Security Features and Volatility Documentation
Agilent Technologies, Inc.
Model Number(s)
U3051C, U3052C, U3053C, U3055A, U3056A, U3057C
Product Family
SATA/SAS Protocol Analyzer/Jammer
**Agilent Part U305X Family**
1.0
Print Date: 2013-01-29
**Copyright**

Page 2 of 8
<Page intentionally left blank>

Page 3 of 8
Contacting Agilent Sales and Service Offices
Assistance with test and measurements needs and information on finding a local Agilent office is
available on the internet at, http://www.agilent.com/find/assist. If you do not have access to the
internet, please contact your field engineer.
Note: In any correspondence or telephone conversation, refer to the product by its model number
and full serial number. With this information, the Agilent representative can determine whether
your unit is still within its warranty period.

Product Declassification and Security Product Name: NA
Model Number(s): U3051C,
U3052C, U3053C, U3055A, U3056A, U3057C
Page 4 of 8
Product Declassification and Security
Model Number(s): U3051C, U3052C, U3053C, U3055A, U3056A, U3057C
Product Name: SerialTek Protocol Analyzers for 6G and 12G SAS/SATA
Product Family Name: SATA/SAS Protocol Analyzer/Jammer
Introduction
This document describes instrument security features and the steps to declassify an instrument
through memory sanitization or removal. For additional information please go to
http://www.agilent.com/find/ad and click on the security instrument tab.
Contents
Introduction............................................................................................................................. 4
Terms and Definitions............................................................................................................. 5
Instrument Memory and Volatility Information ..................................................................... 7

Product Declassification and Security Product Name: NA
Model Number(s): U3051C,
U3052C, U3053C, U3055A, U3056A, U3057C
Page 5 of 8
Terms and Definitions
Definitions:
Clearing –Clearing is the process of eradicating the data on media before reusing the media so
that the data can no longer be retrieved using the standard interfaces on the instrument. Clearing
is typically used when the instrument is to remain in an environment with an acceptable level of
protection.
Sanitization –Sanitization is the process of removing or eradicating stored data so that the data
cannot be recovered using any known technology. Instrument sanitization is typically required
when an instrument is moved from a secure to a non-secure environment such as when it is
returned to the factory for calibration. (The instrument is declassified) Agilent memory
sanitization procedures are designed for customers who need to meet the requirements specified
by the US Defense Security Service (DSS). These requirements are outlined in the “Clearing and
Sanitization Matrix” issued by the Cognizant Security Agency (CSA) and referenced in National
Industrial Security Program Operating Manual (NISPOM) DoD 5220.22M ISL 01L-1 section 8-
301.
Security erase –Security erase is a term that is used to refer to either the clearing or sanitization
features of Agilent instruments.
Instrument declassification –A term that refers to procedures that must be undertaken before an
instrument can be removed from a secure environment such as is the case when the instrument is
returned for calibration. Declassification procedures will include memory sanitization and or
memory removal. Agilent declassification procedures are designed to meet the requirements
specified by the DSS NISPOM security document (DoD 5220.22M chapter 8)

Product Declassification and Security Product Name: NA
Model Number(s): U3051C,
U3052C, U3053C, U3055A, U3056A, U3057C
Page 6 of 8
System Components
Product/System includes the following components
Model number
Name
Description
Reference/Remarks
U3051C
Protocol Analyzer
Protocol Analyzer, SAS/SATA
Product is hosted by a
customer provided PC loaded
with the U3051C product
analyzer SW.
U3052C
Protocol Analyzer
Protocol Analyzer, SAS/SATA
Product is hosted by a
customer provided PC loaded
with the U3052C product
analyzer SW.
U3053C
Protocol Jammer
Protocol Jammer, SAS/SATA
Product is hosted by a
customer provided PC loaded
with the U3053C product
analyzer SW.
U3055A
Protocol Analyzer
Protocol Analyzer, SAS/SATA
Product is hosted by a
customer provided PC loaded
with the U3055A product
analyzer SW.
U3056A
Protocol Analyzer
Protocol Analyzer, SAS/SATA
Product is hosted by a
customer provided PC loaded
with the U3056A product
analyzer SW.
U3057C
Protocol Analyzer
Protocol Analyzer, SAS/SATA
Product is hosted by a
customer provided PC loaded
with the U3057C product
analyzer SW.

Product Declassification and Security Product Name: NA
Model Number(s): U3051C,
U3052C, U3053C, U3055A, U3056A, U3057C
Page 7 of 8
Instrument Memory and Volatility Information
This section contains information on the types of memory available in your instrument. It explains the size of
memory, how it is used, its location, volatility, and the sanitization procedure.
Summary of instrument memory - base instrument (2.0 GB), model number dependent upgrade
options to 72 GB –hardware SW Licence-able to higher memory depth
Memory
Type and
Size
Is Memory user
accessible as a mass
storage device?
Writable During
Normal Operation?
Data Retained When
Powered Off?
Purpose/Contents
Data Input
Method
Location in
Instrument and
Remarks
Sanitization
Procedure
Main
Volatile
Memory
varies with
options from
2.0 GB to 72
GB DDR
SDRAM1
No
Yes
No
Storage for
measurement data; no
customer information
is stored here. Note
that out of this 2.0
GB of DDR SDRAM
memory, U305X
family offers memory
depth options up to
72 GB
Data
captured
through
external
probe
Main board
Cycle power
on any
U305X
family
member
Flash
EEPROM
No
No
Yes
No customer
information; it stores
FPGA configuration
memory only,
including factory
calibration/configurat
ion data and SW
Licensing data
Internal
SerialTek2
SW used
during
manufacturi
ng
Main board …
Not
applicable –
no customer
data stored
Flash
EEPROM
No
No
Yes
No customer
information; it stores
FPGA configuration
memory only, to
interact with the
backplane controller
Internal
connectivity
communicat
ion use only
Main board
Not
applicable –
no customer
data stored
1 –U3053C has no DDR SDRAM
2 –SerialTek manufactures the U305X family of SATA/SAS Protocol Analyzer/Jammer for
resale by Agilent Technologies

Product Declassification and Security Product Name: NA
Model Number(s): U3051C,
U3052C, U3053C, U3055A, U3056A, U3057C
Page 8 of 8
User and Remote Interface Security Measures
Screen and Annotation Blanking
Not applicable to this product
USB Mass Storage Device Security
Not applicable to this product
Remote Access Interfaces
Not applicable to this product
Procedure for Declassifying a Faulty Instrument
Not applicable to this product
