment should only be used by trained personnel.
Please contact your Hill-Rom representave in the event of any uncertaines or quesons.

2
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Table of Contents
Symbol descripon ................................................................................. 2
Safety Instrucons .................................................................................. 3
Denions .............................................................................................. 4
Technical Data ........................................................................................ 4
Dimensions ............................................................................................. 5
Assembly ................................................................................................ 5
Operaon ............................................................................................... 7
Charging the Baery ............................................................................. 10
Maximum Load ..................................................................................... 11
Recommended Liing Accessories ....................................................... 11
Troubleshoong ................................................................................... 13
Recycling instrucons ........................................................................... 13
Cleaning and Disinfecon ..................................................................... 14
Inspecon and Maintenance ................................................................ 16
Symbol Descripon
For indoor use only.
The product has extra protecon against electric shock (Insulaon Class II).
Protecon level against electric shock Type B.
Warning; this situaon require extra care and aenon
Read instrucon guide before use
This product complies with EC direcves.
IP N1 N 2 Protecon level against: ingress of solid objects (N1) and ingress of water (N2).
Manufacturer
Date of manufacture.
Cauon! consult instrucons for use
Consult instrucons for use for more informaon
Baery
,
Pb
,
All baeries in this product must be recycled separately.
- Pb underneath the symbol indicate baeries containing lead
- Single Black line underneath the symbol indicate this product have been placed on the market aer 2005.
UL Recognized Component Mark for Canada and the United States
EFUP, Environmental Friendly Usage Period (years)
Environmentally-friendly product which can be recycled and reused.
The Australian Safety/EMC
PSE Mark (Japan)
Symbol descripon
These symbols can be found in this document and/or on the product.

3
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Intended use
This product is not intended to be used by the paent alone. Liing and transferring a paent shall always be performed
with the assistance of at least one caregiver. This product is used as a means to perform the li but is not in contact with the
paent; therefore we do not go into the various paent condions in this manual. Contact your Hill-Rom representave for
support and advice.
Certain environments and condions can limit the correct us of the mobile lis, including:
Thresholds, unlevel oor surfaces, various obstacles, and extra-thick carpets. These environments and condions can cause the
wheels of the mobile li not to roll as intended, possible imbalance in the mobile li, and increased exeron by the caregiver. If
you are uncertain that your care environment fulls the requirements for correct use of the mobile li, please contact your Hill-
Rom representave for further advice and assistance.
Before use, make sure that:
• the li is assembled in accordance with the assembly instrucons;
• the liing accessory is properly aached to the li;
• the baery has been charged for at least 6 hours;
• you have read the instrucon guides for the li and liing accessories;
• personnel using the li are informed of the correct operaon and use of the li.
Before liing, always make sure that:
• the liing accessories are not damaged;
• the liing accessory is correctly aached to the li;
• the liing accessory hangs vercally and can move freely;
• the liing accessory is selected appropriately, in terms of type, size, material and design, with regard to the paent’s needs;
• the liing accessory is correctly and safely applied to the paent in order to prevent injuries;
• the latches are intact; missing or damaged latches must always be replaced;
• the sling’s strap loops are correctly connected to the sling bar hooks when the sling straps are stretched up but before the
paent is lied from the underlying surface.
Viking™ M mobile li have been tested by an accredited tesng instute and comply with the requirements specied in the
Medical Device Direcve 93/42/EEC, for Class I products.
Viking™ M mobile li comply with the requirements in EN ISO 10535:2006 and CAN/CSA Z10535-03 and applicable parts of
IEC 60601-1, EN 60601-1-2, ANSI/AAMI ES60601-1, CAN/CSA C22.2 no 60601-1, and AS/NZS 3200-1-0.
No modicaon of this product is allowed.
Parcular care must be taken when using powerful sources of electromagnec disturbance, such as diathermy, etc, so that,
for example, diathermy cables are not posioned on or near the li. If you have any quesons, please consult the responsible
assisve device technician or the supplier.
The li may not be used in areas where ammable mixtures may occur, for example, in areas where ammable goods are
stored.
Unbalanced liing poses a pping risk and may damage the li equipment!
Do not raise the li arm manually!
Never leave a paent unaended during a liing situaon!
Safety Instrucons
This Cauon noce is found on the Baery:
CAUTION! NOT TO BE OPENED BY UNAUTHORIZED PERSONNEL
DO NOT SHORT CIRCUIT
USE THE SPECIFIED CHARGER ONLY
MAY EXPOLODE IF DISPOSED IN FIRE
This Cauon noce is found on the Control box:
CAUTION! NOT TO BE OPENED BY UNAUTHORIZED PERSONNEL

4
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Denions
1. Li arm
2. Outer Tube
3. Flexlink
4. Sling Bar with latches
5. Li Mast
6. Emergency Lowering Device (mechanical)
7. Li Motor (Actuator)
8. Base
9. Front wheels
10. Rear wheels with brakes
11. Motor for base-width adjustment
12. Locking handles
13. Product decal
14. Control box with;
Emergency stop
Electrical Emergency Lowering
Electrical Emergency liing
Baery charger indicators
Informaon display
15. Baery
16 Handcontrol
17. Handles
18. *Oponal accessory: Holder for Quick Reference Guide
and color code for sling sizes.
19. Color code for sling sizes
Technical Data
Maximum load: 205 kg (450 lbs.)
Material: Aluminium
Total weight: 33 kg (72.8 Ibs.)
Weight of
heaviest part: 14,8 kg (32.6 Ibs.)
Wheels: Front: 75 mm (3 inch) twin wheels
Rear: 75 mm (3 inch) twin wheels
with brake.
Turning diameter: 1400 mm (55.2 inch)
Emergency
lowering device: Mechanical and electrical
Liing interval: 1270 mm (50.0 inch)
Liing speed
(no load)
36 mm/s
(1.4 inch/s)
Sound level: 46 dB(A)
Protecon class: IP X4
Operang Forces
of Controls: Handcontrol: 5 N
Electrical data: 24 V
Intermient
power:
Int. Op 10/90, acve operaon max
2 min. Only 10% of a given length
of me may be acve, but no more
than 2 min.
Baeries: 24 V 2.9 Ah valve-regulated
lead-acid gel baeries,
Prod. No. 2006106.
Baery charger: Internal charger,, 100-240 V AC,
50-60 Hz, max 400 mA.
Li motor: Permanent magnet motor with
mechanical safety mechanism
24 V, 10.5 A
Motor for base-
width adjustment:
Permanent magnet motor
24 V, 6 A
Surrounding
funconal
environment:
Temperature: +10°C to +40°C,
Humidity: 20% to 90% at 30°C non-
condensing, Air pressure: 800HPa to
1060HPa, Altude: max. 2000m.
The device is intended for use indoors
Type B, in accordance with the electrical
shock protecon class.
Class II equipment.
12
5
1
13
3
2
10
11
9
8
7
4
15
Viking (M)
6
Forward direcon
14
16
17
18*
BATTERY
ON CHARGE
19

5
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Dimensions
Note: The measurements are based on the li being equipped with standard sling bar. When changing to other liing accessories, check that the li sll
achieves desired liing height.
* Dierent measurements apply to Viking M depending on the height-seng posion, see “Assembly”.
** Reference measurement according to Standard EN ISO 10535:2006.
Assembly
Before assembly, make sure you have the following parts: • Locking handles
• Baery
• Instrucon guide, charger cable,
charger connector cable.
• Li mast with li arm, li motor incl. cable, sling bar and
control box with handcontrol
• Base with motor for base-width adjustment, incl. cable
Viking M Measurements: mm / inch
Top view
Lateral view
B
B1
FF1
Amax.
B2
Amin.
**600 mm (24 in)
E
M
N
O
Max. reach posion of li arm
B3
Lmin
Lmax
C
D2
D
Max. reach posion of li arm
D1
**700 mm (28 in)
Amax.* Amin.* B B1 B2 B3***CDD2** E* F F1 Lmax* Lmin* MN O
max. min. max. min.
2020
1970
1920
1440
1390
1340
1230 870 660
650
650
595
1110 690 970 560 195
1100
1050
1000
105 30
1790
1740
1690
520
470
420
385 220 495
79.5
77.6
75.6
56.7
54.7
52.8
48.4 34.3 26.0
25.6
25.6
23.4
43.3 27.2 38.2 22.0 7.7
43.3
41.4
39.4
4.2 1.2
70.5
68.5
66.5
20.5
18.5
16.5
15.2 8.7 19.5
1. Lock both rear wheels.
Place the li mast in
the foot of the base.
2. The
li mast has three height seng posions;
- low posion for lower liing heights.
- standard posion recommended in most cases.
- high posion for extra high liing height.
The distance between two holes is 50 mm (2 in).
See chapter "Dimensions" for measurements.
3. Secure the li mast with the
locking handles provided. Adjust
the posion of the locking
handles so that they point
downwards.
low posion
standard posion
high posion

6
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
10. Place the charger cable on the
hook provided on the mast
aer completed charging.
9. A) Connect the extension cable for the charging cable to the control box.
B) Insert the extension cable in the tension clip underneath the control box.
C) Connect the charging cable to the extension cable.
NOTE! Always charge the baery before using the li the rst me,
See chapter “Charging the Baery”.
A B C
8. Reset the emergency stop by turning
the buon clockwise.
ON CHARGE
BATTERY
7. Hang the handcontrol on
the handle.
6. Oponal accessories:
- Quick reference guide
- Holder for Quick reference guide.
Motor for base
adjustment.
Li motor
Handcontrol
ON CHARGE
BATTERY
Aer assembly and charging, ensure that:
• the baery has been fully charged
• li arm moons correspond with the buons on the handcontrol
• base width adjustment correspond with the buons on the handcontrol
• emergency lowering works properly
(mechanical and electrical)
• Rear wheel brakes, funcons properly.
5. Connect the baery and secure it to the control box
bracket. A click sound can be heard when the baery is
installed correctly.
4. Connect cables to the control box, see
ilustraon. Make sure plugs are fully seated.
The liing height can be aected when liing maximum load during in-run of actuator (up to 10 lis).

7
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
6
4
3
5
2
Operaon
Control Box operaon and informaon
1. Emergency Stop buon
- Acvate: Push the red buon
- Reset: Turn the red buon clockwise.
2. UP (Arrow), Electrical emergency liing.
3.
DOWN (Arrow), Electrical emergency lowering.
Operaon of the push buons 2 and 3 are done by pressing
with a narrow object into the circle mark above each (Arrow).
The Actuator movement stops as soon as the push buon is released.
4. "ON" - lights up green when the charger is connected to mains.*
5. "CHARGE" - lights up yellow constantly during charging and will turn o when
charging is completed.
6. Display Pop-up informaon:
Baery power (100 - 50 %) Ok!
Baery power (50 - 25 %) Baery needs charging.
Baery power (Less than 25 %) baery needs charging.
A buzzer will sound when pressing a push buon.
Note! If the buzzer sound starts during an ongoing li complete the li
and charge the li aerwards!
Charge the li immediately! A buzzer will sound when pressing a
push buon. The remaining baery power can only make the li arm go down.
The li is connected to the mains.
Short circuit warning!
check cables and connecons.
Warning is shown unl repaired!
Overload!
Too much load is applied to the li.
Service needed; contact Hill-Rom.
Handcontrol operaon and indicators
Operate the li using the push buons on the handcontrol. For raising and
lowering: Direconal arrows show the direcon of movement (up/down)
The liing and base movement stops as soon as the push buon is released.
Indicator: 1 - 4
1 - Overload (Kg/Ibs) light "ashes yellow", too much load is applied to the li.
2 - Green light, baery power (100 - 50 %), Ok!
- will constantly light up green when charger is connected to mains.
3 - Yellow light, baery power (50 - 25 %), baery needs charging
4 - Yellow light, baery power (Less than 25 %), baery needs charging.
A buzzer will sound when pressing a push buon.
Note! If the buzzer sound starts during an ongoing li complete the li
and charge the li aerwards!
4 - Light "ashes yellow" and a buzzer will sound when pressing a push buon.
Charge the li immediately! The remaining baery power can only make
the li arm go down.
Note! Please see chapter "Charging the Baery" for more informaon.
Cable
Push buons:
Li arm: Up / Down
Push buons:
Base width: Out / In
kg/lbs
Indicator: 1 - 4
kg/lbs
2
3
4
1
SHORT CIRCUIT
CHECK CONNECTION
!
kg/Ibs.
service
ON CHARGE
BATTERY
1

8
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Never move the li by
pulling on the actuator!
Mechanical Emergency Lowering
Enabling the emergency lowering
- Li the emergency lowering control
straight up, li unl the paent being lied
is on a rm surface, and the strap loops of
the sling can be unhooked. (the funcon
requires a load applied to the li arm).
Do not raise the
li arm manually!
Electrical emergency lowering / liing
Use a narrow object to press into the
circle mark above each (Arrow),
See chapter "Operaon" for more
informaon.
Do not use sharp objects, since this
may cause damage on the control box!
ON CHARGE
To acvate the emergency stop:
Push the red Emergency Stop
buon on the control box.
To reset the emergency stop:
Turn the buon clockwise.
ON CHARGE
BATTERY
ON CHARGE
BATTERY
Locking the Wheels
The rear wheels can be locked to prevent rotang
and turning. The locking/unlocking of the wheels is
done with the foot.
NOTE: When liing, the wheels should be unlocked
so that the li can be moved to the paent’s centre of
gravity. The wheels should be locked, however, if there
is a risk of the li rolling into the paent, for instance,
when liing from the oor.
Locked wheels during liing can increase the risk
of pping.
Unlock
Lock
www.liko.com
© Copyright Liko AB
900002568 Rev 2
2015Maj29
MOD003178
Namn: Dekal Skyddsrör
Art. nr: 900002568
Mått (ytterkant tryckt cirkel): (Ø 46 mm)
Färgkoder: Cirkel, Röd (PMS 185 C), Ilustration, 100% Svart
Övrig info: Trycks på genomskinlig rund bakgrund (IP 5700 Vinyl).
Total number of li cycles with load
Work done by actuator; Amp. x Sec.
Number of overload indicaons
Days since last service/Days between services.
xxx
xx/xxx
xxxxxx
xxxxx
A x S
kg/Ibs.
service
6. Informaon display:
Acvate informaon display by a "quick press" at a U P, push buon.
ON CHARGE
BATTERY

9
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Installaon of Latches
Aer installaon, ensure that the
spring loaded latches is taut against
the sling bar and moves freely in the
sling bar hook.
Posion of the Li when Liing
From/To: Bed Chair/Toilet Seat Floor
NOTE: Place a pillow under the paent’s
head for increased performance and comfort.
Always have the wheels locked when liing
from the oor.
Li correctly!
Before each li, make sure that:
– the Sling loops at opposite sides of the Sling are at the same height
– all the Sling loops are fastened securely in to the Slingbar hooks
– the Slingbar is level during the li, see Figure 1.
If Slingbar is not level (see Figure 2) or if the sling loops is wrongly
aached to the slingbar (see Figure 3) lower the user to a rm surface
and adjust according to the Instrucon Guide of Sling in use.
An improper li can be uncomfortable for the user and cause damage to
the li equipment! (see Figure 2 and gure 3).
Figure 1. Figure 2. Figure 3.

10
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Old baeries are to be deposited at the nearest recycling staon or given to personnel authorized by Hill-Rom.
Wallmounted charger accessory or table charger housing accessory:
Loosen the holder for the charger cable. Remove the baery pack from the control box by loosening the locking device on
top of the baery pack. See chapter "Assembly".
Charger informaon;
"ON" - lights up green when the charger is connected to mains.
"CHARGE" - lights up yellow constantly during charging and will turn o when charging is completed.
Alt. A. Place the baery pack on the wallmounted charger. Plug the charger cable into mains (100-240 VAC)
check that both "ON" and "CHARGE" on the charger lights up.
Alt. B. Place the baery pack on the charger in the table charger housing. Plug the charger cable into mains (100-240 VAC)
check that both "ON" and "CHARGE" on the charger lights up.
Alt. A Alt. B
Alternave charging procedures
ON
CHARGE
ON
CHARGE
Charging the Baery
Charger informaon
1. "ON" - lights up green when the charger is connected to mains.
2. "CHARGE" - lights up yellow constantly during charging and will turn o
when charging is completed.
Charging with the control box internal charger (standard)
Plug the charger cable into mains (100-240 VAC), see charger informaon
1 - 2 above.The baery is fully charged aer about 6 hours and the char-
ger disconnects automacally, the yellow "CHARGE" diode turn o.
For maximum baery life, baeries must be charged regularly. We
recommend charging aer each use or every night.
Maximum charge is reached aer about 6 hours. If the li is not in daily
use, we recommend aer use to acvate the emergency stop (break the
circuit) to reduce loss of the baery power.
Never charge baeries in a wet area!
ON CHARGE
NOTE! If the charger cable (coiled cable) is streched out it should be
replaced to avoid the risk of the cable geng caught and tear.
NOTE! The li cannot be used when the charger cable is plugged into a wall socket.
NOTE! If the yellow "CHARGE" diode at the control box connuos to be lit aer 8 hours,
disconnue charging and replace the baery with a new one.
NOTE! A damaged baery shall be replaced and contact with leaking uids shall be avoided.
BATTERY
ON CHARGE
1. 2.
ON CHARGE

11
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Recommended Liing Accessories
Dierent maximum loads may apply to dierent products on the assembled li unit, sling bar, sling and any other accessories
used. For the assembled li unit, the maximum load is always the lowest maximum load rang for any of the components.
For example, a Viking™ M mobile li which is approved for 205 kg (450 lbs) can be equipped with a liing accessory which is
approved for 200 kg (440 lbs). In this case, the maximum load of 200 kg (440 lbs) applies to the assembled li unit.
Study the markings on the li and liing accessories or contact your Hill-Rom representave if you have any quesons.
Maximum Load
Using liing accessories other than those approved can entail a risk.
Find generally recommended sling bars and accessories for Viking™ M mobile li described below.
When changing sling bar or other liing accessories, the highest possible liing height of the li is aected. Before changing
liing accessories you should always ensure that the li, aer change, can full the desired liing height in order to
manage the liing situaons for which the li is to be used. For addional guidance in selecng a sling, study the operang
instrucons for the respecve sling models. There you will also nd guidance for combining Liko™ sling bars with Liko slings.
Contact your Hill-Rom representave or visit www.liko.com for advice and informaon on Liko’s product range.
* this product is also available in a version with Quick-Release Hook.
SlingBar Mini 220 Prod. No. 3156005
Max. 205 kg (450 lbs)
Universal SlingBar 350* Prod. No. 3156074
Max. 300 kg (660 lbs)
Universal SlingBar 450* Prod. No. 3156075
(Standard on Viking™ M mobile li)
Max. 300 kg (660 lbs)
Universal SlingBar 600* Prod. No. 3156076
Max. 300 kg (660 lbs)
Universal SideBars 450 Prod. No. 3156079
including bag
Max. 300 kg (660 lbs)
Sling Cross-bar 450* Prod. No. 3156021
Max. 300 kg (660 lbs)
Sling Cross-bar 670* Prod. No. 3156018
Max. 300 kg (660 lbs)
SlingBar Cover Paddy 30 Prod. No. 3607001
(ts Universal SlingBars 350, 450,
and 600, as well as SlingBar Slim 350)
Holder for Quick Reference Guide Prod. No. 2000100
Quick Reference Guide Prod. No. 2040400
IMPORTANT!
This quick reference guide does not
replacethe lift’s instruction guide, which
canbe downloaded at www.liko.com.
7EN137503-01
Quick Reference Guide
English
©Copyright Liko AB
ElectricalEmergency Lowering / Raising
5
SafetyInstructions
Latches
• Read the instruction guides for the lift and
liftingaccessories before use.
• Planthe lifting operation carefully.
• Check to ensure that thesling’s strap loops
arecorrectly fastened to the sling bar hooks
whenthe sling strap is extended, but before
thepatient is lifted from the underlying surface.
• Personnel using the lift are informed of the
correctoperation and use of the lift.
• Maximumload:Viking M 205 kg (450 Ibs.)
VikingL 250kg (550 Ibs.)
VikingXL 300 kg (660 Ibs.)
Toretain max. load it is essential to use accessories
ratedfor the same max. load or greater.
7
4
MechanicalEmergency Lowering
6
Lockingthe Wheels
Unlock
Lock
Positionof the Lift when Lifting
Unbalancedlifting poses a tipping risk!
VikingM VikingL,Viking XL
Viking M / L / XL
VikingM, Viking L VikingXL
VikingM Viking L, Viking XL
(VikingM)
Chargingthe Batteries
From/To: Bed Chair/Hygienechair Floor
1
2
3
6
7
54
Indicatorlamps
1.Hand control active
2.Overload
3.Service indication
4.Expected Life Time (ELT)
HandControlIR
2
1
OperationPanel
UP
DOWN
Up(lower lifting speed)
Down(lower lifting speed)
Wideningthe base
Narrowingthe base
Green- hand control active
Yellow- change batteries
Readthe instruction guide for more information.
Note!If the lift has not been used for more
than24 hours, before the HandControl IR can
beused, the system must be activated by
pressingany button on the operation panel.
1 2 3 4
A
A
3
EmergencyStop
Reset:
Activate:
Readthe instruction guide for more information.
• Charge the lift regularly after use.
• The lift does not function during charging.
•
Thelift cannot be charged with the emergency
stopengaged.
Quickreference guides for Liko’s lifts and slings
areavailable for downloading at www.liko.com.
OtherQuick Reference Guides
Ergonomics
Cleaning
SimpleTroubleshooting
Checkto ensure that:
• the emergency stop is not pressed in, see
• the battery of the lift is charged
• the lift has been in use the last 24 hours, see
• the handcontrol does not indicate battery
replacement,see A.
3
1
• Never lift manually – let the lift do the lifting.
• Take it easy. Work calmly and methodically.
• Don’t strain your back! Work in a walking
stance with your back straight.
• Use the bed’s raising and lowering functions.
• Reducethe lever effect. Work close to the
patient and the lift.
1
Whennecessary, clean the lift with a moist cloth,
usingwarm water or disinfectant.
www.liko.com
Manufacturer:
LikoAB
SE-97592 Luleå
Sweden
[email protected]
Readthe instruction guide for more information.
UP
DOWN
XS
S
MS
M L
XL XX
L

12
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Quick-release Hook
Universal
Prod. No. 3156508
Q-link 13
Prod. No. 3156509
Quick-release Hook
TDM
Prod. No. 3156502
X
Y
Z
Quick-Release Hook
Liko™ Quick-Release Hooks is a system for quick change of liing accessories on
Liko’s mobile and staonary lis. Viking™ M mobile li must be equipped with the
Q-link 13 in order to be used with the Quick-release Hook.
The Quick-release Hook Universal ts the Universal SlingBar 350, 450 and 600
(prod. no. 3156074 - 3156076). Quick-release Hook TDM ts the SlingBar Mini
220 (prod. no. 3156005), Sling Cross-bar 450 and 670 (prod. no. 3156021 and
3156018) and Universal TwinBar 670 (prod. no. 3156077).
When changing to a sling bar with quick release hook, the liing height is reduced
by 33 mm (1.3 in) in comparison with a xed sling bar.
Contact Hill-Rom for further informaon.
Viking™ M mobile li can be used in combinaon with the Liko™ OctoStretch
for horizontal liing.
Liko™ OctoStretch with Leveller Prod. No. 3156056
Liko™ OctoStretch Prod. No. 3156055
Bag for SlingBars Prod. No. 2001025
Scale
For weighing paents in combinaon with Viking™ M mobile li, we
recommend using LikoScale™ 350 accessory (adapter 12 mm is required).
Max 350 kg (770 lbs).
LikoScale™ 350 accessory is cered according to the European Direcve
NAWI 90/384 (Non-Automac Weighing Instruments).
Kontakta Hill-Rom för mer informaon.
Viking Armrest M Prod. No. 2047011
Leg Protector Viking S, M Prod. No. 2046011
Adapter 12 mm
Prod. No. 2016504
LikoScale 350
Prod. No. 3156228
Baery charger,
for wallmounng or to use with the Table
charger housing
Prod. No. 2004106
Table charger housing
excl. charger and baery
Prod. No. 2107103
Extra baery
Prod. No. 2006106
Prod. No. 3156056

13
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Troubleshoong
The charger doesn’t work.
The li is stuck in the high posion.
If you hear unusual sound from the li.
1. Check that the charger cables are connected correctly.
2. Make sure that the baery is properly seated in the control box.
3. Try an alternave mains outlet.
4. If the problem persists, please contact Hill-Rom.
1. Make sure that the emergency stop buon has not been
acvated (shall not be pressed in).
2. Make sure that the baery is properly seated in the control box.
3. Check the baery capacity.
4. Check that the handcontrol cable is connected correctly.
5. Electrical emergency lowering, use the operaon panel to
lower the paent onto a rm surface, see chapter; Operaon.
6. Use the mechanical emergency lowering device to lower the
paent onto a rm surface, see chapter; Operaon.
7. If the problem persists, please contact Hill-Rom.
Contact Hill-Rom.
The li do not work up/down
with Hand Control.
The base-width adjustment
doesn’t work (in/out) with the
Hand Control.
1. Make sure that the emergency stop buon has not been
acvated (shall not be pressed in).
2. Check the baery capacity.
3. Make sure that the baery is properly seated in the control box.
4. Check that the charger cable is not connected to an electric outlet.
5. Check that the handcontrol cable is correctly connected to
the control box.
6. Check that the li arm actuator cable is correctly connected to
the control box.
7. Check that the base widht actuator cable is correctly connected to
the control box.
8. If the problem persists, please contact Hill-Rom.
Recycling instrucons
Waste of Electrical and Electronic
Equipment (WEEE).
Metals
Pb-batteries

14
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Cleaning and Disinfecon
Safety recommendaons
Cleaning and disinfecng procedures for Liko Mobile lis. This instrucons do not replace the facility’s own cleaning and
disinfecon policies.
• Wear protecve equipment according to manufacturer’s instrucon and per facility protocol throughout the cleaning
operaons, such as: rubber gloves, goggles, apron, face mask and shoe covers.
• Unplug mains (AC power source) before cleaning and disinfecon.
• Never clean the li by pouring water on it, steam cleaning it, or by using a high-pressure jet.
• Refer to the recommendaons made by the cleaning and disinfecng product manufacturer.
Equipment:
• Protecve equipment (such as: rubber gloves, goggles, apron, face mask and shoe covers) as recommended by the facility
protocol and manufacturers instrucons
• Clean buckets
• Cloths for washing and drying
• So brush
• Warm water
• To nd Cleaning / Disifectants compable or not compable for use on Liko’s products, follow the
”Applicaon of commonly used Cleaning / Disinfectants on Liko products” in this document.
Cleaning instrucons
1. Unplug mains (AC power source) before cleaning and disinfecon.
2. Clean the li with a cloth moistened with warm water and a neutral cleaning agent approved by your organizaon.
A so brush may be used to remove stains and resistant dirt.
3. Wipe o the enre li with a cloth moistened with clean water starng from the top and working down. The cloth shall
not be so damp that it drips. To have access to all areas run the li into the highest and lowest posions and extend the base width
adjustment enrely in and out. Remove the Baery to have access behind the baery.
NOTE! Do not clean the piston rod!
4. Pay special aenon to the following areas:
• Sling bar
• Mechanical emergency lowering
• Handles
• Control box
• Baery
• Hand control
• Emergency stop
• Operaon panel/display (where applicable)
• Lever for base width adjustment (where applicable)
• Pedal for base width adjustment (where applicable)
• Locking handles
• Wheels
Disinfecon Instrucons
1. For the use of suitable disinfectants see ”Applicaon of commonly used Cleaning / Disifectants on Liko products” in this document.
2. Use the choice of disinfectant according to the manufacturer’s instrucons and repeat the work step as in ”Cleaning instrucons"
3. Remove traces of disinfectant aer disinfecon. Wipe o the li with a cloth moistened with clean water starng from the top
and working down. The cloth shall not be so damp that it drips.
The li may not be cleaned with CSI or equivalent.
The hand control may not be cleaned with Viraguard or equivalent.
The control box may not be cleaned with Anioxy Spray or equivalent.
Do not clean!
(piston rod)

15
Viking™ M mobile li • 7EN137107 Rev. 1 www.hill-rom.com I www.liko.com
Applicaon of commonly used Cleaning / Disinfectants on Liko products
Chemical class Acve ingredient pH Cleaners /
Disinfectant *) Manufacturer *) May not be used on the
following items:
Quaternary ammonium chloride Didecyl dimethyl ammonium chloride = 8.704%
Alkyl dimethyl benzyl ammonium chloride = 8.19%
9.0 – 10.0 in use Virex II (256) Johnson/Diversey Foot rest for Sabina™ and
Roll-On™
Quaternary ammonium chloride Alkyl dimethyl benzyl ammonium chloride = 13.238%
Alkyl dimethyl ethylbenzyl ammonium chloride = 13.238%
9.5 in use HB Quat 25L 3M
Accelerated Hydrogen Peroxide Hydrogen Peroxide 0.1 -1.5%
BenzylAlcohol: 1-5% Hydrogen Peroxide 0.1 -1.5% BenzylAlcohol: 1-5%
3 Oxivir Tb Johnson/Diversey The li straps for Golvo™
and ceiling lis
Phenolic Ortho-Phenylphenol = 3.40%
Ortho-Benzyl-para-Chlorophenol = 3.03
3.1 +/- 0.4 in use Wexcide Wexford Labs
Bleach Sodium hypochlorite 12.2 Dispatch Caltech The li straps for Golvo™
and ceiling lis
Alcohol Isopropyl alcohol = 70% 5.0 – 7.0 Viraguard Veridien Hand controls for all lis Quaternary ammonium n-Alkyl dimethyl benzyl ammonium chlorides = 0.105%
n-Alkyl dimethyl ethylbenzyl ammonium chlorides = 0.105%
11.5 - 12.5 CSI Central Soluons Inc. Viking™, Liko M220™, Liko
M230™, Uno™, Sabina™, Golvo™, LikoLight™, Roll-On™, Likorall™, Mulrall™
Benzyl-C12-18-alkyldimethylammonium, chlorides
Benzyl-C12-18-alkyldimethylammonium, chlorides (22 %) 2-Phenoxyethanol (20 %) Tridecylpolyethylenglycolether (15 %) Propan-2-ol (8 %)
approx 8.6 in use Terralin Protect Shülke Foot rest for Sabina™ and
Roll-On™
Organic peroxide (type E, solid) Magnesium monoperoxyphtalate hexahydrate (50-100%)
Anionic surfactant (5-10%) Nonionic surfactant (1-5%)
5.3 in use Dismozon Pur Bode The li straps for Golvo™
and ceiling lis
Ethanol Hydrogen peroxyde (2.5-10 %)
Lauryldimethylamine oxid (0-2.5 %) Ethanol (2.5-10 %)
7Anioxy-Spray WS Anios Control box for all mobile
lis
Troclosene sodium Adipic acid 10-30%
Amorphous silica < 1% Sodium Toluene sulphonate 5-10 % Troclosene sodium 10-30 %
4-6 in use Chlor-Clean Guest Medical Ltd The li straps for Golvo™
and ceiling lis
*) Or equivalent

For trouble-free use, certain details should be checked each day the li is used:
• Inspect the li and check to make sure that there is no external damage.
• Check the sling bar aachment.
• Check the funconality of the latches.
• Check the integrity of the liing moon and the base-width adjustment.
• Check to make sure that the emergency lowering (both electrical and mechanical) works.
• Charge the baeries each day the li is used and then check that the charger works.
When necessary, clean the li with a moist cloth and check that the wheels are free from dirt. Find more detailed
informaon regarding cleaning and disinfecon of your Liko product in chapter; Cleaning and Disinfecon.
The li should not be exposed to running water.
Service
A periodic inspecon of the li should be carried out at least once per year.
Periodic inspecon, repair and maintenance should be performed only in accordance with the Liko™ Service Manual,
and by personnel authorized by Hill-Rom and using original Liko™ spare parts.
Service Agreement
Hill-Rom oers the opportunity to enter into service contracts for the maintenance and regular inspecon of your Liko
product.
Expected Life Time
The product has an expected service life of 10 years when correctly handled, serviced and periodically inspected in accordance
with Liko’s instrucons.
Parts listed below are subject to wear and tear and have specic expected life me:
- Handcontrol, expected life me 2 years,
- Baery, expected life me 3 years.
Transport and Storage
During transport, or if the li is not to be used for a long me, the Emergency Stop should be acvated.
The environment in which the li is transported and stored should have a temperature of;-10°C to +50°C (14 °F- 122°F)
and a relave humidity 20% to 90% at 30°C non-condensing the air pressure should be 800HPa to 1060HPa.
Product Changes
Liko products undergo connuous development, which is why we reserve the right to make product changes without
prior noce. Contact your Hill-Rom representave for advice and informaon about product upgrades.
Design and Quality by Liko in Sweden
The management system for both manufacturing and development of the product is cered in accordance with ISO9001
and its equivalent for the medical device industry, ISO13485. The management system is also cered in accordance with
the environmental standard ISO14001.
Inspecon and Maintenance
(C)2016. Liko R&D AB. All Rights Reserved.
Liko AB
Nedre vägen 100
SE-975 92 Luleå, Sweden
[phone]
www.hill-rom.com I www.liko.com
