Agilent Technologies PNA Series User manual

Installation and Quick Start Guide
Agilent Technologies
PNA Series Network Analyzers
Important: Please read “Preventing PNA Hard Drive
Problems” on page 2-11
Manufacturing Part Number: E8356-90001
Printed in USA
Print Date: April, 15, 2008
Supersedes: January 25, 2008
©Agilent Technologies, Inc. 2002–2008

ii E8356-90001
Warranty Statement
THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROVIDED “AS IS,” AND IS
SUBJECT TO BEING CHANGED, WITHOUT NOTICE, IN FUTURE EDITIONS. FURTHER,
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, AGILENT DISCLAIMS ALL
WARRANTIES, EITHER EXPRESS OR IMPLIED WITH REGARD TO THIS MANUAL AND
ANY INFORMATION CONTAINED HEREIN, INCLUDING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. AGILENT SHALL NOT BE LIABLE FOR ERRORS OR FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE FURNISHING, USE, OR
PERFORMANCE OF THIS DOCUMENT OR ANY INFORMATION CONTAINED HEREIN.
SHOULD AGILENT AND THE USER HAVE A SEPARATE WRITTEN AGREEMENT WITH
WARRANTY TERMS COVERING THE MATERIAL IN THIS DOCUMENT THAT CONFLICT
WITH THESE TERMS, THE WARRANTY TERMS IN THE SEPARATE AGREEMENT WILL
CONTROL.
DFARS/Restricted Rights Notice
If software is for use in the performance of a U.S. Government prime contract or
subcontract, Software is delivered and licensed as “Commercial computer software” as
defined in DFAR 252.227-7014 (June 1995), or as a “commercial item” as defined in FAR
2.101(a) or as “Restricted computer software” as defined in FAR 52.227-19 (June 1987) or
any equivalent agency regulation or contract clause. Use, duplication or disclosure of
Software is subject to Agilent Technologies’ standard commercial license terms, and
non-DOD Departments and Agencies of the U.S. Government will receive no greater than
Restricted Rights as defined in FAR 52.227-19(c)(1-2) (June 1987). U.S. Government users
will receive no greater than Limited Rights as defined in FAR 52.227-14 (June 1987) or
DFAR 252.227-7015 (b)(2) (November 1995), as applicable in any technical data.
Certification
Agilent Technologies, Inc. certifies that this product met its published specifications at the
time of shipment from the factory. Agilent Technologies, Inc. further certifies that its
calibration measurements are traceable to the United States National Institute of
Standards and Technology, to the extent allowed by the Institute's calibration facility, and
to the calibration facilities of other International Standards Organization members.

E8356-90001 iii
Assistance
Product maintenance agreements and other customer assistance agreements are available
for Agilent Technologies, Inc. products. For information about these agreements and for
other assistance, contact Agilent. Refer to “Contacting Agilent” on page 3-2.
Technology Licenses
The hardware and / or software described in this document are furnished under a license
and may be used or copied only in accordance with the terms of such license.
Trademarks
Microsoft is a U.S. registered trademark of Microsoft Corporation. Windows and MS
Windows are U.S. registered trademarks of Microsoft Corporation.
Safety Notes
The following safety notes are used throughout this manual. Familiarize yourself with
each of the notes and its meaning before operating this instrument. All pertinent safety
notes for using this product are located in Chapter 4 , “Safety, Regulatory, and
Environmental Information.”
WARNING Warning denotes a hazard. It calls attention to a procedure which, if
not correctly performed or adhered to, could result in injury or loss
of life. Do not proceed beyond a warning note until the indicated
conditions are fully understood and met.
CAUTION Caution denotes a hazard. It calls attention to a procedure that, if not
correctly performed or adhered to, could result in damage to or destruction of
the instrument. Do not proceed beyond a caution sign until the indicated
conditions are fully understood and met.

iv E8356-90001
Documentation Map
The online Help files are embedded in the analyzer, offering quick
reference to programming and user documentation. From the Help
drop-down menu, you can access the Help system in six different
languages. Also, you can view the Analyzer Product Overview
multimedia presentation and access the analyzer’s Web page.
The Installation and Quick Start Guide helps to quickly familiarize
yourself with the analyzer. Procedures are provided for installing,
configuring, and verifying the operation of the analyzer.
Downloading PNA Documentation from the Web
Documentation for all PNA models is available at http://na.tm.agilent.com/pna/.
This includes PDF versions of PNA Help (the online Help files that are embedded in the
network analyzer), Service Guides, and Installation Notes.

Contents
E8356-90001 Contents-v
1. Operating Precautions
Preventing Electrostatic Discharge Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Preventing Test Port Connector Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Preventing Electrical Overstress Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
2. Installing Your Analyzer
STEP 1. Check the Shipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
STEP 2. Meet Electrical and Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . .2-4
STEP 3. Install the Analyzer on a Bench Top or in an Equipment Rack. . . . . . . . . . . . . . . .2-6
To Install on a Bench Top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
To Install in an Equipment Rack
(Option 1CP2- Rack Mounting For Instruments Equipped With Handles1)
(Option 1CM - Rack Mounting For Instruments Not Equipped With Handles) . . . . . . . . .2-6
STEP 4. Connect the Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
STEP 5. Start Up the Analyzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
STEP 6. Perform Administrative Tasks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
STEP 7. Run the Operator’s Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
STEP 8. Turn Off the Analyzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
Hibernate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
Shutdown. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
Preventing PNA Hard Drive Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Observe Proper Shutdown Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Do NOT Modify or Reconfigure the Operating System. . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Install Antivirus Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Install Windows Critical Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Use AgileUpdate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
3. Getting Help with Your Analyzer
Help System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
PNA on the Internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Contacting Agilent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
4. Safety, Regulatory, and Environmental Information
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Shipment for Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
General Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Safety Earth Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Before Applying Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4
Instructions for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4
Instrument Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Compliance with German Noise Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
EMC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Environmental Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

Contents-vi E8356-90001
Contents
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

E8356-90001 1-1
1Operating Precautions
IMPORTANT Most causes of instrument failure can be avoided if you will apply the
information in this section. PLEASE READ!
Preventing Electrostatic Discharge Damage
Protection against electrostatic discharge (ESD) is essential while removing assemblies
from or connecting cables and assemblies (DUT) to the network analyzer. Static electricity
can build up on your body and can easily damage sensitive internal circuit elements when
discharged. Static discharges too small to be felt can cause permanent damage. To prevent
damage to the instrument:
•always have a grounded, conductive table mat in front of your test equipment.
•always wear a grounded wrist strap, connected to a grounded conductive table mat,
having a 1 MΩresistor in series with it, when handling components and assemblies or
when making connections.
•always wear a heel strap when working in an area with a conductive floor. If you are
uncertain about the conductivity of your floor, wear a heel strap.
•always ground yourself before you clean, inspect, or make a connection to a
static-sensitive device or test port. You can, for example, grasp the grounded outer shell
of the test port or cable connector briefly.
•always ground the center conductor of a test cable and DUT before making a connection
to the analyzer test port or other static-sensitive device. This can be done as follows:
1. Connect a short (from your calibration kit) to one end of the cable and DUT to short
the center conductor to the outer conductor.
2. While wearing a grounded wrist strap, grasp the outer shell of the cable and DUT
connector.
3. Connect the other end of the cable and DUT to the test port and remove the short
from the cable.

1-2 E8356-90001
Operating Precautions
Preventing Electrostatic Discharge Damage
The following table lists Agilent part numbers for ESD protection devices. To order, refer
to “Contacting Agilent” on page 3-2. Figure 1-1 shows a typical ESD protection setup using
a grounded mat and wrist strap.
Figure 1-1 ESD Protection Setup
Description Qty Agilent
Part Number
ESD Protection Devices
Grounding wrist strap 1 9300-1367
5 ft grounding cord for wrist strap 1 9300-0980
2 x 4 ft conductive table mat and 15 ft ground wire 1 9300-0797

E8356-90001 1-3
Operating Precautions
Preventing Test Port Connector Damage
Preventing Test Port Connector Damage
NOTE Agilent strongly recommends that adapters be used as connector savers to
minimize the wear on the analyzer test port connectors. Use
instrument-grade quality adapters or better.
For more information on the proper use and maintenance of connectors, search the
analyzer’s Help system for “Connector Care.” See Chapter 3 , “Getting Help with Your
Analyzer.”
Visual Inspection and Gaging Connectors
Do Do Not
Inspect connectors with magnifying glass Use a connector with a bent or broken center
conductor
Look for metal debris, deep scratches or dents Use a connector with deformed threads
Inspect and gage connectors Use a connector with a protruding center
conductor
Use correct torque wrench Use an out-of-specification connector
Making Connections
Do Do Not
Align connectors first Cross-thread the connection
Rotate only the connector nut Twist connector body to make the connection
Use correct torque wrench Mate different connector types

1-4 E8356-90001
Operating Precautions
Preventing Electrical Overstress Damage
Preventing Electrical Overstress Damage
Excessive RF power or voltage applied to the ports on the front panel will damage the
analyzer. Each port has a label (see photo below) that shows damage levels – these levels
must not be exceeded. Damage levels are also listed in the Specifications section of the
analyzer’s Help system. To view the Help system, see Chapter 3 , “Getting Help with Your
Analyzer.” in this document.
Two ways to protect the PNA input ports from high RF power:
1. Use power limiters at the ports. Information on limiters can be found at:
www.agilent.com/find/mta.
2. Apply the recommendations in PNA Application Note 1408-10, “Recommendations for
Testing High-Power Amplifiers,” found at:
http://cp.literature.agilent.com/litweb/pdf/5989-1349EN.pdf.
Figure 1-2. Labels Showing Damage Level for Each Port

E8356-90001 2-1
2Installing Your Analyzer
STEP 1. Check the Shipment
1. Unpack the contents of the shipping container. (Keep the packaging material in case the
analyzer needs to be returned to the factory.)
Note: The PNA is shipped with ESD-safe protective end caps on the test ports and metal
covers for the front-panel jumpers. Save these items for reuse to ensure shipment safety of
the PNA.
WARNING The network analyzer is heavy. It is recommended that two
individuals, or a mechanical lift, be used to lift or transport the
instrument.
2. Carefully inspect the analyzer to make sure that it was not damaged during shipment.
If your analyzer was damaged during shipment, contact Agilent Technologies. Refer to
“Contacting Agilent” on page 3-2.

2-2 E8356-90001
Installing Your Analyzer
STEP 1. Check the Shipment
3. Use the Contents List in the shipping container to verify the completeness of your shipment.
Although this list is the most accurate, you can also use the following illustration to verify the
items in your shipment. If your shipment is not complete, contact Agilent Technologies. Refer to
“Contacting Agilent” on page 3-2.
Item
Number Part Number Part Description
1 E8356-90001 Installation and Quick Start Guide (this document)
2Uniqueto
country
AC Power Cord
3not applicableaUSB Keyboard (English only)
4not applicablea
a. See the Contents List in the shipping container for the current part number.
USB Mouse
5 5063-9229 Front Handle Kit, RF-Frequency Model
5063-9230b
b. Front handles are not available for the N5242A.
Front Handle Kit, Microwave-Frequency Model
6 W1312-40032 Hole plugs - used to replace the bottom plastic feet of the
PNA when installed in an equipment rack.

E8356-90001 2-3
Installing Your Analyzer
STEP 1. Check the Shipment
NOTE A parallel port adapter, part number 1253-4226, was included with early versions of
the PNA. This adapter is no longer necessary.
4. If you ordered any of the following options, check the parts. Option 1CM or 1CPa(item
numbers 1 or 2, below) are shipped in a separate container.
a. Option 1CP is not available for the N5242A.
Item
Number Option Number Part Description
1 1CM Rack Mount Flange Kit (For analyzers not equipped with
handles)
2 Rack Mount Rail Set
11CPaRack Mount Flange Kit (For analyzers equipped with
handles)
2 Rack Mount Rail Set

2-4 E8356-90001
Installing Your Analyzer
STEP 2. Meet Electrical and Environmental Requirements
STEP 2. Meet Electrical and Environmental Requirements
1. Ensure the available AC power source
meets the following requirements:
2. Ensure the operating environment meets
the requirements found in “Environmental
Information” on page 4-7.
CAUTION This instrument has
autoranging line voltage
input. Be sure the supply
voltage is within the specified
range.
• Frequency
❏50/60/400 Hz for 100 to 120 V -
models E836xA/B and N5230A
❏50/60 Hz for 100 to 120 V - model
N5242A
❏50/60 Hz for 220 to 240 V
•Voltage
❏120/240 VAC
• Power (maximum consumed)
❏350 W - models E836xA/B and
N5230A
❏450 W - model N5242A
NOTE Some analyzer performance
parameters are specified for
25 °C. Refer to the Help
system in the analyzer for the
complete specifications.
3. Verify that the AC power cable is not damaged, and that the power-source outlet
provides a protective earth contact.

E8356-90001 2-5
Installing Your Analyzer
STEP 2. Meet Electrical and Environmental Requirements
CAUTION Always use the three-prong AC power cord supplied with this product.
Failure to ensure adequate earth grounding by not using this cord may cause
product damage.

2-6 E8356-90001
Installing Your Analyzer
STEP 3. Install the Analyzer on a Bench Top or in an Equipment Rack
STEP 3. Install the Analyzer on a Bench Top or in an
Equipment Rack
IMPORTANT Please review all safety information located in Chapter 4 , “Safety,
Regulatory, and Environmental Information” before proceeding with
installing and using the analyzer.
The analyzer can be installed on a bench top or in an equipment rack. When installing an
analyzer equipped with handles1in an equipment rack, use Option 1CP2. When installing
an analyzer not equipped with handles in an equipment rack, use Option 1CM.
In all installations, consider the following ventilation requirements when deciding where
to set up your analyzer.
CAUTION Ventilation Requirements: When installing the product in a cabinet, the
convection into and out of the product must not be restricted. The ambient
temperature (outside the cabinet) must be less than the maximum operating
temperature of the instrument by 4 ×C for every 100 watts dissipated in the
cabinet. If the total power dissipated in the cabinet is greater than 800 watts,
then forced convection must be used.
Refer to the section, listed below, that applies to your installation.
To Install on a Bench Top
When you install the analyzer for bench top use, you may wish to attach the supplied
handles1to the analyzer.
If you wish to install the handles1, follow the instructions provided with the handle kit.
To Install in an Equipment Rack
(Option 1CP2- Rack Mounting For Instruments Equipped With
Handles1)
(Option 1CM - Rack Mounting For Instruments Not Equipped With
Handles)
When you install the analyzer in an equipment rack, you must install rails in the rack to
support the weight of the analyzer. Attach either the Option 1CP2or Option 1CM rack
mount flanges to the analyzer. Secure the analyzer to the equipment rack. Replace the
analyzer bottom plastic feet with the hole plugs provided.
For installation, follow the instructions provided with the rack mount kit and the rail kit.
1. Front handles are not available for the N5242A.
2. Option 1CP is not available for the N5242A.

E8356-90001 2-7
Installing Your Analyzer
STEP 4. Connect the Accessories
STEP 4. Connect the Accessories
You can connect several USB accessories to the PNA. Some PNA models have a four-port
USB hub mounted internally and accessible through the rear panel. You can also use an
optional USB Hub (model N4689) to increase the available USB ports on the PNA.
USB devices, including the optional hub, can be connected to any available USB port. The
PNA will recognize the USB device when it is connected, and run the appropriate software
driver to make the device operate correctly. However, there is a limit to the amount of
current that the PNA USB ports can provide. See PNA Help - “USB port specifications”
(index entry) for more information.
The following is a list of USB devices commonly used with the PNA. Some of these devices
may require additional installation. Refer to the Help that is embedded in the PNA for
more information.
• Mouse — standard
• Keyboard — standard
• Read/Write CD-ROM drive (separate product)
• USB Hub (separate product)
• Printer (separate product)
NOTE Do NOT connect an ECal module to the USB until after the PNA is started.
Once started, press the front panel Help button to learn about ‘Connecting an
ECal module for the first time.’

2-8 E8356-90001
Installing Your Analyzer
STEP 5. Start Up the Analyzer
STEP 5. Start Up the Analyzer
CAUTION Install the instrument so that the detachable power cord is readily
identifiable and is easily reached by the operator. The detachable power cord
is the instrument disconnecting device. It disconnects the mains circuits from
the mains supply before other parts of the instrument. The front panel switch
is only a standby switch and is not a LINE switch. Alternatively, an
externally installed switch or circuit breaker (which is readily identifiable
and is easily reached by the operator) may be used as a disconnecting device.
1. Connect the AC power cable.
2. Turn the analyzer on by pressing the front panel On/Off switch. When the analyzer is
turned on, the On/Off switch changes color from yellow to green.
CAUTION Do NOT press keys on the front panel, rotate the RPG knob, or connect a
USB device during boot up of Windows or of the PNA application program.
Doing so may lead to a front panel lockup state.

E8356-90001 2-9
Installing Your Analyzer
STEP 6. Perform Administrative Tasks
NOTE This product contains the Windows XP operating system. The Network
Analyzer application is supported and qualified only with Windows XP. The
Windows Vista Certificate of Authenticy is valid and applies to the Windows
XP installation.
The first time you start the PNA, the Microsoft Windows license agreement is presented.
Click I Accept, then Next.
STEP 6. Perform Administrative Tasks
We recommend that you consider performing the following administrative tasks shortly
after powering up the analyzer for the first time.
❏Set up the administrator password
❏Enter the computer name
❏Set the time and date
NOTE Do NOT create additional User Accounts until you have read the PNA Help
file topic: “PNA User Accounts and Passwords” which states why and
how this should be done.
Procedures for the above tasks are in the Help system in the analyzer. To view these
procedures:
• On the analyzer’s front panel, press the Help button. Or, on the PNA display, click Help,
Network Analyzer Help.
• Click Quick Start in PNA Help.
• Click Perform Administrative Tasks.
• Click the task you wish to perform.
STEP 7. Run the Operator’s Check
The operator’s check should be performed when you first receive your analyzer, and any
time you wish to have confidence that the analyzer is working properly. The operator’s
check does not verify performance to specifications, but should give you a high degree of
confidence that the instrument is performing properly.
On the System menu, point to Service, and then click Operator’s Check. Follow the
prompts.
For assistance, use the Help button displayed on the screen of the Operator’s Check.

2-10 E8356-90001
Installing Your Analyzer
STEP 8. Turn Off the Analyzer
STEP 8. Turn Off the Analyzer
The PNA can be turned off with or without the use of a mouse.
Without a Mouse - BRIEFLY Press the green front panel On/Off switch.
With a Mouse - Minimize the PNA application, then click Start, Shutdown.
Both methods present a dialog box asking What do you want the computer to do? (If
your PNA does not present a dialog box, type “power on” in the index of the PNA Help
system to learn more.)
Using a mouse or front panel keys (Navigation plus Enter), choose an action:
• Log off (close programs and disconnect from the network)
• Restart (shutdown and start)
• Hibernate (see below)
• Shutdown (see below)
Hibernate
The On/Off switch changes from green to yellow when power is OFF.
The current instrument state is saved to the PNA hard disk drive.
When the PNA is powered ON, this instrument state is loaded, thus saving time over a full
system boot-up.
A password is not required to resume PNA operation from Hibernate mode.
For more hibernate information, type “hibernate” in the index of the PNA Help system.
Shutdown
The On/Off switch changes from green to yellow when power is Off.
The current instrument state is NOT saved to the PNA hard disk drive.
When the PNA is powered ON, a full system boot-up is performed and the PNA powers-up
in the Preset settings.
IMPORTANT Only turn off the PNA using Shutdown mode when preparing to service it, or
provide security via password protection.
Note: Repeatedly doing either of the following two actions WILL cause damage to the PNA
Hard Disk Drive.
1. Only in an emergency should the power cord be removed from the PNA without first
being put in Hibernate or Shutdown mode.
2. If the PNA is locked and you cannot operate the mouse or keypad, turn OFF the PNA by
pressing and holding the power button for at least four seconds.
